FW-C70
Mini Hi-Fi System
3 CD Changer with 150WattsTotal Power
and 4-Speaker Surround Sound System
• 2 x 75Watts RMS Stereo
• 4-Speaker Surround Sound System
• Sound Navigation and 26 Digital Sound Control modes
• 3-Step Dynamic Bass Boost
• 7-Band Spectrum Analyzer with 3 Display modes
• 3-Way Bass Reflex Speaker System with Detachable Grilles
• 6 1/2"Woofer
• CD-Rewritable Compatible
• 40-Track CD Random Program
• AM/FM Stereo DigitalTuning with 40 Presets
• OneTouch CD Synchro Recording
• Subwoofer Ready
• Easy set for radio
• Energy Saving Standby mode (<2 watts)
• 24-Button Remote Control
• Bedroom Clock withWake-upAlarm and Sleep-timer
• 4-Color Packaging
w
a
k
e
u
p
/
s
l
e
e
p
t
i
m
e
r
24
KEY
S
O
U
N
D
N
A
V
I
G
A
T
I
O
N

Sound Enhancement
2 x 75Watts RMS Stereo
75 watts continuous RMS power output per channel, at 6
Ohms, from 80Hz-16kHz, with no more than 10% Total
Harmonic Distortion (THD).
4-Speaker Surround Sound System
Delivers the full, three-dimensional effect of a live
performance from music and movies.The front left and
right speakers fill the room with all the music's detail and
directional sound, producing the "wall of sound". Both the
rear left and right surround speakers add the ambient
reflected sound with echoes and delay for a more life-like
audio experience.
Sound Navigation via jog
The JOG SHUTTLE of this feature adds a new
dimensions in fine-tuning the sound settings and the
incredible surround™ to suit your personal taste.
26-step Digital Sound Control
The feature offers 26 different sound settings based on 6
basic settings : (CLASSIC - 1 setting, ROCK - 5 settings,
VOCAL - 5 settings,TECHNO - 5 settings, OPTIMAL - 5
settings,JAZZ - 5 settings)
3-Step Dynamic Bass Boost (Beat,Punch, Blast)
Bass reproduction is essential for deep and rich music. 3
Step DBB offers the optimal level for any kind of music.
3-Way Bass Reflex Speaker System
Equipped with one 6 1/2" woofer for smooth low and mid
range reproduction, one 2 1/2" ferro-fluid cooled tweeter
and one 1" Polydome tweeter for crisp high tones.
AM/FM Stereo DigitalTuner
State-of-the-art precision tuning system insures precise,
accurate station selection every time, along with the
greatest performance and reliability available.
Subwoofer Ready
Affords easy access to greater dimensions in sound with
output signals available for connection to a subwoofer.
Design
Design Concept
The attractive and shelf appealing emphasis on the sound
control panel dominates and determines this range's
character. The sound control panel emphasis which
supports the entire sound story is reinforced by 2
distinctive rotaries (sound jog and volume) that builds itself
logically up the range with features, finishing, colors and
product design detail difference. Uninterrupted display and
cassette window lens set on a strong underlying profile
gives strong rational while the use of appropriate
backlighting,lightstrips and rings coupled with choice colors
evokes the emotional appeal.
Oversized, MultiColor,Digital FTD Display
This large display is easy to read at any distance with no
distortion or distraction and the multi-color format
makes it easy to recognize different functions at a glance.
Detachable Cloth Speaker Grilles
Detachable cloth covered grilles protect delicate speaker
components with rich, high-tech styling.
Convenience
3-CD Changer with Motorized Drawer
Multi-disc play capability provides more than three hours
of continuous music.
CD-Rewritable Compatible
The player offers 100% playback guarantee of CD-
Rewritable CD's over the entire lifetime of the player. Even
CD-RW audio recordings on computers can be used.
24-Button Remote Control
This infrared remote control operates volume +/–, all
CD functions (POWER, NEXT, PREVIOUS, PLAY,
STOP,PAUSE,REPEAT, SHUFFLE,PROGRAM,DISC 1,
2, 3 ), CD, AUX, TAPE 1/2, TUNER, SLEEP TIMER,
MUTE and sound enhancement features including
Dynamic Bass Boost,and Digital Sound Control.
Easy Set
Press Standby ‘ON’ for 5 secs to automatically program
40 tuner presets.
40-Random Channel Presets
Random memory presets allow pre-programming of up to
40AM and FM station frequencies into the tuner memory.
Auto Store
Automatically stores up to 40 preset FM orAM stations .
40-Track CD Random Program
Store up to 40 of your favorite CD track selections, from
one or multiple discs, to be played back in the order in
which they are programmed anytime you like.
Auto Record Level Control
Micro electronic circuitry constantly monitors the final
audio amplifier stage to insure accurate, distortion-free
recordings every time.
AUX/Video Input
For connection of audio accessory pieces such as a LD
or DVD player,television, or external cassette deck.
Direct Source Selection
Automatically switch to a new source and pause the
current source at the touch of a single button.
Demo Mode
Functions always. Press “STOP” for 5 secs to interrupt
demo mode.
ChangeWhile Play
Flexiblility of changing 2 discs while still listening to the
third disc being played.
One-Touch CD Synchro Recording
One button allows the cassette deck and CD player to
communicate with one another to synchronize the start
of a recording on an analog audio cassette deck with the
start of a CD or a CD program.
Repeat track/disc/all
Repeat your favorite track,disc or all.
Pause
Interrupts playback of a CD without returning to the
beginning of the disc, so when play resumes, the music
begins exactly where it stopped.
Shuffle One/All Discs
Plays all selections on a particular disc or multiple discs in
multi-disc players in random order,ignoring the sequential
order in which they were originally recorded.
UPC Code:0 37849 89278 7
Product Dimensions:
10.4"W x .12.2" H x 15.4" D (electronics)
9.4"W x 12.2" H x 12.4" D (speakers)
7.0" W x 3.5" H x 7.0 "D (surround)
Package Dimensions:
23.4"W x 28.3" H x 15.7" D
Product weight: 44 lbs.
Carton contains: 3CD Changer Mini System, Multi-Function Remote
Control,Batteries, Operating instructions,Warranty information
Printed in Singapore
Date printed : Oct 1999
©1999 Royal Philips Electronics N.V.
All right reserved.
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
As an ENERGY STAR® Partner,Philips has determined that this product meets
the ENERGY STAR® guidelines for energy efficiency
Next/Previous Skip
This two button feature offers you the opportunity to skip
back to the previous track or skip up to the next track
instantly.
Dual MechanicalTape Deck
Feature full function control via a simple, easy-to-use
mechanical push button assembly.
High-Speed Dubbing
High-speed dubbing makes it possible to create good
quality recordings (dubs) from one tape to another at
twice the normal speed in RECORD mode.
Clock/Timer and Sleeptimer
Set the alarm portion of a built-in digital clock to wake
you to music from your favorite CD or an AM/FM radio
station at any desired time of the day. Sleeptimer settings
of 60,45,30 or 15 minutes.
3 Dim Display modes (including nite mode)
2 different display options showing different amounts of
display activity can be selected and 1 nite mode display which
shows minimal display activity and turns most of the lights off.
Energy Saving Standby Mode (<2 watts)
Most systems consume 10-15 watts just on standby.
Philips systems consume less than 2 watts of energy on
standby for big saving to the listener.
Stereo Headphone Jack
