Philips PQ205 User manual

ENGLISH
Introduction
Congratulations on your purchase
and welcome to Philips!To fully benefit from the
support that Philips offers, register your product at
www.philips.com/welcome.
General description (Fig. 1)
1Protection cap
2Shaving heads
3Shaving unit
4Retaining frame
5Central spring of retaining frame
6Release button
7Hair chamber
8On/off slide
9Lid of battery compartment
10 Philips Cleaning Spray (HQ 110) (Optional)
11 Cutter
12 Guard
13 Cleaning brush
Important
Read this user manual carefully before you use the
appliance and save it for future reference.
Warning
- Keep the appliance dry.
- This symbol means: Forbidden to clean under a
running tap (Fig. 2).
- This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
- Children should be supervised to ensure that
they do not play with the appliance.
Caution
- Use and store the appliance at a
temperature between 5°C and 35°C.
- Remove the batteries from the appliance if you
are not going to use it for a month or more.
- Use Philips batteries to achieve optimal shaving
performance.
- Only use the cleaning brush
supplied.
- Make sure the cleaning brush remains clean.
Electromagnetic fields (EMF)
This Philips appliance complies with
all
standards regarding electromagnetic
fields (EMF). If handled properly and according to
the instructions in this user manual, the appliance
PQ205, PQ202
Register your product and get support at
www.philips.com/welcome
4222.002.5270.1
4
7
10
13
16
19
22
2
5
8
11
14
17
20
23
3
6
9
12
15
18
21
24
1

is safe to use based on scientific evidence available
today.
Preparing for use
The appliance operates on two R6 AA 1.5-
volt alkaline batteries. Preferably insert new
Philips alkaline batteries to get optimal shaving
performance.
Make sure that your hands are dry when you
insert the batteries.
1 Remove the lid of the battery
compartment (Fig. 3)
2 Place two batteries in the battery
compartment (Fig. 4).
Note: Make sure the + and - indications on the
batteries match the indications in the battery
compartment.
Note:The shaver does not work if the batteries have
been placed incorrectly.
3 Put the lid of the battery
compartment back onto the
appliance. First place the top part of the lid
(1) and then press down the bottom part
until you hear a click (2) (Fig. 5).
How to avoid damage due to battery
leakage
- Do not expose the appliance to temperatures
higher than 35°C.
- Remove the batteries if you are not going to
use the appliance for a month or more.
- Do not leave empty batteries in the appliance.
Shaving time
Two new Philips alkaline batteries offer a shaving
time of 60 minutes.
Using the appliance
1 Remove the protection cap.
2 Press the on/off slide to unlock it and push it
upwards to switch on the shaver (Fig. 6).
The on/off slide has an integrated switch lock to
prevent accidental switching on of the shaver.
3 Move the shaving heads over your skin. Make
both straight and circular movements (Fig. 7).
Note: Shave on a dry face only. Do not use the shaver
in combination with gel, foam or water.
Note: Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
4 Push the on/off slide downwards to switch off
the shaver.
5 Clean the shaver after every shave, see
chapter ‘Cleaning and maintenance’.
6 Put the protection cap on the shaver after
use to prevent
damage and to avoid dirt
accumulation in the shaving heads (Fig. 8).
Cleaning and maintenance
Never use scouring pads, abrasive cleaning agents
or aggressive liquids such as petrol or acetone to
clean the appliance.
Clean the shaver after every shave to guarantee
better shaving performance.
For the best cleaning result, we advise you to use
Philips Cleaning Spray (HQ110). Ask your Philips
dealer for information.
Note: Philips Shaving Head Cleaning Spray
(HQ110) may not be available in all countries.
Contact the Customer Care Centre in your country
about the availability of this accessory.
After every shave: shaving unit and hair
chamber
1 Switch off the shaver.
2 Clean the top of the appliance with the
cleaning brush
supplied (Fig. 9).
