Philips 190B4CB User manual

190B4
190B4
·19-inch Color LCD SXGA Monitor
Enjoy excellent display performance providing an optimum resolution of 1280 x 1024 for amazing image clarity.
·Standard VGA Analog Input
Provides support for traditional analog signals.
·Embedded Universal AC Power Supply
Conveniently adapts to a variety of mounting configurations using a built-in power supply that
eliminates the hassle of external power supplies.
·Advanced AUTOmatic Adjustment optimizes picture quality
A perfect picture is only three seconds away. Philips auto adjustment provides optimal screen position and
performance with the press of a single button.
·Adjustable Tilt and Swivel Function
Enjoy the most comfortable, productive viewing angle regardless of viewer’s height or the placement
of the monitor.
· Adjustable Viewing Height
You can position the screen to the most comfortable and productive viewing height using the
height-adjustable base.
• sRGB Compliance
Eliminating color reproduction differences, sRGB compliance assures real life colors are consistently and precisely
reproduced in CRT monitors, LCD panels, projectors and other devices.
·Philips First Choice Program
One-call support includes a comprehensive 3-year warranty with a 1-year 48-hour advance swap guarantee.
Ultra Slim Frame ...Delivers a front-to-back depth
and bezel width that leads the industry.
Philips Business Series Monitors
Stealth Black Model
190B4CB
KEY TECHNOLOGIES
POWERSUPPLY
USB Module
(Mist White Only)
PCHU411
190B4CS/74

Product Number 190B4CB/74 (Stealth Black)
190B4CS/74 (Silver-Black)
LCD
•Panel TFT LCD
•Screen Size (inch/cm) 19 inch / 48.26 cm
•Pixel Pitch 0.294 x 0.294mm
•Display Format 1280 x 1024 pixels,
RGB Vertical Stripe,
Anti-glare Polarizer, Hard Coated
•Display Area 376.32 x 301.06mm
•Display Colors 16.7M colors
Scanning
•Vertical Refresh Rate 56 - 76 Hz
•Horizontal Frequency 30 - 82 kHz
Video
•Video Dot Rate 135 MHz
•Input Impedance
-Video 75Ω
-Sync 2kΩ
•Input Signal Levels 0.7 Vp-p
•Sync Input Signal Separate Sync
Composite Sync
Sync on Green
•Sync Polarities Positive and Negative
•Video Interface Analog (D-Sub) Input
Models 190B4CB/74 and 190B4CS/74 are D-Sub
(analog) only. DVI-D (digital) is available only on
190B4CB/94 and 190B4CS/94.
Optical Characteristics
•Contrast Ratio 500 : 1 (typ.)
•Brightness 250 cd/m2 (typ.)
•Peak Contrast Angle 6 o’clock
•White Chromaticity x=0.283 y=0.297 (at 9300° K)
x=0.313 y=0.329 (at 6500° K)
•Viewing Angle V=170° Upper ≥85°(typ.)
(C/R >10) Lower ≥85°(typ.)
H=170° Left ≥85°(typ.)
Right ≥85°(typ.)
•Response Time ≤25 ms (typ.)
(Tr ≤15ms,Tf ≤10ms)
Resolution and Preset Modes
•Max. Resolution 1280 x 1024 at 75Hz
•Recom. Resolution 1280 x 1024 at 60Hz
•15 Factory Preset Modes:
Plug and Play Compatibility
•Display Data Channel DDC 2B (VESA)
•Microsoft®,Windows® Me/2000 XP Compatible
Power Management
Complies with EPA Energy Star and NUTEK specifications
•Typical Operation 45W
•Sleep Mode 1W
Low-Emission Characteristics
•Complies with TCO '03 (190B4CS), TCO '99 (190B4CB), MPRII and prEN50279
(so call MPRII) specifications
Monitor Controls and Functions
•Front Power on/off -Tact Switch
OK -Tact Switch
Auto -Tact Switch
Up/Down (Brightness) -Tact Switch
Left/Right -Tact Switch
•LED indicator Steady Blue -Power On
Amber -Power Save/Off Mode
Flashing Blue -New Mode
Connections and Cables
•Connections on Monitor Body
-Video 15-pin D-sub (analog)
-Power IEC/CEE-22 Type Male Power Inlet
•Cables D-Sub Video Cable, Power Cord
Regulatory Approvals
• TÜV/GS,TÜV-Ergo • FCC-B, UL, CSA
• SEMKO • prEN50279 Low Emission
• CE Mark • NUTEK, Energy Star
• TCO '03 (190B4CS) • TCO '99 (190B4CB)
Physical Specifications
•UPC Code 190B4CB/74 (Stealth Black) 0 37849 93801 0
190B4CS/74 (Silver-Black) 0 37849 93800 3
•Unit Dimensions (WxHxD) 16.8" x 14.9" x 9.3"
425 x 377 x 235 mm (incl base)
16.8" x 14.2" x 2.6"
425 x 377 x 235 mm (excl base)
•Unit Weight 17.4 lbs / 6.5 kg
•Carton Dimensions (WxHxD) 17.8" x 18.9" x 7.0"
450 x 480 x 176 mm
•Carton Weight 19.4 lbs / 8.81 kg
•Tilt -5°~35° / ±175°
•Height Adjustment Range 70mm
•Power Supply 100 - 240 VAC, 50/60Hz
•Power Consumption 45W* (typ.)
•Temperature (operating) +5°C to +35°C/ 41°F to 95°F
•Temperature (storage) -20°C to +60°C/ -4°F to 140°F
•Relative Humidity 20% to 80%
•System mtbf 50K hrs (excluding CCFL 40K hrs)
* Resolution 1280x1024, standard size, contrast max., brightness 50%, 9300°K, Full white pattern. without
Audio.We recommend using 1280 x 1024 at 60Hz non-interlaced mode for the best picture quality
User Options Accessories (sold separately)
•USB module PCHU411 (Mist White)
Carton Contains: 190B4 Monitor, power cord, and user’s manual on CD.
INTERNET ADDRESS: http://www.philips.com
TECHNICAL SUPPORT: [phone] (USA)
[phone] (outside USA)
Printed in the U.S.A., ©2003 Philips Consumer Electronics Co. A Division of Philips Electronics North America
Corp. As an Energy Star partner, Philips has determined th at this product meets the Energy Star guidelines for
energy efficiency. Microsoft andWindows are registered trademarks of Microsoft Corporation. Macintosh is a
registered trademark.
CCM-141 2/04
Literature Order Number: 190B4CB/74 / 190B4CS/74
Resolution H.freq V.freq
640 x 350 31.5(kHz) 70(Hz)
720 x 400 31.5 70
640 x 480 31.5 60
640 x 480 35.0 67
640 x 480 37.5 75
800 x 600 35.2 56
800 x 600 37.9 60
800 x 600 46.9 75
832 x 624 49.7 75
1024 x 768 48.4 60
1024 x 768 60.0 75
1152 x 870 69.0 75
1152 x 900 71.8 76
1280 x 1024 63.9 60
1280 x 1024 80.0 75
(Interlace mode is not supported)
190B4
190B4
Technical Specifications
