Philips AJB4500/05 User manual

EN User manual
Register your product and get support at
www.philips.com/welcome AJB4500
$-%B(1LQGG$-%B(1LQGG 3030

AJB4500_EN.indd 2 7/31/2008 2:31:44 PM

3
Contents
1 Important 5
Safety 5
Important notes for users in the U.K. 7
Notice 9
Recycling 10
2 Your clock radio 11
Introduction 11
What’s in the box 11
Overview of the main unit 12
3 Get started 15
Prepare FM/DAB antenna 15
Connect power 16
Set the clock 16
4 Use your clock radio 18
Adjust the volume level 18
Adjust display brightness 18
Listen to FM radio 18
Program radio stations automatically 18
Program radio stations manually 19
Listen to a preset radio station 19
Show RDS information 19
Listen to Digital Audio Broadcasts (DAB) 20
Tune to DAB radio station manually 21
Scan DAB radio stations automatically 21
Program DAB radio stations manually 22
Listen to a preset DAB radio station 22
Show DAB information 22
$-%B(1LQGG$-%B(1LQGG 3030

4
Set the alarm timer 23
Turn on/off the alarm timer 23
Repeat alarm 24
Reset alarm 24
Stop alarm sound 24
View the alarm settings 24
5 Use more of your clock radio 25
Listen to portable audio players 25
Set the sleep timer 25
Perform more functions through DAB menu 26
6 Product information 28
Specifications 28
Tuner (FM) 28
General information 28
RDS program types 29
About DAB 31
7 Troubleshooting 32
$-%B(1LQGG$-%B(1LQGG 3030

5
1 Important
Safety
Know these safety symbols
This ‘bolt of lightning’ indicates uninsulated material within your
unit may cause an electrical shock. For the safety of everyone in
your household, please do not remove product covering.
The ‘exclamation point’ calls attention to features for which you
should read the enclosed literature closely to prevent operating
and maintenance problems.
WARNING:To reduce the risk of fire or electric shock, this
apparatus should not be exposed to rain or moisture and
objects filled with liquids, such as vases, should not be placed on
this apparatus.
CAUTION:To prevent electric shock, match wide blade of plug
to wide slot, fully insert.
a Read these instructions.
b Keep these instructions.
cHeed all warnings.
dFollow all instructions.
$-%B(1LQGG$-%B(1LQGG 3030

6
eDo not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
h Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
iProtect the power cord from being walked on or
pinched, particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
jOnly use attachments/accessories specified by the
manufacturer.
kUse only with the cart, stand, tripod, bracket, or table
specified by the manufacturer or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
lUnplug this apparatus during lightning storms or when
unused for long periods of time.
mRefer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does not
operate normally,or has been dropped.
$-%B(1LQGG$-%B(1LQGG 3030

7
nApparatus shall not be exposed to dripping or splashing.
oDo not place any sources of danger on the apparatus
(e.g. liquid filled objects, lighted candles).
pThis product may contain lead and mercury. Disposal of
these materials may be regulated due to environmental
considerations. For disposal or recycling information,
please contact your local authorities or the Electronic
Industries Alliance: www.eiae.org.
Where the MAINS plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily
operable.
Important notes for users in the U.K.
Mains plug
This apparatus is fitted with an approved 13 Amp plug.To
change a fuse in this type of plug proceed as follows:
aRemove fuse cover and fuse.
bFix new fuse which should be a BS1362 3 Amp,A.S.T.A.
or BSI approved type.
c Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, it should
be cut off and an appropriate plug fitted in its place.
If the mains plug contains a fuse, this should have a value of 3
Amp. If a plug without a fuse is used, the fuse at the distribution
board should not be greater than 3 Amp.
Note:The severed plug must be disposed off to avoid a possible
shock hazard should it be inserted into a 13 Amp socket
elsewhere.
$-%B(1LQGG$-%B(1LQGG 3030

