Philips Norelco User manual

ENGLISH 4
ESPAÑOL 40
S9721
Congratulations on your purchase and
welcome to Philips Norelco!
To fully benefit from the support that Philips
Norelco offers, register your product at
www.norelco.com/register
¡Felicitaciones en su compra y recepción
a Philips Norelco!
Beneficiar completamente de la ayuda
que las ofertas de Philips Norelco,
colocan su producto en
www.norelco.com/register
14_S9721.indd 3 12/15/14 3:32 PM

IMPORTANT SAFETY
INSTRUCTIONS
When using an electric appliance, basic precautions should
always be followed, including the following:
Read all instructions before using this appliance.
DANGER
To reduce the risk of electric shock:
1. Do not reach for a corded shaver/SmartClean System that
has fallen into water. Unplug immediately.
2. Power plug and the accessories connected to it are not for
immersion or for use in shower.
3. Do not use an extension cord with this appliance.
4. Do not place or store a SmartClean System where it can
fall or be pulled into a tub or sink. Do not place or drop a
SmartClean System into water or other liquid.
5. Always unplug this shaver/SmartClean System from the
electrical outlet immediately after use, except when shaver/
SmartClean System is (re)charging.
6. Unplug and remove power supply cord from shaver
before cleaning.
7. The batteries used in this device may present a fire or
chemical burn hazard if mistreated. Do not disassemble, heat
above 100ºC (212°F) or incinerate.
WARNING
To reduce the risk of burns, fire, electric shock, or
injury to persons:
1. Close supervision is necessary when this shaver/SmartClean
System is used by, on, or near children or invalids.
2. Use this shaver/SmartClean System for its intended
household use as described in this manual. Do not use
attachments or a cleaning cartridge not recommended by
ENGLISH
4
14_S9721.indd 4 12/15/14 3:32 PM

Philips Electronics North America Corporation.
3. Never operate this shaver/SmartClean System if it has a
damaged cord or charging plug, if it is not working properly,
if it has been dropped or damaged, or dropped into water
while plugged in. For assistance call 1-800-243-3050.
4. Keep the shaver/SmartClean System,cord and charging plug
away from heated surfaces.
5. Never drop or insert any object into any opening.
6. Do not clean, charge or plug in shaver/SmartClean System
outdoors or operate where aerosol (spray) products are
being used or where oxygen is being administered.
7. Do not use this shaver with a damaged or broken comb, as
facial injury may occur.
8. Always attach plug to shaver/SmartClean System first, then
plug into outlet and then put razor in SmartClean System.
Be certain plug is inserted firmly into shaver, up to mark
indicated on plug. To disconnect, turn SmartClean System
off, remove charging plug from outlet.
9. Never put the shaver/SmartClean System in direct sunlight
or store at a temperature above 140°F (60°C).
10.Keep the cord dry at all times. Do not handle with wet
hands.
11.To prevent possible damage to the cord, do not wrap cord
around the shaver/SmartClean System.
12.Only use the power plug and other accessories supplied
with the appliance.
SAVE THESE
INSTRUCTIONS
IMPORTANT: The power plug contains a transformer. Do
not cut off the power plug to replace it with another plug, as
this will cause a hazardous condition.
ENGLISH 5
14_S9721.indd 5 12/15/14 3:32 PM

ENGLISH
6
45 - DAY MONEY-BACK GUARANTEE
To enjoy the closest and most comfortable shave from your new Philips Norelco
Men’s Shaver, the shaver should be used exclusively for 3 weeks.This allows your
hair and skin enough time to adapt to the Philips Norelco Shaving System. If, after
that period of time, you are not fully satisfied with your Philips Norelco Men’s
Shaver, send the product back along with dated sales receipt and we’ll refund
you the full purchase price. The shaver must be shipped prepaid by insured
mail, insurance prepaid, have the original sales receipt, indicating pur-
chase price, the date of purchase, and the money-back guarantee return
authorization form enclosed.We cannot be responsible for lost mail.
The shaver must be postmarked no later than 45 days from the date of purchase.
Philips Norelco reserves the right to verify the purchase price of the shaver and
limit refunds not to exceed suggested retail price.
To obtain money-back guarantee return authorization form,
call 1-800-243-3050 for assistance. Delivery of refund check will
occur 6–8 weeks AFTER receipt of returned product.
14_S9721.indd 6 12/15/14 3:32 PM

