Philips DVDR5520H User manual

User Manual
HDD & DVD Player / Recorder
DVDR5520H / DVDR5570H
Premium
Home Service
This product comes with
Refer to the inside page for details.
Read your Quick Start Guide and/or User Manual rst for quick tips
that make using your Philips product more enjoyable.
Register your product and get support
at www.philips.com/welcome

English
2
Dear valued customer,
Thank you for buying a Philips DVD Recorder.
Your product comes with the Philips ‘Premium Home Service’ warranty.
Should you require any assistance in operating your set, Philips offers you professional support via:
Philips Support Center website
www.philips.com/support
or
Philips Consumer Care Helpline *
where our trained representatives will guide you, step-by-step, to solve any issues you have.
If we are unable to provide a solution, Philips will be pleased to pick-up your DVD Recorder from your home; and provide
a service replacement set, within 7 days. That’s the Philips ‘Premium Home Service’ commitment to you. This service comes
free-of-charge (except for Consumer Care Helpline) and applies to all Philips DVD Recorders during the Philips warranty
period.
For more information, please contact a representative via the Philips Consumer Care Helpline.
* Refer to the back page of this manual for the Philips Customer Care phone number in your country.
Please have with you the model number, serial number and purchase date of your product when contacting Philips Customer Care..
United Kingdom, Ireland
Premium Home Service

English
3
For Customer Use:
Read carefully the information located at
the bottom or rear of your DVD
Recorder and enter below the Serial No.
Retain this information for future
reference.
Model No. DVD/HDD RECORDER
DVDR5520H, DVDR5570H
Serial No. _______________
Norge
Typeskilt nnes på apparatens underside.
Observer: Nettbryteren er sekundert
innkoplet. Den innebygde netdelen er
derfor ikke frakoplet nettet så lenge
apparatet er tilsluttet nettkontakten.
For å redusere faren for brann eller elektrisk
støt, skal apparatet ikke utsettes for regn eller
fuktighet.
Italia
DICHIARAZIONE DI CONFORMITA’
Si dichiara che l’apparecchio DVDR5520H,
DVDR5570H, Philips risponde alle prescrizioni
dell’art. 2 comma 1 del D.M. 28 Agosto 1995 n.
548.
Fatto a Eindhoven
Philips Consumer Electronics
Philips, Glaslaan 2
5616 JB Eindhoven, The Netherlands
LASER
Type Semiconductor laser
InGaAlP (DVD)
AIGaAs (CD)
Wave length 658 nm (DVD)
90 nm (CD)
Output Power 30 mW (DVD+RW write)
1.0 mW (DVD read)
1.0 mW (CD read)
Beam divergence 84 degrees (DVD)
61 degrees (CD)
SHOWVIEW® is a registered trademark of
Gemstar Development Corporation. The
SHOWVIEW® system is manufactured under
license from Gemstar Development
Corporation.
Manufactured under license from Dolby
Laboratories. “Dolby”, “Pro-Logic” and the
double-D symbol are trademarks of Dolby
Laboratories.
DivX Ultra Certied products: “DivX,
DivX Ultra Certied, and associated
logos are trademarks of DivX, Inc. and
are used under license.
Trade mark of the DVB Digital Video
Broadcasting Project (1991 to 1996)
HDMI, and HDMI logo and High-Denition
Multimedia Interface are trademarks or
registered trademarks of HDMI licensing
LLC.

