Philips HQ6830/A User manual

ServiceManual
Philips Domestic Appliances and Personal Care
Published by Philips Domestic Appliances and Personal Care Printed in the Netherlands © Copyright reserved Subject to modification
Shaver
HQ6830/A
QUADRA ACTION
This product meets the requirements regard-
ing interference suppression on radio and TV.
After the product has been repaired, it should
function properly and has to meet the safety
requirements as officially laid down at this
moment.
4322 277 00134
02/12
TECHNICAL DATA
Voltage : 100-240 V 50/60Hz
Power consumption : Motor depending
Motor voltage : 2.4 V
Power supply : SMPS
Speed of cutters : > 2100 r.p.m.
Shaving heads : HQ6 - 4822 690 10214
Battery : Green NiMH pack AA
SAP CODING : 8856 830 99999
HINTS FOR REPAIRS
- Remove the shaving unit, to prevent damages
during repairs.
- Remove screws A1 (2x, of which 1 is under
trimmer slide).
- Take cover with trimmer from housing.
- Remove bracket (14 + 21).
- The PC-board can now be removed from the
housing.
- Remove screws B1 (2x) the motor and
hairchamber can now be removed from the
housing.
- Detach the motor clamping spings (item 17) on
the bearing block with a small screwdriver.
GENERAL
• Mainsshaver possible.
• Converts input voltage 8-16V dc to constant
Charge current (NiMH 1100mA, NiCd 680mA)
or Constant motorvoltage at mainsshave.
Start-up voltage min. 11V.
• Open battery protection.
• Undervoltage protection.
• Charging time is determined by
Temperature (absolute or delta).
• Green mains LED (input voltage present).
• Electronic on/off.
!Service
Information !Service
Information

If the HQ6830/A shaver is supplied with a HQ8000 powerplug, remove R35 from the PCB.
Removing R35 will not adversely affect the shaver’s performance.
If the shaver has been supplied with a HQ8000 plug, R35 and its surrounding will look burned. See picture.
If the customer complaint can be related to battery capacity, also replace the battery.
= changed
HQ6830/A

1 4822 479 20261 cleaning brush
2 4822 441 12344 housing PH
3 4822 466 12232 rubber seal
4 4822 219 10711 power plug EU
4822 219 10713 power plug E-EU
4822 219 10715 power plug GB
4822 219 10717 power plug J
5 4822 462 11177 protecting cap
6 4822 441 12327 head housing
7 4822 690 10214 HQ6 shaving head
8 4822 214 13054 power module
9 4822 402 11319 retaining bracket
10 4822 442 01819 hairchamber PH
11 4822 265 11548 connecting pins
12 4822 522 10762 gearwheel unit
13 4822 466 12233 sealing plate
14 4822 402 11318 bracket small
15 4822 522 10763 pinion
16 4822 361 21783 motor
17 4822 492 71735 motor clamp
18 4822 130 34167 Zener diode
19 4822 690 10213 trimmer
20 4822 463 11257 trimmer slide
21 4822 402 11317 bracket large
22 4822 532 13149 spacer AA
23 4822 138 10728 NiMH pack AA
24 4822 442 01818 cover
A 4822 502 14657 s.t.screw spec/T8
B 4822 502 14544 s.t.screw 1.8x18/T8
4822 600 10856 pouch PH
4822 736 16909 DFU (1)
4822 736 16911 DFU (2)
4822 736 16912 DFU (3)
4822 736 16913 DFU (4)
4822 736 16914 DFU (5)
(1) GB D F NL E P I TR
(2) GB D N S FIN DK GR
(3) GB RUS UA HR SLO CZ SK H RO
(4) GB RUS PL EST LV LT
(5) J
* 4222 036 01960 Car cord
NiMH
21
20
19
22
23
A1
24
13
14
16
15
17
18
11
12
7
9
10
8
6
5
1
2
3
4
B1
HQ6830/A

HQ6830/A
