Philips S5000 series User manual

www.philips.com/support/ifu
S5533, S5532,
S5531
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 13000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 1 07-08-20 09:3807-08-20 09:38

English 3
简体中文 12
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 23000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 2 07-08-20 09:3807-08-20 09:38

English
简简简简
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for dierent products. The box shows
which accessories are supplied with your product
and whether your product is bluetooth enabled.
Danger
-Keep the supply unit dry.
Warning
-To charge the battery, only use the detachable
supply unit (HQ8505) provided with the
appliance.
-The supply unit contains a transformer. Do not
cut o the supply unit to replace it with another
plug, as this causes a hazardous situation.
-This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning
and user maintenance shall not be made by
children without supervision.
-Always unplug the appliance before you clean it
under the tap.
3English
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 33000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 3 07-08-20 09:3807-08-20 09:38

-Always check the appliance before you use
it. Do not use the appliance if it is damaged,
as this may cause injury. Always replace a
damaged part with one of the original type.
Philips Quick Clean Pod cartridge uid
-Do not swallow.
-Keep out of reach of children.
Caution
-Never immerse the charging stand in water and
do not rinse it under the tap.
-Never use water hotter than 60°C to rinse the
shaver.
-Only use this appliance for its intended purpose
as shown in the user manual.
-For hygienic reasons, the appliance should only
be used by one person.
-Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive
liquids such as petrol or acetone to clean the
appliance.
-If your shaver comes with a cleaning system,
always use the original Philips Quick Clean Pod
cartridge.
-Always place the cleaning system on a stable,
level and horizontal surface to prevent leakage.
-Always make sure the cartridge compartment is
closed before you use the cleaning system.
-When the cleaning system is ready for use, do
not move it to prevent leakage of cleaning uid.
-Water may drip from the socket at the bottom
of the shaver when you rinse it. This is normal
and not dangerous because all electronics
are enclosed in a sealed power unit inside the
shaver.
4English
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 43000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 4 07-08-20 09:3807-08-20 09:38

-Do not use the supply unit in or near wall
sockets that contain an electric air freshener to
prevent irreparable damage to the supply unit.
-Do not use the appliance on chapped skin,
open wounds, healing wounds, skin recovering
from surgery or if you suer from a skin disease
or skin irritation, such as severe acne, sunburn,
skin infection, skin cancer, inammation,
eczema, psoriasis, nylon allergy etc.
-Do not use the cleansing brush attachment if
you are taking steroid-based medication, as this
may cause irritation or injury.
-If you wear piercings on your face, remove
the piercings before you use the click-on
attachments or make sure that you do not use
the appliance on or near the piercing.
-If you wear jewelry, contact lenses or glasses,
remove them before you use the click-on
attachments, or make sure that you do not use
the appliance on or near jewelry or glasses.
Battery safety instructions
-Only use this product for its intended purpose
and follow the general and battery safety
instructions as described in this user manual.
Any misuse can cause electric shock, burns, re
and other hazards or injuries.
-To charge the battery, only use the detachable
supply unit (HQ8505) provided with the
product. Do not use an extension cord.
-Charge, use and store the product at a
temperature between 5 °C and 35 °C.
-Always unplug the product when it is fully
charged.
5English
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 53000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 5 07-08-20 09:3807-08-20 09:38

-Do not burn products and their batteries and
do not expose them to direct sunlight or to
high temperatures (e.g. in hot cars or near hot
stoves). Batteries may explode if overheated.
-If the product becomes abnormally hot, gives
o an abnormal smell, changes color or if
charging takes much longer than usual, stop
using and charging the product and contact
your local Philips dealer.
-Do not place products and their batteries in
microwave ovens or on induction cookers.
-This product contains a rechargeable battery
that is non-replaceable. Do not open the
product to replace the rechargeable battery.
-When you handle batteries, make sure that your
hands, the product and the batteries are dry.
-To prevent batteries from heating up or
releasing toxic or hazardous substances, do
not modify, pierce or damage products and
batteries and do not disassemble, short-circuit,
overcharge or reverse charge batteries.
-To avoid accidental short-circuiting of batteries
after removal, do not let battery terminals
come into contact with metal object (e.g.
coins, hairpins, rings). Do not wrap batteries in
aluminum foil. Tape battery terminals or put
batteries in a plastic bag before you discard
them.
-If batteries are damaged or leaking, avoid
contact with the skin or eye. If this occurs,
immediately rinse well with water and seek
medical care.
Electromagnetic elds (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic elds.
6English
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 63000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 6 07-08-20 09:3807-08-20 09:38

