Philips Norelco T700 User manual

SP
T700
Rechargeable
Cordless SP
Beard and
Moustache
Trimmer
with
ACU•CONTROL
SYSTEM

IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance,basic safety precautions
should always be followed,including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for aTrimmer that has fallen into water.
Unplug immediately.
2. Do not use while bathing or in a shower.
3. Do not place or storeTrimmer where it can fall or be
pulled into a tub or sink.Do not place in or drop into
water or other liquid.
4. Always unplug this Trimmer from the electrical outlet
immediately after using, except whenTrimmer is
(re)charging.
5. UnplugTrimmer before cleaning.
6. When discardingTrimmer, unplug Trimmer to remove
rechargeable battery.See Battery Removal instruction
sheet.
WARNING
To reduce the risk of burns, fire or injury to persons:
1. Close supervision is necessary when this appliance is
used by,on, or near children or invalids.
2. Use thisTrimmer for its intended household use as
described in this manual.Do not use attachments not
recommended by Philips Electronics North America
Corporation.
3. Never operate thisTrimmer if it has a damaged cord or
plug,if it is not working properly,if it has been dropped,
damaged,or dropped into water.Return the Trimmer
to an Authorized Norelco Service Location for
examination and repair.

4. Keep the Trimmer and Cord away from heated
surfaces.
5. Never drop or insert any object into any opening.
6. Do not charge or plug inTrimmer outdoors or where
aerosol (spray) products are being used or where
oxygen is being administered.
7. Do not use thisTrimmer with a damaged or broken
cutter, as facial injury may occur.
8. Always attach plug to Trimmer first, then into outlet.
To disconnect, turn ON/OFF switch to “OFF”
position (switch is down), then remove plug from
outlet.
9. To prevent possible damage to the cord, do not wrap
cord around the Trimmer.
10. Never put Trimmer in direct sunlight or store in a
pouch at a temperature above 140˚F.
11. ThisTrimmer is for use on human facial hair only.
Do not use thisTrimmer for any other purpose.
SAVETHESE
INSTRUCTIONS
IMPORTANT: YOUR TRIMMER CONTAINSA
NICKEL-CADMIUM RECHARGEABLE BATTERY.
See Battery Removal instruction sheet.

60-DAY MONEY-BACK
GUARANTEE
If you are not fully satisfied with your Norelco Beard and Moustache Trimmer,
send the product back and we’ll refund you the full purchase price.
The Trimmer must be shipped prepaid by insured mail, insurance
prepaid, and have the sales receipt, indicating purchase price and the
date of purchase,enclosed.The Trimmer must be postmarked no later
than 60 days after the date of purchase.Norelco reserves the right to
verify the purchase price of the Trimmer and limit refunds not to
exceed suggested retail price.
Send dated sales receipt, your complete name and address as indicated below,
and the Trimmer,prepaid to:
Norelco Consumer Products Company
A Division of Philips Electronics North America Corporation
P.O.Box 1116
Skokie, IL 60076
Please allow 4-6 weeks for delivery of check. (Please Print)
Name_________________________________________________________
Address________________________________________________________
City___________________________________________________________
State_____Zip__________________________________________________
Telephone No. (____)____________________________________________
REASON FOR RETURNING:______________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
AREA CODE

TABLE OF CONTENTS
ENGLISH INSTRUCTIONS
FEATURES 2 – 3
TO CHARGE / RECHARGE 4 – 5
CORDLESSTRIMMING 5
PUT IT TOTHETEST 5 – 6
ACU•CONTROL SYSTEM 6
TRIMMING 6 – 7
TRIMMING WITHACU•CONTROL 7 – 8
GUIDE COMB
TRIMMING FOR “STUBBLE” LOOK 8
TRIMMING WITHOUT 9
ACU•CONTROL GUIDE COMB
REPLACING GUIDE COMB 9 – 10
ATTACHMENTTOTRIMMER
CLEANING 10 –11
REPLACING THE CUTTING UNIT 11 – 12
ASSISTANCE 12
BATTERYREMOVAL 12
SPANISHINSTRUCTIONS
WARRANTY Back Cover

A. Unique ACU•CONTROL System with
Removable Guide Comb Attachment
B. Selected Hair Length Setting Window
C. Unique,Patented Zoom Ring
with 9 Pre-select Settings:
.06, .1,.16, .22, .3, .38,.48,.6, .72 in./
1.5, 2.5,4, 5.5, 7.5, 9.5,12, 15,18mm
D. 3-Dimensional Rounded Chromium
Steel Cutter Blades
E. ON/OFF Switch
F. Charging Indicator Light on Adaptor
G. Cleaning Brush
H. FullTwo-YearWarranty
I. 60-Day Money-Back Guarantee
FEATURES

