Philips 8846XL User manual

8846XL
8845XL
Rechargeable Tripleheader ®
Cordless/Cord Razor
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 1 (Black plate)

2
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 2 (Black plate)

ENGLISH 3
ESPAÑOL 22
8846XL/8845XL
3
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 3 (Black plate)

IMPORTANT SAFETY
INSTRUCTIONS
When using an electric razor, basic safety precautions should
always be followed, including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for a razor that has fallen into water.
Unplug immediately.
2. Do not use razor while plugged in while bathing or in a shower.
3. Do not place or store razor while plugged in where it can fall
or be pulled into a tub or sink. Do not place or drop into
water or other liquid while plugged in.
4. Always unplug this razor from the electrical outlet immediately
after using, except when razor is (re)charging.
5. Unplug this razor before cleaning.
6. When discarding razor, unplug razor and remove rechargeable
batteries. See Battery Removal instructions.
WARNING
To reduce the risk of burns, fire, electric shock, or injury to
persons:
1. Close supervision is necessary when this razor is used by, on,
or near children or invalids.
2. Use this razor for its intended household use as described in
this manual. Do not use attachments not recommended by
Philips Electronics North America Corporation.
3. Never operate this razor if it has a damaged cord or charging
plug, if it is not working properly, if it has been dropped or
damaged, or dropped into water while plugged in. Return the
ENGLISH4
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 4 (Black plate)

razor to an Authorized Norelco Service Location for
examination and repair.
4. Keep the razor, cord and charging plug away from heated
surfaces.
5. Never drop or insert any object into any opening.
6. Do not charge or plug in razor outdoors or operate where
aerosol (spray) products are being used or where oxygen is
being administered.
7. Do not use this razor with a damaged or broken comb, as facial
injury may occur.
8. Always attach plug to razor first, then to outlet. Be certain that
plug is inserted firmly into razor, up to mark indicated on plug.
To disconnect, turn razor off then remove charging plug from
outlet.
9. Never put the razor in direct sunlight or store in a pouch at a
temperature above 140ºF.
10.Razor can be rinsed under running tap water. Do not submerge
razor in water.
11.To prevent possible damage to the cord, do not wrap cord
around the razor.
SAVE THESE
INSTRUCTIONS
IMPORTANT: The power plug contains a transformer. Do not
cut off the power plug to replace it with another plug, as this will
cause a hazardous condition.
IMPORTANT
YOUR RAZOR CONTAINS NICKEL-CADMIUM
RECHARGEABLE BATTERIES. See Battery Removal instruction
sheet for battery disposal information.
ENGLISH 5
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 5 (Black plate)

ENGLISH6
60 - DAY MONEY-BACK GUARANTEE
To enjoy the closest and most comfortable shave from your new Norelco Men’s
Razor, the razor should be used exclusivelyfor 3 weeks. This allows your hair
and skin enough time to adapt to the Norelco Shaving System. If, after that
period of time, you are not fully satisfied with your Norelco Men’s Razor, send
the product back and we’ll refund you the full purchase price.
The razor must be shipped prepaid by insured mail, insurance prepaid,
and have the sales slip, indicating purchase price and the date of
purchase, enclosed. The razor must be postmarked no later than 60 days
after the date of purchase. Norelco reserves the right to verify the purchase
price of the razor and limit refunds not to exceed suggested retail price.
Send dated sales slip, your complete name and address as indicated
below, and the razor, prepaid to:
Norelco Consumer Products Company
A Division of Philips Electronics North America Corporation
450 North Medinah Road, Dock 16
Roselle, IL 60172-2329
Please allow 4-6 weeks for delivery of check. (Please Print)
Name_________________________________________________________
Address________________________________________________________
City___________________________________________________________
State_____Zip__________________________________________________
Daytime Telephone No. (____)_____________________________________
Email Address___________________________________________________
REASON FOR RETURNING:______________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
______________________________________________________________
AREA CODE
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 6 (Black plate)

Table of Contents
Features......................................................8-9
LED Battery Indicators.............................10
Charging ................................................10-11
Quick charge ..............................................12
Put It To The Test & Shaving Tips ............12
Personal Comfort Control................12-13
How To Shave With An
Electric Razor.......................................13-14
Trimming......................................................14
Cleaning.................................................15-18
Storage..........................................................18
Assistance....................................................19
Accessories.................................................19
Battery Removal ........................................20
Warranty .....................................................21
Spanish .........................................................22
ENGLISH 7
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 7 (Black plate)

8845 XL
Features
Spectra Shaving System
Personal Comfort
Control Dial
Razor Head Assembly
Protective Razor
Head Cap
Individually Floating
Heads
Razor Head
Release Button
• Hair Chamber
captures shaven hair
Electronic
ON/OFF Button
LED Low Battery Indicator
LED Battery Full Indicator
ENGLISH8
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 8 (Black plate)

