Philips SBG315 User manual

SBG315
© & ™ Lucaslm Ltd.
© Disney

7mm
9/32in.
5mm
3/16in.
3mm
1/8in.
1
2
3
6
7
11
8
9
10
4
5

empty page before TOC

English 6
简体中文 19

English
Introduction
Congratulations on your purchase and welcome to
Philips! To fully benefit from the support that
Philips offers, register your product at
www.philips.com/welcome.
General description (Fig. 1)
1 Trimming comb (3mm/ 1/8in.)
2 Trimming comb (5mm/ 3/16in.)
3 Trimming comb (7mm/ 9/32in.)
4 Shaving foil
5 Shaving unit
6 On/off button
7 Battery status indicator
8 Socket for small plug
9 Supply unit
10 Small plug
11 Pouch
Important safety information
Read this important information carefully before
you use the appliance and its accessories and save
it for future reference. The accessories supplied
may vary for different products.
Danger
- Keep the supply unit dry.
Warning
- To charge the battery, only use the detachable
supply unit (HQ8505) provided with the
appliance.
6English

- The supply unit contains a transformer. Do not
cut off the supply unit to replace it with another
plug, as this causes a hazardous situation.
- This appliance can be used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental capabilities
or lack of experience and knowledge if they
have been given supervision or instruction
concerning use of the appliance in a safe way
and understand the hazards involved. Children
shall not play with the appliance. Cleaning and
user maintenance shall not be made by
children without supervision.
- Always unplug the appliance before you clean it
under the tap.
- Always check the appliance before you use it.
Do not use the appliance if it is damaged, as
this may cause injury. Always replace a
damaged part with one of the original type.
- Do not open the appliance to replace the
rechargeable battery.
Caution
- Do not use the supply unit in or near wall
sockets that contain an electric air freshener to
prevent irreparable damage to the supply unit.
- Only use this appliance for its intended purpose
as shown in the user manual.
- For hygienic reasons, the appliance should only
be used by one person.
- Never use water hotter than 60°C to rinse the
appliance.
- Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the
appliance.
7
English

Electromagnetic fields (EMF)
This Philips appliance complies with all applicable
standards and regulations regarding exposure to
electromagnetic fields.
General
- This appliance is waterproof. It is suitable for
use in the bath or shower and for cleaning
under the tap. For safety reasons, the appliance
can therefore only be used without cord.
- The supply unit is suitable for mains voltages
ranging from 100 to 240 volts.
- The supply unit transforms 100-240 volts to a
safe low voltage of less than 24 volts.
The display
Charging indications
Battery low
When the battery is almost empty, the battery
status indicator flashes orange.
Battery charging
When the appliance is charging, the battery status
indicator flashes green.
8English

Battery fully charged
When the battery is fully charged, the battery
status indicator light up green continuously.
Note: The battery status indicator goes out
automatically after 30 minutes.
Charging
Charge the appliance before you use it for the first
time and when the battery status indicator
indicates that the battery is almost empty.
Charging takes approx. 1 hour. A fully charged
appliance has a cordless operating time of up to
50 minutes.
Charging with the supply unit
1Make sure the appliance is switched off.
2Put the small plug in the appliance and put the
supply unit in the wall socket.
The battery status indicator indicates that the
appliance is charging.
3After charging, remove the supply unit from the
wall socket and pull the small plug out of the
appliance.
Using the appliance
Always check the appliance and all accessories
before use. Do not use the appliance or any
accessory if it is damaged, as this may cause
injury. Always replace a damaged part with one of
the original type.
Note: This appliance is for cordless use only.
- Use this appliance for its intended household
use as described in this user manual.
9
English

- For hygienic reasons, the appliance should only
be used by one person.
You can use the appliance wet or dry to shave hair
on all parts of your body below the neckline.
Trimming is easier when the skin and hairs are dry.
Note: Switch off and clean the appliance after each
use.
This symbol indicates that the shaver can be used
in the bath or shower.
Switching the appliance on and off
1To switch the appliance on or off, press the
on/off button once.
Removing or attaching trimming combs
1Make sure the appliance is switched off.
2To attach a comb,snap the front part of the
comb onto the teeth of the shaving unit and
push the projection at the back of the comb
into the appliance ('click').
3To detach a comb, carefully push it upwards off
the appliance and then remove the comb from
the shaving unit.
10 English

Trimming
Trimming tips
- If you are trimming for the first time, be careful.
Do not move the appliance too fast. Make
smooth and gentle movements.
- Since all hairs do not grow in the same
direction, you may want to try different
trimming positions (i.e. upwards, downwards, or
across). Practice is best for optimum results.
- Always make smooth and gentle movements
and make sure that the surface of the comb
always stays in contact with your skin.
- Body hair can be trimmed wet or dry. However,
trimming dry hair is preferable because wet hair
tends to stick to the body.
- When you trim sensitive areas, always use a
trimming comb.
Trimming with comb
Note: When you trim for the first time, start with
the longest comb to familiarize yourself with the
appliance.
Use a trimming comb attached to the shaving unit
to trim parts of your body below the neckline. The
appliance comes with 3 trimming combs. The hair
length settings are indicated on the combs. The
settings correspond to the remaining hair length
after trimming.
Comb mm inch
Trimming comb 3mm 1/8in.
Trimming comb 5mm 3/16in.
Trimming comb 7mm 9/32in.
11
English

