Philips HTS3000 User manual

HTS3000/
HTS3000/
55/98
55/98
7
1-2
1-2
1-3
1-4
1-5
1-6
1-7
2
3
4
5
6
7
8
9
DVD Home Theatre System
313 978532 750

LOCATION OF PCB BOARDS
VERSION VARIATION:
1-2
STANDY PCB
CONTROL PCB
VOL PCB
TUNER PCB
MAIN PCB
POWER PCB
Type/Version
Feature & Board in used
HTS3000
/55
Main PCB ( Power Output 200W)
Power Voltage ( 120/230V )
WMA
X
X
X
X
X
X
/98

1-3
Specications
AMPLIFIER
Total output power
-Home Theater Mode: .................................................... 200 W
Frequency Response: ....................... 180 Hz – 18 kHz / ±3 dB
Signal-to-Noise Ratio: ..............................> 60 dB (A-weighted)
Input Sensitivity
- AUX In : ...................................................................... 500 mV
- TV In: .......................................................................... 250 mV
RADIO
Tuning Range: .............................................FM 87.5–108 MHz
.............................................................................. (50k/100kHz)
.......................................................... AM 531–1602 kHz (9kHz)
........................................................ AM 530–1700 kHz (10kHz)
26 dB Quieting
Sensitivity: ....................................... FM 22 dBf, AM 5000μV/m
IF Rejection Ratio: ................................... FM 60 dB, AM 24 dB
Signal-to-Noise Ratio:.............................. FM 50 dB, AM 30 dB
AM Suppression Ratio: ..............................................FM 30 dB
Harmonic Distortion:............................................ FM Mono 3%
............................................................................ FM Stereo 3%
........................................................................................AM 5%
Frequency Response ...................... FM 180 Hz–9 kHz / ±6 dB
Stereo Separation ......................................... FM 26 dB (1 kHz)
Stereo Threshold ....................................................FM 23.5 dB
DISC
Laser Type Semiconductor
Disc Diametre .........................................................12cm / 8cm
Video Decoding ........................................MPEG-1 / MPEG-2 /
............................................................................../ DivX 3/4/5/6
Video DAC..................................................................... 12 Bits
Signal System ........................................................PAL / NTSC
Video Format............................................................. 4:3 / 16:9
Video S/N ...................................................... 56 dB (minimum)
Composite Video
Output ................................................................. 1.0 Vp-p, 75Ω
Audio DAC ....................................................... 24 Bits / 96 kHz
Frequency Response ......................... 4 Hz–20 kHz (44.1 kHz)
................................................................ 4 Hz–22 kHz (48 kHz)
................................................................ 4 Hz–44 kHz (96 kHz)
PCM ......................................................................... IEC 60958
Dolby Digital ......................................... IEC 60958, IEC 61937
MAIN UNIT
Power Supply Rating: ............................ 110-240 V~; 50-60 Hz
Power Consumption: ........................................................ 40 W
Dimensions:....................................... 360 x 48.5 x 324.1 (mm)
...................................................................................(w x h x d)
Weight: ..........................................................................2.58 kg
FRONT AND REAR SPEAKERS
System: ........................................................ Full range satellite
Impedance: ..........................................................................4 Ω
Speaker drivers: ....................................... 3” full range speaker
Frequency response:...................................... 150 Hz – 20 kHz
Dimensions: ......................................... 100 x 95.5 x 83.5 (mm)
...................................................................................(w x h x d)
Weight: .................................................................0.47 kg/each
CENTRE SPEAKER
System:........................................................ Full range satellite
Impedance: ..........................................................................8 Ω
Speaker drivers: .......................................3” full range speaker
Frequency response:...................................... 150 Hz – 20 kHz
Dimensions:......................................... 100 x 95.5 x 83.5 (mm)
...................................................................................(w x h x d)
Weight: ..........................................................................0.52 kg
SUBWOOFER
Impedance:.......................................................................... 8 Ω
Speaker drivers: ..................................... 165 mm (6.5”) woofer
Frequency response: ........................................40 Hz – 150 Hz
Dimensions: ........................................ 131 x 386 x 315.5 (mm)
...................................................................................(w x h x d)
Weight: ..........................................................................3.60 kg
Specications subject to change without prior notice.