3 Press the release button (1) and pull the
shaving unit a straight up off the shaver
(2) (Fig. 10).
4 Clean the inside of the shaving unit with the
cleaning brush (Fig. 11).
5 Clean the hair chamber with the cleaning
brush (Fig. 12).
6 Put the shaving unit back onto the
shaver (Fig. 13).
Every two months: shaving heads
Note: Do not use cleaning agents or
alcohol to clean the shaving heads. Only use Philips
Cleaning Spray (HQ110).
1 Switch off the shaver.
2 Press the release button (1) and pull the
shaving unit straight up off the shaver
(2) (Fig. 10).
3 To remove the retaining frame, push the sides
of the central spring towards each other
(1).Then lift the retaining frame out of the
shaving unit (2) (Fig. 14).
4 Slide the shaving heads out of the retaining
frame. Remove and clean one shaving head at
a time. Each shaving head consists of a cutter
and a guard (Fig. 15).
Note: Do not clean more than one cutter and
guard at a time, since they are all matching sets.
If you accidentally mix up the cutters and guards,
it may take several weeks before optimal shaving
performance is restored.
5 Remove the guard from the
cutter (Fig. 16).
6 Clean it with the short-bristled side of the
cleaning brush. Brush carefully in the direction
of the arrows (Fig. 17).
7 Clean the guard with the
long-bristled side of the cleaning
brush (Fig. 18)
8 Put the cutter back into the guard after
cleaning (Fig. 19).
9 Slide the shaving heads back into the retaining
frame. (Fig. 20)
10 Put the retaining frame back into the shaving
unit (‘click’) (Fig. 21).
11 Put the shaving unit back onto the
shaver (Fig. 13).
Storage
Keep the appliance dry.
Use and store the appliance at a
temperature between 5°C and 35°C.
1 Switch off the shaver.
2 Put the protection cap on the shaver after
use to prevent
damage and to avoid dirt accumulation in the
shaving heads (Fig. 8).
Replacement
Replace the shaving heads every two years for
optimal shaving results.
Replace damaged or worn shaving heads with
Philips shaving heads only (HQ4+ for China or
HQ56 for the rest of the world).
For instructions on how to remove the shaving
heads, see chapter ‘Cleaning and maintenance’,
section ‘Every two months: shaving heads’.
Accessories
To retain the top performance of your shaver,
make sure you clean it regularly and replace its
shaving heads at the recommended time.
Shaving heads
- We advise you to replace your shaving heads
every two years. Always replace them with
Philips shaving heads only (HQ4+ for China or
HQ56 for the rest of the world) (Fig. 22).
Cleaning
- Use Philips Cleaning Spray (HQ110) to clean
the shaving heads thoroughly.
Environment
- Do not throw away the appliance with the
normal household waste at the end of its life,
but hand it in at an official collection point for
recycling. By doing this, you help to preserve
the environment (Fig. 23).
- Batteries contain substances that may pollute
the environment. Do not throw away batteries
with the normal household waste, but dispose
of them at an official collection point for
batteries. Always remove the batteries before
you discard and hand in the appliance at an
official collection point (Fig. 24).
Guarantee and service
If you need service or information or if you have
a problem, please visit the Philips website at www.
philips.com or contact the Philips Consumer Care
Centre in your country.You find its phone number
in the worldwide guarantee leaflet. If there is no
Consumer Care Centre in your country, go to your
local Philips dealer.
Guarantee restrictions
The shaving heads (cutters and guards) are
not covered by the terms of the international
guarantee because they are subject to wear.
Troubleshooting
This chapter summarises the most common
problems you could encounter with the
appliance. If you are unable to solve the problem
with the information below, contact the Consumer
Care Centre in your country.

