Philips MCD515/98 User manual

MCD515
DVD Micro Theatre
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:091

2
CAUTION
Use of controls or
adjustments or performance
of procedures other than
herein may result in
hazardous radiation
exposure or other unsafe
operation.
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:092

3
1
2
6
$
@
9
%
8
4
#
0
!
&
*
7
(
3
5
TUNING
PRESET
^
)
¡
MIC VOL
MIC IN
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:093

4
1
2
#
7
0
ª
£
3
)
(
*
™
¡
•
8
9
§
∞
&
$
%
!
@
0
7
5
6
8
^
4
DSC
PROGRAMMODEANGLE A-B
IS
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:094

5
.
Manufactured under license from Dolby
Laboratories.
"Dolby", "Pro Logic" and the double-D symbol
are trademarks of Dolby Laboratories.
This product incorporates copyright protection
technology that is protected by method claims of
certain U.S. patents and other intellectual
property rights owned by Macrovision
Corporation and other rights owners. Use of this
copyright protection technology must be
authorized by Macrovision Corporation, and is
intended for home and other limited viewing
uses only unless otherwise authorized by
Macrovision Corporation. Reserve engineering
or disassembly is
prohibited.
DivX, DivX Certified,
and associated logos
are trademarks of
DivXNetworks, Inc and
are used under license.
Windows Media is a trademark of
Microsoft Corporation.
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:095

6
Abkhazian 6566
Afar 6565
Afrikaans 6570
Amharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Avestan 6569
Aymara 6589
Azerhaijani 6590
Bahasa Melayu 7783
Bashkir 6665
Belarusian 6669
Bengali 6678
Bihari 6672
Bislama 6673
Bokmål, Norwegian 7866
Bosanski 6683
Brezhoneg 6682
Bulgarian 6671
Burmese 7789
Castellano, Español 6983
Catalán 6765
Chamorro 6772
Chechen 6769
Chewa; Chichewa; Nyanja
7889
9072
Chuang; Zhuang 9065
Church Slavic; Slavonic 6785
Chuvash 6786
Corsican 6779
Česky 6783
Dansk 6865
Deutsch 6869
Dzongkha 6890
English 6978
Esperanto 6979
Estonian 6984
Euskara 6985
 6976
Faroese 7079
Français 7082
Frysk 7089
Fijian 7074
Gaelic; Scottish Gaelic 7168
Gallegan 7176
Georgian 7565
Gikuyu; Kikuyu 7573
Guarani 7178
Gujarati 7185
Hausa 7265
Herero 7290
Hindi 7273
Hiri Motu 7279
Hrwatski 6779
Ido 7379
Interlingua (International)7365
Interlingue 7365
Inupiaq 7375
Irish 7165
Íslenska 7383
Italiano 7384
Ivrit 7269
Japanese 7465
Javanese 7486
Kalaallisut 7576
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kernewek 7587
Khmer 7577
Kinyarwanda 8287
Kirghiz 7589
Komi 7586
Korean 7579
Kuanyama; Kwanyama 7574
Kurdish 7585
Lao 7679
Latina 7665
Latvian 7686
Letzeburgesch; 7666
Limburgan; Limburger 7673
Lingala 7678
Lithuanian 7684
Luxembourgish; 7666
Macedonian 7775
Malagasy 7771
Magyar 7285
Malayalam 7776
Maltese 7784
Manx 7186
Maori 7773
Marathi 7782
Marshallese 7772
Moldavian 7779
Mongolian 7778
Nauru 7865
Navaho; Navajo 7886
Ndebele, North 7868
Ndebele, South 7882
Ndonga 7871
Nederlands 7876
Nepali 7869
Norsk 7879
Northern Sami 8369
North Ndebele 7868
Norwegian Nynorsk; 7878
Occitan; Provencal 7967
Old Bulgarian; Old Slavonic 6785
Oriya 7982
Oromo 7977
Ossetian; Ossetic 7983
Pali 8073
Panjabi 8065
Persian 7065
Polski 8076
Português 8084
Pushto 8083
Russian 8285
Quechua 8185
Raeto-Romance 8277
Romanian 8279
Rundi 8278
Samoan 8377
Sango 8371
Sanskrit 8365
Sardinian 8367
Serbian 8382
Shona 8378
Shqip 8381
Sindhi 8368
Sinhalese 8373
Slovensky 8373
Slovenian 8376
Somali 8379
Sotho; Southern 8384
South Ndebele 7882
Sundanese 8385
Suomi 7073
Swahili 8387
Swati 8383
Svenska 8386
Tagalog 8476
Tahitian 8489
Tajik 8471
Tamil 8465
Tatar 8484
Telugu 8469
Thai 8472
Tibetan 6679
Tigrinya 8473
Tonga (Tonga Islands) 8479
Tsonga 8483
Tswana 8478
Türkçe 8482
Turkmen 8475
Twi 8487
Uighur 8571
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapuk 8679
Walloon 8765
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 8973
Yoruba 8979
Zulu 9085
Language Code
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:096

