Philips CSP1000 User manual

www.philips.com/welcome
Register your product and get support at
EN User manual
CSP1000 CSP1200

1. Important
Safety
Read and understand all instructions before you use the apparatus.•
If damage is caused by failure to follow instructions, the warranty
does not apply.
Use only the supplied mounting hardware for a safe and secure•
installation.
Thesubwooferisheavy.Attachitrmlytoasolidthickbafe-board.•
Donotcontinuouslyusethespeakersystembeyondthepeakpower•
handling capacity.
Keep credit cards, watches, recorded tapes etc. with magnetic coding•
awayfromthespeakersystemtopreventdamagecausedbythe
magnetsinthespeakers.
Clean the apparatus with soft, damp cloth. Never use substances•
such as alcohol, chemicals or household cleaners on the apparatus.
Notice
Environmental information
Allunnecessarypackaginghasbeenomitted.Wehavetriedtomake
thepackagingeasytoseparateintothreematerials:cardboard(box),
polystyrenefoam(buffer)andpolyethylene(bags,protectivefoamsheet.)
Your system consists of materials which can be recycled and reused
if disassembled by a specialized company. Please observe the local
regulationsregardingthedisposalofpackagingmaterials,exhausted
batteries and old equipment.
Anychangesormodicationsmadetothisdevicethatarenotexpressly
approved by Philips Consumer Lifestyle may void the user’s authority to
operate the equipment.
2009©KoninklijkePhilipsElectronicsN.V.Allrightsreserved.
Specicationsaresubjecttochangewithoutnotice.TrademarksarethepropertyofKoninklijke
PhilipsElectronicsN.V.ortheirrespectiveowners.Philipsreservestherighttochangeproductsat
anytimewithoutbeingobligedtoadjustearliersuppliesaccordingly.

Your car power subwoofer
Congratulations on your purchase, and welcome to Philips! To fully
benetfromthesupportthatPhilipsoffers,registeryourproductat
www.philips.com/welcome.
Introduction
Withthesubwoofer,youcanenjoyhighqualitysoundperformance
with powerful bass and beats.
What’s in the box
Checkandidentifythecontentsofyourpackage:
aSubwoofer
b Screw_4x50mm(x10)
cFrame
2. Installation
Adepthofatleast124mmisrequiredtomountthesubwoofer.
Measure the depth of the area where you are to mount the subwoofer,
and ensure that the subwoofer does not obstruct any other components
of the car.
Option 1: Mount on rear tray
You can mount the subwoofer on the rear tray.
c
ab

1 Turnoffthecarignitionkey.
Ifthepowerison,theclicknoisegeneratedbytheconnection• maydamagethespeakers.
2Paste the supplied template onto the location for mounting the
subwoofer.
3 Markthecut-offholeandthe10boltholes.
4 Cutoutthemarkedareaaanddrilltheboltholes.

5 Connectthesubwoofertotheamplier.
6Mount the subwoofer into the rear tray with the supplied
screws.
10 ~ 15mm Speaker wire
(not supplied)
Amplifier

Option 2: Install in a sealed enclosure
If the subwoofer cannot be mounted on the car, place it in a sealed
enclosure.
1 Makeasealedenclosureindimensionasbelow:
The box:
CSP1000 CSP1200
Height 338mm 358mm
Length 522mm 568mm
Width 232mm 238mm
The mounting hole:
CSP1000 CSP1200
Mounting hole diameter (Outside) 257.3mm 307mm
Mounting hole diameter (Inside) 231.9mm 283.7mm
Screw hole diameter 3.3mm 3.3mm
2 Connectthesubwoofertotheamplier(seestep5of“Option1:
Mountonreartray”section).

3Install the subwoofer into the sealed enclosure with the
supplied screws.
*
*
*
*
*
*
*
*
*
*
3. Product information
Note
Productinformationissubjecttochangewithoutpriornotice.
•
Model CSP1000 CSP1200
Speaker type 25cmsubwoofer 30cm subwoofer
RMS power (Watts) 250W 400W
Peak music power (Watts) 1000W 1600W
Sensitivity (dB/W/m) 88dB 89dB
Frequency response (Hz) 25-1000Hz 20-1500Hz
Impedance (ohms) 4 ohms 4 ohms
Magnet mass (Oz) 55.4Oz 55.4Oz
Mounting depth (mm) 124mm 146mm

4.Troubleshooting
Tokeepthewarrantyvalid,nevertrytorepairthesystemyourself.
If you encounter problems when using this apparatus, go to the Philips
web site (w ww.philips.com/welcome). When you contact Philips,
ensure that the apparatus is nearby and the model number and serial
number are available.
Name of the Parts
Hazardous/toxic Substance
Pb, Lead Hg,Mercury Cd, cadmium Chromium6+ PBB PBDE
Housing O O O O O O
Subwoofer X O O O O O
Loudspeakers O O O O O O
PWBs XO O O O O
Accessories(Remote
control&cables) XO O O O O
O: Indicatesthatthistoxicorhazardoussubstancecontainedinallofthehomogeneousmaterialsforthispartis
belowthelimitrequirementinSJ/T11363-2006.
X: Indicatesthatthistoxicorhazardoussubstancecontainedinatleastoneofthehomogeneousmaterialsused
forthispartisabovethelimitrequirementinSJ/T11363-2006.
Environmental Protection Use Period
Thislogoreferstotheperiod(10years)duringwhichthetoxicorhazardoussubstancesorelementscontainedinelectronic
informationproductswillnotleakormutatesothattheuseofthese[substancesorelements]willnotresultinanysevere
environmentalpollution,anybodilyinjuryordamagetoanyassets.
© 2009 Koninklijke Philips Electronics N.V.
All rights reserved.
CSP1000_93_UM_V3.0