责他们安全的人对他们使用
本产品进行监督或指导。
-应照看好儿童，确保他们不
玩耍本产品。
注意
-必须在 5°C 至 35°C 之
间的温度下使用和存放本产
品。
-如果超过一个月不使用本产
品，请从产品中取出电池。
-请使用飞利浦电池，以实现
最佳的剃须效果。
-仅限使用随附的清洁刷。
-确保清洁刷保持洁净。
电磁场 (EMF)
这款飞利浦产品符合关于电磁
场 (EMF) 的相关标准。据目前
的科学证明，如果正确使用并
按照本用户手册中的说明进行
操作，本产品是安全的。
使用准备
插入电池
本产品使用两节 R6 AA 1.5 伏
碱性电池。最好插入全新的飞
利浦碱性电池，以实现最佳的
剃须效果。
装入电池之前，双手要保持干
燥。
1 取下电池仓盖(图3)
2 将两节电池放入电池仓。(
图4)
注意：确保电池的正负极指示
与电池仓内的正负指示一致。
注意：如果电池装错方向，则
简体中文
简介
感谢您的惠顾，欢迎光临飞
利浦！为了您能充分享受飞
利浦提供的支持，请在 www.
philips.com/welcome 上注册
您的产品。
一般说明 (图 1)
1 保护盖
2 剃须刀头
3 剃毛刀头部件
4 固定架
5 固定架的中央弹簧
6 释放钮
7 毛发储藏室
8 开/关滑钮
9 电池舱盖
10 飞利浦清洁喷雾剂 (HQ
110)（可选）
11 刀片
12 网罩
13 清洁刷
注意事项
使用产品之前，请仔细阅读本
用户手册，并妥善保管以供日
后参考。
警告
-保持器具干燥。
-此符号表示：禁止用在打
开的水龙头下进行清洗。 (
图 2)
-本产品不打算由肢体不健
全、感觉或精神上有障碍或
缺乏相关经验和知识的人（
包括儿童）使用，除非有负
Problem Possible
cause
Solution
The batteries
are empty
Replace the
batteries.
See chapter
‘Preparing for
use’.
The
appliance
makes a
strange noise.
Too much
dirt has
collected in
the shaving
heads.
Clean the shaving
heads.After
cleaning, lubricate
the central point
on the inside of
the guards with
Philips Cleaning
Spray (HQ110).
See chapter
‘Cleaning and
maintenance’.
The shaving
heads are
damaged or
worn.
Replace the
shaving heads.
See chapter
‘Replacement’.
Problem Possible
cause
Solution
The shaver
does not
shave as well
as it used to.
The shaving
heads are
dirty.You
have not
cleaned the
shaver well
enough or
you have not
cleaned it for
a long time.
Clean the shaver
thoroughly
before you
continue shaving.
See chapter
‘Cleaning and
maintenance’.
Long hairs
obstruct the
shaving heads.
Clean the cutters
and guards with
the cleaning
brush supplied.
See chapter
‘Cleaning and
maintenance’,
section ‘Every
two months:
shaving heads’.
The shaving
heads are
damaged or
worn.
Replace the
shaving heads.
See chapter
‘Replacement’.
The shaver
does not
work when
I push the
on/off
slide upwards.
The batteries
are placed
incorrectly.
Make sure the +
and - indications
on the batteries
match the
indications in
the battery
compartment.
The
batteries are
empty.
Replace the
batteries.
See chapter
‘Preparing for
use’.
My skin is
irritated after
shaving.
Your skin
needs time
to get used
to the Philips
shaving
system.
Skin irritation
during the first
2-3 weeks of
use is possible.
After this
period, the skin
irritation usually
disappears.
The rotation
speed of the
shaving heads
is slower than
usual.
Too much
dirt has
collected in
the shaving
heads.
Clean the
shaving heads.
See chapter
‘Cleaning and
maintenance’.