77
English
English ------------------------------------------------ 8
-------------------------------------------------------- 42
Index
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:097

8
English
Contents
General Information
Features ................................................................ 10
Discs for playback .............................................. 10
Supplied accessories .......................................... 10
Environmental information .............................. 11
Care and safety information ...................... 11-12
Connections
Step 1: Placing speakers .................................... 13
Step 2: Connecting speakers ............................ 14
Step 3:Antenna connection ............................. 14
Step 4: Connecting TV ................................. 14-16
Using component Video In jack (Cr Cb Y)
Using Video In jack
Using S-Video In jack
Using an accessory RF modulator
Step 5: Connecting the power cord ............... 16
Optional: Connecting additional equipment 16-
17
Controls
Controls on the system .................................... 18
Controls on the remote control .............. 18-19
Preparations
Step 1: Inserting batteries into the remote
control .................................................................. 20
Using the remote control to operate the
system
Step 2: Setting the clock ................................... 20
Step 3: Setting video preference ............... 21-22
Step 4: Setting language preference ................ 22
Basic Functions
Switching the system on/off ............................. 23
Power-saving automatic standby ..................... 23
Sound control ..................................................... 23
DBB
Volume control ................................................... 23
Microphone Mixing ............................................ 23
Key Control ......................................................... 23
Disc Operations
Playing discs ......................................................... 24
Using the disc menu .......................................... 24
Basic playback controls ............................... 24-26
Pausing playback
Selecting a track/chapter/title
Resuming playback from the last stopped
point
Zoom
Repeat
Repeat A-B
Program
Forward/Reverse Searching
Time search & search by chapter/track
number
Information display during playback
Special disc features ........................................... 26
Playing a Title
Camera Angle
Changing the Audio Language
Changing the Audio Channel
Subtitles
Playing MP3/WMA disc ..................................... 27
General operation
Playback selection
Playing JPEG Picture CD ................................... 27
General operation
Playback selection
Special JPEG features ......................................... 28
Zoom picture
Slide show playback modes
Playback with multi-angles
Playing a DivX disc ............................................. 28
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:098

9
English
Contents
System Menu Options
Basic operations ................................................. 29
SYSTEM SETUP ............................................ 29-31
TV SYSTEM
SCREEN SAVER
TV TYPE
PASSWORD
RATING
DEFAULT
DIVX(R) VOD registration code
LANGUAGE SETUP .......................................... 31
VIDEO SETUP .................................................... 31
BRIGHTNESS
CONTRAST
HUE
SATURATION
AUDIO SETUP ............................................. 31-32
DIGITAL OUT
DOWNMIX
3D PROCESSING
LPCM
NIGHT MODE
MIC SETUP
Radio Reception
Tuning to radio stations .................................... 33
Programming radio stations ............................. 33
Automatic programming ............................... 33
Manual programming ...................................... 33
Tuning to preset radio stations ....................... 33
Changing tuning grid .......................................... 34
Tape Operation/Recording
Tape playback ...................................................... 35
General information on recording ................. 35
Preparation for recording ................................ 36
Synchro start CD recording ............................ 36
One touch recording ......................................... 36
Clock/Timer
Clock setting ....................................................... 37
Timer setting ....................................................... 37
Sleep timer setting ............................................. 37
Specifications ........................................... 38
Tr oubleshooting .............................. 39-40
Glossary ......................................................... 41
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:099

