Philips MCM1006 User manual

Version 1.3
MCM1006
3141 785 37183
Micro Hi-Fi System /51/55/93/77
Published by GD 1201 Service Audio Subject to modification
©Copyright 2012 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
or otherwise without the prior permission of Philips.
CONTENTS
Technical specification and version variation .........................1-1..1-2
Service measurement setup..........................................................1-3
Service aids .................................................................................1-4
Instructions on CD playability ...............................................2-1.. 2-2
Block diagram................................................................................3-1
Wiring diagram ..............................................................................4-1
Circuit diagram...................................................................... .5-1..5-5
Layout diagram.......................................................................6-1..6-4.
Exploded view diagram .................................................................7-1
All manuals and user guides at all-guides.com
all-guides.com

Type /Versions:
Features
Board in used:
MCM1006
Service policy
USB BOARD
DISPLAY BOARD
* TIPS : C -- Component Lever Repair.
M -- Module Lever Repair
-- Used
/51/55/93/77
Feature diffrence
RDS
VOLTAGE SELECTOR
ECO STANDBY - DARK
Type /Versions:
MCM1006
VERSION VARIATION
M/C
M/C
M/C
MAIN BOARD
/51/55/93
USB BOARD
Display board
Main board
PCBs location
1-1
LATAM/APMEA
All manuals and user guides at all-guides.com

Battery location
NA
A4
KT
CHECK
CMT
NAME : Mo Lam Kei
8
SH 190 - 1
2011-07-11
7/11/2011
7/11/2011
Description
Class No
MCM1006
Issued Date
Remark :
Unit in Master carton: N/A
Weight (excluding packing and batteries): 2.05 kg
Units in Dealer carton: 1 set
Finishing:
Material: ABS/HIPS
12
DISPLAY LENS
SPEAKER NET
CD FUNCTION CONTROL KNOB
10
FRONT CABINET
FUNCTION KNOB
6
MP3 JACK
KNOB VOLUME
8
USB JACK
POWER KNOB
4
CD DOOR
FUNCTION PUSH KNOB
Description
Page
CABINET
Dimensions with Boxes 532 x 242 x 200mm (LxWxH)
1
TOP CABINET
2
TUNING KNOB
Dimensions without Boxes: 532x242x200
Weight (including packing): 2.35kg
DEPICTION
Pos
3
5
7
9
11
13
All manuals and user guides at all-guides.com

DC operation / Backup Buffer
POWER CONSUMER
MAINS ( DC ADAPTOR )
Battery type :
Maximum :
( DEMO mode " OFF " ) , NOM. A, INPUT
Standby :
55 / 77 / 78
Yes
60 / 50Hz
/73
No
50 Hz
8
SH 190 - 4
Remarks :
8W
DC operation / Backup Buffer
R20 (UM1 / D-cell) x 6 (9V normal, 6.3V limit)
2011-07-11
CMT
NAME : Mo Lam Kei
KT
CHECK
A4
7/11/2011
7/11/2011
MCM1006
Issued Date
GENERAL PART 1 - GENERAL SPECICFICATION
Class No
Refer to the section of Version Overview
SAFETY requirements
ECO Power mode :
N/A
@ 1/8 Prated , NOM. A, INPUT
Frequency
60 / 50Hz
50 Hz
60 Hz
Voltage Selection
Yes
No
No
Version
97 / 98
/12
/96
PERFORMANCE CLASSES
POWER SUPPLY
MAINS ( A.C. )
120/230Vac ±15%
230 Vac ±10 %
120V+/-15%
220V-10%,240+10%
99-146V, 196-264Vac
ALL climates
: - 10 Dregree till + 50 Degree
RADIATION / IMMUNITY requirments ( EMC )
CLIMATIC requirements
Refer to the section of Version Overview
III
X
X
II
I
Supply + Amplifier
Loudspeaker Boxes
X
X
Recorder
USB
CD
GENERAL DESCRIPTION
CDSM with Tuner , CD, USB
Aux In, Headphone
LIFETIME : 5 Years
Class
Tuner
All manuals and user guides at all-guides.com

