Philips QS6141/32 User manual
Always here to help you
User manual
Register your product and get support at
www.philips.com/welcome
QS6161
QS6141
1
6
Introduction
from the support that Philips offers, register your product at
www.philips.com/welcome.
General description (Fig. 1)
1 Trimming head
2 Regular trimming side (32 mm)
3 Precision trimming side (15 mm)
4 Guiding groove
5 Hair length setting selector
6 Trimming head on/off button
7 Travel lock indication (QS6161 only)
8 Shaving head on/off button
9 Shaving head
10 Battery status indicator
11 Regular trimming comb
12 Precision trimming comb (QS6161 only)
13 Charging stand
14 Adapter with small plug
15 Protection cap
16 Cleaning brush
17 Storage pouch (QS6161 only)
Important
Read this user manual carefully before you use the appliance and save it for
future reference.
Danger
- Keep the adapter dry.
Warning
- Check if the voltage indicated on the adapter corresponds to the local
mains voltage before you connect the appliance.
- The adapter contains a transformer. Do not cut off the adapter to
replace it with another plug, as this causes a hazardous situation.
- This appliance can be used by children aged from 8 years and above
and persons with reduced physical, sensory or mental capabilities or
lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the
appliance. Cleaning and user maintenance shall not be made by
children without supervision.
- Children shall not play with the appliance.
Caution
- Use, charge and store the appliance at a temperature between 5°C
and 35°C.
- Do not charge the appliance in the storage pouch.
- Only use the adapter and the charging stand supplied.
- Never immerse the appliance in water or any other liquid. Only rinse
the appliance under the tap to clean it.
ENGLISH
- If the appliance is subjected to a major change in temperature, pressure
or humidity, let the appliance acclimatise for 30 minutes before you use it.
- If the adapter or the charging stand is damaged, always have it replaced
with one of the original types in order to avoid a hazard.
- Do not use the appliance if the shaving head or one of the trimming
combs is damaged or broken, as this may cause injury.
- This appliance is only intended for trimming and dry shaving facial hair
(beard, moustache and sideburns).
Compliance with standards
- The appliance complies with the internationally approved IEC safety
regulations and can be safely used in the bath or shower.
- This Philips appliance complies with all applicable standards and
Charging
QS6161 only: Charging normally takes approx. 1 hour.
QS6141 only: Charging normally takes approx. 4 hours.
When the appliance is fully charged, it has an operating time of 75 minutes.
Battery status indicator:
-
- When the battery status indicator lights up white continuously, the
battery is fully charged.This indication is shown for 30 minutes.Then
the battery status indicator goes out.
-
empty (approx. 10 minutes of operating time left).
-
empty.You have to charge the appliance before you can use it again.
Note:The appliance can only be charged in the charging stand.
1 Insert the small plug into the charging stand.
Note:The small plug is easiest to insert when the charging stand is folded.
2 Unfold the charging stand (‘click’).
3 Put the adapter in the wall socket.
4 Put the appliance in the charging stand.
ENGLISH 7
,
battery is charging.
,When the battery is fully charged, the battery status indicator lights
up white continuously.
Using the appliance
You can use the appliance to trim or dry shave facial hair (beard,
moustache and sideburns).This appliance is not intended for shaving or
trimming lower body parts.
Trimming with comb
The trimming combs allow you to trim to different lengths.
Start at the highest setting to acquire practice with this appliance.
See the table below for an overview of the hair length settings and the
corresponding hair lengths.
Setting Hair length after trimming
1 1 mm - 3/64 inch
. 1.5 mm - 1/16 inch
2 2 mm - 5/65 inch
. 2.5 mm - 3/32 inch
3 3 mm - 1/8 inch
4 4 mm - 5/32 inch
5 5 mm - 3/16 inch
6 6 mm - 1/4 inch
7 7 mm - 9/32 inch
8 8 mm - 5/15 inch
9 9 mm - 3/8 inch
10 10 mm - 13/32 inch
* no comb = 0.5mm - 1/32 inch
ENGLISH8
1 Hold the appliance in the trimming position, with the trimming head
pointing upwards and the shaving head pointing downwards.
2 Slide the comb into guiding groove of the appliance (‘click’).
3 Press the hair length setting selector and then move it from left to
right or right to left to select a setting.