Measurement Setup
Tuner AM (MW,LW)
T
uner FM
CD
Bandpass
Bandpass
1-4

1-6
NL
WAARSCHUWING
Alle IC’s en vele andere halfgeleiders zijn
gevoelig voor electrostatische ontladingen
(ESD).
Onzorgvuldig behandelen tijdens reparatie kan
de levensduur drastisch doen verminderen.
Zorg ervoor dat u tijdens reparatie via een
polsband met weerstand verbonden bent met
hetzelfde potentiaal als de massa van het
apparaat.
Houd componenten en hulpmiddelen ook op
ditzelfde potentiaal.
I
AVVERTIMENTO
Tutti IC e parecchi semi-conduttori sono
sensibili alle scariche statiche (ESD).
La loro longevità potrebbe essere fortemente
ridatta in caso di non osservazione della più
grande cauzione alla loro manipolazione.
Durante le riparazioni occorre quindi essere
collegato allo stesso potenziale che quello della
massa dell’apparecchio tramite un braccialetto
a resistenza.
Assicurarsi che i componenti e anche gli utensili
con quali si lavora siano anche a questo
potenziale.
GB
Safety regulations require that the set be restored to its original
condition and that parts which are identical with those specified,
be used.
Safety components are marked by the symbol
!
.
NL
Veiligheidsbepalingen vereisen, dat het apparaat bij reparatie in
zijn oorspronkelijke toestand wordt teruggebracht en dat onderdelen,
identiek aan de gespecificeerde, worden toegepast.
De Veiligheidsonderdelen zijn aangeduid met het symbol
!
.
F
Les normes de sécurité exigent que l’appareil soit remis à l’état
d’origine et que soient utiliséés les piéces de rechange identiques
à celles spécifiées.
Less composants de sécurité sont marqués
!
.
D
Bei jeder Reparatur sind die geltenden Sicherheitsvorschriften zu
beachten. Der Original zustand des Geräts darf nicht verändert werden;
für Reparaturen sind Original-Ersatzteile zu verwenden.
Sicherheitsbauteile sind durch das Symbol
!
markiert.
I
Le norme di sicurezza esigono che l’apparecchio venga rimesso
nelle condizioni originali e che siano utilizzati i pezzi di ricambio
identici a quelli specificati.
Componenty di sicurezza sono marcati con
!
.
GB
After servicing and before returning set to customer perform a leakage
current measurement test from all exposed metal parts to earth ground
to assure no shock hazard exist, The leakage current must not
exceed 0.5mA.
CLASS 1
LASER PRODUCT
3122 110 03420
GB
Warning !
Invisible laser radiation when open.
Avoid direct exposure to beam.
S
Varning !
Osynlig laserstrålning när apparaten är öppnad och spärren
är urkopplad. Betrakta ej strålen.
SF
Varoitus !
Avatussa laitteessa ja suojalukituksen ohitettaessa olet alttiina
näkymättömälle laserisäteilylle. Älä katso säteeseen!
GB
WARNING
All ICs and many other semi-conductors are
susceptible to electrostatic discharges (ESD).
Careless handling during repair can reduce life
drastically.
When repairing, make sure that you are
connected with the same potential as the mass
of the set via a wrist wrap with resistance.
Keep components and tools also at this
potential.
F
ATTENTION
Tous les IC et beaucoup d’autres
semi-conducteurs sont sensibles aux
décharges statiques (ESD).
Leur longévité pourrait être considérablement
écourtée par le fait qu’aucune précaution n’est
prise à leur manipulation.
Lors de réparations, s’assurer de bien être relié
au même potentiel que la masse de l’appareil et
enfiler le bracelet serti d’une résistance de
sécurité.
Veiller à ce que les composants ainsi que les
outils que l’on utilise soient également à ce
potentiel.
ESD
D
WARNUNG
Alle ICs und viele andere Halbleiter sind
empfindlich gegenüber elektrostatischen
Entladungen (ESD).
Unsorgfältige Behandlung im Reparaturfall kan
die Lebensdauer drastisch reduzieren.
Veranlassen Sie, dass Sie im Reparaturfall über
ein Pulsarmband mit Widerstand verbunden
sind mit dem gleichen Potential wie die Masse
des Gerätes.
Bauteile und Hilfsmittel auch auf dieses gleiche
Potential halten.
DK Advarse !
Usynlig laserstråling ved åbning når sikkerhedsafbrydere er
ude af funktion. Undgå udsaettelse for stråling.
F
"Pour votre sécurité, ces documents doivent être utilisés par
des spécialistes agréés, seuls habilités à réparer votre
appareil en panne".
GB
ESD PROTECTION EQUIPMENT
Complete Kit ESD3 (small tablemat, wristband,
connection box, estention cable and earth cable .......4822 310 10671
Wristband tester .................................................................4822 344 13999

