Philips HQ8160 User manual

HQ8160
ENGLISH 4
INDONESIA 16
한국어 28
BAHASA MELAYU 40
ภาษาไทย 52
 62
繁體中文 74
简体中文 85

4
Important
Read these instructions for use carefully before using
the appliance and save them for future reference.
Only use the powerplug supplied.
The powerplug transforms 100-240 volts to a
safe low voltage of less than 24 volts.
The powerplug contains a transformer. Do not
cut off the powerplug to replace it with another
plug, as this will cause a hazardous situation.
Do not use a damaged powerplug.
If the powerplug is damaged, always have it
replaced by one of the original type in order to
avoid a hazard.
Make sure the powerplug does not get wet.
Charge and store the appliance at a temperature
between 5 cC and 35 cC.
Never immerse the charging stand in water nor
rinse it under the tap.
Do not recharge the shaver in a closed pouch.
Always unplug the shaver before cleaning it
under the tap.
The appliance complies with the internationally
approved IEC safety regulations and can be safely
cleaned under the tap.
Be careful with hot water. Always check if the water
is not too hot, to prevent your hands from getting
burnt.
This washable shaver is not suitable for shaving
in the shower.
Do not immerse the shaver in water.
,
,
,
,
,
,
,
,
,
,
,
,
,
ENGLISH

Water may leak from the socket at the bottom
of the appliance, when you rinse it.This is normal
and not dangerous because all electronics are
enclosed in a sealed shell inside the shaver.
Electromagnetic elds (EMF)
This Philips appliance complies with all standards
regarding electromagnetic elds (EMF). If handled
properly and in accordance with the instructions in
this instruction manual, the appliance is safe to use
according to scientic evidence available today.
Charging
Make sure the appliance is switched off before you
start charging it.
Charging takes approx. 1 hour.
You can also shave without charging by connecting
the shaver to the mains.
Charge indications
Charging
When the shaver is being charged, the bottom
light blinks red.When the battery contains
enough power for one shave, all lights start
blinking green sequentially.
Battery fully charged
When the battery has been fully charged, all
green lights are on.
A few hours after charging, all lights go out.
,
,
,
ENGLISH 5

Remaining battery capacity
The amount of power left in the battery is
indicated by the number of lights that are on.
The battery capacity is only shown when you
switch the shaver on or off.
When all lights burn green, the battery is 100%
charged.
When the bottom light burns green, 20% of the
battery capacity is left.
Battery running low
When the battery is running low, the bottom
light turns red.
When you switch the shaver off, this light blinks a
few times.
Cordless shaving time
A fully charged shaver has a cordless shaving time of
up to 55 minutes.
Charging the appliance
Charge the shaver when the bottom light burns or
blinks red.
Do not recharge the shaver in a closed pouch.
1 Put the appliance plug in the shaver.
2 Put the powerplug in the wall socket.
3 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver
when the battery has been fully charged.
Charging stand
You can also charge the appliance by placing it in the
charging stand, if provided.
,
-
-
,
ENGLISH6

Place the shaver properly in the plugged-in
charging stand.
Lift the shaver from the stand without tilting it.
Using the appliance
Shaving
1 Switch the shaver on by pressing the on/off
button once.
The blue light ring around the on/off button goes
on to indicate that the motor is running.
Note:When you switch the shaver on, all lights go on
and then the remaining battery capacity is shown for a
few seconds.
2 Move the shaving heads quickly over your skin,
making both straight and circular movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
3 Switch the shaver off by pressing the on/off
button once.
The blue light ring around the on/off button goes
out.
,
,
,
-
-
,
ENGLISH 7

4 Clean the shaver (see chapter ‘Cleaning and
maintenance’).
5 Put the protection cap on the shaver every
time you have used it, to prevent damage.
Trimming
For grooming sideburns and moustache.
1 Open the trimmer by pushing the slide
downwards.
The trimmer can be activated while the motor is
running.
2 Close the trimmer (‘click’).
Cleaning and maintenance
Regular cleaning guarantees better shaving
performance.
The normal way to clean the appliance is to rinse
the shaving unit and the hair chamber with hot
water every time you have used the shaver.
Be careful with hot water.Always check if the
water is not too hot, to prevent your hands from
getting burnt.
Note:Water may leak from the socket at the bottom of
the appliance when you rinse it.This is normal and not
dangerous.
ENGLISH8