English
4
CAUTION
VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN. AVOID
EXPOSURE TO BEAM
ADVARSEL
SYNLIG OG USYNLIG LASERSTRÅLING
VED ÅBNING UNDGÅ UDSÆTTELSE
FOR STRÅLING
VARNING
SYNLIG OCH OSYNLIG
LASERSTRÅLNING NÄR DENNA DEL ÄR
ÖPPNAD BETRAKTA EJ STRÅLEN
VARO!
AVATTAESSA OLET ALTTIINA
NÄKYVÄLLE JA NÄKYMÄTTÖMÄLLE
LASER SÄTEILYLLE. ÄLÄ KATSO
SÄTEESEEN
VORSICHT
SICHTBARE UND UNSICHTBARE
LASERSTRAHLUNG WENN
ABDECKUNG GEÖFFNET NICHT DEM
STRAHL AUSSETZEN
ATTENTION
RAYONNEMENT LASER VISIBLE ET
INVISIBLE EN CAS D’OUVERTURE
EXPOSITION DANGEREUSE AU
FAISCEAU
DK
Advarsel: Usynlig laserstråling ved åbning
når sikkerhedsafbrydere er ude af funktion.
Undgå utsættelse for stråling.
Bemærk: Netafbryderen er sekundært
indkoblet og ofbryder ikke strømmen fra
nettet. Den indbyggede netdel er derfor
tilsluttet til lysnettet så længe netstikket
sidder i stikkontakten.
S
Klass 1 laseraparat
Varning! Om apparaten används på annat
sätt än i denna bruksanvisning specicerats,
kan användaren utsättas för osynlig
laserstrålning, som överskrider gränsen för
laserklass 1.
Observera! Stömbrytaren är sekundärt
kopplad och bryter inte strömmen från
nätet. Den inbyggda nätdelen är därför
ansluten till elnätet så länge stickproppen
sitter i vägguttaget.
SF
Luokan 1 laserlaite
Varoitus! Laitteen käyttäminen muulla kuin
tässä käyttöohjeessa mainitulla tavalla
saattaa altistaa käyttäjän
turvallisuusluokan 1 ylittävälle
näkymättömälle lasersäteilylle.
Oikeus muutoksiin varataan. Laite ei saa
olla alttiina tippu-ja roiskevedelle.
Huom. Toiminnanvalitsin on kytketty
toisiopuolelle, eikä se kytke laitetta irti
sähköverkosta. Sisäänrakennettu verkko-osa
on kytkettynä sähköverkkoon aina silloin,
kun pistoke on pistorasiassa.
Disposal of your old product
Your product is designed and manufactured with high quality materials
and components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a product it
means the product is covered by the European Directive 2002/96/EC.
Please inform yourself about the local separate collection system for
electrical and electronic products.
Please act according to your local rules and do not dispose of your old products with
your normal household waste.The correct disposal of your old product will help
prevent potential negative consequences for the environment and human health.

English
5
This product complies with the radio
interference requirements of the
European Community.
This product complies with
the requirements of the
following directives and
guidelines: 2006/95/EC +
2004/108/EC
‘CONSUMERS SHOULD NOTE THAT NOT ALL HIGH
DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE
ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN
CASE OF 525 OR 625 PROGRESSIVE SCAN PICTURE
PROBLEMS, IT IS RECOMMENDED THAT THE USER
SWITCH THE CONNECTION TO THE ‘STANDARD
DEFINITION’ OUTPUT. IF THERE ARE QUESTIONS
REGARDING OUR TV SET COMPATIBILITY WITH THIS
MODEL 525p AND 625p DVD PLAYER, PLEASE
CONTACT OUR CUSTOMER SERVICE CENTER.’
This product incorporates copyright protec-
tion technology that is protected by US
patents. Use of this copyright protection
technology must be authorised by Macrovi-
sion, and is intended for home and other
limited viewing uses only unless otherwise
authorised by Macrovision. Reverse
engineering or disassembly is prohibited.
U.S. Patent Number 4,631,603; 4,819,098;
4,907,093; 5,315,448; and 6,516,132
CAUTION!
This unit does not contain any user-
serviceable parts. Please leave all
maintenance work to qualied
personnel.

English
6
Table of Contents
General
Care and Safety Information .......................................................................................... 8
Setup precautions.................................................................................................................................................8
Cleaning discs........................................................................................................................................................8
Hard Disk Drive (HDD) handling care...........................................................................................................8
Energy saving message ........................................................................................................................................8
Product Information ....................................................................................................... 9
Introduction...........................................................................................................................................................9
Accessories supplied ...........................................................................................................................................9
Region codes..........................................................................................................................................................9
Special features ............................................................................................................................................10~11
Product Overview
Remote Control ........................................................................................................ 12~14
Using the remote control ................................................................................................................................14
Main Unit ......................................................................................................................... 15
Connections & Setup
Step 1: Basic Recorder Connections......................................................................16~20
Connecting the antenna cables ................................................................................................................16-17
Connecting the video/audio cables .......................................................................................................18~20
Step 2: Optional Connections.................................................................................21~25
Connecting to a Cable Box or Satellite Receiver .....................................................................................21
Connecting to a VCR or other similar device........................................................................................... 22
Connecting to a VCR and Cable Box/Satellite Receiver.........................................................................23
Connecting to an AV amplier/receiver ......................................................................................................24
Connecting to digital input .............................................................................................................................24
Connecting to a camcorder ........................................................................................................................... 25
Step 3: Installation and Set-up................................................................................26~27
Watch TV
Control TV Programmes ....................................................................................... 28~30
Viewing live TV................................................................................................................................................... 28
About Time Shift buffer - temporary HDD storage .......................................................................28~29
Pause live TV function...................................................................................................................................... 30
Instant replay function ..................................................................................................................................... 30
FlexTime function.............................................................................................................................................. 30
Watching digital TV broadcast ...................................................................................................................... 30
Using the toolbar options................................................................................................................................31
Main Menu
Using the Home menu .............................................................................................32~33
About the Home menu.....................................................................................................................................32
Viewing media information..............................................................................................................................33
Recording
Before Recording ......................................................................................................34~37
Recording media ................................................................................................................................................ 34
Default recording settings .......................................................................................................................35~37
Record TV Programmes......................................................................................... 38~44
Record current TV programme.................................................................................................................... 38
Record a specic section of TV programmes .......................................................................................... 38
Simultaneous record and play function........................................................................................................39
Automatic recording from Satellite Receiver............................................................................................ 40
About timer recording......................................................................................................................................41
Timer recording (ShowView system) ...................................................................................................41~42
Timer recording (manually).....................................................................................................................42~43
Changing/Deleting a scheduled recording.................................................................................................. 44
Record from external devices................................................................................ 45~47
Recording from an external device (Camcorder/VCR/DVD player).................................................. 45
Recording from a DV Camcorder .........................................................................................................46~47

