Philips DS8500/05 User manual

Register your product and get support at
www.philips.com/welcome
EN User manual
DS8500
DS8500_05_UM_V1.2.indd 1 2/4/2010 10:52:46 AM

2
English
EN
Contents
1 Important 3
Safety 3
Notice 5
2 Your Docking Speaker 7
Introduction 7
What’s in the box 7
Overview of the main unit 7
Overview of the remote control 9
3 Get started 11
Prepare the remote control 11
Connect power 12
For users in the U.K.: 13
Turn on 14
4 Play 15
Play from iPod/iPhone 15
Play from an external device 16
Adjust volume level 16
Mute sound 17
5 Product information 18
Specications 18
6 Troubleshooting 19
DS8500_05_UM_V1.2.indd 2 2/4/2010 10:52:47 AM

3
1 Important
Safety
Important Safety Instructions
aRead these instructions.
bKeep these instructions.
cHeed all warnings.
dFollow all instructions.
eDo not use this apparatus near water.
fClean only with dry cloth.
gDo not block any ventilation openings. Install in accordance with
the manufacturer’s instructions.
hDo not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including ampliers) that
produce heat.
iProtect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
j Only use attachments/accessories specied by the manufacturer.
k Use only with the cart, stand, tripod, bracket, or table specied by
the manufacturer or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
EN
DS8500_05_UM_V1.2.indd 3 2/4/2010 10:52:47 AM

4
lUnplug this apparatus during lightning storms or when unused for
long periods of time.
m Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
nBattery usage CAUTION – To prevent battery leakage which may
result in bodily injury, property damage, or damage to the unit:
Install all batteries correctly, + and - as marked on the unit.•
Do not mix batteries (old and new or carbon and alkaline, etc.).•
Remove batteries when the unit is not used for a long time.•
The batteries shall not be exposed to excessive heat such as•
sunshine,reorthelike.
oApparatus shall not be exposed to dripping or splashing.
pDo not place any sources of danger on the apparatus
(e.g. liquid lled objects, lighted candles).
qThis product may contain lead and mercury. Disposal of these
materials may be regulated due to environmental considerations.
For disposal or recycling information,
please contact your local authorities or the Electronic Industries
Alliance: www.eiae.org.
rWhere the MAINS plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily operable.
Warning
Never remove the casing of this apparatus.•
Never lubricate any part of this apparatus.•
Never place this apparatus on other electrical equipment.•
Keepthisapparatusawayfromdirectsunlight,nakedamesorheat.•
Ensure that you always have easy access to the power cord, plug or adaptor to•
disconnect the apparatus from the power.
English
EN
DS8500_05_UM_V1.2.indd 4 2/4/2010 10:52:47 AM

5
Important notes for users in the U.K.
Mains plug
Thisapparatusisttedwithanapproved13Ampplug.Tochangeafusein
this type of plug proceed as follows:
1Remove fuse cover and fuse.
2Fix new fuse which should be a BS1362 3 Amp, A.S.T.A. or BSI approved type.
3 Retthefusecover.
Ifthettedplugisnotsuitableforyoursocketoutlets,itshouldbecutoff
andanappropriateplugttedinitsplace.Ifthemainsplugcontainsafuse,
this should have a value of 3 Amp. If a plug without a fuse is used, the fuse
at the distribution board should not be greater than 5 Amp.
Note: The severed plug must be disposed of to avoid a possible shock
hazard should it be inserted into a 13 Amp socket elsewhere.
How to connect a plug
The wires in the mains lead are coloured with the following code: blue =
neutral (N), brown = live (L).
As these colours may not correspond with the colour markings
•
identifying the terminals in your plug, proceed as follows:
Connect the blue wire to the terminal marked N or coloured black.
•
Connect the brown wire to the terminal marked L or coloured red.
•
Do not connect either wire to the earth terminal in the plug, marked E
•
(or e) or coloured green (or green and yellow).
Before replacing the plug cover, make certain that the cord grip is clamped
over the sheath of the lead - not simply over the two wires.
Copyright in the U.K.
Recording and playback of material may require consent. See Copyright
Act 1956 and The Performers’s Protection Acts 1958 to 1972.
Notice
Anychangesormodicationsmadetothisdevicethatarenotexpressly
approved by Philips Consumer Lifestyle may void the user’s authority to
operate the equipment.
EN
DS8500_05_UM_V1.2.indd 5 2/4/2010 10:52:47 AM

