Philips Philishave HQ 6735 User manual

HQ6735
3
ENGLISH 4
BAHASA MELAYU 18
BAHASA INDONESIA 32
TI”NGVI◊T 47
61
74
86

Introduction
The shaver comes with two different kinds of
NIVEA FOR MEN cartridges: Extra Fresh Shaving
Gel for a fresh sensation during and after shaving
and Moisturising Shaving Lotion for sensitive skin.
This gives you the opportunity to try them out
and discover which one suits your skin type best.
Important
Read these instructions for use carefully before
using the appliance and save them for future
reference.
◗Only use the HQ600 powerplug and the
charging stand supplied to charge the shaver.
◗Only the powerplug supplied guarantees safety.
◗The HQ600 powerplug transforms 100-240
volts to a safe low voltage of less than 24 volts.
◗The powerplug contains a transformer. Do
not cut off the powerplug to replace it with
another plug, as this will cause a hazardous
situation.
C◗Never immerse the charging stand in water
nor rinse it under the tap when the charging
stand is plugged in.
C◗The shaver runs at a safe low voltage of less
than 24 volts. It is watertight and can be
cleaned under the tap. Rinse the shaver with
hot water.
Be careful with hot water. Always check if the
water isn't too hot, to prevent your hands from
burning.
ENGLISH4

◗Do not leave the charging stand with the
shaver in it plugged into the mains
continuously.
◗Check if the gel and lotion supplied with the
appliance contain ingredients (see back of
cartridge) to which you are allergic before
you start using the appliance. Do not use the
gel and/or lotion if you are allergic to one or
more ingredients!
◗If the mains cord of this appliance is damaged,
it must always be replaced by Philips or a
service centre authorised by Philips in order
to avoid hazardous situations.
Charging
Charge indications
C◗As soon as you start charging the empty
shaver, the green pilot light goes on.
◗The red pilot light blinks when the batteries
are almost empty.
◗When the batteries are almost empty, the red
pilot light blinks a few times after the shaver
has been switched off.
Charging the appliance
Recharge, store and use the appliance at a
temperature between 5cC and 35cC.
ENGLISH 5

1Insert the small plug into the charging stand
and put the powerplug in the wall socket.
C2Place the shaver in the charging stand.
C3Press until you hear a click.
The shaver automatically switches off when
placed in the charging stand.
4When charging for the first time or after a
long period of disuse: leave the shaver to
charge continuously for 24 hours.
Charging normally takes approx. 8 hour.
A fully charged shaver has a cordless shaving time
of up to approx. 40 minutes.
Inserting the cartridge
Cartridges with moisturising NIVEA FOR MEN
shaving gel/lotion are available in boxes containing
five cartridges and one small plastic pump.
Do not throw the pump away when you replace
an empty cartridge.You will need it for all five
cartridges.
One Philishave NIVEA FOR MEN Cool Skin
cartridge contains enough gel/lotion for approx.
10 shaves.
Remove the shaving gel/lotion cartridge from the
appliance when you are not going to use the
shaver for more than one week.
ENGLISH6

ENGLISH 7
Use only Philishave NIVEA FOR MEN Cool Skin
(HQ160 or HQ161) cartridges.
For hygienic reasons, we advise you to insert a
new pump when you start using a new set of five
cartridges.
When you have run out of shaving gel/lotion
cartridges and you do not know where to buy
them, contact the Customer Care Centre in your
country (see 'Guarantee & service').
Inserting the cartridge
C1Ta ke one cartridge from the box.Take the
pump (supplied in the same box) out of its
bag and push it into the cartridge until it
locks into position with a click.
C2Move the release slide downwards and
open the cover of the cartridge
compartment.
C3Slide the cartridge with the pump into the
shaver. It only fits properly if the white side
of the pump is pointing upwards.
12

4Close the cover (you will hear a click).
5Press the yellow pump button a few times
until the NIVEA FOR MEN shaving
emulsion appears.The shaver is now ready
for use.
BThe NIVEA FOR MEN shaving gel/lotion in the
cartridges will keep for 32 months when stored at
temperatures between 0cC and +40cC.
Using the appliance
Shaving
Switching on the shaver.
1Switch the shaver on by pressing the on/off
button once.
C2Press the yellow pump button to apply
NIVEA FOR MEN shaving gel/lotion to
your skin.
3Move the shaving heads over your skin,
making both straight and circular
movements.
4While shaving, press the pump button
frequently to apply more NIVEA FOR
MEN shaving gel/lotion so that the shaver
keeps gliding smoothly over your face.
ENGLISH8