English
7
Table of Contents
Copy TV programmes from HDD......................................................................... 48~49
About copying .................................................................................................................................................... 48
Copying recordings to recordable DVD..................................................................................................... 48
Changing the screen display for recordable DVD ....................................................................................49
Copy Files
Copy les between HDD, USB and DVD ............................................................. 50~51
Copying les from HDD to USB or recordable DVD.............................................................................50
Copying les from USB to HDD or recordable DVD.............................................................................51
Copying les from CD/DVD to HDD or USB...........................................................................................51
Playback
Playback from HDD .................................................................................................52~54
Hard Disk navigation.........................................................................................................................................52
Content searching..............................................................................................................................................52
Basic operation ...................................................................................................................................................53
Delete/Lock/Protect a title in the HDD .................................................................................................... 54
Repeat hard disk playback............................................................................................................................... 54
Playback from USB device ............................................................................................ 55
Playback from Disc .................................................................................................. 56~58
Playable discs .......................................................................................................................................................56
Starting disc playback................................................................................................................................ 57~58
Additional Playback Features ................................................................................ 59~66
Edit Recordings
Edit Recordings - Hard Disk .................................................................................... 67~71
Changing the title name....................................................................................................................................67
Selecting the genre.............................................................................................................................................67
Video editing................................................................................................................................................68~71
Edit Recordings - Recordable DVD ........................................................................72~77
About editing recordable DVDs................................................................................................................... 72
Changing the disc/title name.......................................................................................................................... 73
Making the edited DVD±RW compatible .................................................................................................. 73
Deleting all recordings/titles.......................................................................................................................... 73
Finalising the DVD±R for playback................................................................................................................74
Deleting a recording/title.................................................................................................................................74
Lock/Unlock the disc for playback ................................................................................................................75
Protecting the recorded titles (DVD±RW)................................................................................................75
Video editing................................................................................................................................................76~77
System Settings
System Menu Options............................................................................................. 78~90
System menu navigation ...................................................................................................................................78
Language settings................................................................................................................................................79
Playback settings.........................................................................................................................................80~81
Video Output settings...............................................................................................................................82~83
Audio settings............................................................................................................................................. 84~85
Analogue Tuner settings.......................................................................................................................... 86~88
Digital Tuner settings....................................................................................................................................... 89
Setup settings ..............................................................................................................................................90~91
Other
Other Information....................................................................................................92~94
Setting up Progressive Scan feature............................................................................................................. 92
Copyright notice................................................................................................................................................ 92
5.1 multi-channel recording.............................................................................................................................93
Installing the latest software.......................................................................................................................... 94
Frequently Asked Questions.................................................................................. 95~97
Troubleshooting..................................................................................................... 98~103
Display panel symbols/messages ....................................................................... 104~105
Glossary / Specication ...................................................................................... 106~108

