Philips HQ9170 User manual

HQ9190, HQ9171, HQ9170
ENGLISH 4
INDONESIA 20
한국어 36
BAHASA MELAYU 52
ภาษาไทย 68
 82
繁體中文 97
简体中文 112

4
Important
Read these instructions for use carefully before using
the appliance and save them for future reference.
Only use the powerplug supplied.
The powerplug transforms 100-240 volts to a safe
low voltage of less than 24 volts.
The powerplug contains a transformer. Do not cut
off the powerplug to replace it with another plug,
as this will cause a hazardous situation.
Do not use a damaged powerplug.
If the powerplug is damaged, always have it
replaced by one of the original type in order to
avoid a hazard.
Make sure the powerplug does not get wet.
Charge and store the appliance at a temperature
between 5 cC and 35 cC.
Never immerse the charging stand in water nor
rinse it under the tap.
Do not recharge the shaver in a closed pouch.
Always unplug the shaver before cleaning it under
the tap.
The appliance complies with the internationally
approved IEC safety regulations and can be safely
cleaned under the tap.
Be careful with hot water. Always check if the water
is not too hot, to prevent your hands from getting
burnt.
Electromagnetic elds (EMF)
This Philips appliance complies with all standards
regarding electromagnetic elds (EMF). If handled
properly and in accordance with the instructions in
this instruction manual, the appliance is safe to use
according to scientic evidence available today.
-
-
-
-
-
-
-
-
-
-
-
ENGLISH

The display
This appliance offers you the unique possibility to
choose the display layout you prefer: a number
layout or a battery symbol layout.
1 Press the on/off button approx. 3 seconds to
enter the menu.
The menu has three different modes: the travel lock
mode and two display layout modes.
You will enter the menu in the travel lock mode,
indicated by a rotating key symbol.
You can scroll through the three modes (travel
lock, battery symbol layout and number layout) by
pressing the on/off button briey in quick succession.
2 To select one of the two display layouts, stop
pressing the on/off button when the layout you
prefer appears on the display.
3 Wait a few seconds without pressing the on/off
button until you hear a beep.
This beep indicates that the display has been set to
the selected layout.
Note:The rst mode you enter after pressing the on/off
button for 3 seconds is the travel lock mode (indicated
by a rotating key symbol). If you do not press the on/off
button again within a few seconds, the travel lock is
activated and the display will not switch to the rst
display layout mode. To deactivate the travel lock, press
the on/off button for 3 seconds again (see chapter
‘Storage’).
You can change the display layout at any time.
Note:When you start using the appliance for the rst
time or after a long period of disuse, it could take
several minutes before anything appears on the display.
,
,
ENGLISH 5

The display provides the following
information:
Charging
Number layout:
When the shaver is being charged, the display shows
the minutes indication and the plug symbol with a
blinking power symbol.
Battery symbol layout:
When the shaver is being charged, the display shows
the battery symbol and the plug symbol with a
blinking power symbol.
Battery fully charged
As soon as the battery has been fully charged,
the word FULL runs across the display.
After a few hours the word FULL stops
appearing.The display shows the minutes
indication and the plug symbol.
Battery running low
Number layout:
When the battery is running low, the display shows a
blinking minutes indication and blinking plug symbol
when you switch the shaver off. HQ9190 only: you
will also hear a few short beeps.
Battery symbol layout:
When the battery is running low, the display shows
a blinking battery symbol and blinking plug symbol
when you switch the shaver off. HQ9190 only: you
will also hear a few short beeps.
,
,
,
,
,
,
ENGLISH6

Battery empty
To indicate that the battery voltage is too low to
operate the appliance, LO appears on the display.
Recharge the battery. See chapter ‘Charging’.
Cleaning shaver
When the shaver is due to be cleaned, the tap
symbol with blinking water drops appears on the
display.
Replacing shaving heads
When the shaving heads need to be replaced
(every two years), the shaving unit symbol starts
blinking when you switch the shaver off. HQ9190
only: at the same time you will hear a beep.
If you do not replace the shaving heads right away,
the shaving unit symbol remains visible during the
next 7 shaves.
You can reset the appliance by pressing the
on/off button for 3 seconds while the shaving unit
symbol is blinking.The shaving unit symbol then
disappears. HQ9190 only: you will hear a short
conrming beep.
If you have not reset the system after these 7
shaves, the system will automatically reset itself.
Demonstration program
The appliance has a unique demonstration program.
Press the on/off button for 6 seconds.
After 3 seconds the lock symbol appears; keep the
on/off button pressed.
The demonstration will start automatically.
During the demonstration the appliance will be
,
,
,
,
-
-
-
,
ENGLISH 7

