Philips 32RF52S User manual

3121 233 42281
Quick Use and Setup Guide
BASIC TV CONNECTIONS
Important Notice/Warning . . . . . . . . . . . . . . . . . . . .1
Making Basic TV Connections
Basic Cable TV Connection . . . . . . . . . . . . . . . . .1
Basic Cable Box Connection . . . . . . . . . . . . . . . .1
Basic Antenna TV Connection . . . . . . . . . . . . . . .1
Basic TV Operation . . . . . . . . . . . . . . . . . . . . . . . .2
Remote Battery Installation . . . . . . . . . . . . . . . . . . .2
Remote Control Button Descriptions . . . . . . . . . . . .2
How to Use the Installation Features . . . . . . . . . .3-4
Using the Language Control . . . . . . . . . . . . . . . . . .3
Setting the Tuner Mode A and B Controls . . . . . . .3
How to Automatically Program Channels . . . . . . . .3
How to Add and Delete Channels . . . . . . . . . . . . . .4
How to set the AutoChron™ Feature (Clock) . . . . .4
How to Name (Label) Channels . . . . . . . . . . . . . . .4
IMPORTANT
NOTE: This owner's manual is used with several
different television models. Not all features (and
drawings) discussed in this manual will necessar-
ily match those found with your television set.
This is normal and does not require that you con-
tact your dealer or request service.
WARNING: TO PREVENT FIRE OR SHOCK
HAZARD DO NOT EXPOSE THIS UNIT TO
RAIN OR EXCESSIVE MOISTURE.
Color TV
Color TV
CONTENTS
75
ANT "A"
Monitor out AV1 in AV2 in
VIDEO
L/Mono
AUDIO
R
Y
Pb
Pr
S-VIDEO
88
SURROUND SOUND
+ R - + L -
12
Your Cable TV input into your home may be a single (75 ohm) cable or a converter box installation. In either case, the con-
nection to the TV is very easy. Follow the steps below to connect
your cable signal to your new television.
If your cable signal comes directly from a round 75Ωcoaxial
cable use the following steps:
1
Connect the open end of the round Cable Company sup-
plied cable to the 75Ωinput on the TV. Screw it down finger
tight.
2
Plug the television in to the wall outlet and turn the TV on.
Refer to the AUTOPROGRAM feature to program all the
available channels on your cable signal.
If your cable signal comes from a cable box, use the following
steps:
3
Connect the open end of the round Cable Company sup-
plied cable to the cable signal IN(put) plug on the back of
the Cable Box.
4
Using a separate round coaxial cable, connect one end to the
OUT(put) plug on the back of the Cable Box.
5
Connect the other end of the round coaxial cable to the
75Ωinput on the back of the television. Screw it down finger
tight.
6
Plug the television in to the wall outlet and turn the TV on.
Refer to the TUNER and AUTOPROGRAM features on page
3 of this Quick Use Guide. TUNER should be set to the
CABLE option. AUTOPROGRAM can be set to program all
the available channels on your cable signal into the televi-
sion’s memory.
CABLE TV
75
ANT "A"
Monitor out AV1 in AV2 in
VIDEO
L/Mono
AUDIO
R
Y
Pb
Pr
S-VIDEO
88
SURROUND SOUND
+ R - + L -
OUTPUT
INPUT
5
6
34
Direct Cable Connection:
Cable Box Connection:
Cable signal coming from
Cable Company (Round
75Ωcoaxial cable)
Jack Panel Back of TV
AC Power
Wall Outlet
Power Plug
from back of TV
Jack Panel Back
of Cable Box
Cable Signal IN from
the Cable Company
Round 75Ω
Coaxial Cable Jack Panel
Back of TV
AC Power
Wall Outlet
Power Plug
from back of TV
Acombination antenna receives normal broadcast chan-
nels (VHF 2–13 and UHF 14–69). Your connection is
easy because there is only one 75Ω(ohm) antenna plug on
the back of your TV, and that’s where the antenna goes.
1If your antenna has a round cable (75 ohm) on the end,
then you're ready to connect it to the TV.
If your antenna has flat, twin-lead wire (300 ohm), you
first need to attach the antenna wires to the screws on a
300- to 75-ohm adapter.
2Push the round end of the adapter (or antenna) onto the
75Ω(ohm) plug on the back of the TV. If the round end of
the antenna wire is threaded, screw it down finger tight.