1-7
Pb(Lead) Free Solder
When soldering , be sure to use the pb free solder.
INDENTIFICATION:
Regardless of special logo (not always indicated)
onemusttreatallsetsfrom1Jan2005onwards,according
next rules:
Important note: In fact also products of year 2004 must
betreatedinthiswayaslongasyouavoidmixingsolder-
alloys(leaded/lead-free).SobesttoalwaysuseSAC305
and the higher temperatures belong to this.
Due to lead-free technology some rules have to be
respected by the workshop during a repair:
•Use only lead-free solder alloy Philips SAC305 with
ordercode 0622149 00106.Iflead-freesolder-paste
is required, please contact the manufacturer of your
solder-equipment. In general use of solder-paste
withinworkshopsshouldbeavoidedbecausepasteis
not easy to store and to handle.
•Use only adequate solder tools applicable for lead-
free solder alloy. The solder tool must be able
–To reach at least a solder-temperature of 400°C,
–Tostabilizetheadjustedtemperatureatthesolder-
tip
–To exchange solder-tips for different applications.
•Adjust your solder tool so that a temperature around
360°C–380°Cisreachedandstabilizedatthesolder
joint.Heating-timeofthesolder-jointshouldnotexceed
~ 4 sec.Avoid temperatures above 400°C otherwise
wear-out of tips will rise drastically and flux-fluid will
be destroyed. To avoid wear-out of tips switch off un-
used equipment, or reduce heat.
•Mixoflead-freesolderalloy/partswithleadedsolder
alloy / parts is possible but PHILIPS recommends
stronglytoavoidmixedsolderalloytypes(leadedand
lead-free).
Ifonecannotavoidordoesnotknowwhetherproduct
is lead-free, clean carefully the solder-joint from old
solder alloy and re-solder with new solder alloy
(SAC305).
•Use only original spare-parts listed in the Service-
Manuals. Not listed standard-material (commodities)
has to be purchased at external companies.
•Special information for BGA-ICs:
–Always use the 12nc-recognizable soldering
temperature profile of the specific BGA (for de-
solderingalwaysusethelead-freetemperatureprofile,
in case of doubt)
–Lead free BGA-ICs will be delivered in so-called ‘dry-
packaging’(sealedpackincludingasilicagelpack)to
protect the IC against moisture. After opening,
dependentofMSL-levelseenonindicator-labelinthe
bag, the BGA-IC possibly still has to be baked dry.
(MSL=Moisture Sensitivity Level). This will be
communicated via AYS-website.
Do not re-use BGAs at all.
•Forsetsproduced before1.1.2005 (exceptproducts
of 2004), containing leaded solder-alloy and
components,all neededspare-parts willbe available
till the end of the service-period. For repair of such
sets nothing changes.
•Onourwebsitewww.atyourservice.ce.Philips.com
you find more information to:
•BGA-de-/soldering (+ baking instructions)
•Heating-profiles of BGAs and other ICs used in
Philips-sets
You will find this and more technical information
within the “magazine”, chapter “workshop news”.
For additional questions please contact your local
repair-helpdesk.

2 - 12 - 1
System , Region Code , etc. Setting Produre
1)System Reset
a) press “system “ buttom on R/C,TV show “setup“
b) select the menu using the and on R/C
c) go preference page to do sysytem reset
3)Version Control Change
a) In open model, press “1“ “5“ “9“ on R/C
b) press “ok” buttom to comrm
c) TV will show message as below:
2)Region Code Change
a) press the “stop” buttom on R/C in open model
c) press”7” “3“ “4“ “4“ “6“ “6“ on R/C,then input desired number
to change region code :
1 USA
2 EU
3 AP
4 Australia ,NZ , Latam
5 Russia , INDIA
6 CHINA
Current model 3000-55 3000-98
Ver 00.18.00-70301-00 region : 4/ 3
Servo: OF.60.00.00
8032: 05.00.04.06 RISC:00.00.02.07
IF current model does not match you set use down arrow
key on the remote to change
4)Password Change
a) press “system “ buttom on R/C,TV show “setup“
b) select the menu using the and on R/C
c) go preference page select “password“ to change
* 000000 is default password supplied.
5)Check on the Sofeware Version
a)open the CD Door
b) press “display“ buttom on R/C
c) TV will show the version on screen
6)Upgrading new sofeware
a)open the CD Door,then insert the CD-R program disc
b)close the DOOR
c) TV will show:
“loading“
pop message“upgrading“
“writing” about 2 minutes
“done “
* the latest upgraded is in version VER 00.18.00-70301-00
C AUTION !
This information is con ncial and may not
be distributed. Only a quadservice
person should reprogram the R egion Code.

2 - 22 - 2
REPAIR INSTRUSTRATOR
Ok or No Chang F901
OK
Check
D902/903/904/908
D909/911/912
OK or No
No
No
OK
CHANG
D902/903/904/908
D909/911/912
Check Repair
IC901/IC902/IC903
/Q902 or output circuit

3 - 1 3 - 1
DISASSEMBLY INSTRUCTIONS
Dismantling of the Front Panel Assembly
1) Open the DVD Tray by using the Open/Close Button
while the Set is ON and disconnect the mains supply after
removing the Tray Cover.
Note: If this is not possible, the DVD Tray
has to be open manually.
Take a mini screw driver about 2mm diameter and make a
marking 24mm from the tip as shown in gure 2 . Place the
set on its side, insert the mini screw driver till the marking
and slide it towards the left as shown in gure 1 until the
Tray moves out of the Front Panel.
2) Return the set to its upright position and remove the Tray
Cover as shown in Figure 3 and close the tray manually by
pushing it back in.
3) Loosen 5 screws and remove the Top Cover by lifting the
rear portion upwards before sliding it out towards the rear.
- 3 screws on the back
- 1 screws each on the left & right side
4) Loosen 6 screws & lift up the top edge of Front Panel
assembly to free some catches before sliding it out towards
the front.
- 3 screws on the bottom
- 1 screw on the inside
- 1 screw each on the left & right side
Figure 3
Figure 2
Dismantling of the Main PCB
1) Loosen 4 screw “ A “ on the top of main board as shown in
gure 4.
2) Loosen 4 screw “B” at the back panel as shown in gure 5.
Figure 4
Figure 5
Figure 1
B