English
8
Cleaning discs
CAUTION!
Risk of damage to discs! Never use
solvents such as benzene, thinner,
cleaners available commercially, or anti-
static sprays intended for discs.
Wipe the disc with a micro bre cleaning
cloth from the centre to the edge in a
straight line movement.
Hard Disk Drive (HDD)
handling care
To avoid damage to the hard disk and
losing important data:
– Do not move the recorder or subject
it to vibration whilst in operation.
– Do not remove the AC power plug
from the mains socket without switching
the recorder to standby mode.
It is recommended to archive important
recording to a recordable DVD as
backup.
Energy saving message
In order to minimise the power
consumption in standby mode, we
recommend you to leave this unit with
Eco mode enable and turn off the front
panel display brightness. See Playback
settings - { Display } option and Setup
settings - { Eco mode } option.
Care and Safety Information
IMPORTANT NOTE!
DO NOT disconnect the recorder from
the power supply unless you are
intending not to use this product for a
long period of time. Power is needed to
enable the recorder to perform essential
tasks like timer recordings and
automatically updating the system date/
time.
Setup precautions
Finding a suitable location
– Place this unit on a at, hard and
stable surface. Do not place the unit on a
carpet.
– Do not place this unit on top of other
equipment that might heat it up (e.g.,
receiver or amplier).
– Do not put anything under this unit
(e.g., CDs, magazines).
– Install this unit near the AC outlet where
the AC power plug can be easily reached.
Space for ventilation
– Place this unit in a location with
adequate ventilation to prevent internal
heat build up. Allow at least 10 cm (4”)
clearance from the rear and the top of
this unit and 5cm (2”) from the left and
right to prevent overheating.
10cm ) 10cm
5cm
5cm
Avoid high temperature, moisture,
water and dust
– This unit must not be exposed to
dripping or splashing.
– Do not place any object or items that
can damage this unit (e.g., liquid lled
objects, lighted candles).

English
9
Introduction
This DVD/Hard Disk Drive (HDD)
recorder changes the way you watch TV.
You have full control over the TV
programmes you watch, because the
Time Shift Buffer function stores all the
programmes that the recorder is tuned
to. You can ‘pause’ TV programmes with
Pause Live TV function, or repeat any
scene with the Instant Replay function.
This recorder is also equipped with
digital terrestrial tuner (DVB-T - Digital
Video Broadcasting - Terrestrial) to
enhance your selection of programmes.
You can receive analogue TV channels,
free-to-air digital terrestrial TV channels
and digital radio signals.
Recording has never been easier with the
built-in Hard Disk Drive, you can record
up to 180~300 hours of video in SEP
(Super Extended Play) recording mode.
Model Hard Disk
Drive
(HDD)
Maximum
recording
hours
DVDR5520H 160 GB 180
DVDR5570H 250 GB 300
On top of that, you can store the DivX
movies, music les and digital camera
photos in the HDD Media Jukebox.
DVDR5520H DVDR5570H
DivX les 150 270
Photos 10,000 10,000
Music les 4,500 7,000
When you want to save or share a
recording, simply copy it to a recordable
DVD. You can also copy recordings
from your video camera or camcorder
through the i-Link connection.
Before you can start using this recorder,
you must complete the basic connection
and initial recorder set-up in three simple
steps.
Step 1: Basic recorder connections.
Step 2: Optional connections for other
devices.
Step 3: Installation and set-up.
Please take time to read this user manual
before using your recorder. It contains
important information and notes
regarding the operation of your DVD
recorder.
Helpful Hint:
– Refer to the type plate at the rear or
bottom of the product for identication and
supply ratings.
Accessories supplied
– Quick Start Guide
– RF antenna cable
– Scart cable
– Remote control and batteries
– Tuner interlink cable
Region codes
DVD movies are usually not released at
the same time in all regions of the world,
thus all DVD players/recorders are
programmed to a specic region code.
Countries DVD Region code
Europe
ALL
2
Product Information

English
10
Special features
Pause Live TV
Every TV programme is now under your
control, allowing you to take a break
without missing a moment. You can
pause any live TV programme by simply
pressing PAUSE LIVE TV button and
resume playback by pressing the PAUSE
LIVE TV button again. You can now
continue watching the remainder of the
programme or if you want to return to
the live TV programme again, just press
the LIVE TV button.
Instant Replay
You can repeat any scene of a live TV
programme by turning the rotary wheel
one click to the left, as often as you like.
If you wish to return to the live TV
programme again, just press the LIVE TV
button.
To enjoy Instant Replay, you need to
turn your recorder on and watch your
favourite TV programmes via your
recorder.
FlexTime
You can be truly exible with your time
now with FlexTime. FlexTime allows you
to start watching a TV programme while
it is still being recorded, you do not need
to wait for the recording to nish before
starting to watch it. Alternatively, you
can also watch another earlier recorded
programme, play a DVD or DivX movie
or enjoy some music while the recorder
is recording the TV programme.
Product Information (continued)
Time Shift Buffer (TSB)
As soon as you turn on your recorder,
the TV channel it is tuned to will be
stored into the Time Shift Buffer. Think
of this as a temporary storage for TV
programmes allowing you great exibility.
It can contain up to 6 (six) hour of TV
programmes and will automatically ush
anything that is older. You can mark
portions of the Time Shift Buffer and
copy them to your recordings list for
later viewing or copying to recordable
DVD. The recorder needs to be turned
on for the Time Shift Buffer to be active.
When the recorder is turned off, the
Time Shift Buffer is automatically cleared.
Digital and analogue tuner
This product features analogue TV
reception, digital terrestrial TV and
DVB-T Radio reception. To select
between the three modes, simply press
the LIVE TV button repeatedly.
Analogue TV
 Digital TV  DVB-T Radio
To enjoy Pause Live TV, you need to turn
your recorder on and watch your
favourite TV programmes via your
recorder.
ShowView
This is a simple programming system for
recorders. To use it, enter the
programming number associated with
your television programme. You can nd
this number in your favourite listings
magazine.