General
-This shaver is waterproof. It is suitable for use
in the bath or shower and for cleaning under
the tap. For safety reasons, the shaver can
therefore only be used without cord.
-The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
-The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
Recycling
-Do not throw away the product with the
normal household waste at the end of its life,
but hand it in at an ocial collection point for
recycling. By doing this, you help to preserve
the environment.
-This product contains a built-in rechargeable
battery which shall not be disposed of with
normal household waste. Please take your
product to an ocial collection point or a
Philips service center to have a professional
remove the rechargeable battery.
-Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when
you discard the appliance. Before you remove
the battery, make sure that the appliance is
disconnected from the wall socket and that the
battery is completely empty.
Take any necessary safety precautions when you
handle tools to open the appliance and when you
dispose of the rechargeable battery.
Be careful, the battery strips are sharp.
7English
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 73000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 7 07-08-20 09:3807-08-20 09:38

1Twist the shaving head to remove it from the
handle.
2Insert a at-head screwdriver under the rim of
the panel and pry o.
3Remove the two screws from the top with a torx
or at-head screwdriver.
4Slide the front shell o.
5Break the bridge on top with a wire cutter.
6Insert a at head screwdriver on either side of
the shaver body to release the hooks.
8English
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 83000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 8 07-08-20 09:3807-08-20 09:38

7Slide the power unit out of the body.
8Bend the snap hooks aside and remove the
transparent cover of the power unit.
9Lift out out the battery holder and cut the wires
with a pair of cutting pliers or scissors.
10 Bend the battery tags aside with a pair of
cutting pliers or a screwdriver.
11 Remove the rechargeable battery.
Warranty and support
If you need information or support, please
visit www.philips.com/support or read the
international warranty leaet.
Warranty restrictions
The shaving heads (cutters and guards) are not
covered by the terms of the international warranty
because they are subject to wear.
9English
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 93000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 9 07-08-20 09:3807-08-20 09:38

Troubleshooting
This chapter summarizes the most common
problems you could encounter with the appliance.
If you are unable to solve the problem with the
information below, visit www.philips.com/support
for a list of frequently asked questions or contact
the Consumer Care Center in your country.
Shaver
Problem Possible cause Solution
The appliance
does not work
when I press
the on/o
button.
The appliance is
still attached to
the wall socket. For
safety reasons, the
appliance can only
be used without
cord.
Unplug the appliance and
press the on/o button to
switch on the appliance.
The rechargeable
battery is empty.
Recharge the battery.
The travel lock is
activated.
Press the on/o button for
3 seconds to deactivate the
travel lock.
The shaving unit is
soiled or damaged
to such an extent
that the motor
cannot run.
Clean the shaving heads
thoroughly or replace them.
The appliance
does not shave
as well as it
used to.
The shaving heads
are damaged or
worn.
Replace the shaving heads.
Hairs or dirt
obstruct the
shaving heads.
Clean the shaving heads
thoroughly.
10 English
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 103000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 10 07-08-20 09:3807-08-20 09:38

Problem Possible cause Solution
Water is
leaking from
the bottom of
the appliance.
During cleaning,
water may collect
between the inner
body and the
outer shell of the
appliance.
This is normal and not
dangerous because all
electronics are enclosed in a
sealed power unit inside the
appliance.
11English
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 113000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 11 07-08-20 09:3807-08-20 09:38

重要安全信息
使用本产品及其附件之前，请仔细阅读本
重要信息，并妥善保管以供日后参考。 随
附的附件可能因产品而异。 包装盒上会
显示产品随附的附件以及产品是否支持蓝
牙。
危险
-保持电源部件干燥。
-警告符号注释： 禁止在打开的水龙头下
进行清洗
(图 )。
警告
-要给电池充电，请仅使用产品随附的可
拆卸电源部件 (HQ8505)。
-电源部件中包含一个变压器。 请勿自
行更换电源部件的插头，否则将导致严
重后果。
-本产品也可以由 8 岁或以上年龄的儿童
以及肢体不健全、感觉或精神上有障碍
或缺乏相关经验和知识的人士使用，但
前提是有人对他们使用本产品进行监督
或指导，以确保他们安全使用，并且让
他们明白相关的危害。 切勿让儿童玩弄
本产品。 不要让儿童在无人监督的情况
下对本产品进行清洁和保养。
-手持部分与电源软线分开后，才能在水
中清洗手持部分。
12 简体中文
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 123000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 12 07-08-20 09:3807-08-20 09:38

