Philips RQ1095 User manual

3
H
I
J
K
L
MN
B
A
E
CD
F
G
R
Q
P
O
5

4

RQ1095, RQ1087, RQ1085, RQ1077, RQ1075
ENGLISH 6
DEUTSCH 28
ESPAÑOL 52
FRANÇAIS 76
ITALIANO 100
NEDERLANDS 124
PORTUGUÊS 148
TÜRKÇE 172

6
Introduction
Thank you for buying this Philips shaver. Please read
this user manual, as it contains information about the
wonderful features of this shaver as well as some tips
to make shaving easier and more enjoyable.
Important
Read this user manual carefully before you use the
shaver, the Jet Clean System and the Power Pod.
Save the user manual for future reference.
Danger
Make sure the adapter does not get wet.
Warning
Be careful with hot water.Always check if the
water is not too hot, to prevent your hands from
getting burnt.
The adapter contains a transformer. Do not cut
off the adapter to replace it with another plug, as
this causes a hazardous situation.
These appliances are not intended for use
by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been
given supervision or instruction concerning use of
the appliances by a person responsible for their
safety.
Children should be supervised to ensure that they
do not play with the appliances.
Caution
Do not use the shaver, the Jet Clean System, the
Power Pod or the adapter if it is damaged.
Charge and store the shaver at a temperature
between 5°C and 35°C.
-
-
-
-
-
-
-
ENGLISH

Always put the protection cap on the shaver
to protect the shaving heads when you are
travelling.
Never use scouring pads, abrasive cleaning agents
or aggressive liquids such as petrol or acetone to
clean the appliance.
Only use the adapter supplied.
If the adapter is damaged, always have it replaced
with one of the original type in order to avoid a
hazard.
Only use the Jet Clean System with the original
HQ200 cleaning uid.
Never immerse the Jet Clean System in water nor
rinse it under the tap.
Use and store the Jet Clean System at a
temperature between 5°C and 35°C.
Always place the Jet Clean System on a stable,
level and horizontal surface to prevent leakage.
Empty the cleaning chamber and clean it
thoroughly by rinsing it with hot tap water every
15 days.
Always place the Jet Clean System on a uid-
resistant surface.
The Jet Clean System thoroughly cleans but does
not disinfect your shaver, therefore do not share
the shaver with others.
The cleaning chamber of the Jet Clean System is
not dishwasher-proof.
When the Jet Clean System is ready for use, do
not move it to prevent leakage of cleaning uid.
Never immerse the Power Pod in water, nor rinse
it under the tap.
-
-
-
-
-
-
-
-
-
-
-
-
-
-
ENGLISH 7

Compliance with standards
The shaver complies with the internationally
approved IEC safety regulations and can be safely
cleaned under the tap.
These Philips appliances comply with all standards
regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this
user manual, the appliances are safe to use based
on scientic evidence available today.
General
The adapter transforms 100-240 volts to a safe
low voltage of less than 24 volts.
Overview (Fig. 5)
AProtection cap
BShaving unit
CTrimmer
DTrimmer on/off slide
EShaver (RQ1090/RQ1062/RQ1060/RQ1052/
RQ1050)
FShaver on/off button
GDisplay
HShaver holder
IJet Clean System (RQ1005/RQ1000)
JJet Clean System on/off button
KCleaning symbol
LDrying symbol
M’Cleaning chamber empty’ symbol
NCleaning chamber
OPower Pod
PCleaning brush
QAdapter
RSmall plug
-
-
-
ENGLISH8

The display
Before you use the shaver for the rst time, remove
the protective foil from the display.
The ve shaver types (RQ1090, RQ1062, RQ1060,
RQ1052 and RQ1050) have different displays, which
are shown in the gures below.
RQ1090
RQ1062/RQ1060
RQ1052/RQ1050
Charging
Charging takes approx. 1 hour.
When you place the shaver in the Jet
Clean System or in the Power Pod, the
display automatically switches off after approx. 5
hours.
RQ1090
When the shaver is charging, the minutes
indication and the plug symbol ash.
The shaving minutes increase until the shaver is
fully charged.
-
-
-
-
-
-
-
ENGLISH 9