Pop-Up Trimmer
Automatic
Worldwide Voltage
100V to 240V AC
Cleaning Brush
Travel/Storage Pouch
Rechargeable - Initial 4
hour Full Charge for up
to 45 minutes of
cordless shave time
1-Hour Quick Charge
Cord/Cordless - To
shave with or without a
cord
Full 2-Year Warranty
60-Day Money-Back
Guarantee
ENGLISH 9
How the Unique Norelco Lift and Cut®
Shaving System Makes Close Comfortable:
Groove channels beard
closer to cutting system Lifter raises hair Slots to cut long hairs Holes to cut short hairs even closer
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 9 (Black plate)

LED Battery Indicators
C
Low Battery Indicator
Left Light turns red when razor needs recharging.
When you turn razor off, the red light will blink for
4 seconds.
CFull Charge Indicator
When batteries have been fully charged the right,
green LED light will blink.
CCharging Indicator Light
The right Green LED Light will light up to indicate
razor is (re)charging.
Charging
◗Battery performance is best if you recharge
only when batteries are (almost) completely
empty.
◗Charging or recharging at temperatures below
40ºF or higher than 95ºF adversely
affects lifetime of batteries.
◗Continuously recharging or continuously using
as a corded razor will reduce life of batteries.
◗You may also shave using the charging plug
provided.This razor will not recharge while
being used corded.
ENGLISH10
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 10 (Black plate)

◗The charging plug transforms 100-240 volts to
a voltage lower than 24 volts.
◗Do not charge razor in pouch.
C1Connect cord to razor. Connect charging
plug into any 100V to 240V AC outlet. Use
only the charging plug provided.
The right green LED light will light up to indicate
razor is (re)charging and will blink when fully
charged.
◗An adaptor plug may be necessary for charging
plug usage in some foreign countries. Use an
attachment plug adaptor of the proper
configuration for the power outlet.
Your new razor will automatically convert to
work on 100V to 240V AC systems.
2First time charging and recharging after
non-use for 1 month or more requires a
full 4 hours.
When batteries are fully charged, the right green
LED light will blink.
Recharging
1First time charging requires 4 hours.After
initial charge, recharging requires
approximately 1 hour.
2When razor is fully charged, disconnect
the charging plug from outlet.
Do not keep razor permanently plugged into
outlet.
ENGLISH 11
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 11 (Black plate)

Quick Charge
When batteries are totally depleted, recharging
the razor for approximately 6 minutes gives
enough energy for a 3 minute cordless shave.
Put ItToTheTest & ShavingTips
◗21-DayTrial and Conversion Process. It is a fact
that your skin and beard need time to adjust to
any new shaving system.
◗Use your new razor exclusively for 3 weeks to
fully enjoy the closeness of a Norelco shave.
◗At first you may not get as close a shave as you
expect, or your face may even become slightly
irritated.This is normal since your beard and
skin will need time to adjust. Invest 3 weeks and
you’ll soon experience the full joy of your new
razor.
◗Stick with it! If you alternate shaving methods
during the adjustment period, it may make it
more difficult to adapt to the Norelco shaving
system.
◗If you are still not convinced after 21 days,
Norelco will refund you the full purchase price,
guaranteed.
Personal Comfort Control
C ◗Your Spectra razor has 9 adjustable settings that
allow you to personalize your shave for your
specific skin type from sensitive to normal skin.
You can select your personal comfort control
setting by turning the dial. Choose a comfort
control setting:
ENGLISH12
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 12 (Black plate)

C ◗For Sensitive Skin:
Choose a comfort control setting between
Neutral ' 'and Sensitive “S” to relax the spring
and pressure of floating heads against your skin
for a gentler, more comfortable shave.
C ◗For Normal Skin:
Choose a comfort control setting between
Neutral ' 'and Normal “N” to tighten the
spring and pressure of the floating heads against
your skin for a faster, more comfortable shave.
HowTo Shave With An Electric Razor
◗Use this razor for its intended household use as
described in this manual.
◗Shaving with a clean, dry face gives the best
results.
C1Turn razor ON. Shave against the direction
of beard growth using both straight and
circular movements.
2Stretch your skin with your free hand so
blades can lift and cut whiskers. Gently
press razor to skin, so the floating heads
can follow the contours of your face. DO
NOT press too hard.Too much pressure
can pinch the skin into the combs.
3Turn razor OFF.
ENGLISH 13
SENSITIVE
NORMAL
P
E
R
S
O
N
A
L
C
O
M
F
O
R
T
C
O
N
T
R
O
L
SENSITIVE
NORMAL
P
E
R
S
O
N
A
L
C
O
M
F
O
R
T
C
O
N
T
R
O
L
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 13 (Black plate)

ENGLISH14
C4Put the protective razor head cap on the
razor to protect razor heads.
Replace Spectra razor heads (model # HQ8)
once a year for optimal shaving results.
Trimming
To groom sideburns and moustache:
1Turn razor ON.
C2Push up Trimmer Slide Switch.
TheTrimmer can be activated while the razor is
running.
C3Hold Trimmer as shown and move in
downward strokes with gentle pressure.
4Close Trimmer by sliding Trimmer switch
down.
5Turn razor OFF.
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 14 (Black plate)