-使用前，请务必检查产品。 请勿使用损
坏的产品，否则可能对人体造成伤害。
请务必用原装型号更换损坏的部件。
飞利浦快速清洗器滤芯液
-切勿吞食。
-请置于儿童接触不到的地方。
注意
-切勿将充电座浸入水中，也不要在自来
水龙头下冲洗。
-切勿使用温度高于 60°C 的热水冲洗
剃须刀。
-只能将本产品用于用户手册中所示的原
定用途。
-出于卫生的目的，本产品只能供一个人
使用。
-切勿使用压缩气体、钢丝绒、研磨性清
洁剂或腐蚀性液体（例如汽油或丙酮）
来清洁产品。
-如果您的剃须刀随附清洁系统，请始终
使用飞利浦原装快速清洗器滤芯。
-清洁系统必须放在稳定、平坦的水平表
面上，以防漏液。
-使用清洁系统前，请始终确保滤芯仓已
关闭。
-清洁系统准备就绪时，切勿移动，以免
清洁液漏出。
13简体中文
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 133000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 13 07-08-20 09:3807-08-20 09:38

-冲洗剃须刀时，水可能从产品底部的插
口漏出。 这是正常的，而且没有危险，
因为所有电子元件都封闭在剃须刀内部
的密封电源部件中。
-请勿在包含电动空气清新器的墙壁插座
上或其周围使用电源部件，以免电源部
件受到不可修复的损坏。
-如果皮肤出现皲裂、开放性伤口、正
在愈合的伤口、皮肤处于术后恢复期或
存在严重粉刺、晒伤、皮肤感染、皮肤
癌、发炎、湿疹、牛皮癣、对尼龙过敏
等皮肤病或皮肤过敏，请勿使用本产
品。
-如果您正在服用类固醇类药物，请勿使
用洁面刷附件，因为这可能会引起过敏
或损伤。
-如果您的面部带有穿环，则需卸下穿环
后再使用卡入式附件或确保不要在穿环
上或附近使用产品。
-如果您戴有首饰、隐形眼镜或眼镜，则
需取下后再使用卡入式附件或确保不要
在首饰或眼镜上或附近使用产品。
电池安全说明
-仅可将本产品用于原定用途，并应遵循
本用户手册中的一般说明和电池安全说
明。 如有滥用，可能会导致电击、烧
伤、火灾和其他危害或伤害。
14 简体中文
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 143000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 14 07-08-20 09:3807-08-20 09:38

-要给电池充电，请仅使用本产品随附的
可拆卸电源部件 (HQ8505)。 请勿使用
延长线。
-充电、使用和存放本产品的温度应介于
5 °C 至 35 °C 之间。
-产品充满电后务必拔下电源插头。
-切勿燃烧产品及其电池，也不要将其暴
露在阳光直射或高温的环境中（例如炎
热的汽车内或热炉附近）。 如果过热，
电池可能会爆炸。
-如果产品异常发热、发出异味、变色或
充电时间比平时长，请停止使用并停止
为其充电，并联系您当地的飞利浦经销
商。
-切勿将产品及其电池放置在微波炉中或
电磁炉上。
-本产品包含不可更换的充电电池。 切勿
拆开本产品更换充电电池。
-处理电池时，请确保您的双手、产品和
电池都是干燥的。
-为防止电池发热或释放有毒有害物质，
切勿改装、刺穿或损坏产品和电池，切
勿拆卸电池、使电池短路、过度充电或
反向充电。
-为避免电池拆卸后发生意外短路，切勿
让电池端子接触金属物体（例如硬币、
发夹、戒指）。 切勿用铝箔包裹电池。
在丢弃之前，请用胶带将电池端子粘住
或将电池放在塑料袋中。
15简体中文
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 153000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 15 07-08-20 09:3807-08-20 09:38

-如果电池损坏或出现泄漏，请避免与皮
肤或眼睛接触。 如果不慎接触，请立即
用清水冲洗并就医。
电磁场 (EMF)
本 Philips 产品符合所有有关暴露于电磁
场的适用标准和法规。
概述
-该剃须刀具有防水性能 (图 )。 适合在
沐浴或淋浴时使用，也可以放在水龙头
下清洗。 出于安全原因，该剃须刀在使
用时不能连接电线。
-符号注释：适合于在洗澡或淋浴时使用
(图 )。 允许在盛水的浴缸、淋浴、洗脸
盆或其他器皿附近使用本器具。
-电源部件适合在 100 - 240 伏的电源电
压下工作。
-该电源部件可将 100-240 伏的电压转换
为 24 伏以下的安全低电压。
回收
-弃置本产品时，请不要将其与一般生活
垃圾放在一起，应将其交给政府指定的
回收中心。 这样做将有利于环保。
-此产品包含内置充电电池；请勿将充电
电池与一般生活垃圾一起弃置。 请您将
产品送到官方收集中心或飞利浦服务中
心，请专业人士移除充电电池。
16 简体中文
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 163000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 16 07-08-20 09:3807-08-20 09:38