7 用清洁刷的长毛一侧清洁网
罩。(图18)
8 清洁后，将刀片重新装回至
网罩。
(图19)
9 滑动剃须刀头，将其重新安
装到固定架上。(图20)
10 将固定架重新安装到剃须刀
头部件上
（可听到“咔嗒”一声）。
(图21)
11 将剃须刀头组件重新安装到
剃须刀上。(图13)
存储
保持器具干燥。
必须在 5°C 至 35°C 之间的
温度下使用和存放本产品。
1 关闭剃须刀。
2 使用后请盖上剃须刀保护
盖，以防止损坏剃须刀头并
避免其内积聚灰尘。(图8)
更换
每两年更换一次刀头以获得最
佳的剃须效果。
只能使用飞利浦剃须刀头（适
用于中国的 HQ4+ 或适用于世
界其他各地的 HQ56）更换损
坏或磨损的剃须刀头。
有关如何拆卸剃须刀头的说
明，请参阅“清洁和保养”一
章中的“每两个月：清洁剃须
刀头”部分。
5 用清洁刷清洁胡茬储藏
室。(图12)
6 将剃须刀头组件重新安装到
剃须刀上。
(图13)
每两个月：清洁剃须刀头
注意：请勿使用清洁剂或酒精
来清洁剃须刀头。只能使用飞
利浦清洁喷雾剂(HQ110)。
1 关闭剃须刀。
2 按释放按钮(1)，垂直向上
拉动剃须刀头部件，将其从
剃须刀(2)中拉出。(图10)
3 要取下固定架，请捏拢中央
弹簧的两侧(1)。然后向上
提起固定架，将其从剃须刀
头部件中取出(2)。(图14)
4 将剃须刀头滑离固定架。一
次取下并清洁一个剃须刀
头。每个剃须刀头包含一组
刀片和网罩。(图15)
注意：不要同时清洁多组刀片
和网罩，因为它们都是相互匹
配的。如果不小心将刀片和网
罩弄混，则需要数周时间才能
恢复产品的最佳剃须性能。
5 从刀片上卸下网罩。(
图16)
6 用清洁刷的短毛一侧清洁刀
片。按箭头方向小心地清
洁。
(图17)
4 向下推动开/关滑钮以关闭剃
须刀电源。
5 每次剃须后均应清洁剃须刀
（请参阅“清洁和保养”一
章）。
6 使用后请盖上剃须刀保护
盖，以防止损坏剃须刀头并
避免其内积聚灰尘。(图8)
清洁和保养
不要使用钢丝绒、研磨性清洁
剂或腐蚀性液体（例如汽油或
丙酮）来清洁产品。
每次剃须后均应清洁剃须刀，
以保证更好的剃须效果。
为了获得最佳的清洁效果，建
议您使用飞利浦清洁喷雾剂
(HQ110)。有关详情，请咨询
飞利浦经销商。
注意：并非所有国家/地区都
销售飞利浦剃须刀头清洁喷雾
剂(HQ110)。请向当地的客户
服务中心了解是否有售。
每次剃须后：清洗剃须刀头
部件和胡茬储藏室
1 关闭剃须刀。
2 用随附的清洁刷清洁产品顶
部。(图9)
3 按释放按钮(1)，垂直向上
拉动剃须刀头部件，将其从
剃须刀(2)中拉出。(图10)
4 用清洁刷清洁剃须刀头部件
的内侧。
(图11)
剃须刀就不会工作。
3 将电池仓盖装回到产品。
首先放入仓盖的顶部(1)，
然后按下底部(2)，直到听
到“咔哒”一声。
(图5)
如何避免因电池泄漏而引起
的损坏
-切勿将产品暴露在温度高于
35°C 的环境中。
-如果一个月或一个月以上不
使用本产品，则将电池取
出。
-切勿将耗尽的电池留在产品
中。
剃须时间
两节全新飞利浦碱性电池可供
60 分钟剃须。
使用本产品
1 取下保护盖。
2 按开/关滑钮将其解锁，然后
向上推打开剃须刀电源。(