1Attach a comb onto the shaving unit (see
'Removing or attaching trimming combs').
2Switch on the appliance (see 'Switching the
appliance on and off ').
3Move the appliance against the direction of hair
growth,.
Note: Make sure that the flat part of the
trimming comb is always fully in contact with
the skin.
4Switch off and clean the appliance after each
use.
Shaving
Shaving tips
This product is only intended for shaving and
trimming body parts below the neckline. Do not
use it to shave or trim facial or scalp hair.
- When shaving sensitive areas for the first time,
you may experience some discomfort, irritation
or reddening of the skin. This is normal as your
skin needs time to adjust to shaving.
- If your hair is longer than 10mm, trim hair to a
length of 3mm first for optimum shaving results.
- For dry use, make sure that your skin is clean
and dry before you use the shaving unit.
- For wet use, prepare your skin with lathered
soap or shaving foam before you use the
appliance.
Shaving with shaving unit
Use the shaving unit without comb to shave body
hair.
12 English

1Remove any trimming comb from the appliance
(see 'Removing or attaching trimming combs').
2Switch on the appliance (see 'Switching the
appliance on and off ').
3Stretch your skin taut with your free hand.
Gently press the shaving unit onto the skin and
move it slowly and smoothly against the
direction of hair growth.
- Do not press too hard. Too much pressure can
distort the foil and cause skin irritation.
- Make sure that the shaving unit is always in full
contact with your skin.
- The shaver is bi-directional, which means that
you can shave by moving the appliance up and
down. Shave against the direction of hair
growth for optimal performance.
4Switch off and clean the appliance after each
use.
Cleaning and maintenance
Regular cleaning guarantees better shaving
results.
Never clean, remove or replace a shaving or
cutting unit while the appliance is switched on.
Always check if the water is too hot, to prevent
burning your hands.
Never dry cutting units or shaving foils with a
towel or tissue, as this may cause damage.
Never use compressed air, scouring pads,
abrasive cleaning agents or aggressive liquids
such as petrol or acetone to clean the
appliance.
13
English

Cleaning the appliance
Clean the appliance after every use (see 'Cleaning
and maintenance').
1Switch off the appliance and disconnect it from
the wall socket.
2Remove the trimming comb from the appliance
and rinse it under the tap.
3Remove the shaving foil from the shaving unit.
Hold the shaving foil by the plastic housing
only.
Note: The foil is delicate. Handle the shaving foil
with care.
4Rinse the shaving foil under a warm running
tap.
5Rinse the hair chamber under a warm running
tap to remove any residue.
6Carefully shake off excess water and let all parts
air dry completely.
Never dry cutting units or shaving foils with a
towel or tissue, as this may cause damage.
7After cleaning, snap the shaving foil back into
the shaving unit.
14 English

Replacement
12M
TT2000
For maximum shaving performance, we advise you
to replace the shaving foil every year. Replace a
damaged shaving foil immediately. Always replace
the shaving foil with original Philips TT2000
shaving unit.
1Switch off the appliance and disconnect it from
the wall socket.
2Pull the shaving foil out of the shaving unit.
3Snap the new shaving foil into the shaving unit
('click').
Note: The foil is delicate. Handle the shaving foil
with care.
4Make sure the shaving foil is firmly attached
before you use the appliance.
Storage
1
2
1Undo the strap, put the appliance in the pouch
and fasten the strap.
2Put the combs in the pouch.
Note: Make sure that the appliance and its
attachments are dry before you store them.
3Hang or put the pouch in a safe place.
15
English

Ordering accessories
To buy accessories or spare parts, visit
www.shop.philips.com/service or go to your
Philips dealer. You can also contact the Philips
Consumer Care Center in your country (see the
international warranty leaflet for contact details).
Available accessories
The following accessories and spare parts are
available:
- TT2000 Philips replacement shaving foil.
Recycling
- Do not throw away the product with the normal
household waste at the end of its life, but hand
it in at an official collection point for recycling.
By doing this, you help to preserve the
environment.
- This product contains a built-in rechargeable
battery which shall not be disposed of with
normal household waste. Please take your
product to an official collection point or a
Philips service center to have a professional
remove the rechargeable battery.
- Follow your country’s rules for the separate
collection of electrical and electronic products
and rechargeable batteries. Correct disposal
helps prevent negative consequences for the
environment and human health.
Removing the rechargeable battery
Only remove the rechargeable battery when
you discard the product. Before you remove
the battery, make sure that the product is
disconnected from the wall socket and that
the battery is completely empty.
16 English

Take any necessary safety precautions
when you handle tools to open the product
and when you dispose of the rechargeable
battery.
1Check if there are screws in the back or front of
the appliance. If so, remove them.
2Remove the back and/or front panel of the
appliance with a screwdriver. If necessary, also
remove additional screws and/or parts until you
see the printed circuit board with the
rechargeable battery.
3Remove the rechargeable battery.
Warranty and support
If you need information or support, please visit
www.philips.com/support or read the
international warranty leaflet.
Warranty restrictions
Cutting units are not covered by the terms of the
international warranty because they are subject to
wear.