TO CHARGE / RECHARGE
◗(Re)charging requires 10 hours.
◗Use only the cord provided.
◗Battery performance is best if you recharge
only when the battery is (almost) completely
empty.
◗Charging or recharging at temperatures below
40°F or higher than 95°F adversely affects
lifetime of battery.
◗Continuously rechargingTrimmer will reduce
life of battery.
C1Be certainTrimmer is OFF.
C2Connect cord toTrimmer. Plug into any
100V to 240VAC outlet. Use only the
cord provided.
◗An adaptor plug may be necessary for cord
usage in some foreign countries. Your new
Trimmer will automatically convert internally
to work on 100V to 240VAC systems.
Do not chargeTrimmer in a pouch.
C3Green Charging Indicator Light on the
adaptor will go on to indicate theTrimmer
is charging.It will take approximately
10 hours to fully charge the battery.
4Disconnect the cord and unplug from
electrical outlet.

Optimize the working life of the battery
◗AfterTrimmer has been charged for the first
time,do not rechargeTrimmer between
trimming sessions. Continue using it until the
battery is completely empty.
◗Discharge the battery completely twice a year
by letting the motor run until it stops.
◗Do not charge for more than 24 hours.
◗Do not keep cord permanently plugged in.
◗If Trimmer hasn’t been used for a long period
of time,Trimmer must be recharged for
10 hours.
CORDLESSTRIMMING
1Charge according to directions. Unplug
Trimmer from outlet.
2Slide ON/OFF switch ON to begin
trimming.
3If the battery is empty and you want to
trim your beard,charge theTrimmer for at
least 1.5 hours and you will have enough
power for one use.
PUT ITTOTHETEST
Like many new products,your NorelcoTrimmer
may take a little getting used to. If you are using
an electricTrimmer for the first time, or if you’ve
been using a different brand, take the time to

acquaint yourself with your newTrimmer.
YourTrimmer features the unique
ACU•CONTROL SYSTEM combined with
an adjustable Zoom Ring to make trimming
facial hairs goof proof.
Throw your scissors away and put your new
Trimmer to the test. We guarantee precise,
professional results or Norelco will refund you
the full purchase price, guaranteed!
ACU•CONTROL SYSTEM
The unique NorelcoACU•CONTROL SYSTEM
puts you in complete control while trimming your
facial hairs with no prior experience needed.
The flexing Guide Comb adjusts automatically to
hug the contours of your face for a trim that is
both even and accurate. And,it’s easy to
maneuver over those hard-to-reach areas such as
the throat and chin. The patented Zoom Ring
Hair Length Selector allows you to choose among
9 preset hair lengths and locks into position so
you can control the exact hair length you desire
or vary the length of your facial hair. The Norelco
ACU•CONTROL SYSTEM with Patented Zoom
Ring Hair Length Selector for professional, goof-
proof results every time or your money back.
TRIMMING
◗Always comb the beard and/or moustache with
a fine comb before you start trimming.

◗If you are trimming for the first time,be careful.
Do not move theTrimmer too fast.
Make smooth and gentle movements.
Trimming withACU•CONTROL
Guide CombAttachment
◗Guide CombAttachment must be onTrimmer
in order to use Zoom Ring.
C1Turn the Zoom Ring to the desired
trimming length setting (see table). The
setting will appear in the window below
the Zoom Ring.
◗If you are trimming for the first time,start by
usingthe maximum trimming length setting #9
to prevent accidentally trimming hairs too short.
As you become familiar with the settings,adjust
Zoom Ring to desired trimming length. Zoom
Ring will“click” into position at each setting.
2Switch theTrimmer ON.
C3To trim in the most effective way,move
theTrimmer against the direction of hair
growth. Make sure the surface of the
Guide Comb always stays in contact with
the skin.
NOTE: Since all hairs do not grow in the same
direction,you may want to try different trimming
positions (i.e.,upwards,downwards, or across).
Practice is best for optimum results.

C4If a lot of hair has accumulated in the
Guide Comb,remove the Comb
Attachment and blow and/or shake the
hair out of the comb. The selected
trimming length setting will not change
when you do this.
Trimming Length SettingsTable
Trimming For“Stubble” Look
C◗Be certain Guide Comb is onTrimmer and
use setting #1 to result in a“stubble” look.
#1 “Stubble” Length or Closely Cropped .06 in./1.5 mm
#2 Short .1 in./2.5 mm
#3 .16 in./4 mm
#4 .22 in./5.5 mm
#5 Medium .3 in./7.5 mm
#6 .38 in./9.5 mm
#7 .48 in./12 mm
#8 .6 in./15 mm
#9 Long .72 in./18 mm