English
11
SAT recording
This function enables you to record a
programme from your Satellite Receiver
or any other device. Make sure that the
device is connected to the
EXT2-TO VCR/SAT socket of this
recorder, and the timer setting has been
done on the connected device.
Follow TV
With this function you can align the
sequence of the channels on your TV
(analogue only) with those on your
recorder. This enhances the efciency of
the system for recordings. Make sure
you have connected the TV to the
EXT1 TO TV socket of this recorder.
* The Follow TV feature may not work
properly on every TV.
i.LINK
i.LINK, also known as ‘FireWire’ or ‘IEEE
1394’, is a digital connection for
connecting your camcorder to enable
you to make high quality copies of your
camcorder videos. The connector can be
found behind the front ap door.
Skip Commercial Block
After recording, the commercial scenes
in the title will be checked and marked if
‘Smart’ chaptering feature is activated
(see page 37). This recorder will
automatically insert chapter markers at
the beginning and the end of the
commercial scenes. When watching the
recording from the hard disk, you can
now skip over commercials by pressing
the NEXT >button.
Product Information (continued)
Media Jukebox
The Hard Disk drive of this recorder
serves as a media jukebox that allows you
to store all sources of recordings (TV
recordings, videos, music and photos).
The titles recorded or copied to the hard
disk will automatically be saved under
separate contents based on the
characteristics of the recordings.
Keyword search
Keyword search saves you from having to
scroll through lists of les on your
recorder’s hard disk. Simply type in
keywords using the alphanumeric keypad
on the remote control and instantly nd
your favourite TV recordings, music les
and DivX videos.
5.1 channel audio recording
Digital 5.1 channel audio recording lets
you capture - along with the video - the
original sound from digital-channel
programme sources. These recordings
play back in multi-channel only when
connected to a 5.1 channel speaker
system.

English
12
Remote Control
a2
– Turns on this unit or turns off to normal
standby mode.
bCAM
– Switches to the camcorder that is
connected to the DV IN CAM2 socket.
cUSB
– Switches to USB mode and shows the
content of the USB device.
dColour coded buttons
– These buttons can be used to select the
coloured options available in some
menus.
e. (PREV/REW) /
> (NEXT/FFW)
– Skips to the previous or next chapter/
track. Hold down the button to make a
reverse/forward search.
PAUSE LIVE TV
1
2
3
4
5
6
7
8
9
10
11
12
13
14
fOPTIONS
– Enters/exits the Options menu. This
menu provides various setting options.
gNavigation cursor / Rotary wheel
– In recorder’s Live TV mode, turning the
rotary wheel to skip backward or
forward in the Time Shift Buffer .
– b B : Cursor buttons for moving to the
left/right. Skip or replay the scene by a
specied length of time in the Time Shift
Buffer.
– : Cursor buttons for moving up/
down.
hOK
– Conrms an entry or selection.
iHOME
– Enters/exits the recorder’s Home menu.
jP +-
– While in Live TV mode, select the next
or previous TV channel or the external
input source (EXT1, EXT2, CAM1).
– While in camcorder mode, select other
external input source (EXT1, EXT2,
CAM1).
kTIMER (SHOWVIEW)
– Enters/Exits the timer programming
mode.
lAUDIO
– Selects an audio language/channel.
mSCART
(only effective when your TV is connected
with the Scart cable to EXT1 of your
recorder)
– Switches to the device that is connected
to the EXT2 Scart connector of your
recorder. If no device is connected to
EXT2, it switches to TV preset instead.
To switch back to recorder mode, press
this button again.
nEDIT
– Enters/exits the editing menu.

