Philips HQ9090/25 User manual


 4
 16
한국어 28
 40
ภาษาไทย 52
 62
繁體中文 73

4

Read this user manual carefully before you use the
appliance and save it for future reference.
- This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
- Children should be supervised to ensure that they
do not play with the appliance.
- Only use the powerplug supplied.
- The powerplug transforms 100-240 volts to a safe
low voltage of less than 24 volts.
- The powerplug contains a transformer. Do not cut
off the powerplug to replace it with another plug,
as this causes a hazardous situation.
- Do not use a damaged powerplug.
- If the powerplug is damaged, always have it
replaced with one of the original type in order to
avoid a hazard.
- Charge and store the shaver at a temperature
between 5°C and 35°C.
- Do not recharge the shaver in a closed pouch.
- Make sure the powerplug does not get wet.
- Always unplug the shaver before cleaning it under
the tap.
- The appliance complies with the internationally
approved IEC safety regulations and can be safely
cleaned under the tap.
Be careful with hot water. Always check if the water
is not too hot, to prevent your hands from getting
burnt.



This Philips appliance complies with all standards
regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this
user manual, the appliance is safe to use based on
scientic evidence available today.


,When you connect the appliance to the mains to
charge it, the power symbol lights up. The power
symbol ashes to indicate that the appliance is
being charged.
- The number of shaving minutes currently available
is shown on the display. This number increases as
charging progresses.
- The light ring ashes during charging.

,The display shows the maximum amount of
shaving minutes.

,When you switch off the shaver, the number of
shaving minutes used appears on the display. The
text ‘minutes used’ is displayed.

The shaving time of a fully charged shaver depends
on your type of beard and your shaving behaviour
and is calculated by the built-in computer.
,The display shows the remaining shaving time in
minutes.
 5


,When the display shows ‘06 minutes left’, the
light ring round the on/off button starts to ash
to indicate that the battery is running low.

,To remind you that the shaver is due to be
cleaned, the tap symbol appears on the display.

,Every two years your shaver will remind you to
replace the shaving heads in order to maintain
optimal shaving results.
- When you switch off the shaver, the shaving unit
symbol appears in the centre of the display and
the word ‘replace’ starts to ash above it.
- The system will automatically reset itself after 7
shaves.

,The appliance has a unique demonstration
program.
During the demonstration the appliance will be
automatically switched on 3 times. Press the on/off
button for 6 seconds until all symbols disappear
from the display. The demonstration will start
automatically.You can interrupt the demonstration by
pressing the on/off button.

Make sure the appliance is switched off before you
start to charge it.
6

Charging takes approx. 1 hour.
You can also shave without charging by connecting
the shaver to the mains.
Do not leave the appliance connected to the mains
for more than 24 hours.

Charge the appliance when the plug symbol and ‘00’
start to ash on the display.
1 Put the appliance plug in the shaver.
2 Put the powerplug in the wall socket.
3 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver
when the battery has been fully charged.

A fully charged shaver has a cordless shaving time of
up to 80 minutes.


1 Press the on/off button once to switch on the
shaver.
,The light ring goes on.
2 Move the shaving heads quickly over your skin,
making both straight and circular movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get accustomed
to the Philips shaving system.
3 Press the on/off button once to switch off the
shaver.
 7

4 Put the protection cap on the shaver every
time you have used it, to prevent damage.

For grooming sideburns and moustache.
1 Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.

Regular cleaning guarantees better shaving
performance.
The easiest and most hygienic way to clean the
appliance is to rinse the shaving unit and the hair
chamber with hot water every time you have used
the appliance.
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.

1 Switch off the shaver, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
8

2 Press the release button (1) and open the
shaving unit (2).
3 Clean the shaving unit and the hair chamber by
rinsing them under a hot tap for some time.
Make sure the inside of the shaving unit and the hair
chamber have been cleaned properly.
4 Rinse the outside of the appliance.
5 Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
6 Open the shaving unit again and leave it open
to let the appliance dry completely.
You can also clean the hair chamber without water
by using the brush supplied.

