Philips 32PFL4507/F7 User manual

Styling Sheet
Contents
This service manual contains information of different types of models.
Make sure to refer to the section describing your model.
TYPE A
32PFL4507/F7 PHILIPS (Serial No.: DS1)
32PFL4507/F8 PHILIPS (Serial No.: XA1)
32PFL4507/F8 PHILIPS (Serial No.: DS1)
TYPE B
32PFL4907/F7 PHILIPS (Serial No.: DS1)
32” LCD TV
chassis PL12.2
120523
© 2012 Funai Electric Co., Ltd.
All rights reserved. No part of this manual may be reproduced, copied, transmitted, disseminated, transcribed,
downloaded or stored in any storage medium, in any form or for any purpose without the express prior written
consent of Funai. Furthermore, any unauthorized commercial distribution of this manual or any revision hereto
is strictly prohibited.
Information in this document is subject to change without notice. Funai reserves the right to change the content
herein without the obligation to notify any person or organization of such changes.
with the design is a registered trademark of Funai Electric Co., Ltd and may not be used in any way
without the express written consent of Funai. All other trademarks used herein remain the exclusive property of
their respective owners. Nothing contained in this manual should be construed as granting, by implication or
otherwise, any license or right to use any of the trademarks displayed herein. Misuse of any trademarks or any
other content in this manual is strictly prohibited. Funai shall aggressively enforce its intellectual property rights
to the fullest extent of the law.

1 PL12.2_ASTCEX
EXPLODED VIEW
[TYPE A]
SSK1
A10
L14
L32
SP3801
SP3802
S7
X6
L4
L14
A3
B17
B17
B18
B18
B9
A14
L13
L4
L13
L4
L13
L13
L13
L13
CL3101
CL3701
CL3801
B3
S7
L23
L4
L4
L51
L4
B11
A23
A20
L4
CL3006
CL1001
LCD Module
L4 A2
A18
See Electrical Parts List for parts with this mark.
Digital Main CBA Unit
Power Supply CBA
Function CBA
AC601
LCD1
A1
A4
B24

2 PL12.2_BSTCEX
[TYPE B]
SSK1
A10
L14
L32
SP3801
SP3802
S7
X6
L4
L14
A3
B17
B17
B18
B18
B9
A14
L13
L4
L13
L4
L13
L13
L13
L13
CL3101
CL3701
CL3801
B3
S7
L23
L4
L4
L51
L4
B11
A23
A20
L4
CL3006
CL1001
LCD Module
L4 A2
A18
See Electrical Parts List for parts with this mark.
Digital Main CBA Unit
Power Supply CBA
Function CBA
AC601
LCD1
A1
A4
B24