English
13
Remote Control (continued)
oLIVE TV
– Switches to live TV mode. It activates
the Time Shift Buffer that allows you to
pause or replay the TV programme at
any time.
– Press repeatedly to toggle between
analogue TV, digital TV and digital radio.
pHDD LIST
– Shows the list of your recordings stored
in the internal hard disk.
qPAUSE LIVE TV u
– Pauses or resumes a live TV programme.
– Starts or pauses playback of any recorded
title or disc.
STOP x
– Stops playback/recording.
– Hold down this button to open or close
the disc tray.
REC
– Starts recording the currently viewed TV
programme. Press repeatedly to set the
recording length in 30-minute increments.
rDISC
– Shows the content of the disc.
sBACK
– Returns to the previous menu.
tTV VOL +-
– Adjusts the volume of the TV (for Philips
TVs or compatible brands only).
uAlphanumeric keypad
– Used to enter numbers or letters (using
SMS style entry).
– Selects a chapter/track/title number to
play.
– Selects the recorder’s preset tuner
channels.
vSUBTITLE
– Selects a DVD or DivX subtitle language.
wINFO
– Displays on-screen information.
xSELECT
– Selects multiple les for copying or
deleting.
– Toggles between ‘T’ (title) and ‘C’
(chapter) selection during disc playback,
then use the ./ > keys to select
the previous or next title/chapter.
– Toggles between upper and lower case
characters while using the alphanumeric
keypad.
PAUSE LIVE TV
16
17
22
23
24
18
19
20
21
15

English
14
Remote Control (continued)
Using the remote control
AOpen the battery compartment cover.
BInsert two batteries type R03 or AAA.
Match the indications (+-) inside the
battery compartment.
CClose the cover.
DPoint the remote control directly at the
remote sensor on the front panel and
select the desired function.
CAUTION!
– Remove batteries if they are
exhausted or if the remote control
is not to be used for a long time.
– Do not mix batteries (old and new
or carbon and alkaline, etc.).
– Batteries contain chemical
substances, they should be disposed
of properly.
Using the alphanumeric keypad to
enter the characters
– Press a number button repeatedly until
the required character or the number
appears.
– To enter special symbols, press button
repeatedly.
– To select upper/lower case (capital/
small) letters, press SELECT.
– To enter a space, press button .

English
15
Main Unit
aSTANDBY-ON
– Turns on this unit or turns off to normal
standby mode.
bDisc tray
cOPEN CLOSE ç
– Opens or closes the disc tray.
dDisplay panel
– Shows information about the current
status of the recorder.
eHOME
– Enters/exits the recorder’s Home menu.
f: Cursor buttons for moving to the
left/right. In recorder’s Live TV mode,
replay or skip the scene by a specied
length of time.
: Cursor buttons for moving up/
down. In camcorder (CAM) mode, select
CAM2, CAM1, EXT1 or EXT2 input
source.
gOK
– Conrms an entry or selection.
hu
– Pauses or resumes a live TV show.
– Starts or pauses playback.
.>
– Skips to the previous or next chapter/
track. Hold down the button to make a
reverse/forward search.
x
– Stops playback/recording.
i z
– Starts recording the currently viewed TV
programme. Press repeatedly to set the
recording length in 30-minute increments.
– Lights up while recording is in progress.
Sockets behind the ap
Flip down the door as indicated by the
OPEN label at the right hand corner.
jDV IN (CAM2) socket
– Input for digital camcorders (also
referred to as FireWire or IEEE1394).
kS-VIDEO -VIDEO-AUDIO (CAM1)
socket
– S-video/Composite video and audio
inputs for camcorder/DVD player/VCR
or other similar device.
lUSB socket
– Input for USB ash drive, USB memory
reader or digital camera.
* Not all brands and models of digital
cameras are supported, except those
compliant with the PTP standard.