Every day: shaving unit and hair chamber
1 Switch the shaver off, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Press the release button to open the shaving
unit.
3 Clean the shaving unit and the hair chamber by
rinsing them under a hot tap for some time.
Make sure you clean the inside as well as the
outside of the shaving unit.
4 Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
5 Open the shaving unit again and leave it open
to let the appliance dry completely.
You can also clean the hair chamber without water
by using the brush supplied.
Every six months: shaving heads
1 Open the shaving unit, turn the lock
anticlockwise (1) and remove the retaining
frame (2).
-
ENGLISH 9

2 Clean the cutters and guards with the brush
supplied.
Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
may take several weeks before optimal shaving
performance is restored.
3 Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit and turn the lock clockwise.
4 Close the shaving unit.
Trimmer
Clean the trimmer every time you have used it.
1 Switch the shaver off, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Clean the trimmer with the brush supplied.
3 Lubricate the trimmer teeth with a drop of
sewing machine oil every six months.
Charging stand
You can clean the charging stand with a moist cloth.
ENGLISH10

Storage
Put the protection cap on the shaver to prevent
damage.
The appliance can be stored in the pouch
supplied.
The shaver can be stored in the charging stand,
if provided.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with HQ9
Philips shaving heads only.
Note:Do not mix up the cutters and the guards to
guarantee optimal shaving performance.
1 Switch the shaver off, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Press the release button to open the shaving
unit.
3 Turn the lock anticlockwise (1) and remove the
retaining frame (2).
,
,
,
ENGLISH 11

4 Remove the shaving heads and place new ones
in the shaving unit. Put the retaining frame
back into the shaving unit and turn the lock
clockwise.
Make sure that the projections of the shaving
heads t exactly into the recesses.
5 Close the shaving unit.
Accessories
The following accessories are available:
HQ8500/HQ8000 powerplug.
HQ9 Philips Shaving Heads.
HQ110 Philips Shaving Head Cleaning Spray
(not available in China).
HQ8010 car cord.
Environment
Do not throw the appliance away with the normal
household waste at the end of its life, but hand
it in at an ofcial collection point for recycling.
By doing this you will help to preserve the
environment.
Disposal of the battery
The built-in rechargeable battery contains substances
that may pollute the environment. Always remove
the battery before discarding the appliance or
handing it in at an ofcial collection point. Dispose
of the battery at an ofcial collection point for
batteries. If you have trouble removing the battery,
you can also take the appliance to a Philips service
-
-
-
-
-
ENGLISH12

centre, which will remove the battery for you and
will dispose of it in an environmentally safe way.
Only remove the battery if it is completely empty.
1 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver.
2 Let the shaver run until it stops and undo the
two screws at the back of the shaver.
3 Undo the two screws in the hair chamber.
4 Undo the three screws in the power unit.
5 Bend the 4 hooks aside (1) to take out the
power unit (2).
Be careful, the hooks are very sharp.
6 Remove the power unit cover by means of a
screwdriver.
7 Remove the battery.
Be careful, the battery strips are very sharp.
Do not connect the shaver to the mains again after
the battery has been removed.
ENGLISH 13

Guarantee & service
If you need information or if you have a
problem, please visit the Philips website at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will nd its phone
number in the worldwide guarantee leaet). If there
is no Customer Care Centre in your country, turn
to your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and
Personal Care BV.
Troubleshooting
1 Reduced shaving performance.
Cause 1: the shaving heads are dirty.The shaver
has not been rinsed long enough or the water
used was not hot enough.
Clean the shaver thoroughly before you continue
shaving. See chapter ‘Cleaning and maintenance’.
Cause 2: long hairs are obstructing the shaving
heads.
Clean the cutters and guards with the brush
supplied. See chapter ‘Cleaning and maintenance’,
section ‘Every six months: shaving heads’.
Cause 3: the shaving heads are damaged or worn.
Replace the shaving heads. See chapter
‘Replacement’.
2 The shaver does not work when the on/off
button is pressed.
Cause 1: the battery is empty.
Recharge the battery. See chapter ‘Charging’.
Cause 2: the appliance is not connected to the
mains.
Put the powerplug in the wall socket.
-
-
-
-
-
ENGLISH14

