Philips Norelco S7740 User manual

BC
S7740
Tripleheader shaver
4222_002_7341_1_DFU-Luxury_A6_v5.indd 1 24/05/17 16:17

2English
IMPORTANT SAFETY
INSTRUCTIONS
When using an electric product, basic precautions
should always be followed, including the following:
Read all instructions before using this product.
DANGER
To reduce the risk of electric shock:
-Do not reach for a corded product/SmartClean
system that has fallen into water. Unplug
immediately.
-Power plug and the accessories connected to it
are not for immersion or for use in shower.
-Do not use an extension cord with this product.
-Do not place or store a Smartclean system
where it can fall or be pulled into a tub or sink.
Do not place or drop a SmartClean system into
water or other liquid.
-Always unplug this product/SmartClean system
from the electrical outlet immediately after use,
except when the product is (re)charging.
-Unplug and remove power cord from the
product before cleaning.
-The batteries used in this product may present
a re or chemical burn hazard if mistreated. Do
not disassemble, heat above 100°C (212°F) or
incinerate.
WARNING
To reduce the risk of burns, re, electric shock,
or injury to persons:
4222_002_7341_1_DFU-Luxury_A6_v5.indd 2 24/05/17 16:17

3
English
-Close supervision is required when this
product/SmartClean system is used by, on, or
near children, or persons with limited physical,
sensory, or mental capabilities or invalids.
-Use this product/SmartClean system for its
intended household use as described in
this manual. Do not use attachments not
recommended by Philips North America LLC.
-Never operate this product/SmartClean system
if it has a damaged cord or charging plug, if it is
not working properly, if it has been dropped or
damaged, or dropped into water while plugged
in. For assistance call 1-800-243-3050.
-Keep the product/SmartClean system, cord,
charging plug and any attachments away from
heated surfaces.
-Never drop or insert any object into any
opening.
-Do not use the adapter in or near wall outlets
that contain an electric air freshener to prevent
damage to the adapter.
-Do not charge, clean or plug in product/
SmartClean system outdoors or operate where
aerosol (spray) products are being used or
where oxygen is being administered.
-Always check cutters and combs before using
the product. Do not use the product if cutters or
combs are damaged, as injury may occur.
-Always attach plug to product/SmartClean
system rst, then plug into outlet and then put
shaver in SmartClean system. Be certain plug is
inserted rmly into shaver/SmartClean system,
up to mark indicated on plug. To disconnect,
turn SmartClean system o, remove charging
plug from outlet.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 3 24/05/17 16:17

4
English
-Never put the product/SmartClean system in
direct sunlight or store at a temperature above
140°F (60°C).
-Keep the power cord dry at all times. Do not
handle with wet hands.
-To prevent possible damage to the cord, do
not wrap cord around the product/SmartClean
system.
-Do not attempt to open the product to remove
or replace the built-in rechargeable battery.
-Only use the power cord and other accessories
supplied with the product.
SAVE THESE
INSTRUCTIONS
IMPORTANT: The power plug contains a
transformer. Do not cut o the power plug to
replace it with another plug as this will cause a
hazardous condition.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 4 24/05/17 16:17

5
English
Contents
Important safety instructions ___________ 2
I
General description (Fig. 1)______________ 7
Introduction__________________________ 7
The display__________________________ 7
Travel lock _________________________ 9
Charge meter_________________________ 10
Charging_____________________________ 10
Using the product_____________________ 12
Cleaning and maintenance______________ 17
Replacement_________________________ 23
Storage______________________________ 26
Accessories__________________________ 27
Assistance___________________________ 27
Disposal_____________________________ 27
Full Two-Year Warranty________________ 28
45-day money-back guarantee _________ 29
4222_002_7341_1_DFU-Luxury_A6_v5.indd 5 24/05/17 16:17