3 - 2 3 - 2
Dismantling of the DVD Module
1) Loosen 4 screws “E” to remove the DVD Module as shown in
gure 8
Dismantling of the Power Board
1) Loosen 4 screws “D” at the top of the Power Board as shown in
gure 7
Dismantling of the Control Board
1) Loosen 9 screws “ C” at the back pancle as shown in gure 6
Note:In some service positions the components or copper patterns of one board may risk touching its neighbouring pc boards or
metallic parts. To prevent such short-circuit use a piece of hard paper or other insulating material between them.
Figure 7
Figure 6
Figure 8
Service Position

4 - 1
4 - 1
BLOCK DIAGRAM
CONTROL PCB
POWER PCB
MAIN PCB

4 - 2
4 - 2
WIRING DIAGRAM
TUNER PCB
MAIN PCB
DVD LOADER
POWER PCB
CONTROL PCB
VOL PCB
VFD PCB
USB PCB
MIC/MP3 PCB

5 - 1 5 - 1
CONTROL BOARD
TABLE OF CONTENTS
FTD Display Pin Assignment............................................................. 5-1
Voltage .............................................................................................. 5-2
Circuit Diagram.................................................................................. 5-3
PCB Layout Top & Bottom View........................................................ 5-4
FTD DISPLAY PIN ASSIGNMENT

5 - 2 5 - 2
VOLTAGE
Pin NO b c e
Voltage 4.7 -0.9 0
˜˖˅˃˃ʳʻʳ˩ˉˆ˄˄˄ʳʼ
Pin NO 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Voltage 2.1 2.4 0 4.6 3.2 4.3 4 3.2 3.2 0 0 0 4.8 -18.9 -25.3 -25.3 -25.3 -25.3 -16.4 23.2
Pin NO 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
Voltage -16 -18.6 -1836 -20.8 -25.3 -25.3 -16.5 -18.7 -16.5 -25.4 -25.4 23.2 4.7 -25.7 -23.2 -23.2 -23.2 -23.2 -23.2 -23.2
Pin NO 41 42 43 44 45 46 47 48 49 50 51 52
Voltage -23.2 -23.2 -23.2 -23.2
ˇˁˊ ˇˁˊ ˃ ˃ ˃ ˄ˁˈ ˃ ˅ˁˆ
Q200

5 - 3 5 - 3
CIRCUIT DIAGRAM
1234
1234
A
B
C
A
B
C
C200 A2
C201 A2
C202 B2
C203 A2
C204 B2
C205 B2
C206 B2
C207 B2
C208 B2
C209 B2
C210 B2
C211 B2
C212 B2
C213 C2
C214 C2
C215 C2
C216 B2
C217 C4
C218 C4
C219 C1
C220 C1
C221 C2
C225 B3
C226 B3
C288 A4
C289 B4
D200 C1
D201 C1
D202 B1
D203 C1
DP200 A1
FB200 B4
IC200 B1
LD200 C4
Q200 C3
R200 A2
R201 A2
R202 A2
R203 A2
R204 B2
R205 B2
R206 C1
R207 C1
R208 C1
R209 C1
R210 C4
R211 B3
R212 B2
R213 C2
R214 C2
R215 C2
R217 B2
R218 C3
R219 C3
R225 C3
R226 C3
RB200AA4
CN203 B4
RB204 B3
SN200 B2
TA200 C1
TA201 C1
TA202 C1
TA203 C1
TA204 C1
TA205 C4
VR200 A4
XL200 B2
ZD200 A2
ZD201 C4
ZD202 C4
ZD203 A2
ZD204 A3
ZD205 B2

5 - 4 5 - 4
PCB LAYOUT - TOP VIEW
PCB LAYOUT - BOTTOM VIEW
123
123
A
B
C
A
B
C
123
123
A
B
A
B
C208 B3
C209 A3
C216 B1
CN203 A3
D200 B4
D201 B4
D202 B1
D203 B2
DP200 B2
JW1 B1
JW10 B3
JW11 B3
JW12 B3
JW13 B3
JW14 B3
JW15 B3
JW16 B3
JW17 B4
JW18 B4
JW19 B4
JW2 A1
JW20 B4
JW21 A1
JW22 A3
JW3 B1
JW4 B1
JW5 B1
JW6 B2
JW7 B2
JW8 B2
JW9 B3
LD200 A1
R200 B3
R201 B3
R202 B3
R203 B3
R211 B2
R213 B1
R214 B2
R215 B1
R219 B1
RB200A A4
RB204 B1
SN200 B3
TA200 B4
TA201 B4
TA202 B1
TA203 B4
TA204 B4
TA205 A1
VR200 A3
XL200 B2
ZD200 B3
ZD205 B2
ZD204 B3
ZD203 B2
ZD202 A4
ZD201 A4
R226 B4
R225 B4
R218 B4
R217 B4
R212 B3
R210 A4
R209 B1
R208 B1
R207 B1
R206 B4
R205 B2
R204 B2
Q200 B4
IC200 B3
FB200 A3
C289 A2
C288 A2
C226 B4
C225 B4
C221 B1
C220 B1
C219 B1
C218 A4
C217 A4
C215 B3
C214 B4
C213 B4
C212 B3
C211 B3
C210 B2
C207 B3
C206 B2
C205 B3
C204 B2
C203 B3
C202 B2
C201 B2
C200 B2