3 The shaving unit has come off the shaver.
The shaving unit has not been placed correctly.
If the shaving unit becomes detached from the
shaver, you can easily put it back by inserting the
hinge into the slot in the rim of the hair chamber
and pushing it home until it locks into place
(‘click’).
-
-
ENGLISH 15

16
Penting
Bacalah petunjuk penggunaan ini dengan saksama
sebelum menggunakan alat dan simpanlah untuk
referensi jika dibutuhkan kelak.
Gunakan hanya steker listrik yang disertakan.
Steker mengubah tegangan 100-240 volt menjadi
tegangan rendah yang aman di bawah 24 volt.
Steker listrik berisi trafo. Jangan memotong
steker listrik dan menggantinya dengan steker
lain, karena dapat membahayakan.
Jangan gunakan steker listrik yang rusak.
Jika steker listrik rusak, harus selalu diganti
dengan tipe yang asli agar terhindar dari bahaya.
Pastikan steker listrik tidak basah.
Isi ulang baterai alat cukur dan simpan alat pada
suhu di antara 5 cC dan 35 cC.
Jangan merendam dudukan pengisi baterai dalam
air maupun membersihkannya di bawah keran air.
Jangan mengisi ulang pencukur di dalam kantong
tertutup.
Cabut steker dari pencukur sebelum
membersihkannya di bawah keran.
Alat cukur ini memenuhi peraturan keselamatan
IEC yang disepakati secara internasional dan
dapat dengan aman dibersihkan di bawah keran
air.
Hati-hati dengan air panas. Selalu periksa apakah air
tidak terlalu panas untuk mencegah luka bakar pada
tangan Anda.
Pencukur yang dapat dicuci ini tidak sesuai untuk
mencukur di bawah pancuran.
,
,
,
,
,
,
,
,
,
,
,
,
INDONESIA

Jangan mencelupkan pencukur ke dalam air.
Air mungkin keluar dari soket bawah alat saat
Anda membilasnya. Ini adalah normal dan tidak
berbahaya karena semua bagian elektronik
disimpan dalam wadah yang tertutup rapat di
dalam alat cukur.
Medan elektromagnet (EMF)
Alat Philips ini mematuhi semua standar yang
berkenaan dengan medan elektromagnet (EMF). Jika
ditangani sebagaimana layaknya dan sesuai dengan
petunjuk dalam buku panduan ini, alat tersebut aman
digunakan menurut bukti ilmiah yang kini tersedia.
Pengisian daya
Pastikan alat dalam kondisi mati sebelum Anda
mengisinya.
Waktu pengisian daya kurang lebih 1 jam.
Anda juga dapat mencukur tanpa mengisi daya
dengan menghubungkan pencukur ke listrik.
Indikator daya
Pengisian daya
Saat baterai pencukur diisi ulang, lampu bagian
bawah akan berkedip merah. Setelah baterai
terisi cukup daya untuk sekali mencukur, semua
lampu akan berkedip hijau secara berurutan.
,
,
,
INDONESIA 17

Baterai terisi penuh
Setelah baterai terisi penuh, semua lampu hijau
akan menyala.
Beberapa jam setelah pengisian, semua lampu mati.
Kapasitas baterai yang tersisa
Jumlah daya yang tersisa dalam baterai
ditunjukkan dengan jumlah lampu yang menyala.
Kapasitas baterai hanya ditunjukkan saat Anda
menghidupkan atau mematikan pencukur.
Apabila semua lampu menyala hijau, baterai terisi
100%.
Apabila lampu bagian bawah menyala hijau,
kapasitas baterai tersisa 20%.
Baterai hampir habis
Apabila daya baterai hampir habis, lampu bagian
bawah menyala merah.
Apabila Anda mematikan pencukur, lampu ini
berkedip beberapa kali.
Waktu pencukuran tanpa kabel
Pencukur yang terisi penuh dapat digunakan tanpa
kabel hingga 55 menit.
Mengisi baterai pencukur
Isi daya pencukur apabila lampu bagian bawah
menyala atau berkedip merah.
Jangan mengisi ulang pencukur di dalam kantong
tertutup.
1 Pasang steker alat pada pencukur.
2 Masukkan steker listrik ke stopkontak.
3 Setelah baterai terisi penuh, cabut steker listrik
dari stopkontak dan lepaskan steker alat dari
pencukur.
,
,
-
-
,
INDONESIA18