TrimmingWithout Guide Comb
Attachment
Remove Guide Comb Attachment if you are:
◗ Defining hair lines
◗ Trimming nape of neck
◗ Removing single, unwanted hairs
1Be certainTrimmer is in the OFF position.
C2Remove the Guide CombAttachment by
pulling it off theTrimmer.
Never pull off the Guide Comb Attachment by
grasping the flexible top portion. Always pull off
by the bottom part of attachment.
3Switch theTrimmer on.
C4Make well-controlled movements. Touch
the hair lightly with theTrimmer.
Replacing Guide CombAttachment
ToTrimmer
1Be certainTrimmer is in OFF position.
2Replace Guide CombAttachment until it
“clicks” into position. The Guide Comb
Attachment can be placed onTrimmer
only one way. If it does not fit properly,
reverse it.

NOTE: The Zoom Ring can be on any setting
when removing or replacing Attachment.
CLEANING
◗Always switchTrimmer OFF before cleaning.
◗ Do not use abrasives,scourers or liquids such
as alcohol,benzene,bleach or acetone to
clean theTrimmer.
◗ Never clean,remove or replace Guide Comb
Attachment with motor ON.
◗ Do not apply pressure to cutters.
◗ Do not touch cutters with hard objects as
this may damage them.
◗ Do not use while bathing,showering or
immerse theTrimmer in water or other
liquids as damage toTrimmer may occur.
During Use:
◗ If cut hairs have accumulated in the Guide
Comb area,pull Guide CombAttachment off
Trimmer and remove hairs by shaking and/or
blowing.
OnceAWeek:
1Make sure theTrimmer is switched OFF
and disconnected from the electrical
outlet.
2Remove the Guide CombAttachment.

C3Open the cutting unit.
C4Clean the cutting unit and the inside of the
Trimmer with the brush supplied.
C5Close the cutting unit by pushing it back
into place on theTrimmer until you hear a
click.
REPLACINGTHE CUTTING UNIT
If your cutters become damaged or worn,
do not continue using theTrimmer.
Replace cutters immediately.
1Open the cutting unit.
C2Remove the old cutting unit by pulling it
upwards.

C3Place the two notches of the new cutting
unit into the guiding slots.
4Push the cutting unit back onto the
Trimmer until you hear a click.
ASSISTANCE
For assistance or the Authorized Norelco Service
Location nearest you,call toll free:
1-800-243-3050
or visit our website: www.norelco.com
Authorized Norelco Service Location information
is available 24 hours a day, 7 days a week.
BATTERY REMOVAL
◗ This NorelcoTrimmer contains rechargeable
Nickel-Cadmium batteries,which must be
disposed of properly.
◗ Batteries should only be removed when
Trimmer is to be discarded.
◗ Refer to Battery Removal instruction sheet
for directions on removing the rechargeable
batteries.

FULL TWO-YEAR WARRANTY
Philips Electronics North America Corporation warrants each new Norelco product, Model
T-700 (except cutters), against defects in materials orworkmanshipfor aperiodof twoyears
from the date of purchase, and agrees to repair or replace any defective product without
charge.
IMPORTANT:This warranty does not cover damage resulting from accident, misuse or
abuse, lack of reasonable care, the affixing of any attachment not provided with the product
or loss of parts or subjecting the product to any but the specific voltage.* Use of
unauthorizedreplacement parts will void this warranty.
PHILIPS ELECTRONICS NORTH AMERICA CORPORATION WILL NOT PAY FOR
WARRANTY SERVICE PERFORMED BY A NON-AUTHORIZED REPAIR SERVICE AND
WILL NOT REIMBURSE THE CONSUMER FOR DAMAGE RESULTING FROM WARRANTY
SERVICE PERFORMED BY A NON-AUTHORIZED REPAIR SERVICE.
NO RESPONSIBILITY IS ASSUMED FOR ANY SPECIAL, INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
In order to obtain warranty service, simply take or ship the product postage prepaid to the
nearest Authorized Norelco Service Location. It is suggested that for your protection you
return shipments of product by insured mail, insurance prepaid. Damage occurring during
shipment is not covered by this warranty. NOTE: No other warranty, written or oral, is
authorized by Philips Electronics North America Corporation. This warranty gives you
specific legal rights, and you may also have other rights which vary from state to state.
Some states do not allow the exclusionor limitation of incidental orconsequentialdamages,
so the above exclusion and limitations may not apply to you.
*Read enclosed instructions carefully.
Manufactured for: Norelco Consumer Products Company
A Division of Philips Electronics North America Corporation
1010 Washington Blvd., Stamford, CT 06912-0015
MADE IN AUSTRIA.
This symbol on the product’s nameplate means it is
listed by Underwriters’ Laboratories, Inc.
Norelco is a Registered Trademark of Philips Electronics
North America Corporation.
ACU•CONTROL and Zoom Ring are Trademarks of Philips Electronics North America Corporation.
PHILIPS and Philips Shield are Registered Trademarks of Koninklijke
Philips Electronics N.V.
© 2001 Philips Electronics North America Corporation. All Rights Reserved.
4203 000 49011

