Philips AD200/05 User manual

www.philips.com/welcome
AD200
User manual
Register your product and get support at

1EN
Contents
1 Important 2
2 Your docking speaker 3
Introduction 3
What's in the box 3
Overview of the main unit 3
3 Prepare 4
Connect power 4
Turn the unit on 4
4 Play 5
Listen to the iPod/iPhone 5
Adjust sound 5
Compatibility 5
Charge the iPod/iPhone 5
Play from an external device 6
5 Specications 7
Amplier 7
General information 7
6 Troubleshooting 8

2EN
1 Important
• Read these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or
otherapparatus(includingampliers)that
produce heat.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Unplug this apparatus during lightning
storms or when unused for long periods
of time.
• Referallservicingtoqualiedservice
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
• Apparatus shall not be exposed to
dripping or splashing.
• Do not place any sources of danger on the
apparatus(e.g.liquidlledobjects,lighted
candles).
• Where the plug of the Direct Plugin
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
Warning
•Never remove the casing of this apparatus.
•Never lubricate any part of this apparatus.
•Never place this apparatus on other electrical
equipment.

3EN
2 Your docking
speaker
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
If you contact Philips, you will be asked for the
model and serial number of this apparatus.The
model number and serial number are on the
bottom of the apparatus.Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
Introduction
With this docking speaker, you can:
• Enjoy music on your iPod/iPhone;
• Charge your iPod/iPhone;
• Enjoy music on external audio player
through MP3 link cable.
What's in the box
Check and identify the contents of your
package:
• Main unit
• AC power adaptor
• Quick start guide
Overview of the main unit
a +/-
• Adjust volume.
b Power socket
• Connect the power adaptor.
c Dock for iPod/iPhone
d MP3-LINK
• Connect an external audio player.
e
• Turn the unit on/off.
b
a
d
c
e

4EN
3 Prepare
Always follow the instructions in this chapter in
sequence.
Connect power
Caution
•Risk of product damage! Make sure that the power
supply voltage matches the voltage printed on the
bottom of the unit.
•Risk of electric shock! When you unplug the AC
adaptor, always pull the plug from the socket. Never
pull the cord.
•Before you connect the AC adaptor, make sure that you
have completed all the other connections.
Connect the AC power adaptor, one end to the
power socket on the back of the unit, and the
other the wall power supply.
Turn the unit on
Press repeatedly on the top to turn the unit
on/off.

5EN
4 Play
Listen to the iPod/iPhone
1 Load your iPod/iPhone.
2 Play your iPod/iPhone.
» Your music on the phone comes out
through the unit.
Adjust sound
To adjust the sound, press the button +/-.
Compatibility
Made for Apple iPod models with 30-pin dock
connector as follows:
• iPodtouch(4thgeneration)
• iPodtouch(3rdgeneration)
• iPodtouch(2ndgeneration)
• iPodtouch(1stgeneration)
• iPodnano(6stgeneration)
• iPodnano(5thgeneration)
• iPodnano(4thgeneration)
• iPodnano(3rdgeneration)
• iPodnano(2ndgeneration)
• iPodnano(1stgeneration)
• iPod mini
• iPod classic
• iPod with video
• iPod with color display
• iPhone 4
• iPhone 3GS
• iPhone 3G
• iPhone
Charge the iPod/iPhone
When the system is connected to power, the
docked iPod/iPhone begins to charge.

6EN
Play from an external device
You can also listen to an external audio player
through the device.
Connect the MP3 link cable, one end to the
MP3-LINK socket at the back, and the other to
the headphone socket.

7EN
5 Specifications
Amplier
Rated Output Power 2 X 2 W RMS
General information
AC Power S009GB0590150
(Philips)
Input: 100-240 V ~,
50/60Hz, 0.3A; Output:
DC 5.9V 1500 mA
Operation Power
Consumption
8 W
Dimensions
- Main Unit
(WxHxD) 184 x 80.85 x 62 mm
Weight
- Main Unit 0.3 kg

8EN
6 Troubleshooting
Warning
•Never remove the casing of this apparatus.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips web site (www.
philips.com/welcome).Whenyoucontact
Philips, ensure that the apparatus is nearby
and the model number and serial number are
available.
No power
•Make sure that the AC power adaptor of
the unit is connected properly.
•Make sure that there is power at the AC
outlet.
No sound
•Adjust the volume.
Docked iPod/iPhone can't be charged
•Make sure that the unit is compatible
the iPod/iPhone.
•Make sure that the unit is successfully
connected to the iPod/iPhone.
•Remove the protective case of your iPod/
iPhone.

Specifications are subject to change without notice
© 2011 Koninklijke Philips Electronics N.V.
All rights reserved.
AD200_05_UM_V1.0