3 PL12.2STPL
MECHANICAL & ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a #have special characteristics important to safety. Before
replacing any of these components, read carefully the product safety notice in this service manual. Don't degrade
the safety of the product through improper servicing.
NOTE: Parts that are not assigned part numbers (---------) are not available.
TYPE A B
Chassis PL12.2 Mechanical Parts List
32PFL4507/F7 (Serial No.: DS1), 32PFL4507/F8 (Serial No.: XA1), 32PFL4507/F8 (Serial No.: DS1) 32PFL4907/F7 (Serial No.: DS1)
Ref. No. Description Parts No.
Depending on the model, the rear cover part number will differ.
A3
for 32PFL4507/F7 (Serial No.: DS1) models
REAR COVER A21F5UH 1EM028929 X
A3
for 32PFL4507/F8 (Serial No.: XA1, DS1) models
REAR COVER A21FAMA 1EM127007 X
A3 REAR COVER A27F5UH 1EM127000 X
A4 DECORATION PLATE A21F5UH 1EM227003 X X
A10 STAND ASSEMBLY 32W A21F5UH 1EM029073 X X
A14 JACK HOLDER A21F0UH 1EM226823 X
A14 JACK HOLDER A27F0UH 1EM332537 X
AC601#AC CORD W/O A GND WIRE UL/CSA/1700/NO/BLACK WAC1720LW005 X X
B9 STAND HOLDER A21F5UH 1EM028931 X X
B11 SENSOR PLATE A21F5UH 1EM437078 X X
B17 WALL MOUNT BRACKET A11N0UH 1EM434637 X X
B18 WALL MOUNT COVER A2170UT 1EM332137 X X
B24 STAND BRACKET A21F5UH 1EM226984 X X
CL3101 FFC WIRE ASSEMBLY 9PIN 9PIN/WHITE/143MM WX1A21F0-111 X X
CL3701 FFC WIRE ASSEMBLY 23PIN 23PIN/WHITE/80MM WX1A21F0-110 X
CL3701 FFC WIRE ASSEMBLY 23PIN 23PIN/WHITE/55MM WX1A27F0-101 X
CL3801 WIRE ASSEMBLY 4PIN 4PIN/341MM&36MM WX1A21F5-302 X X
L4 SCREW P-TIGHT 3X12 BIND HEAD+ BLK GBHP3120 X X
L13 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060 X X
L14 S-TIGHT SCREW M3X6 BIND HEAD+BLACK GBHS3060 X X
L32 DOUBLE SEMS SCREW M4X10 + BLK FPH34100 X X
SP3801 SPEAKER MAGNETIC 8OHM/10W S0313F17 DS08100XQ001 X X
SP3802 SPEAKER MAGNETIC 8OHM/10W S0313F17 DS08100XQ001 X X
SSK1 STAND SCREW KIT A21F5UH 1ESA31176 X X
S1 CARTON A21F5UH 1EM332739 X
S1 CARTON A27F5UH 1EM437000A X
S3 STYROFOAM TOP A21F5UH 1EM029165 X X
S4 STYROFOAM BOTTOM A21F5UH 1EM029166 X X
S6 SET BAG A17F6UH 1EM330877 X X
X1 POLYETHYLENE BAG HDPE 180X340XT0.03 1EM435579 X X
X2#OWNERS MANUAL A21F5UH 1EMN29143 X
X2#OWNERS MANUAL A27F5UH 1EMN29000A X
X3 REMOTE CONTROL TRANSMITTER YKF259-001 URMT34JHG001 X
X3 REMOTE CONTROL UNIT YKF255-010 URMT42JHG004 X
X4 BATTERY R03-B500/01S XB0M451CZB01 X X
X6 QUICK START GUIDE A21F5UH 1EMN29144 X
X6 QUICK START GUIDE A27F5UH 1EMN29104A X
X7 REGISTRATION CARD(PHILIPS) A11P4UH 1EMN27321 X X
X9 BROCHURE (PHILIPS) A01N2UH 1EMN26419 X X
X12 CABLE MANAGEMENT TIE(BLACK) A01F2UH 1EM431197 X X
X17 VUDU SHEET E5S20UD 1VMN30133 X
X18 WIRELESS LAN ADAPTOR WU5502S UWLUSBACM004 X

4 PL12.2STPL
LCD1 LCD PANEL ASSEMBLY
Consists of the following
U24F1P0 X X
A1 FRONT CABINET A21F5UH 1EM028928 X X
A2 REAR FRAME PAINTING A21F0UH 1EM332238 X X
CL1001 FFC 7PIN 7P/P1.0/470MM WX1U24F0-F02 X X
CL3006 FFC 30PIN 30P/P0.5/210MM WX1U24F0-F01 X X
L4 SCREW P-TIGHT 3X12 BIND HEAD+ BLK GBHP3120 X X
L51 SCREW M3X4 M3X4 BIND+ (B-NI) SBH33040 X X
LCD MODULE ---------- X X
TYPE A B
Chassis PL12.2 Mechanical Parts List
32PFL4507/F7 (Serial No.: DS1), 32PFL4507/F8 (Serial No.: XA1), 32PFL4507/F8 (Serial No.: DS1) 32PFL4907/F7 (Serial No.: DS1)
Ref. No. Description Parts No.
TYPE A B
Chassis PL12.2 Electrical Parts List
32PFL4507/F7 (Serial No.: DS1), 32PFL4507/F8 (Serial No.: XA1), 32PFL4507/F8 (Serial No.: DS1) 32PFL4907/F7 (Serial No.: DS1)
Ref. No. Description Parts No.
DIGITAL MAIN CBA UNIT A21F5MMA-002 X
DIGITAL MAIN CBA UNIT A27F5MMA-002 X
POWER SUPPLY CBA A21F0MPW-001 X
POWER SUPPLY CBA A27F0MPW-001 X
IC601#IC PHOTOCOUPLER TLP781F(D4-FUNBLL F) QPEL781FBLLF X X
IC1001#IC LED BACKLIGHT CONTROLLER HA7209PC /SOP /24PIN NSCA0T00H003 X X
FUNCTION CBA A21F5MSW-001 X X
IC4001 IC TOUCH SENSOR MICON CY8C20336A-24LQXIT NSCB0T0TY063 X X
