Philips HQ586 User manual

ServiceManual
Philips Consumer Lifestyle
Published by Philips Consumer Lifestyle Printed in the Netherlands © Copyright reserved Subject to modification
Rechargeable shaver
HQ586
10/05
PRODUCT INFORMATION
- This product meets the requirements regarding
interference suppression on radio and TV.
- After the product has been repaired, it should function
properly and has to meet the safety requirements as
officially laid down at this moment.
TECHNICAL INFORMATION
- Operating Voltage : 1,2 Volt
- Power supply : Rechargeable
- Shaving heads : 2 x HQ53
- SAP coding : HQ586
DISASSEMBLY- AND RE-ASSEMBLY ADVISE
Disassembly:
- Remove the shaving unit, to prevent damages during
repairs
- Remove screws (item 19) (4x)
- Remove top cover
- Remove power supplier/detach connection pins
(item 17) with a small screwdriver
- Set the trimmer coupling piece in the upright postion
(see figure 1)
- Unlock the peg clamping from
the driving unit.
(see figure 2) (A)
- Remove driving unit out of the
housing (see figure 2) (B)
- Open the driving unit
- Remove pinion
- Remove screws (item 21) (2x)
for disconnecting motor from
frame
- To remove the trimmer out of the cover, open the trimmer,
press outsides cover together and take trimmer out of the
cover.
Assembly:
- The assembly must be carried out in the reverse order of
what is discribed under disassembly
- When fitting the shaver it must be checked if wiring is
correctly positioned
REPAIR INSTRUCTION
- No specific issues
OPTIONAL (accessories)
- No specific issues
figure 1
A
A
B
figure 2

HQ586
PARTS LIST & EXPLODED VIEW
2
20
1
3
4
5
6
19
7
8
21
9
10
11
12
13
16
17
14
15
18
19
Pos Service code Description
1
2
3
4
5
6
7
8
9
10
11
12
13
14
4822 479 30183
4222 036 08080
4222 036 12840
4222 036 07830
4222 036 07840
4222 036 10360
4222 036 07860
4222 036 07870
4222 036 07880
4222 036 03610
4222 036 07720
4222 036 07890
4822 138 10633
4222 036 07850
4222 036 07900
cleaning brush
housing
housing assy Icy Blue
protecting cap
bracket
HQ53 shaving heads
head holder assy
hairchamber assy
driving unit
pinion
motor assy
trimmer assy
1AA cell NiCd
tape
seal
Pos Service code Description
15
16
17
18
19
20
21
4222 036 08090
4222 036 08100
4222 036 10330
4222 036 08110
4222 036 07940
4222 036 06790
4222 036 04040
4222 036 08930
4222 036 06800
4822 502 14545
4222 036 07970
4222 036 07390
4222 036 08130
cover assy
cover assy PRC
cover assy KOR
power supplier
contact lip
power plug EU
power plug PRC
power plug JAP
power plug CAN/ROW
screw
switch button
screw (motor)
case