10
English
General Information
Features
Additional Component Connections
Lets you connect other audio and audio/visual
components to the system so you can use the
system’s surround sound speakers.
Parental control (rating level)
Lets you set a rating level so that your children
cannot watch a DVD that has a rating higher
than you set.
Sleep timer
Enables the system to switch to standby mode
automatically at a preset time.
Night Mode
Lets you compress the dynamic range, reducing
the difference in loudness between different
sounds in Dolby Digital mode.
Discs for playback
Your DVD System will play:
–Digital Video Discs (DVDs)
–Video CDs (VCDs)
–SuperVideo CDs (SVCDs)
–Digital Video Discs + Rewritable (DVD+RW)
–Compact Discs (CDs)
–Picture (Kodak, JPEG) files on CDR(W)
–Windows Media Audio (WMA)
– DivX(R) disc on CD-R(W):
–DivX 3.11, 4.x and 5.x
–Supported MP3-CD format.
•ISO 9660 / UDF format
•Max. title/album name –10 characters
•Max. title number plus album is 255.
•Max. nested directory is 8 levels.
•The max. album number is 32.
•The max. MP3 track number is 999.
•Supported sampling frequencies for MP3
disc: 32 kHz, 44.1 kHz, 48 kHz.
•Supported Bit-rates of MP3 disc are: 32, 64,
96, 128, 192, 256 (kbps).
The following formats can’t be supported
•The files like *.VMA, *.AAC, *.DLF, *.M3U,
*.PLS, *.WAV,
•The discs recorded under Joliet format
Region Codes
DVDs must be labeled for ALL regions or Region
3 in order to play on this DVD system.You
cannot play discs that are labeled for other
regions.
Notes:
–For mixed mode discs, only one mode will be
selected for playback according to the recording
format.
–If you are having trouble playing a certain disc,
remove the disc and try a different one. Improperly
formatted discs will not play on this system.
–DTS surround audio output is not available in
this DVD player.
Supplied accessories
–Composite video cable (yellow)
–MW loop antenna
–FM wire antenna
–Remote Control and two AA batteries
–This instruction booklet and a quick start guide
ALL
3
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:0910

11
English
General Information/Maintenance
Environmental information
Any unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialised company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Care and safety information
Avoid high temperatures, moisture,
water and dust
●Do not expose the system, batteries or discs to
humidity, rain, sand or excessive heat (caused by
heating equipment or direct sunlight). Always
keep disc trays closed to avoid dust buildup on
the lens.
●No objects filled with liquids, such as vases, shall
be placed on the apparatus.
●No naked flame sources, such as lighted candles,
should be placed on the apparatus.
●The apparatus shall not be exposed to dripping
or splashing.
Avoid condensation problem
●The lens may cloud over when the player is
suddenly moved from cold to warm
surroundings, making it impossible to play a disc.
Leave the player in the warm environment until
the moisture evaporates.
Do not block the vents
●Do not operate the system in an enclosed
cabinet and allow about 10 cm (4 inches) of free
space all around the player for adequate
ventilation.
10 cm
(4 inches)
10 cm
(4 inches)
10 cm
(4 inches)
DVD Micro Hi-Fi System
●The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers table-cloths, curtains, etc.
Cleaning the cabinet
●Use soft cloth slightly moistened
with a mild detergent solution.
Do not use a solution containing
alcohol, spirits, ammonia or
abrasives.
Cleaning discs
●To clean a CD, wipe it in a straight line from the
center towards the edge using soft and lint-free
cloth. A cleaning agent may damage the disc.
●Write only on the printed side of a CDR(W)
and only with a soft felt-tipped pen.
●Handle the disc by its edge. Do not touch the
surface.
Cleaning the disc lens
●After prolonged use, dirt or dust may
accumulate at the disc lens.To ensure good
playback quality, clean the disc lens with Philips
CD Lens Cleaner or any commercially available
cleaner. Follow the instructions supplied with
cleaner.
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:0911