6
This product complies with the radio interference requirements of the
European Community.
Recycling
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
When you see the crossed-out wheel bin symbol attached to a product, it
means the product is covered by the European Directive 2002/96/EC:
Never dispose of your product with other household waste. Please inform
yourself about the local rules on the separate collection of electrical and
electronic products. The correct disposal of your old product helps prevent
potentially negative consequences on the environment and human health.
Your product contains batteries covered by the European Directive
2006/66/EC, which cannot be disposed of with normal household waste.
Please inform yourself about the local rules on separate collection of
batteries. The correct disposal of batteries helps prevent potentially negative
consequences on the environment and human health.
Environmental information
All unnecessary packaging has been omitted. We have tried to make
the packaging easy to separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.)
Your system consists of materials which can be recycled and reused
if disassembled by a specialized company. Please observe the local
regulations regarding the disposal of packaging materials, exhausted
batteries and old equipment.
English
EN
DS8500_05_UM_V1.2.indd 6 2/4/2010 10:52:48 AM

7
2 Your Docking Speaker
Congratulationsonyourpurchase,andwelcometoPhilips!Tofullybenet
from the support that Philips offers, register your product at www.philips.
com/welcome.
Introduction
With this unit, you can enjoy audio from the iPod/iPhone and other audio
devices.
What’s in the box
Check and identify the contents of your package:
Main unit•
Remote control•
1 x AC adaptor•
1 x AC power cord•
1 x Aux-in cable•
User manual•
Overview of the main unit
EN
DS8500_05_UM_V1.2.indd 7 2/4/2010 10:52:48 AM

8
Front View
a- VOLUME +
Adjust volume.•
biPod/iPhone dock
Back View
a b
d c
English
EN
DS8500_05_UM_V1.2.indd 8 2/4/2010 10:52:48 AM

9
cPower supply socket
dAUX IN
Jack for an external audio device.•
Overview of the remote control
1
Mute volume.•
2
Select Aux-in mode•
i
g
f
h
a
e
b
c
d
EN
DS8500_05_UM_V1.2.indd 9 2/4/2010 10:52:49 AM

10
3Up/down keys
Navigate through the iPod/iPhone menu.•
4Fast forward/backward keys
Fast reverse or fast forward within a track or iPod/iPhone.•
Skip to the previous/next track•
5
Start or pause play.•
6VOL +/-
Adjust volume.•
7MENU
Access the iPod menu.•
8OK
Conrmaselection.•
9
Select iPod/iPhone dock mode•
English
EN
DS8500_05_UM_V1.2.indd 10 2/4/2010 10:52:50 AM

11
3 Get started
Caution
Use of controls or adjustments or performance of procedures other than•
herein may result in hazardous radiation exposure or other unsafe operation.
Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and serial number of
this apparatus.The model number and serial number are on the bottom of
the apparatus.Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Prepare the remote control
Caution
Riskofexplosion!Keepbatteriesawayfromheat,sunshineorre.Never•
discardbatteriesinre.
For rst-time use:
1Remove the protective tab to activate the remote control battery.
To replace the remote control battery:
2Open the battery compartment.
3Insert one CR2032 battery with correct polarity (+/-) as indicated.
4Close the battery compartment.
EN
DS8500_05_UM_V1.2.indd 11 2/4/2010 10:52:50 AM

12
Note
Before pressing any function button on the remote control,•
rstselectthecorrectsourcewiththeremotecontrolinstead
of the main unit.
If you are not going to use the remote control for a long time, remove the
•
battery.
Connect power
Caution
Risk of product damage! Ensure that the power supply voltage corresponds to•
the voltage printed on the bottom of the unit.
Risk of electric shock! When you unplug the AC adaptor, always
•
pull the plug from the socket. Never pull the cord.
Before connecting the AC adaptor, ensure you have completed all other
•
connections.
Note
The type plate is located on the bottom of the main unit.•
English
EN
DS8500_05_UM_V1.2.indd 12 2/4/2010 10:52:50 AM