RQ1062/RQ1060
When the shaver is charging, the plug
symbol ashes.
First the arrowheads of the bottom charge level
ash, then the arrowheads of the second level
ash, and so on until the shaver is fully charged.
RQ1052/RQ1050
When the shaver is charging, the battery symbol
ashes blue.
Battery fully charged
RQ1090
When the battery is fully charged, the minutes
indication is visible on the display and the plug
symbol disappears from the display.
RQ1062/RQ1060
When the battery is fully charged, all arrowheads
and all charge level lights light up blue continuously
and the plug symbol disappears from the display.
When you remove the shaver from the Jet Clean
System or the Power Pod, the arrowheads of the
top charge level light up blue to indicate that the
battery is full.
-
-
-
-
-
-
ENGLISH10

RQ1052/RQ1050
When the battery is fully charged, the battery
symbol lights up blue continuously.
Battery low
RQ1090
When the battery is almost empty (when there
are only 5 or fewer shaving minutes left), the
minutes indication and the plug symbol start to
ash.
When you switch off the shaver, the shaving
minutes and the plug symbol continue to ash for
a few more seconds.You hear a beep when there
are no minutes left.
RQ1062/RQ1060
When the battery is almost empty (when there
are only 5 or fewer shaving minutes left), the
battery symbol ashes red and the arrowheads of
the bottom charge level ash blue.
When you switch off the shaver, the battery
symbol and the arrowheads of the bottom charge
level continue to ash for a few seconds.
RQ1052/RQ1050
When the battery is almost empty (when there
are only 5 or fewer shaving minutes left), the
battery symbol lights up red.
When you switch off the shaver, the battery
symbol starts to ash for a few seconds.
-
-
-
-
-
-
-
ENGLISH 11

Remaining battery capacity
RQ1090
The remaining battery capacity is indicated by the
number of shaving minutes shown on the display.
RQ1062/RQ1060
The remaining battery capacity is indicated by the
ashing arrowheads of a particular charge level
Clean shaver
For optimal shaving performance, we advise you to
clean the shaver after every use.
The tap symbol ashes to remind you to clean the
shaver.
Note:The displays of types RQ1062, RQ1060, RQ1052
and RQ1050 look different but show the same
indication.
Replace shaving unit
For maximum shaving performance, we advise you
to replace the shaving unit every two years.
To remind you to replace the shaving unit, the
shaving unit symbol ashes (all types) and you
hear a beep when you switch off the shaver
(RQ1090 only).This happens at the end of 7
successive shaves to remind you to replace the
shaving unit.
-
-
-
-
ENGLISH12

Note:The displays of types RQ1062, RQ1060, RQ1052
and RQ1050 look different but show the same
indication.
Travel lock
You can lock the shaver when you are going to
travel.The travel lock prevents the shaver from being
switched on by accident.
Activating the travel lock
1 Press the on/off button for 3 seconds to enter
the travel lock mode.
The lock symbol appears on the display (all
types) and you hear a beep (RQ1090 only) to
indicate that the travel lock has been activated.
Note:The displays of types RQ1062, RQ1060, RQ1052
and RQ1050 look different but show the same
indication.
Deactivating the travel lock
1 Press the on/off button for 3 seconds.
The motor starts running to indicate that the
travel lock has been deactivated.
The shaver is now ready for use again.
Note:When you place the shaver in the plugged-in
Power Pod or Jet Clean System, the travel lock is
automatically deactivated.
Blocked shaving heads
If the shaving heads are blocked, the shaving unit
symbol and the tap symbol with exclamation mark
ash. In this case, the motor cannot run because
the shaving heads are soiled or damaged.
,
,
-
ENGLISH 13