INSTRUCCIONES
DE SEGURIDAD
IMPORTANTES
Siempre que utilice un aparato eléctrico usted debe
respetar ciertas precauciones básicas,incluyendo las
indicadas a continuación:
Lea todas las instrucciones antes de utilizar este
aparato.
PELIGRO
Para reducir el riesgo de descarga eléctrica:
1. No intente recuperar una afeitadora que se haya caído
al agua. Desenchúfela inmediatamente.
2. No la utilice mientras se baña o se ducha.
3. No coloque ni guarde la máquina en un sitio donde
pueda caerse o ser empujada a una bañera o un lavabo.
No la coloque ni deje que se caiga al agua u otro líquido.
4. Siempre desenchufe la máquina inmediatamente después
de utilizarla, excepto cuando se está recargando.
5. Desenchufe la máquina antes de limpiarla.
6. Cuando deseche la máquina, desenchúfela para quitarle
la batería recargable. Consulte la hoja de instrucciones
sobre retiro de la batería.
ADVERTENCIA
Para reducir el riesgo de quemaduras,incendio o
lesiones a las personas:
1. Es necesario un estrecho control cuando esta máquina es
utilizada por niños o personas discapacitadas,o cerca ellos.
2. Utilice esta máquina para el uso doméstico previsto, tal
como se describe en este manual.No utilice accesorios
no recomendados por Philips Electronics North America
Corporation.

3. No utilice nunca esta afeitadora si el cordón o el enchufe
están dañados,si no funciona correctamente,si ha
sufrido una caída o se ha dañado o si se ha caído al agua.
Lleve la afeitadora a un centro de servicio autorizado de
Norelco para que sea examinada y reparada.
4. Mantenga la máquina y el cordón alejados de las
superficies calientes.
5. Nunca deje caer ni inserte objeto alguno en ninguna
de las aberturas.
6. No cargue ni enchufe la máquina mientras está al aire
libre,ni donde se estén utilizando productos en aerosol
(pulverizadores) o donde se esté administrando oxígeno.
7. No utilice esta máquina con una cuchilla dañada o rota
ya que puede provocar lesiones faciales.
8. Ponga siempre el cordón en el enchufe de la máquina
primero y luego en la toma de corriente.Para
desconectarla,deslice el botón de encendido y apagado a
la posición de apagado OFF (el botón estará hacia abajo),
luego desconecte el enchufe del tomacorriente.
9. Para evitar posibles daños al cordón, no lo enrolle
alrededor de la máquina.
10. Nunca exponga la máquina a la luz directa del sol ni la
guarde en una bolsa a temperaturas superiores a 140ºF
(60°C).
11. Esta máquina es para pelo facial humano únicamente.
No utilice esta afeitadora para ningún otro propósito.
GUARDE ESTAS
INSTRUCCIONES
IMPORTANTE: SUAFEITADORA CONTIENE UNA
BATERÍA DE NICKEL CADMIO RECARGABLE.
Consulte las instrucciones de retiro de las baterías.

GARANTÍA DE DEVOLUCIÓN DEL
IMPORTE DE 60 DÍAS
Si usted no está plenamente satisfecho con la Afeitadora para Barba y Bigote de
Norelco,devuelva el producto y le reembolsaremos el precio total de compra.
La máquina debe enviarse por correo franqueado y asegurado, con el
seguro pagado, el recibo de compra incluido, con indicación del precio y
la fecha de compra. El matasellos no debe ser posterior a 60 días de la
fecha de compra. Norelco se reserva el derecho de verificar el precio
de compra del producto y limitar los reembolsos de manera que no
excedan el precio de venta sugerido.
Envíe el recibo de compra fechado, su nombre completo y dirección como se
indica más abajo, y el producto franqueado a:
Norelco Consumer Products Company
A Division of Philips Electronics North America Corporation
P.O.Box 1116
Skokie, IL 60076
El envío del cheque se demora de 4 a 6 semanas.
(Escriba sus datos en letra de imprenta).
Nombre ______________________________________________________
Dirección _____________________________________________________
Ciudad _______________________________________________________
Estado________________________ Código postal ___________________
Número de teléfono (_______) __________________________________
MOTIVO DE LA DEVOLUCIÓN: __________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
_____________________________________________________________
CÓDIGO DEL ÁREA