Dudukan pengisi baterai
Anda juga dapat mengisi daya alat cukur dengan
memasangnya pada dudukan pengisi daya, jika
tersedia.
Letakkan alat cukur dalam dudukan pengisi
baterai plug-in.
Angkat pencukur dari dudukannya dengan arah
tegak lurus.
Menggunakan alat
Mencukur
1 Hidupkan pencukur dengan menekan tombol
on/off satu kali.
Cincin lampu biru di sekitar tombol on/off
menyala untuk menunjukkan bahwa motor
bekerja.
Catatan:Apabila Anda menghidupkan atau mematikan
pencukur, semua lampu menyala dan kapasitas baterai
tersisa ditampilkan selama beberapa detik.
2 Gerakkan kepala pencukur dengan cepat pada
kulit Anda, lakukan gerakan lurus maupun
memutar.
Mencukur pada kulit yang kering memberikan hasil
terbaik.
Kulit Anda mungkin memerlukan 2 atau 3 minggu
agar terbiasa dengan sistem pencukuran Philips.
,
,
,
-
-
INDONESIA 19

3 Matikan alat cukur dengan menekan tombol
on/off satu kali.
Cincin lampu biru di sekitar tombol on/off akan
mati.
4 Bersihkan pencukur (lihat bab ‘Pembersihan
dan Perawatan’).
5 Pasang tutup pelindung pada pencukur setiap
kali Anda selesai menggunakannya, agar tidak
rusak.
Memangkas
Untuk merapikan cambang dan kumis.
1 Buka pemangkas dengan menekan sorongan ke
bawah.
Pemangkas dapat dihidupkan saat motor bekerja.
2 Tutup pemangkas (‘klik’).
Pembersihan dan perawatan
Membersihkan secara teratur akan menjamin hasil
cukur yang lebih baik.
Cara yang normal untuk membersihkan alat adalah
dengan mencuci unit pencukur dan tempat rambut
dengan air panas setiap kali Anda selesai bercukur.
Hati-hati dengan air panas. Selalu periksa apakah air
tidak terlalu panas untuk mencegah luka bakar pada
tangan Anda.
,
INDONESIA20

Catatan:Air mungkin merembes keluar dari soket di
bagian bawah alat saat Anda membilasnya. Ini normal
dan tidak berbahaya.
Setiap hari: unit pencukur dan tempat
rambut
1 Matikan alat cukur, cabut steker listrik dari
stopkontak lalu lepaskan steker alat dari
pencukur.
2 Tekan tombol pelepas untuk membuka unit
cukur.
3 Bersihkan unit pencukur dan penampung
rambut dengan membilasnya selama beberapa
saat dengan air panas dari keran.
Pastikan Anda juga membersihkan bagian dalam di
samping bagian luar unit pencukur.
4 Tutup unit pencukur dan kibaskan untuk
membuang air yang tertinggal.
Jangan sekali-kali mengeringkan unit pencukur
dengan handuk atau kertas tisu, karena dapat
merusak kepala pencukur.
5 Buka lagi unit pencukur dan biarkan terbuka
agar kering sama sekali.
Anda juga dapat membersihkan ruang rambut tanpa
air dengan menggunakan sikat yang disertakan.
-
INDONESIA 21

Setiap enam bulan: kepala pencukur
1 Buka unit pencukur, putar kunci berlawanan
arah jarum jam (1) lalu lepaskan bingkainya (2).
2 Bersihkan pemotong dan pelindung dengan
sikat yang disertakan.
Jangan membersihkan lebih dari satu pemotong
dan pelindung sekaligus, karena keduanya
merupakan pasangan. Jika secara tidak sengaja Anda
mencampuradukkan pemotong dan pelindung, akan
dibutuhkan beberapa minggu sebelum pencukuran
dapat kembali optimal.
3 Pasang kembali kepala pencukur ke dalam unit
pencukur. Pasang kembali bingkainya ke dalam
unit pencukur lalu putar kunci searah jarum
jam.
4 Tutup unit pencukur.
Pemangkas
Bersihkan pemangkas setiap kali Anda selesai
menggunakannya.
1 Matikan alat cukur, cabut steker listrik dari
stopkontak lalu lepaskan steker alat dari
pencukur.
2 Bersihkan pemangkas dengan sikat yang
disertakan.
INDONESIA22
