Philips FW-R7 User manual

FW-R7
CDR Mini Hi-Fi System
Mini Hi-Fi System with Integrated CD-Recorder
• 2 x 50 Watts RMS Stereo
• Make your own CDs with Integrated CD-Recorder
• Replay your own CDR disc in any CD player
• 3 CD Changer
• Double Speed Recording from CD
• CD Text input, editing and recording
• Simplified recording modes : CD > CD and Compile CD
• Record onto CD from CD changer, radio, or any external source
• 3-Way Bass Reflex Speaker System
• Subwoofer Ready
• Digital Input and Output
• Automatic Level Control for perfect compilations
• 42-Key Remote Control
w
a
k
e
u
p
/
s
l
e
e
p
/
r
e
c
o
r
d
t
i
m
e
r

Sound Enhancement
2 x 50 Watts RMS Stereo
50 watts continuous output power per channel, at 6
Ohms, from 30 Hz-20 kHz, with no more than 10% Total
Harmonic Distortion (THD).
Integrated Audio CD Recorder
Make your own CD's with Bit-perfect digital quality.
Digital Sound Control and Balance Control
Digital Sound Control allows you to select from pre-set
modes that control the frequency bands of sound to
optimize certain musical styles. Each mode uses graphic
equalizing technology to automatically adjusts the sound
balance to enhance the most important sound
frequencies in your chosen music style from Rock,
Classic,Vocal,Techno, Jazz and Optimal.
Balance control allows the sound adjustment of the left
and right speaker.
Loudness and Pure Sound Control
Loudness is dynamic sound adjustment that amplifies
high and low frequencies depending on the volume (the
higher the volume, the less the amplification). Thereby it
creates 'richer' sound impression already at low volume.
Pure Sound Control allows you to switch off all sound
adjustments at the touch of a button.
3-Way Bass Reflex Speaker System
Equipped with one 6 1/2" woofer for smooth low and
mid range reproduction, one 2 1/2" ferro-fluid cooled
tweeter and one 1" Polydome tweeter for crisp high
tones.
Automatic Digital Record Level Control
During recording from the internal CDC, the unit
automatically equalises volume levels between CDs, so
that there are no unpleasant volume jumps during
playback of the recorded CD.
Incredible Surround™
Dramatically expands the soundfield to envelop the
listener in their music. With the usual two-speaker setup,
Incredible Surround™ widens the soundstage farther to
the left and right while adding the greater depth of clubs,
concert halls and stadiums for a more exciting
experience.
Subwoofer Ready
Affords easy access to greater dimensions in sound with
output signals available for connection to a subwoofer.
Convenience
Unique 'Recording Studio' Control Console
Ergonomic grouping of all your recording functions in
one easy to find section.
Simplified Recording Mode
CD > CD duplicates entire CD, Compile CD is perfect
for simple compilation.
Double Speed Recording from CD
Make your own CD in half the time.
CD-Text
No more need to look-up the track you want to play or
record in the CD inlay booklet, simply select the track by
name from the display, directly from the disc. The display
can show both artist and title for the entire album as
well as individual tracks. With the CDR Mini Hifi System,
you can also create your own CD Text information for
e.g. your own compilations.
3-Disc CD Changer with Motorized Drawer
Multi-disc play capability provides more than three hours
of continuous music.
CD-Rewritable Compatible
The player offers 100% playback guarantee of CD-
Rewritable CD's over the entire lifetime of the player. Even
CD-RW audio recordings on computers can be used.
Integrated digital tuner
Listen and record your favourite radio stations (record in
FM only).
Digital Clock with RecordTimer
Use the built-in digital clock to record that special radio
show from the built-in tuner or any external source
while you are away.
42-Key Remote Control
The ergonimically styled remote control gives you
access to all essential functions, and has a 10-key pad
for entry of CD Text and direct access to track or
tuner presets.
CD Synchro CD Recording
Make a simple synchronised start recording from either
analog or digital sources.
Energy Saving Standby Mode (<2 watts)
Most systems consume 10-15 watts just on standby.
Philips systems consume less than 2 watts of energy on
standby for big saving to the listener.
Shuffle One/All Discs
Plays all selections on a particular disc or multiple discs in
multi-disc players in random order, ignoring the
sequential order in which they were originally recorded.
Design
Design Concept
The attractive design focusses direct attention on the
main product function, the CD Recorder drawer. This
emphasis is supported by the logically designed
recording control panel, with the two control areas
around the jog and volume knobs.
Oversized, MultiColor, Digital FTD Display
This large display is easy to read at any distance with no
distortion or distraction and the multi-color format
makes it easy to recognize different functions at a glance.
Detachable Cloth Speaker Grilles
Detachable cloth covered grilles protect delicate speaker
components with rich, high-tech styling.
UPC Code: 0 37849 89363 0
Product Dimensions:
10.4" W x 12.2" H x 13.2" D (electronics)
9.4" W x 12.2" H x 9.8" D (speakers)
Package Dimensions:
22.8" W x 28.3" H x 14.1" D
Product weight: 48.5 lbs.
Carton contains: 3CD Changer + CDR
Mini Hi-Fi System, Multi-Function Remote
Control, Batteries, Operating instructions,
Warranty information
Inputs and Outputs
1 x Digital Coax Input
A digital input is foreseen to connect digital sound sources.
The built-in sample rate converter ensures that a wide
range of sources can be connected (e.g. CD players, DVD
players, DAT players etc.).
1 x Digital Coax Output
A digital output connection is foreseen to enable digital
(CD) recordings from any of the digital inputs.
1 x Analog Input
A analog input is foreseen to connect analog sound
sources (e.g. phono, CD,Tape,Turntable, etc)
1 x Analog Line Output
A analog output connection is foreseen to enable analog
recordings from any of the analog inputs.
1 x Headphone Jack
Plug in a set of stereo headphones and enjoy your favorite
CD, cassette, or radio station without disturbing other
family members in the room. This convenient feature
allows different people in your household to use different
electronic entertainment media without interference.
1 x Subwoofer connections
Affords easy access to greater dimensions in sound with
output signals available for connection to a subwoofer.
FW-R7
CDR Mini Hi-Fi System
Printed in Singapore
Date printed : Oct 1999
©1999 Royal Philips Electronics N.V.
All rights reserved
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
In some countries, use of the CDR Mini HiFi System as shown or
mentioned in this leaflet may require the authorisation of copyright
holders
As an ENERGY STAR® Partner, Philips has determined that this product meets the
ENERGY STAR® guidelines for energy efficiency.