automatically switched on 2 times.You can interrupt
the demonstration by pressing the on/off button.
Charging
Make sure the appliance is switched off before you
start charging it.
Charging normally takes approx. 1 hour.
You can also shave without charging by connecting
the shaver to the mains.
A fully charged shaver has a cordless shaving time of
up to 30 days.
Charging the appliance
1 Put the appliance plug in the shaver.
2 Put the powerplug in the wall socket.
3 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver
when the battery has been fully charged.
Charging stand
You can also charge the appliance by placing it in
the charging stand.
1 Place the shaver properly in the plugged-in
charging stand.
2 Lift the shaver from the stand without tilting it.
,
ENGLISH8

Removing and inserting the clock
1 Turn the clock anticlockwise (1) (‘click’) and
pull it out (2).
2 Insert the clock (1) and turn it clockwise (2)
(‘click’).
Setting the time
1 Set the time by pressing the small button at the
back of the clock.
The time can only be set forward.
Replacing the battery
1 Remove the cap.Then remove the battery by
means of a miniature screwdriver.
2 Insert a new battery and put the cap back into
place.
ENGLISH 9

Using the appliance
Personal Comfort Control
The Personal Comfort Control system allows
you to adapt the shaver to your skin type.
You can set the shaver to ‘Normal’ for a fast and
comfortable close shave.
You can set the shaver to ‘Sensitive’ for a
comfortable close shave with optimal skin
comfort.
The ‘S’ position is best suited for sensitive skin.
The ‘N’ position is best suited for normal skin.
The in-between positions are suitable for skin
types between normal and sensitive.
HQ9190 only: the display shows the position
selected.
Shaving
1 Switch the shaver on by pressing the on/off
button once.
,
-
-
,
,
,
,
ENGLISH10

When you switch the shaver on or off, all lights
and symbols go on and then the remaining battery
capacity is shown for a few seconds.
2 Move the shaving heads quickly over your skin,
making both straight and circular movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
3 Switch the shaver off by pressing the on/off
button once.
4 Put the protection cap on the shaver every
time you have used it, to prevent damage.
Trimming
For grooming sideburns and moustache.
1 Open the trimmer by pushing the slide
downwards.
The trimmer can be activated while the motor is
running.
2 Closethetrimmerwithyourindexnger.
Cleaning and maintenance
Clean the shaver when the tap symbol with blinking
water drops appears on the display.
Regular cleaning guarantees better shaving
performance.
-
-
ENGLISH 11

The normal way to clean the appliance is to rinse
the shaving unit and the hair chamber with hot
water every time you have used the shaver.
Be careful with hot water.Always check if the
water is not too hot, to prevent your hands from
getting burnt.
Every day: shaving unit and hair chamber
1 Switch the shaver off, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Press the release button to open the shaving
unit.
3 Clean the shaving unit and the hair chamber by
rinsing them under a hot tap for some time.
Make sure the inside of the shaving unit and the hair
chamber have been cleaned properly.
4 Rinse the outside of the appliance.
5 Close the shaving unit and shake off excess
water.
Never dry the shaving unit with a towel or tissue,
as this may damage the shaving heads.
6 Open the shaving unit again and leave it open
to let the appliance dry completely.
You can also clean the hair chamber without water
by using the brush supplied.
ENGLISH12

Every six months: shaving heads
1 Open the shaving unit, turn the lock
anticlockwise (1) and remove the retaining
frame (2).
2 Clean the cutters and guards with the brush
supplied.
Do not clean more than one cutter and guard
at a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it
may take several weeks before optimal shaving
performance is restored.
3 Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit and turn it clockwise.
4 Close the shaving unit.
Trimmer
Clean the trimmer every time you have used it.
1 Switch the shaver off, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
2 Clean the trimmer with the brush supplied.
3 Lubricate the trimmer teeth with a drop of
sewing machine oil every six months.
ENGLISH 13

Charging stand
Never immerse the charging stand in water nor
rinse it under the tap.
You can clean the charging stand with a moist cloth.
Storage
Put the protection cap on the shaver to prevent
damage.
Store the appliance in the luxury cassette/pouch
or place the appliance in the charging stand.
Travel lock
If you are going to travel, it is possible to lock the
shaver.The travel lock prevents the shaver from
being switched on by accident.
Activating the travel lock
1 Press the on/off button for 3 seconds to enter
the travel lock mode (indicated by a rotating
key symbol).
2 Wait a few seconds without pressing the on/off
button to activate the travel lock.
,
,
ENGLISH14

