Philips HD5405 User manual

HD5405

2

3
8
6
4
12
10
8
6
max
min
H
I
J
K
L
A
B
C
D
E
F
G
1

4


 6
 11
 16
 21
 26
 31
 36
 41
 46
 51
 56
 61
 66
 71
 76
 81

6

Congratulations on your purchase and welcome to Philips! To fully benet from the support that
Philips offers, register your product at www.philips.com/welcome.
Philips Cafe Gourmet combines exceptionally aromatic coffee with an exclusive and eye-catching
design. Thanks to the superior ‘Boil & Brew’ principle, the coffee is brewed under ideal conditions.
This principle is derived from the classic coffee-brewing method of pouring a substantial quantity of
water just off the boil onto fresh ground coffee. The striking design allows you to follow this process
from beginning to end. The result is steaming hot coffee with the full avour of manual drip-brewed
coffee, conveniently prepared with a sophisticated coffee maker. Enjoy your Cafe Gourmet!

 Detachable water tank cover with hinged lid
 Temperature sensor
 Water tank with level indication
 Mains cord
 Hotplate
 On/off switch with power-on light
 Measuring spoon
 Coffee jug
 Lid of coffee jug
 Filter holder support
 Drip stop
 Filter holder

Read this user manual carefully before you use the appliance and save it for future reference.

- Never immerse the appliance in water or any other liquid.

- Check if the voltage indicated on the appliance corresponds to the local mains voltage before
you connect the appliance.
- Do not use the appliance if the plug, the cord or the appliance itself is damaged.
- If the mains cord is damaged, you must have it replaced by Philips, a service centre authorised by
Philips or similarly qualied persons in order to avoid a hazard.
- This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their
safety. Children should be supervised to ensure that they do not play with the appliance.
- Children should be supervised to ensure that they do not play with the appliance.
- Do not let the mains cord hang over the edge of the table or worktop on which the appliance
stands.
- Never connect the appliance to a timer switch or remote control system in order to avoid a
hazardous situation.
- Do not remove the lid of the water tank cover while the water is boiling.

- Do not place the appliance on a hot surface and do not let the mains cord come into contact
with hot surfaces.
- Unplug the appliance if problems occur during brewing and before you clean it.


- This appliance is intended to be used in household and similar applications such as:
- staff kitchen areas in shops, ofces and other working environments;
- farm houses;
- by clients in hotels, motels and other residential type environments;
- bed and breakfast type environments;

This Philips appliance complies with all standards regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this user manual, the appliance is safe to use based on
scientic evidence available today.

1 Clean the detachable parts (see chapter ‘Cleaning’).
2 Fill the water tank with water until it is half full.
3 Let the appliance operate once without lling the lter with ground coffee (see chapter
‘Using the appliance’).


1 Make sure the cover is on the water tank.
2 Open the lid of the water tank cover and ll the water tank with fresh, cold water (Fig. 2).
- Make sure you ll the water tank to a level between the minimum and maximum indication
marks.
- Always close the hinged lid of the cover after lling the water tank to make sure the
appliance functions properly.
- The graduations on the left are for large cups (120ml).
- The graduations on the right are for small cups (80ml).
3 Open the lter holder support (Fig. 3).
4 Take a paper lter (size 102/1x2) and fold the sealed edges to prevent tearing and
folding (Fig. 4).
5 Put the lter in the lter holder.
6 Put ground coffee (lter-ne grind) in the lter (Fig. 5).
- For large cups: use one heaped measuring spoon of ground coffee for each cup.
- For small cups: use one level measuring spoon of ground coffee for each cup.
Note: Use lter-ne ground coffee. If you grind the coffee yourself, do not grind it so ne that it is almost
powder-like.
7 Close the lter holder support (Fig. 6).
8 Place the jug on the hotplate (Fig. 7).
Make sure the jug lid is in place. Without the jug lid, the drip stop function (see section ‘Drip stop
function in this chapter) is activated automatically.
9 Press the on/off switch to switch on the appliance (Fig. 8).
10 When all the water has passed through the lter, you can take the jug out of the
appliance (Fig. 9).
 7

11 After you have poured coffee, put the jug with the remaining coffee back onto the hotplate
to keep the coffee hot and to preserve its avour (Fig. 10).
- However, coffee is at its best directly after is has been brewed (Fig. 11).
Tip: When the brewing process is nished, you can pour the hot coffee into a thermos jug to keep it hot
and fresh.

