Philips HQ5801/33 User manual

HQ5802,5801
ENGLISH 4
FRANÇAIS 11
ESPAÑOL 18
PORTUGUÊS 25
37
43
á«Hô©dGá«Hô©dG

Important
C◗Make sure the appliance and the cord do not
get wet.
◗Only use the cord supplied.
Charge indications
C◗Charging
As soon as you start charging the empty shaver,
the green pilot light will go on.
A fully charged shaver has a cordless shaving time
of up to 45 minutes.
Charging
Recharge and keep the appliance at a
temperature between 5cC and 35cC.
The appliance is suitable for mains voltages
ranging from 100 to 240V.
You can also shave without charging by
connecting the shaver to the mains.
To extend the lifetime of the battery,remove the
powerplug from the wall socket and pull the
appliance plug out of the shaver when the battery
has been fully charged.
C1Put the appliance plug in the shaver.
2Put the powerplug in the wall socket.
Do not recharge the shaver in a closed pouch.
ENGLISH4

3When charging for the first time or after a
long period of disuse:leave the shaver to
charge continuously for 12 hours.
Charging normally takes approx.8 hours.
4Remove the powerplug from the socket
and pull the appliance plug out of the
shaver when the battery has been fully
charged.
Shaving
1Switch the appliance on by sliding the
on/off button upwards.
C2Move the shaving heads quickly over your
skin,making both straight and circular
movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philishave system.
3Switch the shaver off.
C4Put the protection cap on the shaver to
prevent damage.
Replace the shaving heads (type HQ5 Reflex
Action) every 2 years for optimal shaving results.
ENGLISH 5

Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.
Cleaning
◗Regular cleaning guarantees better shaving
performance.
C◗For easy and optimal cleaning,the Philishave
Action Clean (shaving head cleaner,type
HQ100) is available.Ask your Philishave dealer
for information.
You can also clean the shaver in the following
way:
Every week:shaving unit
1Switch the shaver off,remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Clean the top of the appliance first,using
the brush supplied.
C3Press the release button and remove the
shaving unit.
ENGLISH6
2
1

C4Clean the inside of the shaving unit and the
hair chamber with the brush.
C5Put the shaving unit back onto the shaver.
Every two months:shaving heads
1Switch the shaver off,remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
C2Press the release button and remove the
shaving unit.
C3Turn the wheel anticlockwise and remove
the retaining frame.
C4Remove and clean the shaving heads
(cutters and guards) one by one.
Do not mix up the cutters and the guards.
This is essential since each cutter has been
ground with its corresponding guard for optimal
performance.If you accidentally mix the sets up,it
could take several weeks before optimal shaving
performance is restored.
ENGLISH 7
2
1
2
1

C5Clean the cutter with the short-bristled
side of the brush.
Brush carefully in the direction of the arrow.
C6Brush the guard.
If necessary,you can clean the shaving unit with a
degreasing liquid (e.g.alcohol).Remember to
lubricate the central point of the guards with a
drop of sewing machine oil after cleaning.
C7Reassemble the shaving unit by replacing
the retaining frame.Press the wheel and
turn it clockwise.
8Put the shaving unit back onto the shaver.
Trimmer
1Switch the shaver off,remove the
powerplug from the wall socket and pull
the appliance plug out of the shaver.
2Clean the trimmer every time you have
used it.
3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
ENGLISH8
2
1

Disposal of the battery
Remove the battery when you discard the
appliance.Do not throw the battery away with
the normal household waste,but hand it in at an
official collection point.You can also take the
battery to a Philips Service Centre,which will
dispose of it in an environmentally safe way.
Only remove the battery if it is completely empty.
1Remove the powerplug from the wall
socket and pull the appliance plug out of
the shaver.
C2Let the shaver run until it stops,undo the
screws and open the shaver.
3Remove the battery.
Do not connect the shaver to the mains again
after the battery has been removed.
Troubleshooting
◗Problem:The shaver does not work after the
on/off button has been slided upwards.
BSolution:Recharge the battery.
If the shaver still does not work,see 'Guarantee &
service'.
ENGLISH 9

Guarantee & service
If you need information or if you have a problem,
please visit the PhilipsWeb site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet).If there is no Customer Care Centre in
your country,turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
ENGLISH10

Important
C◗Veillez à ce que l'appareil et le cordon
d'alimentation ne soient pas exposés à
l'humidité.
◗Utilisez exclusivement le cordon
d'alimentation fourni avec l'appareil.
Indications de charge
C◗Charge
Dès que vous commencez à charger le rasoir
vide,le témoin vert s'allume.
A pleine charge,le rasoir possède
approximativement 45 minutes d'autonomie.
Charge
Chargez et maintenez l'appareil à une
température comprise entre 5cC et 35cC.
Ce rasoir fonctionne sur une tension secteur de
100 à 240~volts.
Vous pouvez également vous raser directement
sans charger préalablement l'appareil en
raccordant directement l'appareil à la tension du
réseau.
Pour prolonger la durabilité des accumulateurs
enlevez le chargeur de la prise de courant,et tirez
la fiche hors du rasoir.
C1Enfoncez la fiche dans le rasoir.
FRANÇAIS 11

2Mettez le chargeur dans la prise de
courant.
Ne chargez jamais l'appareil dans un étui fermé.
3Lorsque vous chargez l'appareil pour la
première fois,ou si l'appareil n'a pas été
utilisé pendant une longue période:
chargez-le pendant 12 heures sans
interruption.
Une charge normale dure 8 heures environ.
4Lorsque le rasoir est complètement
rechargé,retirez d'abord le chargeur de la
prise de courant puis la fiche du rasoir.
Rasage
1Mettez l'appareil en marche en faisant
glisser le bouton marche/arrêt vers le haut.
C2Déplacez rapidement les têtes de rasage
sur la peau en effectuant des mouvements
rectilignes et circulaires.
Les meilleurs résultats de rasage sont obtenus sur
peau sèche.
Votre peau peut avoir besoin de 2-3 semaines
pour s'habituer au système de coupe Philishave.
3Arrêtez le rasoir.
C4Remettez le capot protecteur sur le rasoir
pour éviter tout dommage.
FRANÇAIS12