Note:The displays of types RQ1062, RQ1060, RQ1052
and RQ1050 look different but show the same
indication.
When this happens, you have to clean the shaving
unit or replace it.
The shaving unit symbol and the tap symbol
with exclamation mark continue to ash until you
unblock the shaving heads.
Charging
Charging takes approx. 1 hour.
A fully charged shaver has a shaving time of up to 65
minutes, which is enough for approx. 21 shaves.
The actual shaving time is calculated by the shaver.
If you have a heavy beard, the shaving time may be
less than 65 minutes.The shaving time may also vary
over time, depending on your shaving behaviour and
beard type.
Quick charge
After the shaver has charged for 5 minutes,
it contains enough energy for one shave.
Charging in the Power Pod
1 Put the small plug in the Power Pod.
2 Put the adapter in the wall socket.
3 Pull at the top of the lid (1) and remove it (2).
-
-
ENGLISH14

4 First insert the top of the shaver into the
Power Pod (1) and then press the bottom part
into the Power Pod (2).
Note:The shaver cannot be placed in the Power Pod
when the protection cap is on the shaving unit.
The display shows that the shaver is charging
(see chapter ‘The display’).
Charging in the Jet Clean System
1 Put the small plug in the Jet Clean System.
2 Put the adapter in the wall socket.
3 Place the shaver upside down in the holder
with the display pointing towards the front of
the Jet Clean System.
Note: RQ1090, RQ1062, RQ1060 only: when you turn
the shaver upside down, the indications on the display
are also turned upside down so you can still see the
remaining battery capacity.
4 Press the shaver tightly into the holder to lock
it into place.
Note:The shaver cannot be placed in the Jet Clean
System when the protection cap is on the shaving unit.
The display shows that the shaver is charging
(see chapter ‘The display’).
Using the shaver
Shaving
1 Press the on/off button once to switch on the
shaver.
,
,
ENGLISH 15

The display lights up for a few seconds.
2 Move the shaving heads over your skin. Make
both straight and circular movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
3 Press the on/off button once to switch off the
shaver.
The display lights up for a few seconds and then
shows the remaining battery capacity (RQ1090/
RQ1062/RQ1060 only).
Trimming
You can use the trimmer to groom your sideburns
and moustache.
1 Pull the shaving unit off the shaver.
2 Press the on/off button once to switch on the
shaver.
The display lights up for a few seconds.
3 Press the trimmer slide forwards to slide out
the trimmer.
4 You can now start trimming.
5 Press the trimmer slide backwards to retract
the trimmer.
6 Press the on/off button once to switch off the
shaver.
The display lights up for a few seconds and then
shows the remaining battery capacity (RQ1090/
RQ1062/RQ1060 only).
,
-
-
,
,
,
ENGLISH16

7 Insert the lug of the shaving unit into the slot
in the top of the shaver (1).Then press the
shaving unit downwards (2) to attach it to the
shaver (‘click’).
Cleaning and maintenance
Never use scouring pads, abrasive cleaning agents
or aggressive liquids such as petrol or acetone to
clean the appliance.
The best and most hygienic way to clean the
shaver is in the Jet Clean System.You can also
rinse the shaver under the tap or clean it with the
brush supplied.
Be careful with hot water.Always check if the
water is not too hot, to prevent your hands from
getting burnt.
Clean the shaver after every shave for optimal
shaving performance.
You can clean the outside of the shaver with a
damp cloth.
Regular cleaning guarantees better shaving
performance.
Cleaning the shaving unit in the Jet Clean
System
The Jet Clean System has three cleaning programs:
the eco program, the normal program and the
intensive program.The shaver automatically chooses
the appropriate cleaning program.
Preparing the Jet Clean System for use
Fill the cleaning chamber before rst use.
1 Put the small plug in the Jet Clean System.
-
-
-
-
-
ENGLISH 17

2 Put the adapter in the wall socket.
The holder automatically moves to the highest
position.
3 Simultaneously press the release buttons on
both sides of the cleaning chamber (1).Then lift
the Jet Clean System off the cleaning chamber
(2).
The cleaning chamber remains behind.
4 Unscrew the cap from the bottle with cleaning
uid and remove the airtight seal.
5 Fill the cleaning chamber with HQ200 cleaning
uid up to the MAX indication.
6 Place the Jet Clean System back onto the
cleaning chamber.
Make sure the release buttons click back into place.
Using the Jet Clean System
1 Place the shaver in the holder.
The display shows that the shaver is charging
(see chapter ‘The display’).
2 Press the on/off button on the Jet Clean
System to start the cleaning program.
The shaver display stops showing the charging
indication.
,
,
,
,
ENGLISH18