Do not press the shaver too hard against your
skin while shaving. If you prefer, you can wet your
face before shaving.
◗When you have run out of shaving emulsion,
you can also use the shaver without it on a
dry face.
The shaver will not perform optimally when used
without shaving gel/lotion.
◗Your skin may need 2-3 weeks to get
accustomed to the Philishave system.
Switching of the shaver
1Switch the shaver off.
C2Put the protection cap on the shaver every
time you have used it, to prevent damage.
Remove the cartridge and clean the shaver if you
are not going to use the appliance for more than
one week. Rinse the shaver after each shave.
Trimming
The shaver has a separate trimmer for grooming
sideburns and moustache.
1Switch the shaver off.
Clean the shaver before you attach the trimmer.
ENGLISH 9

C2Press the release button to open the
shaving unit and pull the shaving unit off
the shaver.
C3Tilt the trimmer slightly backwards and fit
it onto the shaver.
4Remove the trimmer by pressing the
release button again and pulling the
trimmer off the shaver.
Cleaning and maintenance
Shaving unit
Rinse the shaving unit and the hair chamber with
hot water (60cC - 80cC) after every use.
1Switch the shaver off.
C2Press the release button to open the
shaving unit.
C3Clean the shaving unit and the hair
chamber by rinsing them under a hot tap
for some time.
Never dry the shaving unit with a towel or tissue
as this may damage the shaving heads.
ENGLISH10
2
1
2

C4Rinse the outside of the shaver.
Make sure the inside of the shaving unit and the
hair chamber have been cleaned properly. Close
the shaving unit and shake off excess water.
Charging stand
1Unplug the charging stand.
2Clean the charging stand with a moist
cloth.
Trimmer
1Clean the outside of the trimmer with the
brush supplied after every use.
C2Open the trimmer to clean it on the
inside.
C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
Replacement
Replace the shaving heads every two years for
optimal shaving results.
1Switch the shaver off.
ENGLISH 11
OIL

C2Press the release button to open the
shaving unit.
C3Turn the wheel anticlockwise and remove
the retaining frame.
C4Remove the shaving heads and place the
new ones in the shaving unit.
C5Put the retaining frame back onto the
shaving unit, press the wheel and turn it
clockwise.
Replace damaged or worn shaving heads with
Philishave HQ167 Cool Skin shaving heads only.
Storage
C◗After cleaning, the wet shaver can be placed in
the charging stand.
◗The appliance and the trimmer can be stored
in the pouch or cassette supplied.Whether
you have a pouch or a cassette depends on
your type of shaver.
ENGLISH12
1
1
2
1
1

Environment
Disposal of batteries
The built-in rechargeable batteries contain
substances that may pollute the environment.
Remove the batteries when you discard the
shaver. Do not throw the batteries away with the
normal household waste, but hand them in at an
official collection point.You can also take the
appliance to a Philips service centre, which will
remove them for you and will dispose of them in
an environmentally safe way.
Only remove the batteries if they are completely
empty.
C1Let the shaver run until it stops, undo the
screws and open the shaver.
2Remove the batteries.
Do not put the shaver back into the charging
stand after the batteries have been removed.
Accessories
The following accessories are available:
HQ167 Philishave Cool Skin shaving heads.
HQ160 NIVEA FOR MEN Cool Skin moisturising
shaving emulsion.
HQ161 NIVEA FOR MEN Cool Skin moisturising
fresh shaving gel.
ENGLISH 13

HQ8000 powerplug.
HQ100 Philishave Action Clean
(shaving head cleaner).
HQ101 Philishave Action Clean refill
(shaving head cleaning liquid).
HQ110 Philishave shaving head cleaner
(shaving head cleaning spray).
Guarantee & service
If you need information or if you have a problem,
please visit the Philips Web site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet). If there is no Customer Care Centre in
your country, turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
Troubleshooting
1The shaving heads do not move smoothly
over the skin:
BCause: not enough shaving emulsion has been
applied.
◗Press the pump button a few times until a
sufficient amount of NIVEA FOR MEN shaving
emulsion has been released to allow the
shaving heads to move smoothly over your
face again.
ENGLISH14

