Philips HQ 6890/A User manual

Domestic Appliances and Personal Care
Service
Service
Service
QUADRA ACTION
HQ 6890/A
Shaver
Published by Philips Domestic Appliances and Personal Care Printed in The Netherlands Copyright reserved Subject to modification
©
99/12
4322 277 00145
PCS 104 742
HINTS FOR REPAIRS
-
-
-
-
-
-
-
GENERAL
Remove the shaving unit, to prevent damages
during repairs.
Remove screws A1 (2x, of which 1 is under
trimmer slide).
Take cover with trimmer from housing.
Remove bracket (14 + 21).
The PC-board can now be removed from the
housing.
Remove screws B1 (2x) the motor and hair-
chamber can now be removed from the housing.
Detach the motor clamping spings (item 17)
on the bearing block with a small screwdriver.
• Mainsshaver possible.
• Converts input voltage 8-16V dc to constant
Charge current (NiHH 1100mA, NiCD 680mA)
or Constant motorvoltage at mainsshave.
Start-up voltage min. 11V.
• Open battery protection.
• Undervoltage protection.
• Temperature protection of battery (only NiMH).
• Charge condition of battery is managed by
microcontroller. Charge current is regulated and
discharge currents is measured.
• Charge condition of battery shown on LCD display
(minutes left) with backlighting. Full indication
with flashing (2Hz) of backlighting.
• Electronic on/off.
TECHNICAL DATA
Voltage
Power consumption
Motor voltage
Power supply
Speed of cutters
Shaving heads
Battery
SAP CODING: 8856 890 99999
CAUTION!
WHILE CHECKING THE P.C.-BOARD REMEMBER
THAT MOST COMPONENTS AND MOTOR ARE
ENERGIZED BY MAINS VOLTAGE.
100-240 V 50/60Hz
Motor depending
2.4 V
SMPS
> 2100 r.p.m.
HQ6 - 4822 690 10214
Green NiMH pack AA
:
:
:
:
:
:
:
PRODUCTS MEETS THE REQUIREMENTS REGARDING
INTERFERENCE SUPPRESION ON RADIO AND TELEVISION.
- AFTER THE PRODUCT HAS BEEN REPAIRED IT SHOULD
FUNCTION PROPERLY AND HAS TO MEET THE SAFETY
REQUIREMENTS AS LAID DOWN OFFICIALLY ESTABLISHED
AT THIS MOMENT.
!Service
Information

NiMH
HQ 6890/A
A1
1
2
3
B1
4
5
6
7
9
10
11
12
13
24
22
21
20
19
2625
23
14
16
15
17
18
8
PCS 104 742
1 4822 479 20261 cleaning brush
2 4822 441 12355 housing PH
3 4822 466 12232 rubber seal
4 4822 219 10711 power plug EU
4822 219 10713 power plug E-EU
4822 219 10715 power plug GB
4822 219 10717 power plug J
5 4822 462 11177 protecting cap
6 4822 441 12327 head housing
7 4822 690 10214 HQ6 shaving head
8 4822 214 13061 power module
9 4822 402 11319 retaining bracket
10 4822 442 01834 hairchamber PH
11 4822 265 11548 connecting pins
12 4822 522 10762 gearwheel unit
13 4822 466 12233 sealing plate
14 4822 402 11318 bracket small
15 4822 522 10763 pinion
16 4822 361 21783 motor
17 4822 492 71735 motor clamp
18 4822 130 34167 Zener diode
19 4822 690 10217 trimmer
20 4822 463 11259 trimmer slide
21 4822 402 11317 bracket large
22 4822 532 13149 spacer AA
23 4822 138 10728 NiMH pack AA
24 4822 442 01833 cover
25 4822 135 00282 LCD complete
26 4822 256 10572 holder
A 4822 502 14657 s.t.screw spec/T8
B 4822 502 14544 s.t.screw 1.8x18/T8
4822 600 10861 pouch PH
4822 462 11183 stand
4822 736 16936 DFU (1)
4822 736 16937 DFU (2)
4822 736 16938 DFU (3)
4822 736 16939 DFU (4)
4822 736 16941 DFU (5)
(1) GB D F NL E P I TR
(2) GB D N S FIN DK GR
(3) GB RUS UA HR SLO CZ SK H RO
(4) GB RUS PL EST LV LT
(5) J
* 4222 036 01960 Car cord