8
How to connect a plug
The wires in the mains lead are coloured with the following code:
blue = neutral (N), brown = live (L).
As these colours may not correspond with the colour markings
identifying the terminals in your plug, proceed as follows:
Connect the blue wire to the terminal marked N or
coloured black.
Connect the brown wire to the terminal marked L or
coloured red.
Do not connect either wire to the earth terminal in the
plug, marked E (or e) or coloured green (or green and
yellow).
Before replacing the plug cover, make certain that the cord grip
is clamped over the sheath of the lead - not simply over the
two wires.
Copyright in the U.K.
Recording and playback of material may require consent. See
Copyright Act 1956 and The performer’s Protection Acts 1958
to 1972.
•
•
•
$-%B(1LQGG$-%B(1LQGG 3030

9
Warning
Never remove the casing of this clock radio.
Never lubricate any part of this clock radio.
Place this clock radio on a flat, hard and stable surface.
Never place this clock radio on other electrical equipment.
Only use this clock radio indoors. Keep this clock radio away
from water, moisture and liquid-filled objects.
Keep this clock radio away from direct sunlight, naked flames or heat.
•
•
•
•
•
•
Notice
Any changes or modifications made to this device that are not
expressly approved by Philips Consumer Lifestyle may void the
user’s authority to operate the equipment.
This product complies with the radio interference requirements
of the European Community.
This product complies with the requirements of the following
directives and guidelines: 2004/108/EC + 2006/95/EC
$-%B(1LQGG$-%B(1LQGG 3030

10
Recycling
Your product is designed and manufactured with high quality
materials and components, which can be recycled and reused.
When you see the crossed-out wheel bin symbol attached to
a product, it means the product is covered by the European
Directive 2002/96/EC:
Never dispose of your product with other household waste.
Please inform yourself about the local rules on the separate
collection of electrical and electronic products.The correct
disposal of your old product helps prevent potentially negative
consequences on the environment and human health.
Environmental information
All unnecessary packaging has been omitted.We have tried
to make the packaging easy to separate into three materials:
cardboard (box), polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can be recycled
and reused if disassembled by a specialized company. Please
observe the local regulations regarding the disposal of packaging
materials, exhausted batteries and old equipment.
$-%B(1LQGG$-%B(1LQGG 3030

11
2 Your clock radio
Congratulations on your purchase, and welcome to Philips! To
fully benefit from the support that Philips offers, register your
product at www.philips.com/welcome.
Introduction
With this clock radio, you can enjoy both FM radio and Digital
Audio Broadcasting (DAB) radio.You can also listen to portable
audio players through this clock radio.
You can set two separate alarm timings. For the alarm sound,
you can select the FM radio, DAB radio, or the buzzer.
What’s in the box
Check and identify the contents of your package:
Main unit
User manual
Quick start guide
•
•
•
$-%B(1LQGG$-%B(1LQGG 3030

12
Overview of the main unit
aSELECT
Set the clock.
Program FM/DAB radio stations.
Confirm DAB menu selection.
bINFO/MENU
Select DAB menu.
Display DAB and RDS information.
•
•
•
•
•
j
n
o
k
i
g
h
c
d
e
f
l
m
b
a
j
n
o
k
i
g
h
c
d
e
f
l
m
b
a
$-%B(1LQGG$-%B(1LQGG 3030

13
cSOURCE
Select a mode: DAB, FM TUNER, MP3 LINK or
clock (standby).
d PRESET
Select a preset radio station.
Set the time for the clock and alarm.
eBRIGHTNESS CONTROL/REPEAT ALARM
Select the display brightness.
Repeat the alarm.
fDisplay panel
Show current status.
g TUNING
Tune to FM/DAB radio stations.
Select DAB menu option.
h VOLUME
Adjust the volume level.
i SCAN
Scan FM/DAB radio stations.
j SLEEP/AL RESET
Set the sleep timer.
Reset the alarm.
k SET ALARM AL1/AL2
Set the alarm.
l FM/DAB antenna
Improve FM/DAB reception.
m Audio in cable
Connect to a portable audio player.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
$-%B(1LQGG$-%B(1LQGG 3030

14
n Power plug
Power supply plug.
o Reset button
Reset the clock radio.
•
•
$-%B(1LQGG$-%B(1LQGG 3030