The drip stop function enables you to remove the jug from the coffeemaker before the brewing
process is nished. When you remove the jug, the drip stop stops the ow of coffee into the jug.
Note: The brewing process does not stop when you remove the jug. Place back the jug as soon as possible
to prevent overowing.
Note: Make sure the jug lid is in place when you put the jug back onto the hotplate. Without the jug lid,
the drip stop function is activated automatically.

1 Open the lter holder support (Fig. 12).
2 Lift the lter holder with the paper lter out of the lter holder support (Fig. 13).
3 Throw away the used paper lter with the coffee grounds (Fig. 14).
4 Switch off the appliance. (Fig. 15)

If you want to make another jug of fresh coffee right away, switch off the appliance and let it cool
down for three minutes. Fill the water tank with cold water again and put a new amount of ground
coffee in a new paper lter. Now you can make fresh coffee again.
Note: If you do not let the appliance cool down for three minutes before you brew coffee again,
water starts dripping into the lter holder right away.
- Make sure you pour the rst amount of fresh water against the temperature sensor in the
centre of the cover (Fig. 16).
When you do this, the outow opening in the bottom of the water tank closes again.

Never immerse the appliance in water or any other liquid.
Never use scouring pads, abrasive cleaning agents or aggressive liquids such as petrol or acetone
to clean the appliance.
1 Switch off and unplug the appliance.
2 Clean the outside of the appliance with a moist cloth.
3 Clean the detachable parts in hot water with some washing-up liquid or in the dishwasher.
4 Clean the rubber insert in the outow opening of the water tank every month and after
every descaling procedure (Fig. 17).
Do not forget to put the insert back into place before you use the appliance again.
Never remove the rubber insert if there is still hot water in the water tank.
8


Regular descaling prolongs the life of the appliance and guarantees optimal brewing results for a
long time.
In case of normal use (two brewing cycles a day), descale your coffeemaker:
- Every two months if you use soft or ltered water (up to 18dH);
- Every month if you use hard water (over 18dH).
Contact your local water board for information about the water hardness in your area.
1 Fill the water tank with 0.8 litres of white vinegar (4% acetic acid). Do not put a lter or
ground coffee in the lter holder.
2 Switch on the appliance and let it complete one brewing cycle.
Note: For thorough descaling, repeat step 1 to 2 to make sure no scale is left in the appliance. You can
use the vinegar from the rst cycle.
3 Let the appliance complete two more brewing cycles with fresh, cold water to remove any
vinegar and scale residues.
4 Clean the jug and the lter holder (see chapter ‘Cleaning’).
Note: You can also use an appropriate liquid descaler. In that case, follow the instructions on the package
of the descaler. Do not use a powder descaler or descaling tablets.

Is your jug broken or do you want an extra jug?
You can order a glass jug from your local Philips dealer or a Philips service centre under type
number HD7919.

- Do not throw away the appliance with the normal household waste at the end of its life, but
hand it in at an ofcial collection point for recycling. By doing this, you help to preserve the
environment. (Fig. 18)

If you need service or information or if you have a problem, please visit the Philips website at
www.philips.com or contact the Philips Consumer Care Centre in your country (you nd its phone
number in the worldwide guarantee leaet). If there is no Consumer Care Centre in your country,
go to your local Philips dealer.

This chapter summarises the most common problems you could encounter with the appliance. If
you are unable to solve the problem with the information below, contact the Consumer Care
Centre in your country.
Problem Solution
The appliance fails to heat the water to
boiling point. Make sure that the appliance is plugged in.
Make sure that the wall socket is live.
Make sure that the appliance is switched on.
 9

Problem Solution
The water tank does not drain properly
or does not drain at all. Make sure that the appliance is plugged in.
Make sure that the wall socket is live.
Make sure that the appliance is switched on.
Make sure that the cover of the water tank is placed
correctly.
Descale and clean the coffeemaker. Pay special
attention to the rubber insert in the outow opening
of the water tank (see chapters ‘Descaling’ and
‘Cleaning’).
The water ows straight into the
jug when I ll the water tank. Make sure that you place the cover on the water tank before you ll it.
If you have just brewed coffee, let the appliance cool
down for 3 minutes before you brew coffee again.