-遵循您的国家/地区有关分类回收电子电
气产品和充电电池的规定。 正确弃置产
品有助于避免对环境和人类健康造成不
良后果。
拆下充电电池
在废弃器具前，必须将电池从器具中取
出。 卸下电池之前，请确保本产品与电源
断开连接并且电池电量已耗尽。
当您使用工具打开产品时以及在您弃置充
电电池时，请采取必要的安全保护措施。
注意，电池带非常锋利。
1 旋转剃须刀头，将其从手柄上拆下。
2 将平头螺丝刀插入面板边缘下方，然
后将其撬出。
3 用梅花螺丝刀或平头螺丝刀卸下顶部
的两颗螺丝。
17简体中文
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 173000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 17 07-08-20 09:3807-08-20 09:38

4 将前壳滑下。
5 用钢丝钳剪断顶部的连接片。
6 将平头螺丝刀插入剃须刀机身一侧以
松开钩子。
7 将电源部件滑出机身。
8 将安全钩向外掰，取下电源部件的透
明保护盖。
18 简体中文
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 183000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 18 07-08-20 09:3807-08-20 09:38

9 拉出电池舱，用钢丝钳或剪刀将电线
剪断。
10 用钢丝钳或螺丝刀将电池标签向外
掰。
11 卸下充电电池。
保修和支持
如需信息或支持，请访问 www.philips.
com/support 或阅读保修卡。
保修条款
由于剃须刀头（刀片和网罩）属于易磨损
物品，因此不在国际保修条款的涵盖范围
之列。
мȞġĈҴˀΙĀǩ؆Ӎߒʔ
ˌɫǩ؆
ĈҴˀΙ
໾
(Pb)
᰽
(Hg)
⬡
(Cd)
ԣᲱ
(Cr (VI) )
Ġ⅑ԓ᧠
(PBB)
Ġ⅑ȕ᧠⓭
(PBDE)
PCB’s
מŪǗɢذ XOOO
OO
Electrical
contact pins
ǗˈǦ
XOOO
OO
Power plug
Ǘ۷૝Ǽ XOOO
OO
XOOO
OO
ǕȪϜ֪֙SJ/T 11364Āܪǭৠ뺯
OȪФ˽ĈҴˀΙć˽ˌɫǨĈߴΙࠒնġĀߒʔߴćGB/T 26572ܪǭĀՄʔđŘĪ뺯
Internal
metal parts
ʭˌɫ
XȪФ˽ĈҴˀΙψɺć˽ˌɫĀԚĂߴΙࠒնġĀߒʔɸŜGB/T 26572
ܪǭĀՄʔđ뺯
19简体中文
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 193000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 19 07-08-20 09:3807-08-20 09:38

-该表格中所显示的“有害物质”在产品
正常使用情况下不会对人身和环境产生
任何伤害。
-该表格中所显示的“有害物质”及其存
在的部件向消费者和回收处理从业者提
供相关物质的存在信息，有助于产品废
弃时的妥善处理。
ϔ৮喟下ݖ⊓⩢ߕݰ䶨ܭ
ಸ喟444
䷊Ⴧ⩢ࢸ喟7嗣
䷊Ⴧ䶾⢴喟)[
䷊Ⴧ䓀ڒߌ⢴喟8
⩌ϔᬒ᱌喟䄤㻮ϔ৮᱙Ҁ
ϔౝ喟పᎬ⤍⊤
⤍⊤㏼≻➦ࡧ下ݖ⊓უᏚ⩢கᰶ䭽ڙ
ప⤍⊤ጯ▣䩴⥡ⴠጒࡧ
ڕప䶫჏᰺ߎ☚㏬
᱙ϔ৮ᵦᢛపᴴ(#
(#ݣ䕍
*19
保留备用
发行日期: 30/4/2020
故障种类和处理方法
本章归纳了使用本产品时最常见的一些问
题。如果您无法根据以下信息解决问题，
请访问 www.philips.com/support 查阅常
见问题列表，或联系您所在国家/地区的客
户服务中心。
20 简体中文
3000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 203000.053.1643.2 APA SDFU/IIB Bklt A6 FC 30x30 China.indd 20 07-08-20 09:3807-08-20 09:38
