Philips HQ7200 User manual

HQ 7200
ENGLISH 4
DANSK 12
DEUTSCH 20
 29
SUOMI 38
NORSK 45
SVENSKA 52
65
73

4
Important
Read these instructions for use carefully before using
the appliance and save them for future reference.
Only use the powerplug supplied.
The powerplug transforms 100-240 volts to a
safe low voltage of less than 24 volts.
The powerplug contains a transformer. Do not
cut off the powerplug to replace it with another
plug, as this will cause a hazardous situation.
Do not use a damaged powerplug.
If the powerplug is damaged, always have it
replaced by one of the original type in order to
avoid a hazard.
Make sure the powerplug does not get wet.
Store the appliance at a temperature between
5 cC and 35 cC.
Always unplug the shaver before cleaning it
under the tap.
The appliance complies with the internationally
approved IEC safety regulations and can be safely
cleaned under the tap.
Be careful with hot water. Always check if the water
is not too hot, to prevent your hands from getting
burnt.
This washable shaver is not suitable for shaving
in the shower.
Do not immerse the shaver in water.
Water may leak from the socket at the bottom
of the appliance when you rinse it.This is normal
and not dangerous because all electronics are
enclosed in a sealed power unit inside the shaver.
,
,
,
,
,
,
,
,
,
,
,
,
ENGLISH

Using the appliance
Shaving
1 Put the appliance plug in the shaver.
2 Put the powerplug in the wall socket.
3 Switch the shaver on by pressing the on/off
button once.
The power-on lights go on to indicate that the
motor is running.
4 Move the shaving heads quickly over your skin,
making both straight and circular movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
5 Switch the shaver off by pressing the on/off
button once.
The power-on lights go out.
6 Clean the shaver (see chapter ‘Cleaning and
maintenance’).
7 Put the protection cap on the shaver every
time you have used it, to prevent damage to
the shaving heads.
Trimming
For grooming sideburns and moustache.
1 Open the trimmer by pushing the slide
downwards.
The trimmer can be activated while the motor is
running.
-
-
ENGLISH 5

2 Close the trimmer (‘click’).
Cleaning and maintenance
Regular cleaning guarantees better shaving
performance.
Be careful with hot water.Always check if the
water is not too hot, to prevent your hands from
getting burnt.
Note: Water may leak from the socket at the bottom
of the appliance when you rinse it.This is normal and
not dangerous.
Every day: shaving unit and hair chamber
1 Switch the shaver off, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Press the release button to open the shaving
unit.
3 Clean the shaving unit and the hair chamber by
rinsing them under a hot tap for some time.
ENGLISH6

Make sure you clean the inside as well as the
outside of the shaving unit.
4 Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
5 Open the shaving unit again and leave it open
to let the appliance dry completely.
You can also clean the hair chamber without water
by using the brush supplied.
Every six months: shaving heads
1 Open the shaving unit, turn the lock
anticlockwise (1) and remove the retaining
frame (2).
2 Clean the cutters and guards with the brush
supplied.
Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
may take several weeks before optimal shaving
performance is restored.
3 Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit and turn the lock clockwise.
4 Close the shaving unit.
,
ENGLISH 7

Trimmer
Clean the trimmer every time you have used it.
1 Switch the shaver off, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Clean the trimmer with the brush supplied.
3 Lubricate the trimmer teeth with a drop of
sewing machine oil every six months.
Storage
Put the protection cap on the shaver to prevent
damage to the shaving heads.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with HQ8
Philips shaving heads only.
Note: Do not mix up the cutters and the guards to
guarantee optimal shaving performance.
1 Switch the shaver off, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
,
,
ENGLISH8

2 Press the release button to open the shaving
unit.
3 Turn the lock anticlockwise (1) and remove the
retaining frame (2).
4 Remove the shaving heads and place new ones
in the shaving unit. Put the retaining frame
back into the shaving unit and turn the lock
clockwise.
Make sure that the projections of the shaving
heads t exactly into the recesses.
5 Close the shaving unit.
Accessories
The following accessories are available:
HQ8000 powerplug.
HQ8 Philips shaving heads.
HQ110 Philips Shaving Head Cleaning Spray.
HQ8010 car cord.
Environment
Do not throw the appliance away with the
normal household waste at the end of its life,
but hand it in at an ofcial collection point for
recycling. By doing this you will help to preserve
the environment.
-
-
-
-
,
ENGLISH 9

Guarantee & service
If you need information or if you have a
problem, please visit the Philips website at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will nd its phone
number in the worldwide guarantee leaet). If there
is no Customer Care Centre in your country, turn
to your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and
Personal Care BV.
ENGLISH10

Troubleshooting
1 Reduced shaving performance.
Cause 1: the shaving heads are dirty.The shaver has
not been rinsed long enough or the water used was
not hot enough.
Clean the shaver thoroughly before you continue
shaving. See chapter ‘Cleaning and maintenance’.
Cause 2: long hairs are obstructing the shaving heads.
Clean the cutters and guards with the brush
supplied. See chapter ‘Cleaning and maintenance’,
section ‘Every six months: shaving heads’.
Cause 3: the shaving heads are damaged or worn.
Replace the shaving heads. See chapter
‘Replacement’.
2 The shaver does not work when the on/off
button is pressed.
Cause 1: the appliance is not connected to the
mains.
Put the powerplug in the wall socket.
3 The shaving unit has come off the shaver.
The shaving unit has not been placed correctly.
If the shaving unit becomes detached from the
shaver, you can easily put it back by inserting
the hinge into the slot in the rim of the hair
chamber and pushing it home until it locks into
place (‘click’).
,
,
,
,
,
ENGLISH 11

12
Vigtigt
Læs brugsvejledningen omhyggeligt igennem, inden
apparatet tages i brug, og gem den til eventuel
senere brug.
Brug kun det medfølgende netstik.
Net/transformerstikket omformer 100-240Volt
til en lav sikkerhedsspænding under 24Volt.
Netstikket indeholder en transformer. Derfor
må det aldrig klippes af og udskiftes med et
andet stik, da dette ved efterfølgende brug kan
være meget risikabelt.
Brug aldrig et beskadiget netstik.
Hvis netstikket beskadiges, må det kun udskiftes
med et originalt netstik af samme type for at
undgå enhver risiko ved efterfølgende brug af
apparatet.
Sørg for, at netstikket ikke bliver vådt.
Apparatet skal oplades og opbevares ved en
temperatur mellem 5 cC og 35 cC.
Tag altid stikket ud af shaveren, inden den skylles
under vandhanen.
Produktet opfylder de internationalt godkendte
IEC-sikkerhedsregler og kan skylles under
rindende vand uden risiko.
Vær forsigtig med varmt vand. Kontrollér altid, at
vandet ikke er for varmt, så du ikke skolder dine
hænder.
Denne vaskbare shaver er ikke beregnet til brug
i brusebadet.
Kom aldrig shaveren ned i vand.
,
,
,
,
,
,
,
,
,
,
,
DANSK