7
Table of Contents
Features...................................................... 8-11
Multi-Level Display ................................12-14
Charge Meter ...............................................14
Before First Use .....................................14-15
Charging ...................................................15-17
Recharging .....................................................17
Quick Charge ...............................................17
Put It To The Test & Shaving Tips........17-18
How to Shave
With An Electric Shaver.......................18-20
Trimming ..................................................20-22
Travel Lock ....................................................22
Cleaning....................................................23-32
Replacing the Shaving Unit ..................32-36
Maintenance ..................................................36
Storage......................................................36-37
Assistance ......................................................37
Battery Recycling .........................................37
Accessories ...................................................38
Warranty........................................................39
Spanish............................................................40
ENGLISH
14_S9721.indd 7 12/15/14 3:32 PM

8ENGLISH
Features
Contour Detect Technology
Shaving Unit
• Hair Chamber
captures shaven
hair
Super Lift and
Cut Action
Electronic
On/Off Button
Personal Settings
Multi-Level Display
• Shows battery
charge
percentage
• Battery Charge,
Full & Low
Indicators
Cleaning
Indicator
Travel Lock
Replacement
Shaving Unit
Indicator
Blocked Shaving
Heads Indicator
14_S9721.indd 8 12/15/14 3:32 PM

9
Click-on Precision
Trimmer
Automatic Worldwide
Voltage 100V to 240V AC
Travel Pouch
Retaining Ring Holder
Rechargeable 1-hour full
charge for up to 50 min.
of cordless shaving time
Quick Charge
Cordless - To shave
without a cord
Full 2-Year Warranty
45-Day Money-Back
Guarantee
ENGLISH
14_S9721.indd 9 12/15/14 3:32 PM

10
14_S9721.indd 10 12/15/14 3:32 PM

ENGLISH
11
Features
SmartClean System Pro
SmartClean System Cap
Shaver Holder
On/Off Button
Charging
Indicator
Ready Indicator
Progress Bar
Cleaning
Cartridge
Replacement
Indicator
Drying
Indicator
Cleaning
Indicator
Cleaning Cartridge
Release Button
Cleaning Cartridge
14_S9721.indd 11 12/15/14 3:32 PM

12 ENGLISH
Multi-Level Display
◗Remove any sticker or protective foil from
the display before using shaver.
◗The display provides the following
information:
◗Charging Indicator
C-Quick charge:You will hear a beep when you
connect the power cord to an electrical outlet.
When the battery symbol rapidly blinks, the
shaver contains enough energy for one shave.
-When the shaver is charging, the battery charge
percentage and battery symbol slowly blink white.
-The remaining battery capacity is indicated by
the battery charge percentages on the display.
◗Full Charge Indicator
C-When the battery has been fully charged,
the battery charge percentage lights up
continuously. After approximately 30 minutes the
display automatically switches off again.
-If the on/off button is pressed during or after
charging, the shaver will beep indicating the shaver
is still connected to the outlet.
◗Remaining Battery Capacity
C-The remaining battery capacity is indicated by
the battery charge percentage on the display.
◗Low Battery Indicator
C -When the battery is almost empty (5 or less
shaving minutes left), the battery indicator blinks
orange and you will hear a beep.
14_S9721.indd 12 12/15/14 3:32 PM

13
ENGLISH
C◗Personal Settings
Choose between three speed settings that best
fits your skin and hair type: slow for a more skin-
friendly shave, normal for a thorough shave and
fast for a high powered shave. Press the – or +
buttons and the bar lights up white continuously.
C◗Replacement Shaving Unit Indicator
Every year, depending on your shaving behavior,
the replacement shaving unit indicator lights up
white continuously, the arrows blink white and
you will hear a beep. See 'Replacing the Shaving
Unit' section for instructions to reset the shaver.
This reminds you that with new shaving heads
you will guarantee yourself optimal shaving
performance.
C ◗ Blocked Shaving Heads Indicator
If the display shows a blinking replacement
shaving unit and faucet, a red exclamation mark
and the shaver beeps, clean the shaver thoroughly
before continuing to shave (see ‘Cleaning’). After
cleaning, if the blinking replacement shaving unit
and faucet with exclamation mark remain on the
display, immediately replace the shaving unit
(see ‘Replacing the Shaving Unit’).
C◗Cleaning Indicator
For optimal shaving performance, we
recommend cleaning the shaver after EACH use.
The blinking faucet will remind you the
shaving unit needs to be cleaned. This happens
after each shave.
14_S9721.indd 13 12/15/14 3:32 PM