6 - 1 6 - 1
MAIN BOARD
TABLE OF CONTENTS
Internal IC Diagram ........................................................................... 6-1
Circuit Diagram.................................................................................. 6-2
PCB Layout Top View ....................................................................... 6-3
PCB Layout Bottom View .................................................................. 6-4
Voltage .............................................................................................. 6-5
28 27 26 25 21
2223
24 20 19 18 1516 17
MUTE
Thermal
Shut dowm
10k
10k
10k
10k
25k
25k
25k
15k
Vcc1
1234567891011 12 13 14
VINFC TRB-1 RSGO2 VINSL+ REGO1 FWD REV VCC1 VOTR- VOTR+ VOSL+ VOSL- VOFC- VOFC+
MUTE BLAS VINTK TRB-2 NC VINLD GND VCTL NC VCC2 VOLD- VOLD+ VOTK- VOTK+
RGND VCC1
Prc-DRV TRA Y
DRIVER
Sled
Driver(4X) Actuator Driver(6X)
Spindle
Driver(4X) Driver(6X)
Actuator
Vcc2
Vcc2
+
-
+
-
+ -
+ -
+ -
+ -
INTERNAL IC DIAGRAM - CO4558A SO8
INTERNAL IC DIAGRAM - V5888S HOSP

6 - 2 6 - 2
Circuit Diagram
1234
1234
A
B
C
D
A
B
C
D
C1001 D3
C1002 D3
C1003 D3
C1004 D3
C1005 D3
C1006 D3
C1007 D3
C1008 D3
C1009 D3
C101 D2
C1010 D3
C1011 D4
C1012 D3
C1013 D3
C1015 D4
C1016 D4
C1017 D4
C1018 D4
C1019 D4
C102 D2
C1020 D4
C1021 D4
C1022 D4
C1023 D4
C1024 D4
C1025 D4
C1026 D4
C1027 D4
C103 D2
C110 D1
C1101 B2
C1102 B2
C1103 B2
C1104 B3
C1105 A2
C1106 A2
C1107 A2
C1108 A3
C111 D1
C1110 A3
C1111 A3
C1112 A3
C1113 A3
C1114 A3
C1117 A3
C112 D1
C113 D1
C1136 C3
C114 D1
C116 D1
C117 D1
C118 D1
C119 D1
C120 D1
C121 D1
C122 D1
C123 D1
C124 D3
C125 D3
C126 D3
C127 D3
C128 C3
C129 C3
C130 B3
C131 B2
C132 B2
C133 C2
C134 C2
C135 C2
C136 B2
C137 B2
C139 B2
C140 B2
C141 B2
C142 B2
C144 B2
C157 B1
C158 B1
C159 B1
C160 B1
C162 B1
C165 B1
C166 B1
C179 C4
C180 C4
C181 C4
C182 C4
C183 C4
C184 C4
C185 C4
C186 C4
C188 C4
C189 D1
C190 C4
C191 C4
C193 D4
C194 D4
C195 C4
C196 C4
C197 C4
C301 A1
C302 A1
C303 A1
C304 A1
C315 A1
C316 A1
C317 A1
C318 A1
C319 A1
C320 A1
C321 A1
C322 A1
C323 A1
C324 A1
C325 A1
C326 A1
C327 A1
C328 A1
C329 A1
C330 A1
C332 A1
C334 A1
C335 A1
C336 A1
C339 A2
C340 A2
C341 A2
C342 A2
C343 A2
C344 A2
C345 A2
C346 A2
C347 A2
C348 A2
C349 A2
C350 A2
C401 B3
C402 B3
C403 B3
C404 B3
C405 B3
C406 B3
C407 B3
C408 B3
C409 B3
C410 B3
C411 B3
C412 B3
C413 B3
C414 B3
C415 B3
C416 B3
C417 B3
C418 B3
C419 B3
C420 B3
C421 B3
C422 B3
C423 B3
C425 B3
C426 B3
C427 B3
C431 B3
C432 B3
C433 B3
C434 B3
C435 C3
C436 C3
C437 C3
C438 C3
C439 B3
C440 C3
C441 C3
C502 B4
C504 B4
C505 B4
C506 B4
C507 B4
C508 B4
C509 B4
C520 B4
C521 B4
C523 B4
C524 B4
C525 B4
C526 B4
C527 A4
C528 B4
C529 B4
C530 B4
C533 B4
C534 B4
C537 B4
C538 B4
C539 B4
C540 B4
C541 B4
C542 C4
C544 C4
C545 C4
C546 C4
C547 C4
C548 C4
C549 C4
C550 B4
C551 B4
C553 B4
C554 B4
C555 B4
C556 B4
C557 B4
C558 C4
C559 B4
C560 B4
C563 B4
C564 B4
C567 B4
C568 B4
C569 C3
C570 C3
C571 C3
C572 B4
C573 B4
C574 B4
C575 B4
C576 C4
C577 C4
C578 B4