3Plug the television in to the wall outlet and turn the TV
on. Refer to the TUNER and AUTOPROGRAM features on
page 3 of this Quick Use Guide. TUNER should be set to the
ANTENNA option. AUTOPROGRAM can be set to program
all the available channels on your cable signal into the televi-
sion’s memory.
ANTENNA TV
75
ANT "A"
Monitor out AV1 in AV2 in
VIDEO
L/Mono
AUDIO
R
Y
Pb
Pr
S-VIDEO
88
SURROUND SOUND
+ R - + L -
13
2
Antenna Connection:
Jack Panel
Back of TV
Power Plug
from back of TV
AC Power
Wall Outlet
Round 75Ω
Coaxial Cable
from Antenna
Twin
Lead Wire
300 to 75-ohm
Adapter
Outdoor or Indoor Antenna
(Combination VHF/UHF)
The combination antenna receives normal
broadcast channels 2-13 (VHF) and 14-69 (UHF).

䡲
2
BASIC TV AND REMOTE OPERATION
Y
our television has a set of controls located on the top of
the cabinet for use when the remote control is not needed.
1Press the POWER button to turn the TV ON.
Note: The time it takes the TV to startup can be affected
by the AutoChron™ feature (page 4). With AutoChron ON,
the TV will search for a PBS channel to set the clock
before powering itself on. This can take several seconds.
2Press the VOLUME (+) button to increase the sound
level or the VOLUME (–) button to lower the sound level.
Pressing both buttons at the same time will display the
onscreen menu. After you are in the menu, use these buttons
to make adjustments or selections.
3Press the CHANNEL– (down) or + (up) button to select
TV channels. Use these buttons to make adjustments or
selections in the onscreen menu.
There is also a set of Audio and Video Input jacks located on the
side of the television cabinet. This jack panel also contains a S-video
and headphone jack. These jacks are great for connecting a video
camcorder or any accessory device that will only be hooked up tem-
porarily.
TELEVISION
13
+–
VOLUME
+–
CHANNEL
2
Remote Sensor Window
Audio, Video, S-Video
and Headphone Jacks
located on the side of
the television.
Volume and Channel buttons are located
on the top of the television cabinet.
To load the supplied batteries into the remote:
1Remove the battery compartment door on the back of
the remote.
2Place the batteries (2-AA) in the remote. Be sure the (+)
and (–) ends of the batteries line up correctly (the inside of
the case is marked).
3Reattach the battery compartment door.
Be sure to point the remote at the Remote Sensor window on the
front of the television when using the remote control to operate the
television.
REMOTE CONTROL BATTERIES
Remote Control
(shown from the bottom)
Battery Compartment Door
2 “AA” Batteries
Battery Compartment
REMOTE CONTROL BUTTONS
Sleep Button
Press to set the TV to automatically turn itself OFF. Press to set the TV
to automatically turn itself OFF after a period of time. Choose 15, 30,
45, 60, 90, 120, 180, or 240 minute before the TV will automatically
turn off.
Status/Exit Button
Press to see the current channel number on the TV screen. Also press to
clear the TV screen after control adjustments.
TV/VCR/ACC Mode Switch
Slide to the TV position to control TV functions, to the VCR position to con-
trol VCR functions, or to the ACC position to control the functions of acces-
sory devices (a cable converter, DBS, or DVD, for example).
Multimedia Button
Press repeatedly to select the different signal sources connected to the
A/V inputs on the TV.
VCR-Record Button
Press to start the recording of a videotape.
Incr. Surr. Button
Press to set various factory Surround Sound listening modes.
Number Buttons
Press the number buttons to select TV channels. When selecting single-
digit channels, press the number of the desired channel. The TV will
pause for a few seconds and then tune to the selected channel. (Note:
You can press 0, then the number also.) For channels 100 and above,
first press 1then the next two numbers of the desired channel.
Sound Button
Press to select an AutoSound™ control. Choose from three factory-set
controls (VOICE, MUSIC, and THEATRE) and a PERSONAL control
that you set according to your own preferences through the onscreen
Sound menu. The three factory-set controls will tailor the TV sound so
as to enhance the particular type of program you are watching.
Menu Button
Press for the onscreen menu to appear. Pressing the menu button after
menu selections are made will eliminate the menu from the display.
