Philips 23-LCD FLAT TV CRYSTAL CLEAR III 23PF8946 User manual

23" LCD flat TV Crystal Clear III 23PF8946
Enhanced picture and sound
Here is an LCD TV that not only enhances the décor of your home with its European styling and slim
design, but also provides a great A/V experience with Crystal Clear III, Active Control, Virtual Dolby
Surround and unique flat speakers
Better quality images that reveal more detail
• High-definition LCD WXGA display, 1280 x 768p
• Crystal Clear III for natural images with enhanced quality
• Active Control optimizes picture quality whatever the source
Superb sound reproduction
• Unique new slim speakers deliver better stereo performance.
• Virtual Dolby Surround for a cinema-like audio experience
Multi-purpose convenience
• PC Monitor function built in for added convenience
• Built-in FM radio to enjoy your favorite radio stations.
Stylish design
• Compact, sleek design and small size fits in every room

23PF8946/37
23" LCD flat TV Crystal Clear III
Technical specifications Product highlights
Date of issue 2005-12-02
Version: 3.0
12 NC: 8670 000 20293
EAN: 87 10895 83930 3
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
© 2005 Koninklijke Philips Electronics N.V.
All Rights reserved.
www.philips.com
Picture/Display
•Aspect ratio: Widescreen
•Brightness: 450 cd/m²
•Contrast ratio (typical): 450:1
•Diagonal screen size: 23 inch / 58 cm
•Visible diagonal screen size: 58 cm
•Display screen type: LCD WXGA Active Matrix
TFT
•Picture enhancement: 2D Combfilter, Active
Control, Crystal Clear III, Sharpness Adjustment,
Progressive Scan, Contrast Plus
•Screen enhancement: Anti-Reflection coated
screen
•Viewing angle (h / v): 140 / 125 degree
•Panel resolution: 1280 x 768p
Supported Display Resolution
Sound
•Sound Enhancement: Dynamic Bass Enhancement
•Sound System: Virtual Dolby Surround
•Output Power: 10W
Loudspeakers
•Number of Loudspeakers: 2
Convenience
•Ease of Installation: Autostore, Fine Tuning, PLL
Digital Tuning, Automatic Channel Install(ACI),
Automatic Tuning System (ATS)
•Ease of Use: Auto Volume Leveller (AVL), Top
Controls, Program List, AutoSound, AutoPicture
•Remote control type: RC19335021/01
•Clock: Sleep Timer
•VESA Mount: 100 x 100 mm
•Child Protection: Child Lock+Parental Control
Tuner/Reception/Transmission
•Tuner bands: Hyperband, S-Channel, UHF, VHF
•TV system: NTSC
•Video Playback: NTSC
•Aerial Input: 75 Ohm F-type
•Tuner Display: PLL
•Number of Preset Channels: 100
Connectivity
•Number of AV connections: 2
•Other connections: PC-In VGA, FM Antenna, F-
Type (75 ohm), HD input via VGA
•AV 1: CVI, AV In
•AV 2: S-Video, AV in
•Front / Side connections: Headphone out, Audio
in
Power
•Power consumption: 80 W
•Standby power consumption: <3 W
•Ambient temperature: +5°C/+45°C
Dimensions
•Product weight: 10.2 kg
•Dimensions (with base) (W x H x D):
704x420x217mm
Accessories
•Included Accessories: Mini jack to Cinch (Female),
Table top stand
•
•Computer formats
Resolution Refresh rate
720 x 400 70Hz
640 x 480 60, 67, 72, 75Hz
800 x 600 56, 60, 72, 75Hz
832 x 624 75Hz
1024 x 768 60, 70, 75Hz
•Video Formats
Resolution Refresh rate
640 x 480i 1Fh
640 x 480p 2Fh
720 x 576i 1Fh
720 x 576p 2Fh
1920 x 1080i 2Fh
Unique new slim speakers
Enjoy improved balanced sound and stereo performance
like you've never heard before. The slim speakers use
patented technology featuring a hi-fi like magnet system
and unique speaker cones.
Virtual Dolby Surround
Incredible Surround is an audio technology from Philips
that dramatically magnifies the sound field to immerse
you in the audio. Using state-of-the-art electronic phase
shifting, Incredible Surround mixes sounds from left and
right in such a way that it expands the virtual distance
between the two speakers. This wider spread greatly
enhances the stereo effect and creates a more natural
sound dimension. Incredible Surround means you
experience total surround with greater depth and width of
sound without the use of additional speakers.
PC Monitor
This set has a VGA input which is compatible with the
display output signal from your PC. This means you have
the convenience of using it both as a TV and PC Monitor
and for multi-tasking.
LCD WXGA display, 1280 x 768p
This WXGA display with state-of-the-art LCD screen
technology gives you HD resolution of 1280 x 768p
pixels. It produces brilliant flicker-free progressive scan
pictures with optimum brightness and superb colors. This
vibrant and sharp image will provide you with an
enhanced viewing experience.
Crystal Clear III
Crystal Clear III combines a whole range of enhancements
to provide a better picture. They include a 2D Comb filter,
Dynamic contrast, Blue stretch and Green enhancement
so that you always get the most natural looking colors.
Active Control
Active Control ensure that noise and sharpness
improvements are continuously made at a rate of 60
times per second. By continually adjusting picture setting
over 3,000 times per minute, Active Control Plus ensures
that the viewing experience is optimized.
Compact Design
The compact set fits in every room due to its sleek design
and size. Due to limited depth of the product, it even fits
on a book shelf.
FM Radio (TV)
An FM radio capable of storing 40 preset stations in built
in. On-screen station naming makes navigation simple,
and a handy Clock Screensaver is also included for use
while listening.