3 The motor switches off and the key symbol is
visible on the display to indicate that the travel
lock has been activated.
Note:If you press the on/off button again within a few
seconds after entering the travel lock mode, the travel
lock will not be activated. Instead, you will have entered
one of the two display layout modes. If you want to
return to the travel lock mode, press the on/off button
two more times until you are back in the travel lock
mode (indicated by rotating the key symbol). Then wait
a few seconds without pressing the on/off button to
activate the travel lock.
You can always return to the menu by pressing
the on/off button for 3 seconds.
Deactivating the travel lock
Press the on/off button for 3 seconds.
The motor starts running to indicate that the shaver
has been unlocked.The shaver is now ready for use
again.
Replacement
Replace the shaving heads when the shaving unit
symbol appears on the display.
Replace damaged or worn shaving heads with HQ9
Philips shaving heads only.
1 Switch the shaver off, remove the powerplug
from the wall socket and pull the appliance plug
out of the shaver.
,
,
ENGLISH 15

2 Press the release button to open the shaving
unit.
3 Turn the lock anticlockwise (1) and remove the
retaining frame (2).
4 Remove the shaving heads and place new ones
in the shaving unit.
Make sure that the projections of the shaving heads
t exactly into the recesses.
5 Put the retaining frame back into the shaving
unit (1) and turn the lock clockwise (2).
6 Close the shaving unit.
The shaving unit symbol will go out if you keep
the on/off button pressed for 3 seconds.
Accessories
The following accessories are available:
HQ8500/HQ8000 powerplug.
HQ9 Philips Shaving Heads.
HQ110 Philips Shaving Head Cleaning Spray (not
available in China).
HQ8010 car cord.
,
-
-
-
-
ENGLISH16

Environment
Do not throw the appliance away with the
normal household waste at the end of its life,
buthanditinatanofcialcollectionpointfor
recycling. By doing this you will help to preserve
the environment.
The built-in rechargeable battery contains
substances that may pollute the environment.
Always remove the battery before discarding the
applianceorhandingitinatanofcialcollection
point.Disposeofthebatteryatanofcial
collection point for batteries. If you have trouble
removing the battery, you can also take the
appliance to a Philips service centre, which will
remove the battery for you and will dispose of it
in an environmentally safe way.
Disposal of the shaver battery
Only remove the battery if it is completely empty.
1 Remove the powerplug from the wall socket
and pull the appliance plug out of the shaver.
2 Let the shaver run until it stops, undo the
screws and open the shaver.
3 Remove the battery.
Do not connect the shaver to the mains again after
the battery has been removed.
,
,
ENGLISH 17

Guarantee & service
If you need information or if you have a
problem, please visit the Philips website at
www.philips.com or contact the Philips Customer
Care Centre in your country (you will nd its phone
number in the worldwide guarantee leaet). If there
is no Customer Care Centre in your country, turn
to your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and
Personal Care BV.
Troubleshooting
1 Reduced shaving performance
Cause 1: the shaving heads are dirty.The shaver
has not been rinsed long enough or the water
used was not hot enough.
Clean the shaver thoroughly before you continue
shaving. See chapter ‘Cleaning and maintenance’.
Cause 2: long hairs are obstructing the shaving
heads.
Clean the cutters and guards with the brush
supplied. See chapter ‘Cleaning and maintenance’,
section ‘Every six months: shaving heads’.
Cause 3: the shaving heads are damaged or worn.
Replace the shaving heads. See chapter
‘Replacement’.
2 The shaver does not work when the on/off
button is pressed.
Cause 1: the shaving heads are dirty.
Recharge the battery. See chapter ‘Charging’.
Cause 2: the appliance is not connected to the
mains.
Put the powerplug in the wall socket.
-
-
-
-
-
-
-
-
-
-
ENGLISH18

3 The shaving unit has come off the shaver.
Cause: the shaving unit has not been placed
correctly.
If the shaving unit becomes detached from the
shaver, you can easily reattach it (‘click’).
4 The display shows the word CHECK and
a blinking shaving unit symbol and tap unit
symbol.
Cause 1: long hairs and dirt are obstructing the
shaving heads.
Clean the shaver thoroughly before you continue
shaving. See chapter ‘Cleaning and maintenance’.
Cause 2: the shaving heads are damaged or worn.
Replace the shaving heads. See chapter
‘Replacement’.
-
-
-
-
-
-
ENGLISH 19