6
English
12
20
19
5
7
6
10
9
15
14
16
17 18
1
2
3
4
8
11
13
1
4222_002_7341_1_DFU-Luxury_A6_v5.indd 6 24/05/17 16:17

7
English
General description (Fig. 1)
1 SmartClick precision trimmer
2 Shaving unit with hair chamber
3 Handle
4 Socket for small plug
5 3-Level battery indicator
6 Unplug for use symbol
7 Travel lock symbol
8 Replacement shaving head reminder
9 Cleaning reminder
10 SmartClean system cleaning cartridge
11 Cleaning cartridge release button
12 SmartClean system holder
13 SmartClean system cap
14 On/o button
15 Cleaning cartridge replacement symbol
16 Cleaning symbol
17 Ready symbol
18 Charging symbol
19 Power plug
20 Small plug
Travel case (not shown)
Introduction
Congratulations on your purchase and welcome to
Philips Norelco!
To fully benet from the support that Philips
Norelco oers, register your product at
www.norelco.com/register.
The display
Note: Remove any sticker or protective foil from
the display before using the product.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 7 24/05/17 16:17

8
English
Charging
Note: If you press the on/o button during
charging, the 'unplug for use' symbol ashes white
to remind you that you have to disconnect the
product from the wall outlet.
Quick charge: When the battery is empty and
you connect the product to an electrical outlet,
the lights of the battery charge indicator light up
one after the other repeatedly. When the product
contains enough energy for one shave, the bottom
light of the battery charge indicator starts ashing
slowly.
While the product continues to charge, rst the
bottom light of the battery charge indicator ashes
and then lights up continuously. Then the second
light ashes and then lights up continuously, and
so on until the product is fully charged.
Battery fully charged
Note: This product can only be used without a
cord.
When the battery is fully charged, all lights of
the the battery charge indicator light up white
continuously.
Note: When the battery is full, the display switches
o automatically after 30 minutes.
Remaining battery charge
The remaining battery charge is shown by the
lights of the battery charge indicator that light up
continuously.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 8 24/05/17 16:17

9
English
Battery low
When the battery is almost empty, the bottom light
of the battery charge indicator ashes orange.
’Unplug for use’ reminder
The ‘unplug for use’ symbol ashes to remind you
that you have to disconnect the product from the
power outlet before you can switch it on.
Cleaning reminder
Clean the shaver after every shave for optimal
performance (see 'Cleaning and maintenance').
When you switch o the product, the cleaning
reminder ashes to remind you to clean the
product.
Travel lock
You can lock the product when you are going to
travel. The travel lock prevents the product from
being switched on by accident (see 'Travel lock').
4222_002_7341_1_DFU-Luxury_A6_v5.indd 9 24/05/17 16:17

10
English
Replacing shaving heads
For maximum shaving performance, replace the
shaving heads every year. The product is equipped
with a replacement reminder which reminds you
to replace the shaving heads. The shaving unit
symbol lights up and the arrows ash to indicate
that you have to replace the shaving heads.
Note: After replacing the shaving heads, you need
to reset the replacement reminder by pressing the
on/o button for 7 seconds.
Charge meter
Charge Meter monitors amount of remaining
battery power available. Remaining battery
capacity is based on the amount of power
consumed shaving per minute and is dependent
upon your skin and beard type, whether you use
pre-shave lotion, and how often the styler is used.
Initially your shaver may need to go through 2 or
3 full charge/recharge cycles before remaining
battery capacity indicators begin to display your
accurate battery power left.
Charging
-Charging, recharging, or using the product at
temperatures below 40°F (4.5°C) or higher than
95°F (35°C) adversely aects lifespan of the
battery.
-Do not charge the shaver in a pouch or travel
case.
-The power plug transforms 100-240V AC to less
than 24V DC.
Charge the shaver before you use it for the rst
time and when the display indicates that the
battery is almost empty.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 10 24/05/17 16:17