C579 B4
C580 B4
C581 B4
C582 B4
C583 B4
C802 B2
C803 B2
C804 B2
C805 C2
C806 C2
C807 B2
C808 B2
C809 B2
C810 C2
C811 B2
C812 B2
C813 B2
C814 B2
C815 C2
C816 B2
C817 B2
C818 B2
C819 C1
C820 C1
C823 C2
C824 C2
C825 C2
C826 C2
C827 C2
C828 C2
C829 C2
C830 C2
C831 C2
C833 C1
C834 C1
C835 C1
C836 C1
C838 C1
C839 C1
C840 C1
C841 C1
C842 C1
C843 C1
C844 C1
C845 C1
C846 C1
C847 C2
C848 C2
C849 C2
C850 C1
C851 C1
C852 C1
C853 C1
C854 C1
C855 C1
C856 D1
C857 D1
C858 D1
CN101 D1
CN103 B1
CN104 B1
CN801 C1
CN802 D1
CN803 C1
D101 D1
D102 D1
D103 D1
D104 D1
D105 D1
D105 D1
D106 D1
D107 D1
D108 D1
D109 D1
D401 B3
D402 B3
D403 C3
D801 C1
D802 C1
FB101 D2
FB104 D1
FB105 D1
FB106 D1
FB107 D1
FB108 D1
FB109 D1
FB110 D3
FB1101 A3
FB1102 A2
FB1103 A3
FB111 D3
FB1111 A3
FB1112 A3
FB112 C3
FB113 B2
FB114 B2
FB115 B2
FB116 B1
FB121 C4
FB122 C4
FB123 C4
FB124 C4
FB125 B1
FB126 B1
FB127 B1
FB128 D3
FB401 B3
FB801 B2
FB802 B2
FB803 C1
FB804 C1
FB805 D1
IC101 C2
IC102 C3
IC103 D3
IC104 D2
IC105 D3
IC302 A1
IC303 A1
IC304 A1
IC305 A2
IC401 B3
IC501 B4
IC502 B4
IC801 C1
JK301A A1
JK501 B4
JK1103 A3
JK501A B4
L1101 A2
L1102 A2
L1103 A2
L1104 A2
L302 A2
L307 A2
L308 A2
L501 B4
L502 B4
L503 B4
L504 A4
L505 C4
L506 C4
L507 C4
L508 B4
L511 B4
L514 B4
Q101 D1
Q102 D1
Q103 D1
Q104 B1
Q107 C3
Q110 C3
Q111 C3
Q301 A2
Q401 A3
Q402 B3
Q403 C3
Q801 C1
Q802 C1
R106 D1
R107 D1
R108 D1
R109 D1
R110 D1
R1101 B2
R1102 B2
R1103 B2
R1104 B3
R1105 A3
R1107 A3
R111 D1
R1110 A3
R1114 A3
R112 D1
R113 D1
R114 D1
R115 D2
R117 D2
R118 D2
R119 D2
R120 D3
R121 D3
R122 D3
R123 D3
R124 D3
R125 D3
R126 C3
R127 C3
R128 B3
R129 C2
R130 B2
R131 B2
R133 B2
R134 B2
R146 B1
R147 B1
R151 B1
R152 B1
R153 B1
R155 B1
R156 B1
R157 B1
R158 B1
R159 C3
R160 D3
R162 C4
R163 C4
R165 A2
R166 B1
R167 B1
R180 C3
R181 C3
R182 D2
R186 C3
R187 C3
R188 C3
R3001 A2
R3002 A2
R301 A1
R3012 A2
R302 A1
R303 A1
R304 A1
R315 A1
R316 A1
R317 A1
R318 A1
R319 A1
R320 A1
R321 A1
R322 A1
R323 A1
R324 A1
R325 A1
R326 A1
R328 A1
R329 A1
R330 A1
R332 A1
R335 A1
R336 A1
R337 A1
R338 A1
R340 A1
R342 A1
R343 A2
R344 A2
R345 A2
R346 A2
R347 A2
R348 A2
R349 A2
R350 A2
R353 A2
R354 A2
R355 A2
R357 A2
R358 A2
R401 B3
R402 B3
R403 B3
R404 B3
R405 B3
R406 B3
R407 B3
R408 A3
R410 B3
R416 B3
R418 B3
R419 B3
R421 B3
R422 B3
R423 B3
R501 B4
R502 B4
R503 B4
R505 A4
R506 B4
R507 B4
R508 B4
R509 B4
R510 B4
R511 B4
R512 B4
R514 B4
R515 C4
R516 C4
R517 C4
R519 B4
R520 B4
R521 B4
R522 B4
R523 B4
R524 B4
R525 B4
R526 B4
R527 C4
R532 B4
R533 C4
R801 B2
R802 B2
R803 C2
R806 C1
R807 C1
R808 B2
R812 C1
R813 C1
R814 C1
R815 C2
R816 C2
R817 C1
R818 C1
R819 C1
R820 C1
R821 C1
R822 C1
R823 C1
R824 C2
R825 C1
R826 C1
R828 C1
R830 C1
R831 D1
R832 C1
R833 C1
R834 D1
R836 C1
R837 C1
R838 C1
R839 C1
R840 C1
R841 C1
R842 C1
R843 C1
R844 C1
RA101 D3
RB101 C4
RB102 C4
XL101 B2
ZD101 B1
ZD102 C4
ZD104 C4
ZD105 C4
ZD1101 A3
ZD1102 A3
ZD1103 A3
ZD1104 A3
ZD1105 A3
ZD1106 A3
ZD1111 A3
ZD1112 A3
ZD303 A1
ZD304 A1
ZD305 A2
ZD401 C3