20
Penting
Bacalah petunjuk penggunaan ini dengan saksama
sebelum menggunakan alat dan simpanlah untuk
referensi jika dibutuhkan kelak.
Gunakan hanya steker listrik yang disertakan.
Steker mengubah tegangan 100-240 volt menjadi
tegangan rendah yang aman di bawah 24 volt.
Steker listrik berisi trafo. Jangan memotong steker
listrik dan menggantinya dengan steker lain, karena
dapat membahayakan.
Jangan gunakan steker listrik yang rusak.
Jika steker listrik rusak, harus selalu diganti dengan
tipe yang asli agar terhindar dari bahaya.
Pastikan steker listrik tidak basah.
Isi ulang baterai alat cukur dan simpan alat pada
suhu di antara 5 cC dan 35 cC.
Jangan merendam dudukan pengisi baterai dalam
air maupun membersihkannya di bawah keran air.
Jangan mengisi ulang pencukur di dalam kantong
tertutup.
Cabut steker dari pencukur sebelum
membersihkannya di bawah keran.
Alat cukur ini memenuhi peraturan keselamatan
IEC yang disepakati secara internasional dan dapat
dengan aman dibersihkan di bawah keran air.
Hati-hati dengan air panas. Selalu periksa apakah air
tidak terlalu panas untuk mencegah luka bakar pada
tangan Anda.
Medan elektromagnet (EMF)
Alat Philips ini mematuhi semua standar yang
berkenaan dengan medan elektromagnet (EMF). Jika
ditangani sebagaimana layaknya dan sesuai dengan
petunjuk dalam buku panduan ini, alat tersebut aman
digunakan menurut bukti ilmiah yang kini tersedia.
-
-
-
-
-
-
-
-
-
-
-
INDONESIA

Layar
Alat ini memberi Anda kemungkinan unik untuk
memilih tata letak tampilan sesuai pilihan Anda:
tata letak dengan angka atau tata letak dengan
simbol baterai.
1 Tekan tombol on/off kira-kira 3 detik untuk
masuk ke menu.
Menu memiliki tiga modus yang berbeda: modus
travel lock [penguncian saat bepergian] dan dua
modus tata letak tampilan.
Anda akan memasuki menu dalam modus travel
lock, yang ditandai oleh simbol kunci yang
berputar.
Anda bisa bergulir melintasi tiga modus (travel lock,
tata letak simbol baterai dan tata letak angka) dengan
menekan sekilas tombol on/off secara beruntun.
2 Untuk memilih salah satu dari dua tata letak
tampilan, hentikan tombol on/off sewaktu tata
letak yang Anda inginkan muncul pada layar.
3 Tunggu beberapa detik tanpa menekan tombol
on/off sampai Anda mendengar bunyi bip.
Bunyi bip ini menandakan bahwa tampilan sudah
disetel ke tata-letak yang dipilih.
Catatan:Modus pertama yang Anda masuki setelah
menekan tombol on/off selama 3 detik adalah
modus travel lock (ditandai oleh simbol kunci yang
berputar). Jika Anda tidak menekan lagi tombol on/off
dalam beberapa detik, maka modus travel lock akan
diaktifkan dan layar tidak akan beralih ke modus tata
letak tampilan pertama. Untuk menonaktifkan travel
lock, tekan lagi tombol on/off selama 3 detik (lihat bab
‘Penyimpanan).
Anda dapat mengubah modus tampilan kapan saja.
,
,
INDONESIA 21

Catatan:Apabila Anda menggunakan pencukur untuk
yang pertama kali atau setelah lama tidak digunakan,
dibutuhkan beberapa menit sebelum ada yang tampil
di layar.
Layar memberikan informasi berikut:
Pengisian daya
Tata letak angka:
Apabila alat cukur sedang diisi, layar menunjukkan
indikasi menit dan simbol steker berikut simbol listrik
yang berkedip.
Tata letak simbol baterai:
Apabila alat cukur sedang diisi, layar menunjukkan
simbol baterai dan simbol steker berikut simbol
listrik yang berkedip.
Baterai terisi penuh
Segera setelah baterai terisi penuh, muncul
tulisan FULL pada layar.
Setelah beberapa jam, tulisan FULL menghilang.
Layar menunjukkan indikasi menit dan simbol
steker.
Baterai hampir habis
Tata letak angka:
Apabila baterai mulai lemah, layar menunjukkan
indikasi menit dan simbol steker yang berkedip-kedip
ketika Anda mematikan alat cukur. Hanya HQ9190:
Anda juga akan mendengar bunyi bip pendek
beberapa kali.
Tata letak simbol baterai:
Apabila baterai mulai lemah, layar menunjukkan
simbol baterai dan simbol steker yang berkedip-
kedip ketika Anda mematikan alat cukur. Hanya
HQ9190: Anda juga akan mendengar bunyi bip
pendek beberapa kali.
,
,
,
,
,
,
INDONESIA22