11
English
Charging takes approx. 1 hour. A fully charged
shaver has a shaving time of up to 50 minutes.
Note: You cannot use the product while it is
charging.
Charging with the power cord
1Make sure the product is switched o.
2Put the small plug in the product and
connect the power plug into any 100V to
240V AC outlet. Use only the power cord and
SmartClean system provided.
The display on the shaver will indicate the
product is charging.
3After charging, remove the power plug from
the wall outlet and pull the small plug out
of the product.
Note: An adapter plug may be necessary for
cord usage in some foreign countries. Use
an attachment plug adapter of the proper
conguration for power outlet.
Charging in the SmartClean system
1Put the small plug in the back of the
SmartClean system.
2Put the power plug into any 100V to 240V AC
outlet. Use only the power cord provided.
3Press the top cap to be able to place the
shaver in the holder ('click').
1
2
4222_002_7341_1_DFU-Luxury_A6_v5.indd 11 24/05/17 16:17

12
English
4Hold the shaver upside down above the
holder. Make sure the front of the shaver points
towards the SmartClean system holder.
5Place the shaver in the holder, tilt the shaver
backwards and press down the top cap to
connect the shaver (‘click’).
The battery symbol starts to ash to indicate
that the product is charging. When the battery
is fully charged, the battery symbol lights up
continuously.
6To remove the shaver, press the top cap down,
pull the shaver forward and lift shaver from
holder.
Using the product
Always check the product and all
accessories before using. Do not use the
product or any accessory if it is damaged,
as this may cause injury. Always replace a
damaged part with one of the original type.
This symbol indicates that the product can be used
in the bath or shower.
-Use this product for its intended household use
as described in this manual.
-For hygienic reasons, the product should only
be used by one person.
-Trimming is easier when the skin and hair are dry.
-Make sure the SmartClean System does not get
wet or near water.
Note: This product can only be used without
a cord.
1
23
4222_002_7341_1_DFU-Luxury_A6_v5.indd 12 24/05/17 16:17

13
English
Put it to the test
-21 Day Trial and Conversion Process. It is a fact
that your skin and beard need time to adjust to
a new grooming system.
-Use your new shaver exclusively for 3 weeks to
fully enjoy the closeness of a Philips Norelco
shave.
-At rst you may not get as close a shave as you
expect, or your face may even become slightly
irritated. This is normal since your beard and
skin will need time to adjust. Invest 3 weeks and
you'll soon experience the full joy of your new
shaver.
-Stick with it! If you alternate shaving methods
during the adjustment period, it may make it
more dicult to adapt to the Philips Norelco
shaving system.
-If you are still not convinced after 21 days,
Philips Norelco will refund you the full purchase
price as long as the request is received within
45 days of purchase.
Switching the appliance on and o
1To switch the product on or o, press the on/o
button once.
Shaving
For best results on skin comfort, pre-trim your
beard if you have not shaved for 3 days or longer.
Dry shaving
1Switch the product on.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 13 24/05/17 16:17

14
English
2Move the shaving heads over your skin in
circular movements to catch all hairs growing in
dierent directions. Exert gentle pressure for a
close, comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
3Switch o and clean the product after each use.
The display lights up for a few seconds to show
the remaining battery status.
Wet shaving
For a more comfortable shave, you can also use
this product on a wet face with shaving foam or
shaving gel.
1Apply some water to your skin.
2Apply shaving foam or shaving gel to your skin.
3Rinse the shaving unit under the tap to ensure
that the shaving unit glides smoothly over your
skin.
4Switch the product on.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 14 24/05/17 16:17

15
English
5Move the shaving heads over your skin in
circular movements to catch all hairs growing in
dierent directions. Exert gentle pressure for a
close, comfortable shave.
Note: Do not press too hard, this can cause skin
irritation.
Note: Rinse the shaving unit regularly to ensure
that it continues to glide smoothly over your skin.
6Dry your face.
7Switch o and clean the product after each use.
Note: Make sure you rinse all foam or shaving gel
o the product.
Using the click-on attachments
Removing or attaching the click-on
attachments
1Make sure the product is switched o.
2Pull the attachment straight o the product.
Note: Do not twist the attachment while you pull it
o the product.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 15 24/05/17 16:17

