Philips FW890P User manual

FW890P
CD Mini System
3000
wattswattsPMPOPMPO
d
i
g
i
t
a
l
r
e
c
o
r
d
i
n
g
r
e
a
d
y
I
N
T
E
R
A
C
T
I
V
E
S
O
U
N
D
S
T
U
D
I
O
2x240
+80+2x40
MPO
watts
watts
5 Speaker Dolby® Pro Logic Mini System
• 3000 watts PMPO
• 2 x 240 watts, 80 watts, 2 x 40 watts Music Power
• 2 x 120 watts, 40 watts, 2 x 20 watts RMS Stereo
• 5 Speaker Dolby® Pro Logic Surround Sound System
• G-Sound Technology
• Interactive Sound Studio
• 9-band Spectrum Analyzer with 5 Display Modes
• 3-way Bass Reflex Speaker System with Detachable Grilles
• Super Large Woofer
• Magnetically Shielded (Front and Center Speakers)
• CD Text
• CD-Rewritable compatible
• Full RDS suite including ‘NEWS’ & Traffic Announcement (/22 & /34)
• Dolby B Noise Reduction (/22 & /34)
• Dual Logic Tape Deck with Auto Reverse (R+1)
• Digital Recording Ready (digital and line out)
• Subwoofer Ready
• Karaoke Feature
• Energy Saving Standby mode (<2 watts) (/22 & /34)

2
21 3
TAPE 1/2 AUXTUNERTV
CD
DBBSURROUND DSC
PROGRAMREPEAT SHUFFLE
DPL MUTE
BALANCE
LR
CENTER
REAR
SIDE PAUSE SLEEP TIMER
Å
-+
-+
CD DIRECT
VOLUME
á
à
ë
í
É
Ç
TEST
TONE
/21 /22 /30 /33 /34
Asia Pacific
Australia/NZ •
Middle East/SAfrica
Latam •
Europe •
E Europe •
Mexico •
tuner
FM65.81-74MHz •
FM87.5-108MHz • • • •
MW522-1602kHz ••• •
LW153-279kHz •
FM75 ohm clickfit ••• •
mains supply
120/230V 50~60Hz •
230V/50Hz •• •
general
made in sticker •••
amplifier
• 3000 watts PMPO
• 2 x 240 watts, 80 watts, 2 x 40 watts Music Power
• 2 x 120 watts, 40 watts, 2 x 20 watts RMS,
±10% THD, 6 Ohm, 1 kHz
• 5 Speaker Dolby® Pro Logic Surround Sound
System
• G-Sound Technology:
- Super Large Woofer
- Super Class G Amplifier
- Gyros switching
- G-Bass port
- G-cone
- Ferro Fluid Tweeter
• Interactive Sound Studio:
- 26 modes Digital Sound Control
- Automatic Digital Sound Control
- Calibration
- 26 modes Virtual Environment Control
(hall, disco, concert, cinema, club, arcade)
- 4 Studio Effects
(surf, 3D pan, hold, strobe) + MAX
- 6 personal settings
• 3-step Dynamic Bass Boost
(Beat, Punch, Blast)
• Bass Optimization
compact disc player
• CD Text
• motorized front loading 3 CD changer
• CD-Rewritable compatible
• digital servo technology
• bit-check D/A converter
• 40-track CD Random Program
• play modes (repeat/shuffle/program)
• repeat track/disc/all
• change 2 discs while playing 1
tuner
• RDS: station name, program type, RDS text,
clock set (/22 & /34)
• RDS: ‘NEWS’ & Traffic Announcement (/22 & /34)
• FM/MW/LW Digital Tuner with 40 presets (LW /22)
• easy set/auto store for radio (and clock /22 & /34)
tape deck
• Dolby B Noise Reduction (/22 & /34)
• Dual Logic Tape Deck
• Auto Reverse (R+1)
• high and normal speed dubbing
• CD synchro recording
• automatic recording level control
• automatic tape type selection
• electronic speed control and full auto stop
• electronic tape counter
loudspeaker boxes
• 3-way Bass Reflex
• 8" woofer
• 2.5" Ferro Fluid Tweeter
• 2 x 1" polydome tweeter
• magnetically shielded
• detachable grilles
• G-Bass Port in rear side
• click-fit connectors
surround speakers
• 1-way surround speakers (4" full range)
• 6 Ohm
center speaker
• 1-way speaker (4" full range)
• 12 Ohm
• magnetically shielded
connections
• stereo headphones: 3.5mm stereo jack
• video/aux: cinch type sockets
• subwoofer out: cinch type socket
• Digital Recording Ready:
- digital out: cinch type socket
- line out: cinch type socket
• color coded cables:
- front: red/black
- center: blue/black
- surround: grey/white
• Karaoke mic: 3.5mm jack
general
• 5 display modes incl. NITE mode
• multicolor FTD display
• 9-band Spectrum Analyzer
• music calender
• demo mode
• clock/timer
• 2 timer modes (wake-up/sleep)
• wake-up with CD, tuner or tape
• 35-key AV Remote Control
• automatic clock set via RDS (/22 & /34)
• Karaoke Feature
• Energy Saving Standby mode (<2 watts) (/22 & /34)
5 Speaker Surround Sound System
Philips 5 Speaker Dolby® Pro Logic Surround
Sound System treats homeviewers to cinema sound
quality that has until now,remained in the realm of
cinemas.Simply connect to hifiVCR or stereoTV.
( )
Dolby® Pro Logic 3 CD changer mini system
standard product information
EAN:87 10101 35807 9 (/34)
EAN:87 10101 35806 2 (/22)
EAN:87 10101 35802 4 (/21)
EAN:87 10101 36194 9 (/30)
Product Dimensions:
265mmW x 310mmH x 363mmD (center unit)
260mmW x 338mmH x 315mmD (speakers)
224mmW x 98mmH x 224mmD (surround)
260mmW x 140mmH x 240mmD (center)
Package Dimensions:
664mmW x 712mmH x 474mmD
Product weight: 23 kg
Carton contains: CD Mini System, Surround Sound Speakers,Center
speaker,Multi-Function Remote Control,Batteries (2 x AA),
Operating instructions,Warranty information,FM antenna,AM antenna
Printed in Singapore
Date printed : Sept 1998
Specifications subject to change without notice.
© 1998 Koninklijke Philips Electronics N.V.
All rights reserved.
Dolby Pro-Logic,the Dolby B NR System and the double-D symbol
are trademarks of Dolby Laboratories Licensing Corporation.
Manufactured under license from Dolby Laboratories Licensing
Corporation.