1 Open the shaving unit, pull it off the shaver and
remove the retaining frame.
 9

2 Clean the cutters and guards with the brush
supplied.
Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
may take several weeks before optimal shaving
performance is restored.
3 Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit.
Make sure that the projections of the shaving heads
t into the recesses.
4 Put the shaving unit back onto the shaver and
close it.

Clean the trimmer every time you have used it.
1 Switch off the shaver, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Clean the trimmer with the brush supplied.
3 Lubricate the trimmer teeth with a drop of
sewing machine oil every six months.
10


1 Put the protection cap on the shaver to
prevent damage.
2 Store the appliance in the luxury pouch or
place the appliance in the stand.

If you are going to store the shaver for a longer
period or if you are going to travel, it is possible to
lock the shaver. The travel lock prevents the shaver
from being switched on by accident.

1 Press the on/off button for 3 seconds.
,The motor is switched off and the key symbol
rotates once. The travel lock has now been
activated.

1 Press the on/off button for 3 seconds.
,The key symbol lights up and ashes a few times.
The motor starts running to indicate that the
shaver has been unlocked.
The shaver is now ready for use again.
 11


Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with HQ9
Philips SmartTouch shaving heads only.
1 Switch off the shaver, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Open the shaving unit and remove the
retaining frame.
You can also remove the shaving unit by pulling it off
the shaver.
3 Remove the shaving heads and place new ones
in the shaving unit. Put the retaining frame back
into the shaving unit.
Make sure that the projections of the shaving heads
t into the recesses.
4 Close the shaving unit.

The following accessories are available:
- HQ9 SmartTouch Shaving Heads.
- HQ110 Philips Shaving Head Cleaning Spray (not
available in China).

- Do not throw away the appliance with the normal
household waste at the end of its life, but hand
it in at an ofcial collection point for recycling. By
doing this, you help to preserve the environment.
- The built-in rechargeable shaver battery contains
substances that may pollute the environment.
12

Always remove the battery before you discard
and hand in the shaver at an ofcial collection
point. Dispose of the battery at an ofcial
collection point for batteries. If you have trouble
removing the battery, you can also take the shaver
to a Philips service centre. The staff of this centre
will remove the battery for you and will dispose of
it in an environmentally safe way.
The built-in rechargeable battery contains substances
that may pollute the environment.

Only remove the battery if it is completely empty.
1 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver.
2 Let the shaver run until it stops, undo the
screws and open the shaver.
3 Remove the battery.
Do not connect the shaver to the mains again after
the battery has been removed.

If you need information or if you have a problem,
please visit the Philips website at www.philips.com
or contact the Philips Customer Care Centre
in your country (you nd its phone number in
the worldwide guarantee leaet). If there is no
Customer Care Centre in your country, go to
your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and
Personal Care BV.
 13


The shaving heads (cutters and guards) are not
covered by the terms of the international guarantee
because they are subject to wear.

1 Reduced shaving performance.
- Cause 1: the shaving heads are dirty. The shaver
has not been rinsed long enough or the water
used was not hot enough.
Clean the shaver thoroughly before you continue
shaving. See chapter ‘Cleaning and maintenance’.
- Cause 2: long hairs are obstructing the shaving
heads.
Clean the cutters and guards with the brush
supplied. See chapter ‘Cleaning and maintenance’,
section ‘Every six months: shaving heads’.
- Cause 3: the shaving heads are damaged or worn.
Replace the shaving heads. See chapter
‘Replacement’.
2 The shaver does not work when the on/off
button is pressed.
- Cause 1: the battery is empty.
Recharge the battery. See chapter ‘Charging’.
- Cause 2: the appliance is not connected to the
mains.
Put the powerplug in the wall socket.
Never wipe the shaving unit with a towel or a
tissue, as this could damage the shaving heads.
3 The shaving unit has come off the shaver.
- Cause: the shaving unit has not been placed
correctly.
14

If the shaving unit becomes detached from the
shaver, the unit can be easily put back on the shaver
again.
 15