- The line above the hair length setting selector shows which setting you
have selected.
4 Press the trimming head on/off button once to switch on the
trimming head.
,QS6161 only:The on/off button lights up to indicate that the
trimming head is operating.
324
ENGLISH 9
5 To trim the hair, move the trimming comb through the hair slowly.
Tips
- Always make sure that the tips of the trimming comb points in the
direction in which you move the appliance.
-
contact with the skin to obtain an even hair length result.
- Since hair grows in different directions, you need to move the appliance
in different directions as well (upward, downward or across).
- You can switch on the trimming head while the shaving head is
operating. If you do this, the shaving head is switched off immediately.
- Trimming is easier when the skin and hair are dry.
6
to switch off the trimming head.
Trimming without comb
The comb keeps the trimming head at a set distance from your head.You
can use the trimming head without comb.If you use the trimming head
without comb, your hair is cut off close to the skin (approx. 0.5 mm).
1 To remove the comb, pull it off the appliance.
2 Press the trimming head on/off button to switch on the trimming
head.
3 Hold the appliance with the trimming head pointing upwards and
make downward strokes with the regular side of the trimming head.
Using the precision side of the trimming head
The precision trimming head is only half as wide as the regular trimming
head. It therefore allows more precise styling of the area around the ears,
the sideburns and also around the mouth and under the nose.
ENGLISH10
1 To use the precision side of the trimming head, simply turn the
trimming head until the precision side points towards the front of
the appliance.
2 Press the trimming head on/off button to switch on the trimming
head.
3 Hold the appliance with the trimming head pointing upwards and
make downward strokes with the precision trimming head.
Shaving
Before you use the shaving head, always check it for damage or wear. If
the shaving head is damaged or worn, do not use it, as injury may occur.
Replace a damaged shaving head before you use it again (see chapter
‘Replacement’).
Shaving tips and tricks
- The shaving head is suitable for both wet and dry use. Use the shaving
head with shaving gel or foam for extra skin comfort, or use the
shaving head dry for extra convenience.
- Make sure that the shaving head is in full contact with the skin.
- You can switch on the shaving head while the trimming head is
operating. If you do this, the trimming head is switched off immediately.
- Your skin may need 2 or 3 weeks to get accustomed to the Philips
shaving system.
Wet shaving
1 Apply some water to your skin.
ENGLISH 11
2 Apply shaving foam or shaving gel to your skin.
3 Rinse the shaving unit under the tap to ensure that the shaving unit
glides smoothly over your skin.
4 Hold the appliance in the shaving position, with the shaving head
pointing upwards and the trimming head pointing downwards.
5 Press the shaving head on/off button once to switch on the shaving
head.
,QS6161 only:The on/off button lights up to indicate that the shaving
head is operating.
6 Place the shaving head on the skin and move the appliance against
the direction of hair growth while you press it lightly.
ENGLISH12
7 To switch off the shaving head after use, press the shaving head on/
off button again.
8 Clean the shaving head (see chapter ‘Cleaning and maintenance’,
section ‘Quick cleaning the shaving head after wet shaving’).
Dry shaving
1 Hold the appliance in the shaving position, with the shaving head
pointing upwards and the trimming head pointing downwards.
2 Press the shaving head on/off button once to switch on the shaving
head.
,QS6161 only:The on/off button lights up to indicate that the shaving
head is operating.
3 Place the shaving head on the skin and move the appliance against
the direction of hair growth while you press it lightly.
4 To switch off the shaving head after use, press the shaving head on/
off button again.
ENGLISH 13
Overload protection
If you press the trimming head or shaving head too hard onto your skin
or if its cutters gets blocked (e.g. by clothes etc.), the on/off button of the
the appliance switches off automatically. Remove whatever is blocking the
cutters before you use the appliance again.
Cleaning and maintenance
Clean the appliance after every use.
Never use compressed air, scouring pads, abrasive cleaning agents or
aggressive liquids such as petrol or acetone to clean the appliance.
Only clean the appliance and the adapter with the cleaning brush
supplied.
