Philips HQT764/00 User manual

ENGLISH 4
DEUTSCH 11
FRANÇAIS 19
NEDERLANDS 27
ESPAÑOL 35
ITALIANO 43
PORTUGUÊS 51
 59
TÜRKÇE 67
HQT764
3

Important
◗Check if the voltage indicated on the
powerplug corresponds to the mains voltage
in your home before you connect the
appliance.
◗Make sure that the appliance does not get
wet.
◗This appliance is only designed for trimming
the human beard.Do not use the appliance
for any other purpose.
◗Keep the appliance out of the reach of
children.
◗Charge and store the appliance at a
temperature between 15cC and 35cC.
Charging
Charge the appliance fully before you start using
it for the first time.
C1Make sure the appliance is switched off.
C2Insert the appliance plug into the
appliance.
3Put the powerplug in the wall socket.
C◗The green pilot light on the powerplug will go
on to indicate that the appliance is charging.
It will take approx.10 hours to fully charge the
battery.
ENGLISH4
CHARGE

Do not charge the appliance for more than 24
hours.
A fully charged appliance has a cordless trimming
time of up to 40 minutes.
◗The appliance does not run from the mains.
When the battery is empty,charge it as
described above.
Optimise the lifetime of the rechargeable
battery
When the appliance has been charged for the
first time,we advise you to use it until the battery
is completely empty.
Do not recharge the appliance in between the
trimming sessions.
Continue using the appliance until the motor
almost stops running during a session.Then
recharge the battery.Follow this procedure at
least twice a year.
Trimming
Always comb the beard and/or moustache with a
fine comb before you start trimming.
If you are trimming for the first time,be careful
Do not move the trimmer too fast.Make smooth
and gentle movements.
ENGLISH 5

Trimming with comb attachment
C1Turn the Precision Zoom Lock`to the
desired trimming length setting (see table).
The setting will appear in the window below the
Precision Zoom Lock`.
BIf you are trimming for the first time,start by using
the maximum trimming length setting:setting 9.
2Switch the appliance on.
C3To trim in the most effective way,move
the trimmer against the direction of hair
growth.Make sure the surface of the comb
always stays in contact with the skin.
C4If a lot of hair has accumulated in the
comb,remove the comb attachment and
blow and/or shake the hair out of the
comb.The selected trimming length setting
will not change when you do this.
ENGLISH6
99

Trimming length settings table
Trimming with the unique 'stubble
look' setting
C◗Using setting 1 will result in a 'stubble look'.
Trimming without comb attachment
Full beards and single hairs
C1Remove the comb attachment by pulling it
off the appliance.
Never pull at the flexible top of the comb
attachment.Always pull at the bottom part.
2Switch the appliance on.
C3Make well-controlled movements.Touch
the hair lightly with the trimmer.
ENGLISH 7
resulting beard length
1.5 mm
2.5 mm
4.0 mm
5.5 mm
7.5 mm
9.5 mm
12.0 mm
15.0 mm
18.0 mm
setting
1
2
3
4
5
6
7
8
9

Cleaning
Do not use abrasives,scourers or liquids such as
alcohol,petrol or acetone to clean the appliance.
1Make sure the appliance is switched off
and disconnected from the mains before
you start cleaning it.
2Remove the comb attachment.
C3Open the cutting unit.
C4Clean the cutting unit and the inside of the
appliance with the brush supplied.
C5Close the cutting unit by pushing it back
onto the appliance until you hear a click.
The appliance does not need any lubrication.
Replacing the cutting unit
A worn or damaged cutting unit should only be
replaced with an original Philishave cutting unit,
available from authorised Philips service centres.
1Open the cutting unit.
C2Remove the old cutting unit by pulling it
upwards.
ENGLISH8

C3Place the two lugs of the new cutting unit
into the guiding slots.
4Push the cutting unit back onto the
appliance until you hear a click.
Environment
The built-in rechargeable battery contains
substances that may pollute the environment.
Remove the rechargeable battery when you
discard the appliance.
Do not throw the battery away with the normal
household waste but hand it in at an official
collection point.
You can also take the appliance to a Philips
service centre,where the staff will be happy to
help you remove the battery and dispose of it in
an environmentally safe way.
1Disconnect the appliance from the mains
and let the appliance run until the motor
stops.
C2Undo the screw in the housing of the
trimmer.
C3Separate the 2 housing parts by means of a
screwdriver.
ENGLISH 9

C4Insert the screwdriver into the small slot
in the printed circuit board marked with
an arrow.Push the screwdriver down until
parts of the printed circuit board break
off.
C5Remove the battery-holder including the
rechargeable battery.
C6Separate the rechargeable battery from
the battery-holder.
Do not connect the appliance to the mains again
after it has been opened!
Guarantee & service
If you need information or if you have a problem,
please visit the PhilipsWeb site at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will find its
phone number in the worldwide guarantee
leaflet).If there is no Customer Care Centre in
your country,turn to your local Philips dealer or
contact the Service Department of Philips
Domestic Appliances and Personal Care BV.
ENGLISH10

Wichtig
◗Prüfen Sie,bevor Sie das Gerät in Betrieb
nehmen,ob die Spannungsangabe auf dem
Steckernetzgerät mit der örtlichen
Netzspannung übereinstimmt.
◗Achten Sie darauf,dass das Gerät nicht nass
wird.
◗Das Gerät ist nur zum Schneiden von
menschlichen Bärten bestimmt.Benutzen Sie
es niemals für andere Zwecke.
◗Halten Sie das Gerät außer Reichweite von
Kindern.
◗Laden Sie das Gerät nur bei
Umgebungstemperaturen zwischen 15cC
und 35cC.Bewahren Sie es auch bei
Temperaturen in diesem Bereich auf.
DenAkku aufladen
Laden Sie den Akku voll auf,bevor Sie das Gerät
zum ersten Mal benutzen.
C1Achten Sie darauf,dass das Gerät
ausgeschaltet ist.
C2Stecken Sie den Gerätestecker in das
Gerät.
3Stecken Sie dann das Steckernetzgerät in
die Steckdose.Wenn das Steckernetzgerät
dieses Gerätes beschädigt ist,verwenden
Sie sich bitte an Ihren Kundendienst.
DEUTSCH 11

C◗Die Kontroll-Lampe leuchtet auf und zeigt an,
dass derAkku geladen wird.
Nach ca.10 Stunden ist der Akku voll aufgeladen.
Lassen Sie das Gerät nicht länger als 24 Stunden
am Netz.
Mit dem voll aufgeladenen Akku können Sie das
Gerät bis zu 40 Minuten kabelfrei benutzen.
◗Das Gerät kann nicht direkt am Netz
betrieben werden.Ist derAkku leer,so laden
Sie ihn bitte wie oben beschrieben auf.
Verlängern Sie die Nutzungsdauer Ihres
Akkus
Wir empfehlen Ihnen,das Gerät nach dem ersten
Laden des Akkus so lange zu benutzen,bis der
Akku völlig leer ist.
Laden Sie den Akku nicht zwischen den
verschiedenen Anwendungen nach.
Warten Sie immer solange bis der Motor
innerhalb einer Anwendung anhält und laden Sie
den Akku erst dann wieder auf.Befolgen Sie diese
Prozedur mindestens zweimal jährlich.
Den Bart schneiden
Kämmen Sie den Bart/den Schnurrbart vor dem
Gebrauch des Geräts stets mit einem feinen
Kamm aus.
DEUTSCH12
CHARGE