16

Bacalah petunjuk pengguna ini secara seksama
sebelum Anda menggunakan alat dan simpan untuk
referensi di kemudian hari.
- Alat ini tidak dimaksudkan untuk digunakan oleh
orang (termasuk anak-anak) dengan cacat sik,
indera atau kecakapan mental yang kurang, atau
kurang pengalaman dan pengetahuan, kecuali jika
mereka diberikan pengawasan atau pengarahan
mengenai penggunaan alat oleh orang yang
bertanggungjawab bagi keselamatan mereka.
- Anak kecil harus diawasi untuk memastikan
mereka tidak bermain-main dengan alat ini.
- Gunakan hanya steker listrik yang disertakan.
- Steker mengubah tegangan 100-240 volt menjadi
tegangan rendah yang aman di bawah 24 volt.
- Steker listrik berisi trafo. Jangan memotong steker
listrik dan menggantinya dengan steker lain, karena
ini dapat membahayakan.
- Jangan gunakan steker listrik yang rusak.
- Jika steker listrik rusak, gantilah selalu dengan salah
satu tipe yang asli agar terhindar dari bahaya.
- Isi baterainya dan simpan pencukur pada suhu
antara 5°C dan 35°C.
- Jangan mengisi ulang pencukur di dalam kantong
tertutup.
- Pastikan steker listrik tidak basah.
- Cabut steker dari pencukur sebelum
membersihkannya di bawah keran.
- Alat cukur ini memenuhi peraturan keselamatan
IEC yang disepakati secara internasional dan dapat
dengan aman dibersihkan di bawah keran air.
Hati-hati dengan air panas. Selalu periksa apakah air
tidak terlalu panas untuk mencegah luka bakar pada
tangan Anda.



Alat Philips ini mematuhi semua standar yang
berkenaan dengan medan elektromagnet (EMF). Jika
ditangani dengan benar dan sesuai dengan petunjuk
pengguna ini, alat tersebut aman digunakan menurut
bukti ilmiah yang kini tersedia.


,Apabila Anda menghubungkan alat ke stopkontak
listrik untuk mengisi dayanya, simbol daya
akan menyala. Simbol daya berkedip untuk
menandakan alat sedang diisi.
- Jumlah menit pencukuran yang tersedia pada saat
itu ditunjukkan pada layar. Jumlah ini bertambah
seiring dengan kelajuan pengisian daya baterai.
- Lingkaran lampu berkedip-kedip sewaktu
pengisian.

,Layar tampilan menunjukkan jumlah menit
pencukuran maksimum.

,Apabila Anda mematikan alat cukur, jumlah menit
pencukuran yang terpakai akan muncul pada
layar. Tulisan ‘minutes used’ ditampilkan.

Waktu pencukuran alat cukur yang terisi penuh
tergantung pada jenis janggut Anda dan cara
Anda mencukur, dan dihitung oleh komputer yang
terpasang dalam alat itu.
 17

,Layar menunjukkan sisa waktu pencukuran dalam
menit.

,Apabila layar menampilkan tulisan ‘06 minutes
left’ [sisa 6 menit], lingkaran lampu di sekitar
tombol on/off mulai berkedip yang menandakan
baterai lemah.

,Untuk mengingatkan Anda bahwa sudah
waktunya alat cukur dibersihkan, akan muncul
simbol keran di layar.

,Setiap dua tahun, alat cukur Anda akan
mengingatkan Anda untuk mengganti kepala
pencukur agar hasil pencukuran tetap optimal.
- Apabila Anda mematikan alat cukur, simbol alat
cukur akan muncul di tengah layar dan tulisan
‘replace’ [ganti] mulai berkedip di atasnya.
- Sistem akan secara otomatis menyetel ulang
sendiri setelah 7 kali pencukuran.

,Alat cukur ini memiliki program peragaan yang
unik.
Selama demo, alat akan secara otomatis dihidupkan
sebanyak 3 kali. Tekan tombol on/off selama 6 detik
sampai semua simbol menghilang dari layar. Demo
18

akan dimulai secara otomatis. Anda dapat menyela
demo dengan menekan tombol on/off.