图6)
开/关滑钮具有集成式开关锁，
可防止意外打开剃须刀电源。
3 将剃须刀头在皮肤上移动。
作直线和迂回动作。(图7)
注意：仅限在干爽的面部剃
须。请勿将本剃须刀与凝胶、
剃须泡沫或水结合使用。
注意：您的皮肤可能需要2
到3周才能适应飞利浦剃须系
统。

问题 可能的
原因 解决方法
我在剃
须后出
现皮肤
过敏。
您的皮
肤需要
一定的
时间来
适应飞
利浦剃
须刀。
在前 2-3
周的使用
过程中，
可能会出
现皮肤过
敏。在此
之后，皮
肤过敏
通常会消
失。
剃须刀
头的转
速比平
时慢。
剃须刀
头中积
聚了太
多的灰
尘。
清洁剃须
刀头。
请参阅“
清洁和保
养”一
章。
电池已
耗尽
更换电
池。见“
使用准
备”一
章。
问题 可能的
原因 解决方法
过长的
胡须堵
塞了剃
须刀
头。
用随附的
清洁刷
清洁刀片
和网罩。
见“清洁
和保养”
中“每两
个月：剃
须刀头”
部分。
剃须刀
头已损
坏或磨
损。
更换剃须
刀头。
见“更
换”一
章。
向上推
动开/
关滑钮
时剃须
刀不工
作。
电池放
置不正
确。
确保电池
的正负
极指示与
电池仓内
的指示一
致。
电池已
耗尽。
更换电
池。见“
使用准
备”一
章。
果您所在的国家/地区没有飞利
浦客户服务中心，请与当地的
飞利浦经销商联系。
保修条款
由于剃须刀头（刀片和网罩）
属于易磨损物品，因此不在国
际保修条款的涵盖范围之列。
故障种类和处理方法
本章归纳了使用本产品时最可
能遇到的问题。如果您无法根
据下面的信息解决问题，请联
系您所在国家/地区的飞利浦客
户服务中心。
问题 可能的
原因 解决方法
剃须刀
的剃须
效果没
有以前
好。
剃须刀
头变
脏。您
没有将
剃须刀
清洁干
净，或
长时间
未清洁
过剃须
刀。
在继续剃
须之前，
请先彻底
清洗剃须
刀。见“
清洁和保
养”一
章。
附件
为了保持剃须刀的最佳性能，
请确保定期清洁并在推荐的时
间更换剃须刀头。
剃须刀头
-建议您每两年更换一次剃须
刀头。务必仅使用飞利浦
剃须刀头（适用于中国的
HQ4+ 或适用于世界其他各
地的 HQ56）进行更换。 (
图 22)
清洁
-使用飞利浦清洁喷雾剂
(HQ110) 彻底清洁剃须刀
头。
环保
-弃置产品时，请不要将其与
一般生活垃圾堆放在一起；
应将其交给官方指定的回
收中心。这样做有利于环
保。 (图 23)
-电池包含可能污染环境的物
质。不要将电池和普通生活
垃圾一同丢弃，而应交给正
式的电池收集点处理。丢弃
产品时，一定要将电池取
出，并将产品送到官方指定
的回收站。 (图 24)
保修与服务
如果您需要服务或信息，或有
任何疑问，请访问飞利浦网
站：www.philips.com。您也
可与所在国家/地区的飞利浦客
户服务中心联系（可从全球保
修卡中找到其电话号码）。如

问题 可能的
原因 解决方法
产品发
出奇怪
的噪
音。
剃须刀
头中积
聚了太
多的灰
尘。
清洁剃须
刀头。清
洁后，用
飞利浦清
洁喷雾剂
(HQ110)
润滑网罩
内侧的中
央点。请
参阅“清
洁和保
养”一
章。
剃须刀
头已损
坏或磨
损。
更换剃须
刀头。
见“更
换”一
章。
2011/07/15
