• 2 x 150 watts + 50 watts + 2 x 25 watts RMS Stereo
• 5-Speaker Dolby® Pro-Logic Surround Sound System
• wOOx Technology Speaker System for deeper bass
• Sound Navigation via Jog (6 Digital Sound Control modes, 6 Virtual Environment
Control modes and 6 Personal Settings)
• 3-step wOOx Level Control
• 7-Band Spectrum Analyzer with 3 Dim Display modes
• Bass & Treble Control
• 3-way Bass Reflex Speaker System with wOOx Speaker Technology
•6
1/2"Top Firing wOOx woofer
• Plays CD, CD-R and CD-RW discs
• Dual Logic Tape Deck with Auto Replay
• Line Out + Digital Out for perfect CD recording
• Eco Power Standby mode (<2 watts)
Mini Hi-Fi System with 3CD Changer,
400 Watts Total Power, 5 Speaker Dolby
Pro-Logic System and wOOx Technology
400 w
VEC
FWP880
FWP880

Sound Enhancement
2 x 150Watts + 50Watts + 2 x 25Watts Dolby®
Pro Logic Output Mode
150 Watts L/R front, 50 Watts center, 25 Watts L/R rear
RMS output power per channel at 6 ohms from 80Hz-
16kHz,with no more than 10%Total Harmonic distortion.
5-Speaker Dolby® Pro Logic Surround Sound
System
Provide the current industry standard for home theater
sound fromVCR and laserdisc movies.The front left and
right speakers deliver detailed, directional sound as the
center channel speaker "steers" dialogue/vocal sound to
where you see the mouth moving - at the TV screen.
Both surround speakers add a greater sense of depth
with special effects and time delay, making every living
room a home theater with spaceships overhead, aliens
behind the couch but no gum on the floor.
wOOxTechonology
Philips patented wOOx Technology ensures superior bass
results. The dual suspension bass radiator, together with
dedicated amplifier circuitry, is especially designed to produce
and handle high dynamic sound signals at very low
frequencies. Because of the dual suspension, the excursion
of the membrane can be extreme (see illustration). This, in
combination with the symmetrical sandwich construction,
provides for very low and precise bass without noticeable
distortion. The net effect of using wOOx Technology is a
tight bass sound that is significantly "lower and louder" than
conventional mini shelf systems.
Interactive Sound Studio
(Jog + DSC +VEC + PS)
The Sound Navigation System is a complete set of sound
manipulation tools consisting of
6 Digital Sound Control settings : (CLASSIC, ROCK,
VOCAL,TECHNO,OPTIMAL, JAZZ),
6 Virtual Environment Control Modes : (HALLl,
DISCO,CONCERT,CINEMA,CLUB, ARCADE),
6 personal settings :To preserve your favorite sound
settings and save them into 6 different memory settings,
3-Step wOOx Level Control
As the human ear does not perceive low frequencies at
the same level as higher frequencies (though at the same
"volume"), the bass sound needs to be enhanced to
achieve maximum impact. The wOOx is progressively
driven at different optimization levels in setting wOOx 1,
2 and 3.
3-Way Bass Reflex Speaker System with Bass
Radiator with wOOx
Equipped with one 61/2" woofer for smooth low and mid
range reproduction, one 21/2" ferro-fluid cooled tweeter
and one 1" Polydome tweeter for crisp high tones. 61/2"
top wOOx Bass Radiator entrance bass reproduction
together with wOOx Duplication Control.
Magnetic Shielding
Left front, right front and center speakers are all
equipped with magnetic shielding to prevent interference
with color television picture tube purity.
Subwoofer Ready
Affords easy access to greater dimensions in sound with
output signals available for connection to a subwoofer.
Convenience
3-CD Changer with Motorized Drawer
Multi-disc play capability provides more than three hours
of continuous music.
Plays CD,CD-R and CD-RW discs
The player offers 100% playback guarantee of CD, CD-R
and CD-RW discs over the entire lifetime of the player.
Even CD-RW audio recordings on computer can be used.
Auto Reverse
The feature employs an auto reverse mechanism to
sense the end of the tape and automatically reverse the
direction of tape travel in the PLAY mode providing an
uninterrupted, continuous flow of music without
manually flipping the cassette tape.