12
English
General Information/Maintenance
Finding a suitable location
●Place the player on a flat, hard, stable surface.
●Install this unit near the AC outlet and where the
AC power plug can be reached easily.
Cleaning the head and the tape paths
●To ensure good recording and playback quality,
clean the head A, the capstan(s) B, and
pressure roller(s) Cafter every 50 hours of
tape operation.
●Use a cotton swab slightly moistened with
cleaning fluid or alcohol.
●You also can clean the head by playing a
cleaning tape once.
CBABC
Demagnetising the head
●Use a demagnetising tape available at your
dealer.
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:0912

13
English
Connections
IMPORTANT!
–The type plate is located at the rear
of the system.
–The voltage selector located at the
back of this system is preset at
220V-240V from the factory. For
countries that operate at 110V-127V,
please adjust to 110V-127V before you
switch on the system.
–Before connecting the AC power cord
to the wall outlet, ensure that all other
connections have been made.
–Never make or change any
connections with the power switched on.
–High voltage! Do not open.You run the
risk of getting an electric shock.
–The machine does not contain any user-
serviceable parts.
–Modification of the product could result
in hazardous radiation of EMC or other
unsafe operation.
To avoid overheating of the system, a
safety circuit has been built in.Therefore,
3
SUB
WOOFER OUT
AUX/
CDR IN
R
LINE OUT
DIGITAL
OUT
L
RL
+
R
+
L
SPEAKERS 8Ω
MW ANTENNA FM ANTENNA
Speaker
(right)
Speaker
(left)
3
LINE OUT
DIGITAL
OUT
RL
FM wire
antenna
AUDIO
IN
S-VIDEO
IN
VIDEO IN
AUDIO
IN
S-VIDEO
IN
VIDEOIN
TVIN
5
Cr
Cb
Y
MW loop
antenna
AC power cord
your system may switch to Standby mode
automatically under extreme conditions.
If this happens, let the system cool down
before reusing it (not available for all
versions).
Step 1: Placing speakers
Front
speaker
( left )
Front
speaker
( right )
VIEWING AREA
Place the front left and right speakers at equal
distances from theTV set and at an angle of
approximately 45 degrees from the listening
position.
Notes:
–To avoid magnetic interference, do not position
the front speakers too close to your TV set.
–Allow adequate ventilation around the DVD
System.
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:0913

14
English
FM Antenna
●For better FM stereo reception, connect an
outdoor FM antenna to the FM AERIAL (FM
ANTENNA) terminal.
Step 4: ConnectingTV
IMPORTANT!
–You only need to make one video
connection from the following options,
depending on the capabilities of your TV
system.
–Connect the DVD system directly to
theTV.
Using component Video In jack (Cr Cb
Y)
3
AUX/
CDR IN
R
LINE OUT
DIGITAL
OUT
L
RL
AM ANTENNA FM ANTENNA
1
2
Connections
Step 2: Connecting speakers
12
Connect the speaker wires to the SPEAKERS
terminals, right speaker to "RIGHT" and left
speaker to "LEFT", coloured (marked) wire to
"+" and black (unmarked) wire to "-". Fully insert
the stripped portion of the speaker wire into the
terminal as shown.
Notes:
– Ensure that the speaker cables are correctly
connected. Improper connections may damage the
system due to short-circuit.
–For optimal sound performance, use the
supplied speakers.
– Do not connect more than one speaker to any
one pair of +/- speaker terminals.
– Do not connect speakers with an impedance
lower than the speakers supplied. Please refer to
the SPECIFICATIONS section of this manual.
Step 3: Antenna connection
Connect the supplied MW loop antenna and FM
antenna to the respective terminals.Adjust the
position of the antenna for optimal reception.
MW Antenna
MW
●Position the antenna as far as possible from a TV,
VCR or other radiation source.
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:0914