Cleaning the trimming head
1 Switch off the appliance.
2 Pull the comb off the trimming head.
3 Clean the trimming head under the tap.
Cleaning the trimming head connector
Note: Make sure that you clean the trimming head connector at least once
1 Switch off the appliance.
2 Gently pull the trimming head off the appliance.
ENGLISH14
3 Remove the hairs from the inside of the trimming head connector
with the cleaning brush.
4 Clean the inside of the trimming head with the cleaning brush.
5 After cleaning, put the trimming head back onto the appliance.
Quick cleaning of the shaving head after wet shaving or shaving
with shaving foam
1
2 Switch on the appliance and hold the shaving head in the water
collected in your cupped hand.
The running motor will help clean the inside of the shaving head.
3 Move the shaving head around until all visible foam has disappeared.
if it is damaged.
ENGLISH 15
Thoroughly cleaning of the shaving head
1 Switch off the appliance.
2 Pull the shaving head off the appliance.
if it is damaged.
3 Rinse the shaving head with lukewarm water.
Do not clean the shaving head with the cleaning brush, as this may cause
damage.
4 Remove hairs from the cutters with the cleaning brush.
may cause damage.
5 After cleaning, snap the shaving head back onto the appliance (‘click’).
ENGLISH16
Replacement
In case of frequent use, replace the shaving foil and the cutters every year.
Shaving foil
1 Pull the shaving head off the appliance.
2 Remove the old shaving foil from the shaving head.
3 Snap the new shaving foil into the shaving head (‘click’).
Cutters
1 Pull the shaving head off the appliance.
2 Remove the cutters.
3 Snap the new cutters onto the appliance (‘click’).
Storage
You can fold the charging stand for easy travelling or storage.
1 To fold the charging stand: fold the base of the charging stand against
the appliance holder.
2 Put the protection cap on the shaving unit.
Travel lock (QS6161 only)
The appliance has an integrated travel lock which prevents the appliance
from accidentally being switched on during travel.
1 To activate the travel lock, press and hold the trimming head on/off
button, the shaving head on/off button or both for at least 4 seconds
,The travel lock is only activated when the indication lights up
continuously.
2 To deactivate the travel lock, press and hold the trimming head on/
off button, the shaving head on/off button or both for at least
,The travel lock is now deactivated and the appliance switches on.
ENGLISH 17
Ordering accessories
To buy accessories or spare parts, visit www.shop.philips.com/service
or go to your Philips dealer.You can also contact the Philips Consumer
contact details).
Environment
- Do not throw away the appliance with the normal household waste
recycling. By doing this, you help to preserve the environment.
- The built-in rechargeable battery contains substances that may pollute
the environment.Always remove the battery before you discard and
removing the battery, you can also take the appliance to a Philips
service centre.The staff of this centre will remove the battery for you
and will dispose of it in an environmentally safe way.
Removing the rechargeable battery
Only remove the rechargeable battery if it is completely empty.
1 Disconnect the appliance from the mains and let the appliance run
until the motor stops.
2 Remove the shaving head and the cutters from the appliance.
3 Undo the four screws of the top cover with a screwdriver.
4 Remove the cover.
5 Insert a screwdriver under the back panel and remove the panel.
6 Insert the screwdriver under the cover of the basic body and
remove the cover.
,Now you see a printed-circuit board.
7 Break the battery from the printed-circuit board.
Be careful, the battery strips are very sharp.
Guarantee and support
If you need information or support, please visit www.philips.com/
support
ENGLISH18
19
Introduktion
Tillykke med dit køb og velkommen til Philips! For at få fuldt udbytte af den
support, Philips tilbyder, skal du registrere dit produkt på www.philips.com/
welcome.
1 Trimmehoved
2 Side til regelmæssig trimning (32 mm)
3 Side til præcisionstrimning (15 mm)
4 Styrerille
5 Indstillingsvælger for hårlængde
6 On/off-knap for trimmerhoved
7 Rejselås-indikator (kun QS6161)
8 On/off-knap for shaverhoved
9 Skærhoved
10 Batteristatusindikator
11 Kam til regelmæssig trimning
12 Kam til præcisionstrimning (QS6161)
13 Opladeenhed
14 Adapter med lille stik
15 Beskyttelseskappe
16 Rensebørste
17 Opbevaringsetui (kun QS6161)
Vigtigt
Læs denne brugsvejledning omhyggeligt igennem, inden apparatet tages i
brug, og gem den til eventuelt senere brug.