2011-07-11
MCM1006
Class No
CHECK
8
SH 190 - 5
7/11/2011
Issued Date
CMT
NAME : Mo Lam Kei
KT
GENERAL PART 1 - TECHNAICAL SPECICFICATION
A4
7/11/2011
( *1 ) Electrical parameters are to be measuremend at specker terminals across 6 Ohm load ( pure resistor )
with rated input signal in AUX mode; with DBB OFF
Remarks
Rated Impedance
Left / Right : 4 Ohms at 125Hz to 16KHz
LOUDSPEAKER ( BOXES )
2.5 mW +/-0.3mW ,
at R Load = 32 ohm @ max volume, 0dB, 1kHz CD
DC Operation
: .2W, 1 Channels (Lim: -1dB)
Frequency Response
: 125Hz - 14KHz
Microphone
-6 dB track (Audio Disc 1 ,Trk 35
Booster Out
( At 500mW Output in flat Mode)
USB
-6 dB track (Copy from Audio Disc 1 ,Trk 35)
Headphone
AUX
500mV
Digital Coaxial Out
Tuner
FM 67.5KHZ,AM80% Modulation(Limit :-6db)
Line Out ( Left / Right )
CD
-6 dB track (Audio Disc 1 ,Trk 35
Subwoofer Out
INTERCONNECTS
Input Sensitity ( ± dB ) rated ouput power at 1 kHz
Line Output Voltage ( *1 )
WOOX :
N/A
SIS :
N/A
Residual Noise ( Volume Minium )
0.06
DSC :
NA
uW
VAC :
N/A
DBB
Yes
Hum ( Volume Minimun )
OUTPUT stage Protection : Yes Temperature : YES Shorcircuit : Yes
.
INDICATORS
0.5
uW
TECHNIAL DESCRIPTION
2 x 2W matching LOUDSPEAKER of 2 x 4R. One INPUT SOURCE
GENERAL PART
N.A
N.A
Standby Mode Indicator : LCD display off
ECO Mode Indiicator : NA
ELECTRICAL DATA
( At Cold Condition with 10% THD )
N.A
OUTPUT POWER ( * 1 ) At THD = 10% , 1KHz sinewave
Main Operation
: 2W, 1 Channels (Lim: -1dB)
N.A
3
All manuals and user guides at all-guides.com

CMT
NAME : Mo Lam Kei
KT
CHECK
SH 190 - 6
2011-07-11
8
7/11/2011
A4
CLOCK / CD SPECICFICATION
Issued Date
7/11/2011
Class No
MCM1006
DBB effect
USB PART
- Refer to Philips USB direct user requirement
spec.
: 62dBA(Lim 57 dBA)
Channel Separation(10K)
: 30dB (Lim. 16dB)
CD Shock sens.
: 5kg
THD (100 ~10kHz)
: 2%(Lim 3.0%)
Channel Separation(1K)
: 40dB (Lim. 26dB)
: NA
Volume at Wakeup
: NA
THD (1kHz)
: 1.5%(Lim 2.0%)
Channel Unbalance (250 to 10k Hz)
: <= 3dB
Frequency Response(±3dB)
(@ volume max - 20dB and DBB off mode)
: 100Hz~10kHz
Signal to Noise Ratio(A-weighted)
INDICATORS
No of Timer Settings
CD PART
Display Type
: LCD
: NA
Clock Accuracy
TECHNIAL DESCRIPTION
CLOCK PART
Timer Setting
: NA
Remarks Time Setting
: NA
Timer Wakeup Mode
: NA
DBB
8+/- 2 dB at AUX 500mV, 1kHz
All manuals and user guides at all-guides.com
all-guides.com