ENGLISH 15
Cleaning
Every week: Razor Heads
C ◗The easiest and most hygienic way to clean the
razor heads is to rinse them every week with
hot water.Water from the tap should be on a
hot setting.
BE CAREFULTO TEST WATER FIRST SO AS
NOT TO BURN OR SCALD HANDS.
◗Regular cleaning guarantees better shaving
results.
◗You may also quickly rinse your razor heads
after each use.
1Always turn razor OFF, remove the
charging plug from outlet and remove cord
from razor before cleaning.
C2Press the Razor Head Release Button, flip
open the Razor Head Assembly.
C3Clean razor heads and hair chamber by
running under hot water.
4Close the Razor Head Assembly and shake
off excess water.
C5Open Razor Head Assembly again and
leave open to air dry.
6You may also clean the hair chamber
without water by using the supplied brush.
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 15 (Black plate)

ENGLISH16
Once A month: Razor Heads
◗Do not mix up the cutters and combs as the
shaving performance may be adversely affected
for several weeks before optimal shaving
performance is restored.
1Turn razor OFF, remove the charging plug
from the outlet and cord from the razor.
C2Press the razor head release button, open
and lift off the razor head assembly.
C3Turn the center wheel counterclockwise,
and remove the retaining frame.
4Remove and clean one set of cutters and
combs at a time.
C5Separate the cutter from the comb and
rinse clean under hot water.
◗Do not clean more than one cutter and comb
at a time, since they are all matching sets. If you
accidentally interchange the cutters and combs,
it could take several weeks before optimal
shaving performance is restored.
C6Replace the set back into the Razor Head
Assembly so that the 'wings' on the comb
fit within the brackets located towards the
center of the assembly.
◗The set will only fit into the Razor Head
Assembly if the 'wings' are between the
brackets.
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 16 (Black plate)

Make sure that the two pointy edges of the comb
fit into the recesses.
7Repeat the process for the other two sets
of cutters and combs.
8Replace the frame.
C9Press down and turn wheel clockwise until
it locks into place.
10 Replace the Razor Head Assembly back on
razor.
Once A Month: Razor Heads
For optimum performance, razor cutters and
combs should be cleaned in a degreasing liquid
(e.g. Norelco Razor Cleaner, model RC1776, or
rubbing alcohol ) and lubricated, with Norelco
Razor Lubricant, model AL80, or one drop of
mineral oil (in the center of the head).This helps
prevent wear of the shaving heads.
After Each Use:Trimmer
1Turn razor OFF.
2Push Trimmer Slide Switch up to pop up
Trimmer.
C3Clean Trimmer with the brush every time
you use it.
ENGLISH 17
2
1
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 17 (Black plate)

C4Lubricate the Trimmer teeth with Norelco
Razor Lubricant (model AL80) or with one
drop of mineral oil every 6 months.
5Close Trimmer by sliding Trimmer switch
down.
This razor has no other user-serviceable parts.
Any other service should be performed by an
Authorized Norelco Service Location.
Storage
◗Be sure Razor is turned off. Remove cord from
outlet and Razor before storing in a safe, dry
location where it will not be crushed, banged,
or subject to damage.
◗Do not wrap cord around Razor when
storing.
◗Store cord in a safe location where it will not
be cut or damaged.
◗Do not place or store Razor where it can fall or
be pulled into a tub or sink, water or other
liquid while plugged in.
◗Put the Protective Razor Head Cap on razor
to protect heads.
ENGLISH18
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 18 (Black plate)

Assistance
◗For assistance or the Authorized Norelco
Service Location nearest you, call toll free:
1-800-243-3050
or visit our website: www.norelco.com
◗Authorized Norelco Service Location
information is available 24 hours a day, 7 days a
week.
Accessories
◗Replacement Heads
Model HQ8 - For maximum razor
performance, replace your Norelco Spectra
razor heads once a year.
◗Razor Cleaner
RC1776 - Norelco Razor Head Cleaner.
◗Razor Lubricant
AL80 - Norelco Razor Lubricant.
◗Car Cord Adaptor Cable
HQ8010 - Charges razor from a 12V battery
in your car, truck, van, boat or camper.
◗Norelco Razor Accessories may be purchased
at a store near you, an Authorized Norelco
Service Location, on our website
www.norelco.com or by using the order
form enclosed.
ENGLISH 19
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 19 (Black plate)

ENGLISH20
Battery Removal
◗This Norelco Razor contains rechargeable
Nickel-Cadmium batteries, which must be
disposed of properly.
◗Batteries should only be removed when razor
is to be discarded.
◗Refer to Battery Removal instruction sheet for
directions on removing the rechargeable
batteries.
8845XL 8846XL.QXD 2/25/04 3:44 PM Page 20 (Black plate)