Fare
- Hold adapteren tør.
Advarsel
- Kontrollér, om den angivne netspænding på adapteren svarer til den
lokale netspænding, før du slutter strøm til opladeren.
- Adapteren indeholder en transformer.Adapteren må ikke klippes af og
udskiftes med et andet stik, da dette vil forårsage en farlig situation.
- Dette apparat kan bruges af børn fra 8 år og op og personer med
reducerede fysiske, sensoriske eller mentale evner eller manglende
viden eller erfaring, hvis de er blevet vejledt eller instrueret i brug af
apparatet på en sikker måde og forstår de involverede risici. Børn må
ikke lege med apparatet. Rengøring og brugervedligeholdelse må ikke
foretages af børn uden opsyn.
- Lad ikke børn lege med apparatet.
Forsigtig
- Brug, oplad og opbevar altid apparatet ved en temperatur mellem 5°C
og 35°C.
- Oplad ikke apparatet i opbevaringsetuiet.
- Brug kun medfølgende adapter og opladeenhed.
- Apparatet må aldrig nedsænkes ned i vand eller andre væsker. Skyl kun
apparatet under vandhanen for at rengøre det.
DANSK
- Hvis apparatet udsættes for store temperatursvingninger, tryk eller
fugtighed, skal du lade det akklimatisere sig i 30 minutter, inden det
tages i brug.
- Hvis adapteren eller opladeenheden beskadiges, må delene kun
udskiftes med tilsvarende originale dele af samme type for at undgå
enhver risiko.
- Brug ikke apparatet, hvis shaverhovedet eller en af trimmekammene er
beskadiget eller i stykker, da det kan forårsage personskade.
- Dette apparat er udelukkende beregnet til trimning og tør barbering af
ansigtshår (skæg, moustache og bakkenbarter).
Overholdelse af standarder
- Produktet opfylder de internationale IEC-sikkerhedsregler og kan uden
risiko bruges i kar- eller brusebad.
- Dette Philips-apparat overholder alle branchens gældende standarder
og regler angående eksponering for elektromagnetiske felter.
Opladning
Kun QS6161: Opladning tager normalt ca. 1 time.
Kun QS6141: Opladning tager normalt ca. 4 timer.
Når apparatet er fuldt opladet, har det en brugstid på 75 minutter.
Batteristatusindikator:
- Når batteristatusindikatoren blinker hvidt, lader batteriet.
- Når batteristatusindikatoren lyser konstant hvidt, er batteriet fuldt
opladet. Denne indikation vises i 30 minutter. Derefter slukkes
batteristatusindikatoren.
- Når batteristatusindikatoren blinker orange, er batteriet næsten tomt
(ca. 10 minutters brugstid tilbage).
- Når batteristatusindikatoren blinker orange hurtigt, er batteriet tomt.
Du skal oplade apparatet, før du kan bruge det igen.
Bemærk:Apparatet kan kun oplades i opladeenheden.
1 Sæt det lille stik i opladeren.
2 Fold opladeenheden ud (“klik”).
3 Slut adapteren til stikkontakten.
4 Placer apparatet i opladeindikatoren.
DANSK20
This manual suits for next models
2
Table of contents
Languages:
Other Philips Electric Shaver manuals
Philips
Philips PT715 User manual
Philips
Philips HQ6990 User manual
Philips
Philips S91xx User manual
Philips
Philips S7000 series User manual
Philips
Philips NORELCO SP9883 User manual
Philips
Philips HQ5430/16 User manual
Philips
Philips RQ1061 User manual
Philips
Philips QP2532 User manual
Philips
Philips HQ9160/27 User manual
Philips
Philips S91 series User manual
Philips
Philips Bikini Perfect HP6379 User manual
Philips
Philips HQ6830/A User manual
Philips
Philips Norelco BT9810 User manual
Philips
Philips HQ7762 User manual
Philips
Philips HQT788 User manual
Philips
Philips S5898 User manual
Philips
Philips S3580 User manual
Philips
Philips 8138XL/43 User manual
Philips
Philips HQ7330 User manual
Philips
Philips Ladyshave Body Contour HP6317/02 User manual