125dBf
Large Signal
Search Time
60
Sec.
130dBf
SH 190 - 7
2011-07-11
24-32
19 - 35
Search Time
Sec.
CMT
NAME : Mo Lam Kei
8
Search tuning sensitivity
dBuV/m
Search tuning sensitivity
7/11/2011
A4
KT
CHECK
Class No
MCM1006
Issued Date
7/11/2011
Remarks
TUNER SPECICFICATION
dB
dB
114 dBuV/m
dBuV/m
120 dBuV/m
AM / MW
Nom.
--
Lim.
--
dBuV/m
20
50
dBf
24
55
dBf
--
18
Lim.
--
22
FM
Nom.
Wave Range
Noise Limited Sensitivity 26 dB
Image Rejection
IF Rejection
Stereo - 46 dB Quieting
48
51
dBf
Distortion ( RF 1mV, Frq Dev.75 kHz )
3
5
%
Distortion ( RF 50mV, m=80% )
%
- 3 dB Limiting Point
: 17
25
dBf
AGC figure of merit
dB
IF
: 10.7
± 0.3
MHz
IF
kHz
ELECTRICAL DATA
A.M
Nom
Limit
Unit
F.M.
Nom
Limit
Unit
Refer to version overview
INDICATORS : NA
AERIAL
FM : Telescope
AM/MW : Ferrite
Search tuning stop accuracy
RF >= 1V/m
RF >= a26 to 1V/m
WAVE RANGE
FM
Refer to version overview
AM
MW
50
dBA
TECHNIAL DESCRIPTION
GENERAL PART
Refer to version overview
FM S/N Ratio(A weighted) Mono input
80dBf
55
+/- 1
0
Step
Search Tuning Stop Accuracy RF:
91~120dBf
R/F:31~91dBf
FM Channel Seprantion -400/1K/5K
21/25/18
18/20/15
dB
dBf
Modulation Hum
dB
Modulation Hum
45
40
dB
All manuals and user guides at all-guides.com

1-3
LF Generator
e.g. PM5110
Recorder
Use Universal Test Cassette CrO2 SBC419 4822 397 30069
LEVEL METER
e.g. Sennheiser UPM550
with FF-filter
S/N and distortion met
e
e.g. Sound Technology ST170
L
R
DUT
or Universal Test Cassette Fe SBC420 4822 397 30071
LEVEL METER
e.g. Sennheiser UPM550
with FF
-
filter
S/N and distortion meter
e.g. Sound Technology ST1700B
L
R
DUT
CD
Use Audio Signal Disc
(replaces test disc 3)
SBC429 4822 397 30184
Bandpass
250Hz-15kHz
e.g. 7122 707 48001
LF Voltmeter
e.g. PM2534
DUT
S/N and distortion meter
e.g. Sound Technology ST1700B
Frame aerial
e.g. 7122 707 89001
Tuner AM (MW,LW)
To avoid atmospheric interference all AM-measurements have to be carried out in a Faraday´s cage.
Use a bandpass filter (or at least a high pass filter with 250Hz) to eliminate hum (50Hz, 100Hz).
RF Generator
e.g. PM5326
Ri=50:
Bandpass
250Hz-15kHz
e.g. 7122 707 48001
LF Voltmeter
e.g. PM2534
DUT
RF Generator
e.g. PM5326
S/N and distortion meter
e.g. Sound Technology ST1700B
Use a bandpass filter to eliminate hum (50Hz, 100Hz) and disturbance from the pilottone (19kHz, 38kHz).
Ri=50:
Tuner FM
MEASUREMENT SETUP
All manuals and user guides at all-guides.com

1-4
SERVICE AIDS
GB WARNING
All ICs and many other semi-conductors are
susceptible to electrostatic discharges (ESD).
Careless handling during repair can reduce life
drastically.
When repairing, make sure that you are
connected with the same potential as the mass
of the set via a wrist wrap with resistance.
Keep components and tools also at this
potential.
ESD
CLASS 1
LASER PRODUCT
GB
Safety regulations require that the set be restored to its original
condition and that parts which are identical with those specified,
be used
Safety components are marked by the symbol !.
Lead free
All manuals and user guides at all-guides.com

Set remains closed!
N
Y
Play a CD
for at least 10 minutes
Y
playability
ok ?
N
playability
ok ?
add Info for customer
"SET OK"
check playability
N
Y
playability
ok ?
check playability
check playability
return set
Customer complaint
"CD related problem"
"fast" lens cleaning
1
2
3For flap loaders (= access to CD drive possible)
cleaning method 4is recommended
INSTRUCTIONS ON CD PLAYABILITY
2 - 1
Exchange CDM
1-4For description - see following pages