14 ENGLISH
◗Travel Lock
The shaver is equipped with a travel lock function.
You can use the travel lock function when you are
going to store the shaver for a longer period or if
you are going to take the shaver with you when
traveling. See ‘Travel Lock’ section for instructions
on how to use this function.
Charge Meter
◗Charge Meter monitors amount of remaining
battery power available. Remaining battery
percentage is based on the amount of
power consumed shaving per minute and is
dependent upon your skin and beard type,
whether you use pre-shave lotion, and how
often the trimmer is used.
◗Initially your shaver may need to go through 2
or 3 full charge/recharge cycles before
remaining battery charge percentage indicator
begins to display your accurate battery power
left.
Before First Use
◗Charge the shaver before you start using it
(see ‘Charging’). Make sure the shaver is
switched off before you start charging it.
14_S9721.indd 14 12/15/14 3:32 PM

15
ENGLISH
◗Remove any sticker or protective foil from
the display before using shaver.
Important
◗Only use the power cord or SmartClean
System provided to charge the shaver.
◗The power plug transforms 100-240V AC to
less than 24V DC.
Charging
 ◗ Charging, recharging or storing at
temperatures below 40ºF or higher than 95ºF
adversely affects lifetime of batteries.
◗Charging or recharging requires one full hour.
◗A fully charged shaver has a shaving time of up
to 50 minutes.
◗You may recharge when the display indicates
the battery is almost empty.
◗This shaver will not operate corded directly
from the electrical outlet.
◗Do not charge shaver in a pouch.
C1Connect cord directly to shaver (1) and
connect the power plug into any 100V to
240V AC outlet (2). Use only the power
cord provided.
◗An adaptor plug may be necessary for power
cord usage in some foreign countries. Use
an attachment plug adaptor of the proper
configuration for the power outlet.
1
2
14_S9721.indd 15 12/15/14 3:32 PM

16 ENGLISH
The power cord will automatically convert to
work on 100V to 240V AC systems.
2The display on the shaver will indicate
shaver is charging.
3Charging requires one full hour. A fully
charged shaver has a cordless shaving time
of up to 50 minutes.
Charging Shaver with SmartClean
System
1Connect the small plug to the SmartClean
System. Connect the power plug into any
100V to 240V AC outlet. Use only the
power cord provided.
C 2Press the top cap to open the SmartClean
System.
C 3Hold the shaver head side down above the
shaver holder.
14_S9721.indd 16 12/15/14 3:32 PM

17
ENGLISH
C4Place the shaver into the holder (1), push
shaver back (2) and press down the top
cap to connect the shaver (3) (click).
The shaver will only fit in the SmartClean System
in one direction.
5The battery symbol slowly blinks to
indicate shaver is charging.
6Charging requires one full hour.A fully
charged shaver has a cordless shaving time
of up to 50 minutes.
C 7Press the top cap (1), pull the shaver
forward (2) and lift shaver from holder (3).
Recharging
1Recharging requires one full hour.
Recharge when the display indicates the
battery is almost empty.
Quick Charge
When batteries are totally depleted, recharging
the shaver for approximately 3-5 minutes gives
enough energy for a 3-minute cordless shave.
Put ItToTheTest & ShavingTips
◗21 Day Trial and Conversion Process.It is a fact
that your skin and beard need time to adjust to
a new shaving system.
3
1
2
3
1
2
14_S9721.indd 17 12/15/14 3:32 PM