2Reduced shaving performance:
BCause 1: the shaving heads are dirty.The shaver
has not been cleaned immediately after use
and/or has not been rinsed long enough and/or
the water used to rinse the shaver was not hot
enough.
◗Clean the shaver thoroughly before you
continue shaving (see 'Cleaning').
BCause 2: long hairs are obstructing the shaving
heads.
C◗Remove the retaining frame.
C◗Clean the cutters and guards.
Do not clean more than one cutter and guard at
a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
could take several weeks before optimal shaving
performance is restored.
◗Remove the hairs.
◗Put the shaving heads back into the shaving
unit. Put the retaining frame back onto the
shaving unit, press the wheel and turn it
clockwise.
BCause 3: the shaving heads are damaged or worn.
◗Remove the retaining frame.
◗Remove the old shaving heads from the
shaving unit and replace them with new ones.
ENGLISH 15
1
1
2

Damaged or worn shaving heads (cutters and
guards) must only be replaced with the original
Philishave HQ167 Cool Skin shaving heads.
◗Put the retaining frame back onto the shaving
unit, press the wheel and turn it clockwise.
3The shaver does not work when the on/off
button is pressed:
BCause: the batteries are empty
◗Recharge the batteries.
4The cover of the cartridge compartment
cannot be closed
BCause 1: the cartridge has not been inserted
correctly.
◗Insert the cartridge correctly. It only fits
properly into the shaver if the white side of
the pump is pointing upwards.
BCause 2: the cartridge has not been pushed far
enough into the shaver.
◗Press the cartridge until it is properly seated.
5The NIVEA FOR MEN shaving emulsion
has changed colour or has turned watery.
BCause: the NIVEA FOR MEN shaving emulsion
has not been stored at the right temperature.
ENGLISH16

◗Insert a new cartridge.
6Skin irritation occurs:
BCause 1: your skin has not yet become
accustomed to this shaving system.
◗Allow 2-3 weeks for your skin to get
accustomed to this shaving system.
BCause 2: the shaving emulsion irritates your skin.
◗Tr y the other type of shaving emulsion.
◗Wet your face before shaving with the shaving
emulsion.
If the irritation does not disappear within 24
hours, we advise you to stop using the shaving
emulsion and to contact your doctor.
7In case of other problems:
◗See 'Guarantee & service'
ENGLISH 17

Pengenalan
Alat pencukur dibekal dengan dua jenis kartrij
NIVEA FOR MEN yang berlainan:suatu gel
mencukur yang segar untuk deria rasa yang segar
semasa dan selepas mencukur dan losen
mencukur yang sederhana untuk kulit yang
sensitif.Ini memberi anda peluang untuk
mencubanya dan memastikan yang mana satu
yang paling sesuai dengan jenis kulit anda.
Penting
Baca arahan penggunaan ini dengan teliti sebelum
menggunakan peralatan dan simpan untuk rujukan
di masa depan.
◗Guna hanya plag kuasa HQ600 dan penegak
cas yang dibekalkan untuk mengecas alat
pencukur.
◗Hanya plag kuasa yang dibekal menjamin
keselamatan.
◗HQ600 plag kuasa mengubah 100-240 volt ke
suatu voltan rendah yang selamat yang kurang
daripada 24 volt.
◗Plag kuasa itu mengandungi sebuah
transformer. Jangan potong plag kuasa untuk
menggantikannya dengan plag yang lain kerana
ini akan menimbulkan situasi berbahaya.
C◗Jangan rendam penegak cas dalam air
mahupun bilaskannya di bawah air paip bila
penegak cas diplagkan.
BAHASA MELAYU18