6 - 3 6 - 3
PCB Layout Top View
1234
A
B
C
1234
A
B
C
C1111 A1
C129 A1
C130 A1
C197 A1
C315 A1
C316 A1
C317 A1
C318 A1
C321 A1
C322 A1
CN103 A1
FB1101 A1
FB1102 A1
FB1111 A1
FB1112 A1
FB112 A1
FB114 A1
FB125 A1
FB126 A1
FB127 A1
IC302 A1
JK1103 A1
JK301A A1
L1101 A1
L1102 A1
L1103 A1
L1104 A1
R1105 A1
R1107 A1
R1110 A1
R1114 A1
R128 A1
R129 A1
R151 A1
R152 A1
R153 A1
R155 A1
R156 A1
R315 A1
R316 A1
R317 A1
R318 A1
R319 A1
R320 A1
R322 A1
R808 A1
ZD1101 A1
ZD1103 A1
ZD1105 A1
C1023 A2
C123 A2
C126 A2
C323 A2
C324 A2
C325 A2
C326 A2
C327 A2
C328 A2
C332 A2
C335 A2
C336 A2
C439 A2
D105 A2
D105 A2
FB1103 A2
FB111 A2
IC103 A2
IC104 A2
IC303 A2
IC304 A2
Q110 A2
Q111 A2
R122 A2
R123 A2
R165 A2
R180 A2
R181 A2
R187 A2
R188 A2
R301 A2
R302 A2
R303 A2
R304 A2
R323 A2
R324 A2
R325 A2
R326 A2
R328 A2
R329 A2
R330 A2
R332 A2
R335 A2
R336 A2
R337 A2
R338 A2
R340 A2
R342 A2
R343 A2
R344 A2
R345 A2
R347 A2
R416 A2
RA101 A2
ZD1111 A2
ZD303 A2
ZD304 A2
C340 A3
C342 A3
C344 A3
C346 A3
C347 A3
C348 A3
C349 A3
C402 A3
C405 A3
C406 A3
C409 A3
C410 A3
C413 A3
C414 A3
C415 A3
C534 A3
C549 A3
C564 A3
C583 A3
D401 A3
FB401 A3
IC305 A3
IC401 A3
JK501 A3
L302 A3
L307 A3
L308 A3
L505 A3
L506 A3
L514 A3
Q301 A3
R3001 A3
R3002 A3
R346 A3
R348 A3
R349 A3
R350 A3
R353 A3
R354 A3
R355 A3
R357 A3
R358 A3
R401 A3
R402 A3
R403 A3
R404 A3
R405 A3
R407 A3
R418 A3
R419 A3
R421 A3
ZD305 A3
C509 A4
C520 A4
C529 A4
C530 A4
C533 A4
C550 A4
C559 A4
C560 A4
C563 A4
C580 A4
C581 A4
C582 A4
JK501A A4
L501 A4
L502 A4
L503 A4
L504 A4
L507 A4
L508 A4
L511 A4
R406 A4
C132 B1
C137 B1
C144 B1
C158 B1
C159 B1
C185 B1
C802 B1
C804 B1
C805 B1
C806 B1
C812 B1
C813 B1
C814 B1
C816 B1
C818 B1
C819 B1
C820 B1
C823 B1
C824 B1
C825 B1
C826 B1
C827 B1
C828 B1
C830 B1
C833 B1
C836 B1
C838 B1
C839 B1
C840 B1
C843 B1
C846 B1
CN801 B1
D801 B1
D802 B1
FB115 B1
FB116 B1
FB124 B1
FB801 B1
FB802 B1
FB803 B1
FB804 B1
IC101 B1
Q104 B1
Q801 B1
Q802 B1
R130 B1
R131 B1
R134 B1
R146 B1
R147 B1
R801 B1
R802 B1
R806 B1
R807 B1
R812 B1
R815 B1
R817 B1
R818 B1
R821 B1
R823 B1
R836 B1
R837 B1
R838 B1
R839 B1
R840 B1
R841 B1
R842 B1
R843 B1
XL101 B1
ZD101 B1
C1024 B2
C110 B2
C113 B2
C1136 B2
C114 B2
C124 B2
C165 B2
C166 B2
C184 B2
C189 B2
C841 B2
C842 B2
C845 B2
CN101 B2
CN104 B2
CN802 B2
CN803 B2
D101 B2
D102 B2
D103 B2
D104 B2
D106 B2
D107 B2
D108 B2
D109 B2
FB104 B2
FB105 B2
FB106 B2
FB107 B2
FB108 B2
FB109 B2
FB110 B2
FB122 B2
FB123 B2
FB805 B2
IC102 B2
IC105 B2
IC801 B2
Q101 B2
Q102 B2
Q103 B2
R106 B2
R107 B2
R108 B2
R109 B2
R110 B2
R111 B2
R115 B2
R120 B2
R121 B2
R126 B2
R157 B2
R158 B2
R166 B2
R167 B2
R408 B2
R816 B2
R819 B2
R820 B2
R825 B2
R826 B2
R828 B2
R830 B2
R831 B2
RB101 B2
C179 B3
C181 B3
C190 B3
C196 B3
C419 B3
C420 B3
C440 B3
C441 B3
C544 B3
C551 B3
C570 B3
C571 B3
D402 B3
FB121 B3
IC502 B3
Q107 B3
Q401 B3
Q402 B3
Q403 B3
R162 B3
R163 B3
R186 B3
R422 B3
R423 B3
R517 B3
ZD102 B3
ZD104 B3
ZD105 B3
ZD401 B3
C1020 B4
C502 B4
C504 B4
C521 B4
C523 B4
C524 B4
C537 B4
C538 B4
C539 B4
C540 B4
C541 B4
C542 B4
C553 B4
C554 B4
C567 B4
C568 B4
C569 B4
IC501 B4
R503 B4
R505 B4
R506 B4
R514 B4
R519 B4
R520 B4
R527 B4
R532 B4
R533 B4
RB102 B4