Troubleshooting
This chapter summarizes the most common
problems you could encounter with the product. If
you are unable to solve the problem with the
information below, visit www.philips.com/support
for a list of frequently asked questions or contact
the Consumer Care Center in your country.
Problem Possible cause Solution
The appliance
does not work.
The rechargeable
battery is empty.
Charge the battery (see
'Charging').
17
English

Problem Possible cause Solution
The appliance is
still attached to the
wall socket.
For safety reasons, the
appliance can only be
used without cord. Unplug
the appliance and switch
the appliance on.
The appliance
does nog work as
well as it used to.
The shaving foil is
damaged or worn.
Replace the shaving foil
(see 'Replacement').
Hair or dirt obstruct
the shaving foil.
Clean the shaving foil (see
'Cleaning and
maintenance').
The operating
time on a full
charge decreases.
Hair or dirt obstruct
the shaving foil.
Clean the shaving foil (see
'Cleaning and
maintenance').
Reduced
trimming and/or
shaving
performance.
The appliance is
used in the wrong
way.
Use this appliance for its
intended purpose as
shown in the user manual
(see 'Using the appliance').
The shaving foil is
dirty.
Clean the shaving foil (see
'Cleaning and
maintenance').
The battery is
running low.
Charge the battery (see
'Charging').
The trimming comb
is not attached
properly.
Reattach the trimming
comb (see 'Removing or
attaching trimming
combs').
You are trimming
very curly hair.
The trimming comb may
not be able to straighten
the hairs properly. Try
straightening the hair with
your hands during
trimming.
18 English

简体中文
简介
感谢您的惠顾，欢迎光临飞利浦！ 为了让您能充分享
受飞利浦提供的支持，请在 www.philips.com/welcome
上注册您的产品。
基本说明（图 1）
1 修剪梳（3 毫米/1/8 英寸）
2 修剪梳(5 毫米/3/16 英寸)
3 修剪梳（7 毫米/9/32 英寸）
4 剃毛刀网
5 剃须刀头部件
6 开/关按钮
7 电池状态指示灯
8 小插头插口
9 电源部件
10 小插头
11 存储袋
重要安全信息
使用本产品及其附件之前，请仔细阅读本重要信息，并
妥善保管以供日后参考。 随附的附件可能因产品而
异。
危险
- 保持电源部件干燥。
- 警告符号注释： 禁止在打开的水龙头下进行清洗。
警告
- 要给电池充电，请仅使用产品随附的可拆卸电源部
件 (HQ8505)。
- 电源部件中包含一个变压器。 请勿自行更换电源部
件的插头，否则将导致严重后果。
19
简体中文

- 本产品也可以由 8 岁或以上年龄的儿童以及肢体不
健全、感觉或精神上有障碍或缺乏相关经验和知识
的人士使用，但前提是有人对他们使用本产品进行
监督或指导，以确保他们安全使用，并且让他们明
白相关的危害。 切勿让儿童玩弄本产品。 不要让儿
童在无人监督的情况下对本产品进行清洁和保养。
- 手持部分与电源软线分开后，才能在水中清洗手持
部分。
- 使用前，请务必检查产品。 请勿使用损坏的产品，
否则可能对人体造成伤害。 请务必用原装型号更换
损坏的部件。
- 切勿拆开本产品更换充电电池。
警告
- 请勿在包含电动空气清新器的墙壁插座上或其周围
使用电源部件，以免电源部件受到不可修复的损
坏。
- 只能将本产品用于用户手册中所示的原定用途。
- 出于卫生的目的，本产品只能供一个人使用。
- 切勿使用温度高于 60°C 的热水冲洗本产品。
- 切勿使用压缩气体、钢丝绒、研磨性清洁剂或腐蚀
性液体（例如汽油或丙酮）来清洁产品。
电磁场 (EMF)
本 Philips 产品符合所有有关暴露于电磁场的适用标准
和法规。
概述
- 符号注释：适合于在洗澡或淋浴时使用。 允许在盛
水的浴缸、淋浴、洗脸盆或其他器皿附近使用本器
具。
- 该产品具有防水性能。 适合在沐浴或淋浴时使用，
也可以放在水龙头下清洗。 出于安全原因，该产品
在使用时不能连接电线。
- 电源部件适合在 100 - 240 伏的电源电压下工作。
- 该电源部件可将 100-240 伏的电压转换为 24 伏以
下的安全低电压。
20 简体中文