18 ENGLISH
◗Use your new shaver exclusively for 3 weeks to
fully enjoy the closeness of a Philips Norelco
shave.
◗At first you may not get as close a shave as you
expect, or your face may even become slightly
irritated.This is normal since your beard and
skin will need time to adjust. Invest 3 weeks
and you’ll soon experience the full joy of your
new shaver.
◗Stick with it! If you alternate shaving methods
during the adjustment period, it may make it
more difficult to adapt to the Philips Norelco
shaving system.
◗If you are still not convinced after 21 days,
Philips Norelco will refund you the full
purchase price as long as the request is
received within 45 days of purchase.
HowTo ShaveWith An Electric Shaver
C◗ This symbol on the shaver indicates that the
shaver can be used in the bath or shower.
◗Make sure the SmartClean System does not
get wet or near water.
◗Use this shaver for its intended household use
as described in this manual.
Shaving
◗For best results pre-trim your beard if you
have not shaved for 3 days or longer.
14_S9721.indd 18 12/15/14 3:32 PM

19
ENGLISH
C1Turn shaver ON by pressing the on/off
button once. Shave against the direction
of beard growth using only circular
movements.
The shaver display will light up briefly.
BSelect your personal setting before using shaver.
(See 'Multi-Level Display' chapter).
2Stretch your skin with your free hand so
blades can lift and cut whiskers. Gently
press shaver to skin so the floating heads
can follow the contours of your face.
DO NOT press too hard.Too much
pressure can pinch the skin into the combs.
3Turn shaver OFF by pressing the on/off
button once.
The display lights up for a few seconds and then
shows the remaining battery charge percentage.
4Clean the shaver after each use (see
chapter ‘Cleaning’).
C5Place the shaver in the SmartClean System
to protect shaver heads.
Wet Shaving
You can also use the shaver on a wet face with
shaving foam or gel.
C1Apply some water to your skin.
14_S9721.indd 19 12/15/14 3:32 PM

ENGLISH
C2Apply shaving foam or gel to your skin.
3Rinse the shaving unit under the tap
to ensure that the shaving unit glides
smoothly over your skin.
4Press the on/off button once to switch on
the shaver.
C5Move the shaving heads in circular
movements over your skin.
NOTE: Rinse the shaver under the tap regularly
to ensure that it continues to glide smoothly over
your skin.
6Dry your face and thoroughly clean
the shaver after each use (see chapter
‘Cleaning’).
NOTE: Make sure you rinse all foam or gel off the
shaver.
C7Place the shaver in the SmartClean System
to protect heads.
Trimming
To Groom Sideburns and Moustache:
C1Pull the shaving unit straight off the shaver.
NOTE: Do not turn the shaving unit while you
pull it off the shaver.
20
14_S9721.indd 20 12/15/14 3:32 PM

ENGLISH
C2Insert the raised notch of the trimmer into
the slot in the top of the shaver. Press the
trimmer down to attach it to the shaver.You
will hear a ‘click’.
3Turn shaver ON.
The display lights up for a few seconds.
C4Hold trimmer to exact hairline desired.
Move trimmer downward with gentle
pressure.
5Trim beard, moustache or sideburns using
the trimmer.
6Turn shaver OFF when finished.
The display lights up for a few seconds and then
shows the remaining battery capacity charge
percentage.
7Thoroughly clean the trimmer after using
(see ‘Cleaning’).
C8 Pull the trimmer straight off the shaver.
NOTE: Do not turn or twist the trimming unit
while you pull it off the shaver.
C9 Insert the raised notch of the shaving unit
into the slot in the top of the shaver. Press
the shaving unit down to attach it to the
shaver.You will hear a ‘click’.
21
14_S9721.indd 21 12/15/14 3:32 PM

ENGLISH
C10 Place the shaver in the SmartClean System
to protect heads.
Travel Lock
If you are going to store the shaver for a longer
time period or if traveling, it is possible to lock the
shaver.The travel lock prevents the shaver from
being switched on by accident.
Activating the travel lock
C1Press the ON/OFF button for 3 seconds.

◗The travel lock symbol lights up white
continuously.
◗The shaver beeps and the lock symbol blinks.
2The travel lock has now been activated.
Deactivating the travel lock
1Press the ON/OFF button for 3 seconds.
C2The lock symbol blinks and then lights up
continuously. The shaver is now ready for
use.
BThe shaver unlocks automatically when charging in
the SmartClean System
22
3 se
c.
14_S9721.indd 22 12/15/14 3:32 PM