16
English
3Insert the lug of the attachment into the slot in
the top of the product. Then press down the
attachment to attach it to the product (‘click’).
Using the precision trimmer
You can use the trimmer to groom your beard,
sideburns and moustache.
1Attach the trimmer to the product ('click').
2Switch on the product.
3Hold the trimmer perpendicular to the skin and
move the product downwards while you exert
gentle pressure.
4Clean the trimmer after use.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 16 24/05/17 16:17

17
English
Travel lock
Activating the travel lock
1Press the on/o button for 3 seconds to enter
the travel lock mode.
While you activate the travel lock, the travel
lock symbol lights up continuously. When the
travel lock is activated, the travel lock symbol
ashes.
Deactivating the travel lock
1Press the on/o button for 3 seconds.
The travel lock symbol ashes and then lights
up continuously. The product is now ready for
use again.
Note: The shaver unlocks automatically when
charging in the SmartClean system or when
connected to an electrical outlet.
Cleaning and maintenance
-Regular cleaning guarantees better shaving
results.
-The SmartClean system and shaver may be
wiped clean using a damp cloth.
-Never clean, remove or replace shaving unit
while motor is on.
-Do not apply pressure to shaving head combs.
-Do not touch shaving heads with hard objects
as this may dent or damage precision-made
slotted combs.
3 sec.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 17 24/05/17 16:17

18
English
-Do not use abrasives, scourers or aggressive
liquids such as gasoline or acetone to clean the
shaver.
-Do not place or clean any parts of the
SmartClean system in a dishwasher.
Cleaning the shaver under the tap
Clean the shaver after every shave for optimal
performance.
Always check if the water is too hot,
to prevent burning your hands.
Never dry the shaving unit with a towel
or tissue, as this may damage the shaving
heads.
While rinsing shaving heads, water may
drip out of the base of shaver. This is a
normal occurrence.
1Switch the product on.
2Rinse the shaving unit under a warm tap.
3Switch o the product. Pull the shaving head
holder o the bottom part of the shaving unit.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 18 24/05/17 16:17

19
English
4Rinse the hair chamber under the tap.
5Rinse the shaving head holder under a warm
tap.
6Carefully shake o excess water and let the
shaving head holder air dry.
7Attach the shaving head holder to the bottom
part of the shaving unit (‘click’).
Cleaning the shaver in the SmartClean system
Keep cleaning cartridge(s) out of reach
of children. Do not take internally. Avoid
contact with eyes. In case of eye contact,
thoroughly ush with cold water. If
irritation persists, get medical attention.
-Only use this shaver, SmartClean System and
cleaning cartridge (JC302) provided to charge
or clean shaver.
-For optimal cleaning results, replace the
cleaning cartridge every 3 months.
-Other Philips Norelco shavers may not work
with this SmartClean System.
-To avoid evaporation, do not expose cleaning
solution to direct sunlight.
-The SmartClean system thoroughly cleans but
does not disinfect your shaver, therefore, do not
share shaver with others.
4222_002_7341_1_DFU-Luxury_A6_v5.indd 19 24/05/17 16:17

20
English
-Place the SmartClean system on a at, stable
and uid-resistant surface to avoid any leakage.
Be careful not to tip or move the SmartClean
System when it is ready for use.
-Use this product for its intended household use
as described in this manual.
Preparing the SmartClean system for use
Caution: Do not tilt the SmartClean system
to prevent leakage.
Note: Hold the SmartClean system while you
prepare it for use.
1Put the small plug in the back of the
SmartClean system.
2Put the power plug in the wall outlet.
3While holding the SmartClean system with
one hand, press the button on the side of the
SmartClean system and lift the top part of the
SmartClean system.
4Pull the seal o the cleaning cartridge.
5Place the cleaning cartridge in the SmartClean
system.
1
2
4222_002_7341_1_DFU-Luxury_A6_v5.indd 20 24/05/17 16:17