English
16
MAINS
HDMI
OUT
S-VIDEO
OUT
AUDIO
OUT
COAXIAL
DIGITAL OUT
COMPONENT
VIDEO OUT
COAXIAL
DIGITAL
IN
CVBS-OUT
P
B
P
R
Y
R
L
TO VCR/SAT EXT2
TO TV EXT1
ANALOG
ANTENNA INPUT
TO TV ANTENNA
INPUT
DIGITAL
ANTENNA INPUT
DIGITAL ANTENNA
LOOP THROUGH
ANTENNA INTERCONNECT CABLE
(OPTIONAL, REFER TO MANUAL)
G-LINK
Step 1: Basic Recorder Connections
Connecting the antenna
cables
These connections enable you to watch
and record TV programmes.
This recorder has two types of tuner
input, one for digital TV reception and
one for analogue TV reception. If you
have a separate indoor digital terrestrial
antenna or you want to connect your
recorder to Cable TV as well as antenna,
follow option 2. Otherwise, follow
option 1.
Helpful Hints:
– Depending on how you have currently
connected your TV channel (directly from an
off-air antenna or cable box or VCR), you’ll
have to disconnect some of the cables before
you make the antenna connection.
– If you want to connect to a VCR and/or a
separate Cable Box/ Satellite Receiver, see
‘Step 2: Optional Connections’ for details.
Before you start ...
Select a suitable antenna connection.
Option 1: Connecting to a single
off-air antenna
Use this connection if you have only an
off-air antenna and wish to receive both
analogue and digital TV programmes.
AConnect the existing Antenna cable (it
can be from the off-air wall socket or
Cable Box) to the DIGITAL
ANTENNA INPUT socket on the
recorder.
BConnect the Tuner interlink cable
(supplied) to the DIGITAL
ANTENNA LOOP THROUGH and
ANALOG ANTENNA INPUT
sockets on the recorder.
CConnect a RF antenna cable (supplied)
from the TO TV ANTENNA INPUT
socket on the recorder to the
antenna input socket on your TV (usually
labelled as ANT, ANTENNA IN, RF IN).
Option 1

English
17
Option 2: Connecting to Cable TV
antenna and/or separate indoor
terrestrial antenna
Use this connection if you have a
separate indoor digital terrestrial antenna
or want to connect your recorder to
Cable TV as well as off-air antenna.
AConnect the existing Cable TV antenna
cable to the ANALOG ANTENNA
INPUT socket on the recorder.
BConnect the digital terrestrial antenna
cable to the DIGITAL ANTENNA
INPUT socket on the recorder.
CConnect a RF antenna cable (supplied)
from the TO TV ANTENNA INPUT
socket on the recorder to the
antenna input socket on your TV (usually
labelled as ANT, ANTENNA IN, RF IN).
Helpful Hint:
– Only free-to-air digital TV channels can be
received (no reception of ‘conditional access’
/ Smartcard channels).
MAINS
HDMI
OUT
S-VIDEO
OUT
AUDIO
OUT
COAXIAL
DIGITAL OUT
COMPONENT
VIDEO OUT
COAXIAL
DIGITAL
IN
CVBS-OUT
P
B
P
R
Y
R
L
TO VCR/SAT EXT2
TO TV EXT1
ANALOG
ANTENNA INPUT
TO TV ANTENNA
INPUT
DIGITAL
ANTENNA INPUT
DIGITAL ANTENNA
LOOP THROUGH
ANTENNA INTERCONNECT CABLE
(OPTIONAL, REFER TO MANUAL)
G-LINK
Option 2
Step 1: Basic Recorder Connections (continued)

English
18
Step 1: Basic Recorder Connections (continued)
Connecting the video/audio
cables
This connection enables you to view the
playback from this recorder. You only
need to choose one of the options
below to make your video connection.
– For a standard TV, follow option 1, 2
or 3.
– For a progressive scan TV, follow
option 4.
– For a HDMI TV, follow option 5.
Helpful Hint:
– Audio connection is only required if you
are connecting this recorder to your TV using
the S-VIDEO, CVBS or COMPONENT VIDEO
socket.
Option 1: Using the Scart socket
Connect a scart cable (supplied) from the
EXT1-TO TV socket on the recorder
to the corresponding SCART socket on
the TV.
Helpful Hint:
– Use the EXT2-TO VCR/SAT socket for
connecting the recorder to additional device.
Option 2: Using the S-Video socket
AConnect a S-video cable (not supplied)
from the S-VIDEO OUT socket on the
recorder to the S-Video input socket
(usually labelled as Y/C or S-VHS) on the
TV.
BConnect the audio cables (not supplied)
from the AUDIO OUT sockets on the
recorder to the audio input sockets on
the TV.
Option 3: Using the Video (CVBS)
socket
AConnect a composite video cable (yellow
- not supplied) from the CVBS OUT
socket on the recorder to the video
input socket (usually labelled as A/V In,
Video In, Composite or Baseband) on the
TV.
BConnect the audio cables (not supplied)
from the AUDIO OUT sockets on the
recorder to the audio input sockets on
the TV.
HDMI
OUT
S-VIDEO
OUT
AUDIO
OUT
C
O
DIGI
CVBS-OUT
Y
R
L
TO VCR/SAT EXT2
TO TV EXT1
ANALOG
ANTENNA INPUT
TO TV ANTENNA
INPUT
DIGITAL
ANTENNA INPUT
DIGITAL ANTENNA
LOOP THROUGH
ANTENNA INTERCONNECT CABLE
(OPTIONAL, REFER TO MANUAL)
G-LINK
TV
Option 1
HDMI
OUT
S-VIDEO
OUT
AUDIO
OUT
COAXIAL
DIGITAL OUT
COMPONENT
VIDEO OUT
COAXIAL
DIGITAL
IN
CVBS-OUT
P
B
P
R
Y
R
L
TO VCR/SAT EXT2
TO TV EXT1
DIGITAL
ANTENNA INPUT
DIGITAL ANTENNA
LOOP THROUGH
ANTENNA INTERCONNECT CABLE
(OPTIONAL, REFER TO MANUAL)
TV
Option 3
Option 2
OR