13
1Insert the plug from the AC adaptor to the DC IN socket on the
back of the main unit.
2Connect one end of the AC power cord to the AC adaptor.
3Connect the other end of the AC power cord to the wall outlet.
For users in the U.K.:
For users in the U.K.: please follow the instructions in “Important note
for users in the U.K.” under “Important” part.
EN
DS8500_05_UM_V1.2.indd 13 2/4/2010 10:52:51 AM

14
Turn on
The unit turns on automatically when connected to power.
When user approaches the unit, light LED under volume button on»
the main unit turns on automatically.
Switch to standby
In DOCK mode: disconnect the iPod/iPhone from the unit over 15•
minutes.
The unit switches to Standby mode automatically.»
In Aux-in mode: the device no longer play music over 15 minutes.
•
The unit switches to standby mode automatically.»
English
EN
DS8500_05_UM_V1.2.indd 14 2/4/2010 10:52:51 AM

15
4 Play
Play from iPod/iPhone
You can enjoy audio from iPod/iPhone through this unit.
Compatible iPod/iPhone
Apple iPod and iPhone models with a 30-pin dock connector. Made for :
iPod nano (2nd generation)•
iPod nano (3rd generation)•
iPod nano (4th generation)•
iPod nano (5th generation)•
iPod classic•
iPod touch (1st generation)•
iPod touch (2nd generation)•
iPod touch (3rd generation)•
iPhone•
iPhone 3G•
iPhone 3GS•
Load the iPod/iPhone
1Place the iPod/iPhone in the dock.
Remove the iPod/iPhone
1Pull the iPod out of the dock.
EN
DS8500_05_UM_V1.2.indd 15 2/4/2010 10:52:51 AM

16
Listen to the iPod/iPhone
1Ensure that the iPod/iPhone is loaded correctly.
2Press to select DOCK mode.
3Press .
The connected iPod/iPhone starts play.»
To pause/resume play, press
• .
To skip to a track, press fast forward/backward keys.•
To search during play, press and hold fast forward/backward•
keys, then release to resume normal play.
To navigate the menu, press• MENU, then press up/down keys
to select, and press OKtoconrm.
Charge the iPod/iPhone
When the unit is connected to power, the docked iPod/iPhone begins to
charge.
Play from an external device
You can also listen to an external audio device through this unit.
1Press to select Aux-in mode.
2Connect the supplied Aux-in cable to:
the• AUX IN jack (3.5mm) on the back of the unit.
the headphone jack on an external device.•
3Start to play the device (see the device user manual).
Adjust volume level
1During play, press VOL +/- to increase/decrease the volume level.
English
EN
DS8500_05_UM_V1.2.indd 16 2/4/2010 10:52:51 AM

17
Mute sound
1During play, press MUTE to mute/unmute sound.
EN
DS8500_05_UM_V1.2.indd 17 2/4/2010 10:52:52 AM

18
5 Product information
Note
Product information is subject to change without prior notice.•
Specications
Amplier
Rated Output Power 2X15 W RMS
Signal to Noise Ratio 85 dB
AUX IN 0.6 V RMS 10 kohm
General information
AC power (power adaptor) OH-1048A1802500U-u
Input: 100-240V~, 50/60Hz,
1.5A MAX;
Output: 18V 2.5A;
Operation Power Consumption 40W
Standby Power Consumption <1W
Dimensions
- Main Unit (W x H x D) 158 x 420 x 139 mm
Weight
- Main Unit 3.32 kg
English
EN
DS8500_05_UM_V1.2.indd 18 2/4/2010 10:52:52 AM

19
6 Troubleshooting
Warning
Never remove the casing of this apparatus.•
To keep the warranty valid, never try to repair the system yourself.
If you encounter problems when using this apparatus, check the following
points before requesting service. If the problem remains unsolved, go to
the Philips web site (www.philips.com/welcome).When you contact Philips,
ensure that the apparatus is nearby and the model number and serial number
are available.
No power
Ensure that the AC power plug of the unit is connected properly.•
Ensure that there is power at the AC outlet.•
No sound
Adjust the volume.•
No response from the unit
Disconnect and reconnect the AC power plug, then turn on the unit•
again.
EN
DS8500_05_UM_V1.2.indd 19 2/4/2010 10:52:52 AM

© 2010 Koninklijke Philips Electronics N.V.
All rights reserved.
Document order number:
DS8500_05_UM_V1.2
DS8500_05_UM_V1.2.indd 24 2/4/2010 10:52:44 AM