15
3 Get started
Caution
Use the controls only as stated in this user manual.•
Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and
serial number of your clock radio.The model number and
serial number are on the bottom of your clock radio.Write the
numbers here:
Model No. __________________________
Serial No. ___________________________
Prepare FM/DAB antenna
1Fully extend the antenna and fix it to the wall as shown
below.
$-%B(1LQGG$-%B(1LQGG 3030

16
Connect power
Caution
Risk of product damage! Ensure that the power supply
voltage corresponds to the voltage printed on the back or
the underside of the clock radio.
Risk of electric shock! When you disconnect the power
supply, always pull the plug from the socket. Never pull the
cord.
•
•
1Connect the power plug to the power outlet.
Set the clock
1In standby mode, press and hold SELECT for two seconds.
[SYNC ON] is displayed and [ON] begins to blink.
2Press PRESET to select ON or OFF.
If you select [ON], the clock radio reads the DAB/RDS time
and sets the clock automatically.
»
»
SocketSocket
$-%B(1LQGG$-%B(1LQGG 3030

17
If you select [OFF], the clock radio turns off the time
synchronization.
3Press SELECT to confirm.
The time format [24H] or [12H] begins to blink.
4 Press PRESET to select 24H or 12H.
5 Press SELECT to confirm.
The hour digits are displayed and begin to blink.
6 Press PRESET to set the hour.
7Press SELECT to confirm.
The minute digits are displayed and begin to blink.
8 Press PRESET to set the minute.
9 Press SELECT to confirm the clock setting.
Note
The accuracy of the transmitted time depends on the RDS
station that transmits the time signal.
If the power supply is disconnected, the settings and clock
are saved for 3 minutes.
•
•
»
»
»
»
$-%B(1LQGG$-%B(1LQGG 3030

18
4 Use your clock radio
Adjust the volume level
1During play, press VOLUME to increase/decrease the
volume level.
Adjust display brightness
1Press BRIGHTNESS CONTROL/REPEAT ALARM
repeatedly to select different brightness of the display:
Full brightness
Half brightness
Backlight off
Listen to FM radio
1Press SOURCE repeatedly to select [FM--TUNER].
2 Press TUNING to tune to a radio station.
To search for a radio station automatically:
1Press TUNING .
2 Press SCAN.
The FM tuner tunes to a station with strong reception
automatically.
Program radio stations automatically
You can program a maximum of 20 preset radio stations.
1 Press SOURCE repeatedly to select [FM--TUNER].
2 Press and hold SCAN for two seconds.
[FM SCAN] appears.
•
•
•
»
»
$-%B(1LQGG$-%B(1LQGG 3030

19
All available stations are programmed in the order of
waveband reception strength.
The first programmed radio station broadcasts automatically.
Program radio stations manually
You can program a maximum of 20 preset radio stations.
1Tune to a radio station.
2Press PRESET to select the desired preset number.
3Press and hold SELECT for two seconds.
The preset number of the saved station appears.
Tip
To overwrite a programmed station, store another station
in its place.
•
Listen to a preset radio station
1Press SOURCE repeatedly to select [FM--TUNER].
2Press PRESET to select a preset number.
Show RDS information
RDS (Radio Data System) is a service that allows FM stations
to show additional information. If you tune to a RDS station, the
station name is displayed.
1 Tune to a RDS station.
»
»
»
$-%B(1LQGG$-%B(1LQGG 3030

20
2 Press INFO/MENU repeatedly to scroll through the
following information (if available):
Station name
Radio text messages
Program type such as [NEWS] (news(, [SPORT] (sport),
[POP M] (pop music)...
Clock time
Frequency
Tip
Detailed definitions of RDS program types are available
(see ‘RDS program types’ on page 29).
•
Listen to Digital Audio Broadcasts (DAB)
Digital Audio Broadcasting (DAB), is a way of broadcasting radio
digitally through a network of transmitters. It provides you with
more choice, better sound quality and more information.
1Press SOURCE repeatedly to select [DAB].
When you enter the DAB mode for the first time, the clock
radio automatically scans DAB radio stations.The clock radio
stores all available DAB radio stations and then broadcasts the
first available station.
The last selected DAB radio station broadcasts automatically.
»
»
»
»
»
»
»
$-%B(1LQGG$-%B(1LQGG 3030