15
English
1Use the component video cables (red/blue/
green) to connect the system’s Cr Cb Y jacks to
the corresponding Component video input jacks
on theTV set.
2To hear the sound of this DVD Player through
your TV, use the audio cables (white/red-not
supplied) to connect LINE OUT (L/R) jacks of
the DVD Player to the corresponding AUDIO
IN jacks on the TV.
Using Video In jack (CVBS)
3
R
LINE OUT
DIGITAL
OUT
L
RL
AM ANTENNA FM ANTENNA
AUDIO
IN
2
1
1Use the composite video cable (yellow) to
connect the system's VIDEO OUT jack to the
video input jack (or labelled as A/V In,Video In,
Composite or Baseband) on the TV set.
2To hear the sound of this DVD Player through
your TV, use the audio cables (white/red-not
supplied) to connect LINE OUT (L/R) jacks of
the DVD Player to the corresponding AUDIO
IN jacks on the TV.
Using S-Video In jack
1Use the S-Video cable (not supplied) to connect
the system's S-VIDEO OUT jack to the S-
Video input jack (or labelled asY/C or S-VHS)
on theTV set.
2To hear the sound of this DVD Player through
your TV, use the audio cables (white/red-not
supplied) to connect LINE OUT (L/R) jacks of
the DVD Player to the corresponding AUDIO
IN jacks on the TV.
Connections
3
R
LINE OUT
DIGITAL
OUT
L
RL
AM ANTENNA FM ANTENNA
AUDIO
IN
2
1
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:0915

16
English
Using an accessory RF modulator
IMPORTANT!
–If yourTV set only has a single
Antenna In jack (or labelled as 75 ohm or
RF In), you will need a RF modulator in
order to view the DVD playback via TV.
See your electronics retailer or contact
Philips for details on RF modulator
availability and operations.
1Use the composite cable (yellow) to connect the
system's VIDEO OUT jack to the video input
jack on the RF modulator.
2Use an RF coaxial cable (not supplied) to
connect the RF modulator to your TV's RF jack.
Connections
Step 5: Connecting the power
cord
IMPORTANT!
–Never make or change any connection
with the power switched on.
After everything is connected properly, plug in
the AC power cord to the power outlet.
Optional: Connecting additional
equipment
IMPORTANT!
–Some discs are copy-protected.You
cannot record the disc through a VCR or
digital recording device.
–When making connections, make sure
the colour of cables matches the colour
of jacks.
–Always refer to the owner's manual of
the other equipment for complete
connection and usage details.
SUB
WOOFER OUT
AUX/
CDR IN
R
LINE OUT
DIGITAL
OUT
L
RL
+
R
+
L
SPEAKERS 8Ω
AM ANT
AUDIO
INPUT
AUDIO OUT
L
R
A
B
3
AUDIO IN
R L
VIDEO
IN
TO TVANT IN
CH3 CH4
2
1
RF coaxial cable to TV
Back of RF Modulator
(example only)
Antenna or
Cable TV signal
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:0916