English
19
Step 1: Basic Recorder Connections (continued)
Option 4: Using Component
video socket / Connecting to a
Progressive Scan TV
The progressive scan video quality is only
available when using Y Pb Pr connection
and a progressive scan TV is required. It
provides superior picture quality when
watching DVD movies.
AConnect the component video cables
(red/ blue/green - not supplied) from the
Y PBPRsockets on the recorder to the
corresponding component video input
sockets (usually labelled as Y Pb/Cb Pr/Cr
or YUV) on the TV.
BConnect the audio cable (red/white - not
supplied) from the AUDIO OUT
sockets on the recorder to the audio
input sockets on the TV.
Note:
To enable Y Pb Pr (YUV) connection, you
must set the recorder’s video output
correctly.
AMake an addition video connection from
this recorder to your TV using Scart,
S-Video or Video (CVBS).
BTurn on your TV to the correct viewing
channel for the above video connection.
CWhen you have completed the
installation and set-up, change the video
output setting of this recorder as
follows:.
1) Press OPTIONS.
2) Move to { Settings } > { Video
output } > { Active video output }
>{Comp. video (YUV) }, then
press OK to conrm.
To activate Progressive Scan output, see
‘Other information - Setting up
Progressive Scan feature’ for details.
DSwitch your TV to the correct viewing
channel for the Component video
connection (refer to your TVs user
manual).
MAI
N
HDMI
OUT
S-VIDEO
OUT
AUDI O
OUT
COAXIAL
DIGITAL OUT
COMPONENT
VIDEO OUT
COAXIAL
DIGITAL
IN
CVBS-OUT
PB
PR
Y
R
L
TO VCR/SAT EXT2
TO TV EXT1
ANALOG
ANTENNA INPUT
TO TV ANTENNA
INPUT
DIGITAL
ANTENNA INPUT
DIGITAL ANTENNA
LOOP THROUGH
ANTENNA INTERCONNECT CABLE
(OPTIONAL, REFER TO MANUAL)
G-LINK
TV
Option 4

English
20
Step 1: Basic Recorder Connections (continued)
Option 5: Connecting to a HDMI-
compatible TV
HDMI (High Denition Multimedia
Interface) is a digital interface that allows
pure digital video transmission without
the loss of image quality.
Connect a HDMI cable (not supplied)
from the HDMI OUT on the main unit
to the HDMI IN on a HDMI-compatible
device (e.g., HDMI TV, HDCP compliant
DVI TV).
Helpful Hints:
– Some HDMI TVs/monitors from different
manufacturers may adhere to different
standards resulting in unreliable signal
transfers.
– The HDMI connector is only compatible
with HDMI compliant devices and DVI-TVs.
– The teletext information will not be
accessible in the recorder’s Live TV mode.
Note:
To enable HDMI connection, you must
set the recorder’s video output correctly.
AMake an addition video connection from
this recorder to your TV using Scart,
S-Video or Video (CVBS).
BTurn on your TV to the correct viewing
channel for the above video connection.
CWhen you have completed the
installation and set-up, change the video
output setting of this recorder as
follows:.
1) Press OPTIONS.
2) Move to { Settings } > { Video
output } > { Active video output }
>{HDMI output }, then press OK
to conrm.
DSwitch your TV to the correct viewing
channel for the HDMI connection (refer
to your TVs user manual).
HDMI
OUT
S-VIDEO
OUT
AUDIO
OUT
COAXIAL
DIGITAL OUT
COMPONENT
VIDEO OUT
COAXIAL
DIGITAL
IN
CVBS-OUT
PB
PR
Y
R
L
TO VCR/SAT EXT2
TO TV EXT1
ANALOG
ANTENNA INPUT
TO TV ANTENNA
INPUT
DIGITAL
ANTENNA INPUT
DIGITAL ANTENNA
LOOP THROUGH
ANTENNA INTERCONNECT CABLE
(OPTIONAL, REFER TO MANUAL)
G-LINK
TV
Option 5