C◗Alat pencukur berfungsi pada voltan rendah
yang selamat kurang daripada 24 volt.Ia adalah
kalis air dan boleh dibersihkan di bawah air
paip.Bilas alat pencukur dengan air panas.
Berhati-hati dengan air panas. Sentiasa periksa
agar air tidak terlalu panas, untuk mengelak tangan
anda dari terlecur.
◗Jangan biarkan penegak cas bersama dengan
alat pencukur berada di dalamnya diplag ke
dalam bekalan utama secara berterusan.
◗Periksa sekiranya gel dan losen yang
dibekalkan dengan peralatan mengandungi
bahan-bahan (lihat belakang kartrij) yang anda
alergi sebelum anda mula menggunakan
peralatan.Jangan gunakan gel dan/atau losen
sekiranya anda alergi kepada satu atau lebih
bahan tersebut!
◗Sekiranya kord utama peralatan ini rosak, ia
mesti sentiasa digantikan oleh pusat khidmat
Philips atau pusat khidmat yang dibenarkan
oleh Philips untuk mengelakkan keadaan
berbahaya.
Mengecas
Arahan cas
C◗Sebaik sahaja anda mula mengecas pencukur
yang kosong, lampu panduan hijau akan
menyala.
◗Lampu panduan merah berkelip-kelip apabila
bateri-bateri hampir kosong.
BAHASA MELAYU 19

◗Bila bateri-bateri hampir-hampir kosong,
lampu panduan merah berkelip-kelip beberapa
kali selepas alat pencukur dimatikan.
Mengecas peralatan
Cas semula, simpan dan gunakan alat pada suhu
antara 5cC dan 35cC.
1Masukkan plag kecil ke penegak cas dan
pasangkan plag kuasa di soket dinding.
C2Letakkan alat pencukur di penegak cas.
C3Tekan sehingga anda dengar suatu bunyi
klik.
Alat pencukur dimatikan secara automatik apabila
ditempatkan di penegak cas.
4Apabila mengecas untuk kali pertama atau
selepas sesuatu tempoh lama tidak
digunakan: biarkan alat pencukur dicaskan
berterusan selama 24 jam.
Masa mengecas biasanya mengambil masa lebih
kurang 8 jam.
Alat pencukur yang telah dicas penuh mempunyai
masa mencukur tanpa kord lebih kurang 40 minit.
Memasuk kartrij
Kartrij dengan gel/losen mencukur NIVEA FOR
MEN yang lembap tersedia dalam kotak-kotak
BAHASA MELAYU20

yang mengandungi lima kartrij dan satu pam
plastik yang kecil.Jangan buang pam tersebut bila
anda mengganti suatu kartrij yang kosong. Anda
akan perlukannya bagi semua lima kartrij.
Satu kartrij Philishave NIVEA FOR MEN Cool
Skin mengandungi emulsi yang mencukupi untuk
lebih kurang 10 cukuran.
Alih kartrij gel/losen mencukur dari peralatan bila
anda tidak mengguna alat pencukur lebih daripada
satu minggu.
Guna hanya kartrij Philishave NIVEA FOR MEN
Cool Skin (HQ160 atau HQ161).
Untuk tujuan kesihatan, kami nasihatkan anda
untuk masukkan pam baru apabila anda mula
mengunakan set lima kartrij yang baru.
Apabila anda telah kehabisan kartrij gel/losen
mencukur anda dan anda tidak tahu di mana
untuk membelinya, hubungi Pusat Penjagaan
Pelanggan di negara anda (lihat 'Jaminan &
khidmat')
Memasukkan kartrij
C1Ambil satu kartrij dari kotak.Ambil pam
(yang dibekalkan di dalam kotak yang
sama) dari beg dan tolakkannya ke dalam
kartrij sehingga ia terkunci di dalam
kedudukannya dengan bunyi klik.
BAHASA MELAYU 21

C2Alih dan lepaskan luncuran ke bawah dan
buka penutup bekas kartrij.
C3Tolak kartrij dengan pam ke dalam alat
pencukur. Ia hanya muat dengan betul
sekiranya bahagian putih pam menghala ke
atas.
4Tutup penutup (anda akan dengar bunyi klik).
5Tekan butang kuning pam beberapa kali
sehingga emulsi cukuran NIVEA FOR MEN
kelihatan.Alat pencukur kini sedia untuk
digunakan.
BGel/losen mencukur NIVEA FOR MEN dalam
kartrij akan tahan selama 32 bulan bila disimpan
pada suhu antara 0cC and +40cC.
Menggunakan peralatan
Mencukur
Hidupkan alat pencukur.
1Hidupkan alat pencukur dengan menekan
butang hidup/mati sekali.
C2Tekan butang pam kuning untuk memakai
gel/losen mencukur NIVEA FOR MEN
kepada kulit anda.
BAHASA MELAYU22
12