The cleaning light starts to ash and the shaver is
automatically lowered into the cleaning uid.
The cleaning light ashes throughout the
cleaning program, which takes 4 to 6 minutes,
depending on the cleaning program.
During the rst phase of the cleaning program,
the shaver automatically switches on and off
several times and moves up and down.
During the second phase of the cleaning
program, the shaver is placed in the drying
position, indicated by a ashing drying symbol.
This phase takes approx. 2 hours.The shaver
stays in this position until the end of the
program.
After the cleaning program, the charging
indication appears on the shaver display (see
chapter ‘The display’).
Note: If you press the on/off button of the Jet
Clean System during the cleaning program, the
program aborts and resets. In this case, the cleaning or
drying light stops ashing and the holder returns to its
starting position.
Note: If you remove the adapter from the wall socket
during the cleaning program, the program aborts.The
holder remains in its current position.When you put
the adapter back into the wall socket, the holder moves
to the highest position.
When the uid level drops below the minimum
level, the cleaning light and the ‘cleaning chamber
empty’ symbol start to ash and the holder
returns to its starting position.
If you use the washing machine to clean your
shaver every day, you need to rell the cleaning
chamber approx. every 15 days.
,
,
,
,
,
-
-
ENGLISH 19

Cleaning the Jet Clean System
1 Simultaneously press the release buttons on
both sides of the Jet Clean System (1).Then lift
the Jet Clean System off the cleaning chamber
(2).
The cleaning chamber remains behind.
2 Pour any remaining cleaning uid out of the
cleaning chamber.
You can simply pour the cleaning uid down the sink.
3 Rinse the cleaning chamber under the tap.
The cleaning chamber is not dishwasher-proof.
4 Fill the cleaning chamber with HQ200 cleaning
uid up to the MAX indication.
5 Place the Jet Clean System back onto the
cleaning chamber.
Make sure the release buttons click back into place.
You can clean the Jet Clean System with a moist
cloth.
Clean the cleaning chamber every 15 days.
,
-
-
ENGLISH20

Cleaning the shaving unit under the tap
1 Switch off the shaver.
2 Pull open the three shaving heads one by one.
3 Rinse all three shaving heads and all three hair
chambers under a hot tap for 30 seconds.
Be careful with hot water. Always check if the
water is not too hot, to prevent your hands from
getting burnt.
4 Carefully shake off excess water and leave the
shaving heads open to let the shaving unit dry
completely.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
Cleaning the shaving unit with the brush
supplied
1 Switch off the shaver.
2 Pull open the three shaving heads one by one.
3 Clean the shaving heads and the hair chambers
with the brush supplied.
4 Close the shaving heads.
ENGLISH 21

Cleaning the trimmer with the brush
supplied
Clean the trimmer every time you have used it.
1 Switch off the shaver.
2 Press the trimmer slide forwards to slide out
the trimmer.
3 Clean the trimmer with the short-bristled side
of the brush supplied. Brush up and down along
the trimmer teeth.
4 Switch the shaver on and off and repeat step 3.
5 Press the trimmer slide backwards to retract
the trimmer.
Tip: For optimal trimmer performance, lubricate the
trimmer teeth with a drop of sewing machine oil every
six months.
Storage
There are two ways to store the shaver or to take it
with you when you travel:
put the shaver in the Power Pod or in the Jet
Clean system. Make sure the protection cap is not
on the shaving unit.
slide the protection cap onto the shaving unit to
prevent damage to the shaving heads.
Replacement
Replace the shaving unit when the shaving unit
symbol appears on the display. Replace a damaged
shaving unit right away.
-
-
ENGLISH22
