Philips HQ6845 User manual

ENGLISH 4
BAHASA MELAYU 14
BAHASA INDONESIA 24
TI”NG VI◊T 34
 44
53
62
71
HQ6854

Warning
Please read these instructions before using the
appliance.
◗Only use the cord supplied.
C◗Make sure the appliance and the cord do not
get wet.
Charge indications
C◗Charging
As soon as you start charging the empty shaver,
the green pilot light will go on.
C◗Battery fully charged
When the battery has been fully charged, the
green pilot light will start blinking.
A fully charged shaver has a cordless shaving time
of up to approx. 30 minutes.
C◗Battery running low
When the battery is running low, the lower pilot
light turns red.When you have switched off the
shaver, the red light will blink for 4 seconds.
Charging
Recharge, store and use the appliance at a
temperature between 5cC and 35cC.
The appliance is suitable for mains voltages
ranging from 100 to 240V.
ENGLISH4

You can also shave without charging by
connecting the shaver to the mains.
To extend the lifetime of the battery, remove the
plug from the wall socket and pull the appliance
plug out of the shaver when the battery has been
fully charged.
C1Put the appliance plug in the shaver.
2Put the plug in the wall socket.
Do not recharge the shaver in a closed pouch.
3When charging for the first time or after a
long period of disuse: leave the shaver to
charge continuously for 4 hours.
Charging normally takes approx. 1 hour.
4Remove the plug from the wall socket and
pull the appliance plug out of the shaver
when the battery has been fully charged.
Shaving
1Switch the shaver on by sliding the on/off
button upwards (1).
C2Move the shaving heads quickly over your
skin, making both straight and circular
movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philishave system.
3Switch the shaver off (0).
ENGLISH 5

C4Put the protection cap on the shaver every
time you have used it, to prevent damage.
Replace the shaving heads (type HQ55) every 2
years for optimal shaving results.
Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.
Cleaning
Regular cleaning guarantees better shaving
performance.
C◗For easy and optimal cleaning, the Philishave
Action Clean (shaving head cleaner, type
HQ100) is available.Ask your Philishave dealer
for information.
You can also clean the shaver in the following
way:
Every week: shaving unit
1Switch the shaver off (0), remove the plug
from the wall socket and pull the appliance
plug out of the shaver.
ENGLISH6

C2Clean the top of the appliance first, using
the brush supplied.
C3Press the release button and remove the
shaving unit.
C4Clean the inside of the shaving unit and the
hair chamber with the brush.
C5Put the shaving unit back onto the shaver.
Every two months: shaving heads
Replace the shaving heads (type HQ55) every 2
years for optimal shaving results.
1Switch the shaver off (0), remove the plug
from the wall socket and pull the appliance
plug out of the shaver.
ENGLISH 7
2
1

C2Press the release button and remove the
shaving unit.
C3Turn the wheel anticlockwise and remove
the retaining frame.
C4Remove and clean the shaving heads
(cutters and guards) one by one.
Do not mix up the cutters and the guards.
This is essential since each cutter has been
ground with its corresponding guard for optimal
performance. If you accidentally mix the sets up, it
could take several weeks before optimal shaving
performance is restored.
C5Clean the cutter with the short-bristled
side of the brush.
Brush carefully in the direction of the arrow.
C6Brush the guard.
You can also clean the shaving unit with a
degreasing liquid (e.g. alcohol). If you do, lubricate
the central point of the guards with a drop of
sewing machine oil after cleaning.This prevents
wear of the shaving heads.
ENGLISH8
2
1
1
2

C7Reassemble the shaving unit: turn the
wheel clockwise.
8Put the shaving unit back onto the shaver.
Trimmer
Clean the trimmer every time you have used it.
1Switch the shaver off (0), remove the plug
from the wall socket and pull the appliance
plug out of the shaver.
C2Clean the trimmer with the brush
supplied.
C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Replacing the shaving heads
Replace the shaving heads every two years for
optimal shaving results.
1Switch the shaver off (0), remove the plug
from the wall socket and pull the appliance
plug out of the shaver.
C2Press the release button and remove the
shaving unit.
ENGLISH 9
1
2
2
1

C3Turn the wheel anti-clockwise and remove
the retaining frame.
C4Remove the shaving heads and place the
new ones in the shaving unit.
C5Reassemble the shaving unit: turn the
wheel clockwise.
Replace damaged or worn shaving heads with
Philishave HQ55 shaving heads only.
Storing
C◗Put the protection cap on the shaver to
prevent damage.
◗The appliance can be stored in the pouch
supplied.
Disposal of the battery
The built-in rechargeable battery contains
substances that may pollute the environment.
Remove the battery when you discard the
appliance. Do not throw the battery away with
the normal household waste, but hand it in at an
ENGLISH10
1
2
1
2

official collection point.You can also take the
battery to a Philips Service Centre, which will
dispose of it in an environmentally safe way.
Only remove the battery if it is completely empty.
1Remove the plug from the wall socket and
pull the appliance plug out of the shaver.
C2Let the shaver run until it stops, undo the
screws and open the shaver.
3Remove the battery.
Do not connect the shaver to the mains again
after the battery has been removed.
Troubleshooting
1Reduced shaving performance
BCause 1: the shaving heads are dirty.
BThe shaver has not been cleaned well enough or
has not been cleaned for a prolonged period.
◗Clean the shaver thoroughly before you
continue shaving (see 'Cleaning').
BCause 2: long hairs are obstructing the shaving
heads.
C◗Remove the retaining frame.
ENGLISH 11
1
2

C◗Clean the cutters and guards.
Do not clean more than one cutter and guard at
a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it may
take several weeks before optimal shaving
performance is restored.
◗Remove the hairs with the brush supplied.
◗Put the retaining frame back onto the shaving
unit.
BCause 3: shaving heads are damaged or worn. See
'Replacing the shaving heads'.
Replacing the shaving heads every 2 years
prevents wear of the shaving heads.
◗Put the retaining plate back onto the shaving
unit.
2The shaver does not work when the
ON/OFF button is pushed upwards (1).
BCause: the battery is empty. See 'Charging'.
◗Recharge the battery.
ENGLISH12