17
English
Connections
Viewing and listening to the playback of
other equipment A
Connect the system's AUX (R/L) jacks to the
AUDIO OUT jacks on the other audio/visual
device (such as a TV,VCR, Laser Disc player or
cassette deck).
Before starting operation, press SOURCE on
the front panel to select AUX or press AUX on
the remote in order to activate the input source.
Connecting an active subwoofer B
Connect the DVD micro system's
SUBWOOFER OUT jack to the AUDIO
INPUT jack on an active subwoofer (not
supplied).
3
SUB
WOOFER OUT
AUX/
CDR IN
R
LINE OUT
DIGITAL
OUT
L
RL
AM ANTENNA FM ANTENNA
DIGITAL IN
D
AUDIO IN
L
R
VIDEO IN
C
Using the VCR for recording DVDs C
Connect one of the system's VIDEO OUT
jacks to the corresponding VIDEO IN jack and
LINE OUT (R/L) jacks to the AUDIO IN jacks
on the VCR.This will allow you to make analogue
stereo (two channel, right and left) recordings.
Recording (digital) D
Connect the system's DIGITAL OUT jack to
the DIGITAL IN jack on a digital recording
device (such as DTS-Digital Theatre compatible,
with Dolby Digital decoder).
Before starting operation, set the DIGITAL OUT
according to the audio connection. (See “System
Menu Options-DIGITAL OUT”.)
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:0917

18
English
Controls
Controls on the system
1STANDBY-ON y
–switches the system on/off.
2Display screen
–to view the current status of the system.
3SOURCE
–to select the respective sound source : DVD
TAPE, AUX or TUNER.
4BAND / DISPLAY
for Tuner ............. to select waveband : FM or MW.
for DVD/VCD/CD/MP3-CD displays disc
information on theTV screen
and system display panel during
playback.
5PROGRAM
for VCD/CD/MP3-CD…to program disc tracks.
for Tuner ............. to program preset radio stations.
6PRESET í/ë
for Tuner ............. to select a preset radio station.
for DVD/VCD/CD/MP3 CD… to select a
desired track.
7TUNING 22/33
*for DVD/VCD/CD................... to fast reverse/
forward the disc. (It is impossible to fast reverse /
forward for MP3-CD)
for Tuner ............. to tune to a lower or higher
radio frequency.
for Tape ............... to rewind or fast forward.
8Ta pe deck
9OPEN/CLOSE ç
–to open the tape compartment.
0ÉÅ
–to start or interrupt playback.
!9
for DVD/VCD/CD/MP3-CD…to stop playback
or to clear a program.
for Tape ............... to stop playback or recording.
@VOLUME
–to increase or decrease the volume.
–to adjust the hours and minutes for the clock/
timer functions.
#RECORD
– to start recording.
$CLOCK SET
*for Clock .......... (on the system only) to set the
clock function.
%iR sensor
–infrared sensor for remote control.
^OPEN•CLOSE ç
–to open or close the disc tray.
& DSC
– selects different types of preset sound equalizer
settings (FLAT, CLASSIC, JAZZ, POP or ROCK).
*DBB/INCREDIBLE SURROUND
– to create a super-enhanced stereo effect.
–to enhance the bass.
(n
–to connect headphones.
)MIC IN
–to connect microphone
¡MIC VOL
–to adjust the mixing level for Karaoke
Controls on the remote control
1y
–switches the system on/off.
2Numeric Keypad (0-9)
–inputs a track/title/chapter number of the disc.
3PROGRAM
–DVD/VCD/CD/MP3-CD: enters the program
menu.
– Picture CD: during playback, to select a slide
show mode.
–Tuner: programs preset radio stations.
4 SOURCE
– to select the respective sound source : DISC
TUNER, TAPE or AUX.
5 SYSTEM MENU (disc mode only)
–to enter or exit the system menu bar.
* = Press and hold the button for more than three seconds.
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:0918