Pastikan alat telah dimatikan sebelum mengisi
baterainya.
Waktu pengisian daya kurang lebih 1 jam.
Anda juga dapat mencukur tanpa mengisi daya
dengan menghubungkan pencukur ke listrik.
Jangan biarkan alat tersambung ke sumber listrik
lebih dari 24 jam.

Isilah baterai alat ketika simbol steker dan ‘00’ mulai
berkedip di layar.
1 Pasang steker alat pada pencukur.
2 Masukkan steker listrik ke stopkontak.
3 Setelah baterai terisi penuh, cabut steker listrik
dari stopkontak dan lepaskan steker alat dari
pencukur.

Alat cukur yang terisi penuh dapat digunakan tanpa
kabel hingga selama 80 menit.


1 Tekan tombol on/off satu kali untuk
menghidupkan alat cukur.
,Lingkaran lampu menyala.
 19

2 Gerakkan kepala pencukur dengan cepat pada
kulit Anda, lakukan gerakan lurus maupun
memutar.
Mencukur pada kulit yang kering memberikan hasil
terbaik.
Kulit Anda mungkin memerlukan 2 atau 3 minggu
agar terbiasa dengan sistem pencukuran Philips.
3 Tekan tombol on/off sekali untuk mematikan
pencukur.
4 Pasang tutup pelindung pada pencukur setiap
kali Anda selesai menggunakannya, agar tidak
rusak.

Untuk merapikan cambang dan kumis.
1 Buka pemangkas dengan menyorong geseran ke
atas.
Pemangkas dapat dihidupkan saat motor bekerja.

Membersihkan secara teratur akan menjamin hasil
cukur yang lebih baik.
Cara termudah dan paling higienis untuk
membersihkan alat adalah membilas unit pencukur
dan tempat rambut dengan air panas setiap kali
setelah Anda selesai menggunakan alat cukur.
Hati-hati dengan air panas. Selalu periksa apakah air
tidak terlalu panas untuk mencegah luka bakar pada
tangan Anda.
20



1 Matikan pencukur, cabut steker listrik dari
stopkontak di dinding lalu lepaskan steker alat
dari pencukur.
2 Tekan tombol pelepas (1) dan buka unit
pencukur (2).
3 Bersihkan unit pencukur dan penampung
rambut dengan membilasnya selama beberapa
saat dengan air panas dari keran.
Pastikan bahwa bagian dalam unit pencukur dan
tempat rambut telah dibersihkan dengan sempurna.
4 Bilas bagian luar pencukur.
5 Tutup unit pencukur dan kibaskan untuk
membuang air yang tertinggal.
Jangan sekali-kali mengeringkan unit pencukur
dengan handuk atau kertas tisu, karena dapat
merusak kepala pencukur.
6 Buka lagi unit pencukur dan biarkan terbuka
agar kering sama sekali.
Anda juga dapat membersihkan ruang rambut tanpa
air dengan menggunakan sikat yang disertakan.

1 Buka unit pencukur, tarik keluar dari alat cukur
dan lepaskan bingkai penahan.
 21

2 Bersihkan pemotong dan pelindung dengan
sikat yang disertakan.
Jangan membersihkan lebih dari satu pemotong
dan pelindung sekaligus, karena keduanya
merupakan pasangan. Jika secara tidak sengaja Anda
mencampuradukkan pemotong dan pelindung, akan
dibutuhkan beberapa minggu sebelum pencukuran
dapat kembali optimal.
3 Pasang kembali kepala pencukur ke dalam unit
pencukur. Pasang kembali bingkai penahan ke
dalam unit pencukur.
Pastikan bahwa tonjolan kepala pencukur masuk
seluruhnya ke dalam wadahnya.
4 Pasang kembali unit pencukur pada alat cukur
lalu tutup.

Bersihkan pemangkas setiap kali Anda selesai
menggunakannya.
1 Matikan pencukur, cabut steker listrik dari
stopkontak di dinding lalu lepaskan steker alat
dari pencukur.
2 Bersihkan pemangkas dengan sikat yang
disertakan.
3 Lumasi gigi pemangkas dengan satu tetes
minyak mesin jahit setiap enam bulan.
22