6 - 4 6 - 4
PCB Layout Bottom View
1234
A
B
C
1234
A
B
C
C193 A1
C194 A1
C506 A1
C507 A1
C508 A1
C526 A1
C527 A1
C528 A1
C557 A1
R501 A1
R506 A1
R507 A1
R508 A1
R509 A1
R510 A1
R511 A1
R512 A1
R522 A1
R524 A1
R525 A1
R526 A1
C1025A2
C304 A2
C339 A2
C341 A2
C343 A2
C345 A2
C350 A2
C401 A2
C403 A2
C404 A2
C407 A2
C411 A2
C412 A2
C416 A2
C417 A2
C422 A2
C423 A2
C425 A2
C426 A2
C427 A2
R410 A2
R516 A2
C1010A3
C1012A3
C1016A3
C1022A3
C1117 A3
C122 A3
C125 A3
C301 A3
C302 A3
C303 A3
C329 A3
C330 A3
C334 A3
C408 A3
R117 A3
R118 A3
R119 A3
R124 A3
R125 A3
ZD1112A3
C1001A4
C1004A4
C1005A4
C1008A4
C1013A4
C1015A4
C1026A4
C1101 A4
C1102 A4
C1103 A4
C1104 A4
C1105 A4
C1106 A4
C1107 A4
C1108 A4
C1110 A4
C1112 A4
C1113 A4
C1114 A4
C128 A4
C133 A4
C134 A4
C162 A4
C319 A4
C320 A4
R1101 A4
R1102 A4
R1103 A4
R1104 A4
R127 A4
R159 A4
R321 A4
ZD1102A4
ZD1104A4
ZD1106A4
C1011 B1
C1021B1
C431 B1
C432 B1
C433 B1
C434 B1
C505 B1
C525 B1
C555 B1
C556 B1
C558 B1
C572 B1
C573 B1
C574 B1
C575 B1
C578 B1
C579 B1
R502 B1
R521 B1
R523 B1
C1018B2
C1027B2
C180 B2
C191 B2
C195 B2
C418 B2
C421 B2
C435 B2
C436 B2
C437 B2
C438 B2
C545 B2
C546 B2
C547 B2
C548 B2
C576 B2
C577 B2
D403 B2
R515 B2
C1002B3
C1003B3
C1006B3
C1007B3
C1017B3
C111 B3
C112 B3
C116 B3
C117 B3
C118 B3
C119 B3
C120 B3
C121 B3
C127 B3
C182 B3
C183 B3
C188 B3
C850 B3
C851 B3
C852 B3
C853 B3
C854 B3
C855 B3
C856 B3
C857 B3
C858 B3
FB101B3
FB128B3
R112 B3
R113 B3
R114 B3
R160 B3
R182 B3
R3012B3
R832 B3
R833 B3
C1009B4
C101 B4
C1019B4
C102 B4
C103 B4
C131 B4
C135 B4
C136 B4
C139 B4
C140 B4
C141 B4
C142 B4
C157 B4
C160 B4
C186 B4
C803 B4
C807 B4
C808 B4
C809 B4
C810 B4
C811 B4
C815 B4
C817 B4
C829 B4
C831 B4
C834 B4
C835 B4
C844 B4
C847 B4
C848 B4
C849 B4
FB113 B4
R133 B4
R803 B4
R813 B4
R814 B4
R822 B4
R824 B4
R844 B4