45-key Remote Control
This infrared remote control operates volume +/±,all CD
functions (POWER, NEXT, PREVIOUS, PLAY, STOP,
PAUSE, SHUFFLE, REPEAT, PROGRAM, CD123, CD
DIRECT 1,2,3, F and G), TV/AV, AUX/CDR select,
TUNER select, TAPE 1/2 select, CLOCK, AUTO REV.
select, DIM and sound enhancement features including
Personal setting select, Digital Sound Control (DSC),
Virtual Environment Control (VEC), Bass & Trebles
Control (BTC), TIMER ON/OFF, SLEEP, wOOx on/off,
wOOx level select and the Dolby® Prologic mode select,
TestTone select,Balance L/R,Center +/- and Rear +/-.
Easy Set
Press Standby `ON' for 5 secs to automatically program
40 tuner presets.(FM only)
Auto Store
Automatically stores up to 40 preset FM orAM stations .
40-track CD Random Program
Store up to 40 of your favorite CD track selections, from
one or multiple discs, to be played back in the order in
which they are programmed anytime you like.
Auto Record Level Control
Micro electronic circuitry constantly monitors the final
audio amplifier stage to insure accurate, distortion-free
recordings every time.
AUX/Video Input
For connection of audio accessory pieces such as a LD
or DVD player,television,or external cassette deck.
Direct Source Selection
Automatically switch to a new source and pause the
current source at the touch of a single button.
Demo Mode
Functions always. Press 'STOP' for 5 secs to interrupt
demo mode.
Direct Play Button
Allows you to select and play any CD in the carousel by
touching only one button.
ChangeWhile Play
Flexiblility of changing 2 discs while still listening to the
third disc being played.
Shuffle One/All Discs
Plays all selections on a particular disc or multiple discs in
multi-disc players in random order, ignoring the
sequential order in which they were originally recorded.
UPC Code: 0 3784990 9201
Product Dimensions:
10.4"W x 12.2" H x 15.4" D (electronics)
9.4"W x 13.8" H x 12.4" D (speakers)
9.4"W x 5.1" H x 5.9" D (center speaker)
9.4"W x 5.1" H x 5.9" D (surround speakers)
Package Dimensions:
28.5"W x 28.0" H x 14.3" D
Product weight: 52.9 lbs.
Carton contains: 3CD Changer Mini
System, Surround Speakers, Center
Speaker, Multi-Function Remote Control,
Batteries, Operating instructions, Warranty
information
Repeat track/disc/all
Repeat your favorite track, disc or all.
High-Speed Dubbing
High-speed dubbing makes it possible to create good
quality recordings (dubs) from one tape to another at
twice the normal speed in RECORD mode.
Clock/Timer and Sleeptimer
Set the alarm portion of a built-in digital clock to wake you
to music from your favorite CD or an AM/FM radio station
at any desired time of the day. Sleeptimer settings of 60,
45,30 or 15 minutes.
3 Dim Display modes (including nite mode)
2 different display options showing different amounts of display
activity can be selected and 1 nite mode display which shows
minimal display activity and turns most of the lights off.
Eco Power Standby Mode (<2 watts)
Most systems consume 10-15 watts just on standby.Philips
systems consumes less than 2 watts of energy on standby for
big savings to the listener.
Design
Design Concept
The attractive and shelf appealing emphasis on the sound
control panel dominates and determines this range’s
character.
Detachable Cloth Speaker Grilles
Detachable cloth covered grilles protect delicate speaker
components with rich, high-tech styling.
Printed in Singapore
Date printed :Sep 2000
©2000 Royal Philips Electronics N.V.
All rights reserved
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
Dolby® and Dolby® Pro Logic are trademarks of Dolby Laboratories
As an ENERGY STAR® Partner, Philips has determined that this product
meets the ENERGY STAR® guidelines for energy efficiency.
suspension 1suspension 2
excursion 1
excursion 2
excursion 2
excursion 1
wOOxTechnology
double suspension = double excursion
FWP880
FWP880
13
2
46
5
79
8
VOLUME
0
2
AUX/CDR
TV/AV
CD 123 TUNER TAPE 1/2
AUTO REV.CLOCK
á
à
ë
í
Ç
++ --
SHUFFLE
REPEAT
DIM
TV VOL TV VOL
DSC
WOOX LEVELWOOXSLEEPTIMER ON/OFF
TEST TONE
DPL
VEC
PER. BTC
BALANCE
LR
REAR
CENTER
É
Å