19
English
6DISC MENU (disc mode only)
–DVD/VCD: enters or exits the disc contents
menu.
–VCD2.0: switches the playback control mode on
or off .
722/33
Tuner
–press to tune to a lower/higher radio frequency
gradually.
–press and hold, then release the key to start
automatic search for a radio frequency
downward/upward.
Disc
–(not for MP3 CD) searches backward/forward in
a disc at different speeds.
– In DISC mode, to select a movement direction in
the disc menu or system menu bar.
83/4
– In DISC mode, to select a movement direction in
the disc menu or system menu bar.
9OK
–to exit or confirm the selection.
0í/ë
–Disc: skips to the previous/next chapter/title/
track.
–Tuner: selects a preset radio station.
!STOP 9
– In DISC mode, to stop playback or clear a
program.
@PLAY/PAUSE 2;
–In DISC mode, to start or interrupt playback.
#VOL +/-
–adjusts the volume upward/downward.
–adjusts the hours and minutes in clock/timer
setting mode.
–switches the set timer ON or OFF.
$ANGLE
–selects a DVD camera angle.
%SUBTITLE
–selects a subtitle language.
^ SLEEP
–to set the sleep (auto-off) timer function.
&IS
– to create a super-enhanced stereo effect.
*DSC
– selects different types of preset sound equalizer
settings (FLAT, CLASSIC, JAZZ, POP or ROCK).
(DBB
–enables or disables bass enhancement.
) MUTE
–to interrupt or resume sound reproduction.
¡DISPLAY (OSD)
– displays information on TV screen during
playback.
™ECHO
– to adjust the echo in the karaoke mode.
£MODE
–to select various repeat modes or the shuffle
play mode for a disc.
≤A-B
–for VCD/CD: to repeat a specific section within
the same track.
–for DVD: to repeat a specific section in a disc.
∞AUDIO
for VCD
–sets Stereo, Mono-Left or Mono-Right sound
mode.
for DVD
–selects an audio language.
§TIMER
*– to set the timer.
≥ZOOM
–DVD/VCD/Picture CD: enlarges or reduces a
picture or active image on the TV screen.
•KEY
– to change the tone level to suit your vocal range.
ªGOTO
– In DISC mode, to fast search in a disc by
entering a time, title, chapter or track.
Notes for remote control:
–First, select the source you wish to
control by pressing one of the source select
keys on the remote control (DISC or
TUNER, for example).
–Then select the desired function ( 2;, í,
ëfor example).
* = Press and hold the button for more than three seconds.
Controls
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:0919

20
English
IMPORTANT!
–Make sure to complete the
preparation procedures before operating
the system.
Step 1: Inserting batteries into
the remote control
1Open the battery compartment.
2Place two batteries (Type R06 or AA) in the
compartment with the correct polarity as
indicated by “+” and “–” symbols.
3Close the cover.
Using the remote control to operate the
system
1Point the remote control directly
at the remote sensor (iR) on the
front panel.
2Select the source you wish to
control by pressing one of the
source select buttons on the
remote control (for example
DISC,TUNER).
3Then select the desired function
(for example 2;, í, ë).
CAUTION!
–Remove batteries if they are
exhausted or will not be used for a long
time.
–Do not use old and new or different
types of batteries in combination.
–Batteries contain chemical substances,
so they should be disposed of properly.
Step 2: Setting the clock
1Go to Standby mode.
2Press and hold CLOCK SET on the front
panel.
➜“SET CLOCK” is displayed briefly.Then, the
hour digits flash on the display screen.
3Turn the VOLUME control on the front panel
or press VOL +/- on the remote to set the
hours.
4Press CLOCK SET again.
➜The minute digits flash on the display screen.
5Turn the VOLUME control on the front panel
or press VOL +/- on the remote to set the
minutes.
6Press CLOCK SET to confirm the clock
setting.
Notes:
–This system only supports 24-hour mode.
– The clock setting will be erased when the system
is disconnected from the power supply.
–The system will exit clock setting mode if no
button is pressed within 30 seconds.
T
PRESET
Preparations
pg001-pg041_MCD515-98-Eng 2006.4.26, 10:0920