Cursor Buttons (Left, Right, Up, Down)
Press these buttons to highlight, select, and adjust items on the TV's
onscreen menu.
Volume (+) or (–) Buttons
Press to adjust the TV sound level.
Mute Button
Press to turn the TV sound OFF. Press again to return the sound to its
previous level.
Power Button
Press to turn the TV ON and OFF.
CC Button
Press to select Closed Captioning options within the menu. (See the
Instructions for Use manual for details.)
Light Button
Press to back-light the buttons on the remote control.
Clock Button
Press the CLOCK button to access the onscreen Clock menu.
TV/VCR (A/CH) Button
TV/VCR – Press while in the VCR mode (the VCR indicator on the
front of the VCR will light) to view the playback of a tape. Press again
to place in the TV position (the VCR indicator light will go off) to view
one program while recording another program.
A/CH – Press to toggle between the currently viewed channel and the
previously viewed channel.
Program List Button
Press to display a list of channel numbers and their names (see the
“Tuner,” “Auto Program,” “Channel Edit,” and “Name” sections on
pages 3 and 4 for proper setup). Each channel will appear as a selec-
table menu item. The current channel will be highlighted by default.
Only five channels will be shown onscreen at one time; press the
CURSOR UP or CURSOR DOWN button to scroll the list and high-
light a channel. Press the CURSOR RIGHT button to tune to the high-
lighted channel. Channels marked “Skipped” in the “Channel Edit”
control will not appear in the list. Each channel that is being blocked
by AutoLock™ will appear with a padlock icon to indicate that the
channel is not viewable.
Picture Button
Press to select an AutoPicture™ control. Choose from four factory-set
controls (MOVIES, SPORTS, WEAK SIGNAL, and MULTI MEDIA)
and a PERSONAL control that you set according to your own prefer-
ences through the onscreen PICTURE menu. The four factory-set con-
trols will tailor the TV picture so as to enhance the particular type of
program you are watching, or to improve the picture of a program that
has a weak signal.
Surf Button
Press to select previously viewed channels. You can place up to 10 chan-
nels in memory. Then by pressing the SURF button you can quickly view
the select channels. (See the “Using the Channel Surf Control” section in
your Instructions for Use manual to see how to select a series of channels
using the Surf button.)
VCR 䊴䊴,■,䊳,䊳䊳,II Buttons
Press to rewind, stop, play, fastforward, or pause a
videotape.
Channel (+) or (–) Buttons
Press to change the tuned channel.
Power ON LED

䡲
SOUND
FEATURES
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
INSTALL
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
AUTO
CABLE
ANTENNA
1
2
4
6
3
5
7
ENGLISH
FRANCAIS
ESPANOL
˜
AUTO
CABLE
ANTENNA
6
HOW TO USE THE INSTALLATION FEATURES
For or Spanish- and French-speaking TV owners, an onscreen LANGUAGE option is present. The LANGUAGE control
enables you to set the TV’s onscreen menu to be shown in either
English, Spanish, or French.
1Press the MENU button on the remote control to show
the onscreen menu.
2Press the CURSOR DOWN button repeatedly until
INSTALL is highlighted.
3Press the CURSOR RIGHT button to shift the menu to
the left and highlight LANGUAGE.
4Press the CURSOR RIGHT button to highlight the
LANGUAGE control options.
5Press the CURSOR UP or CURSOR DOWN button to
select ENGLISH, ESPANOL (Spanish), or FRANCAIS
(French).
6Press the STATUS/EXIT button to clear the menu from
the screen.
LANGUAGE
The TUNER MODE feature allows you to change the TV’s sig- nal input to CABLE, ANTENNA, or AUTO. It’s important for
the TV to know if you want to receive channels from a cable TV
signal or a normal antenna signal.
NOTE: The AUTO mode setting helps the TV determine the type
of signal or channels being received when AUTO PROGRAM is
activated.
1Press the MENU button on the remote control to show
the onscreen menu.
2Press the CURSOR DOWN button repeatedly until
INSTALL is highlighted.
3Press the CURSOR RIGHT button to shift the menu to
the left.
4Press the CURSOR DOWN button to highlight the
TUNER MODE control.
5Press the CURSOR RIGHT button to highlight the tuner
options.
6With the TUNER MODE control set to AUTO, Auto
Program (see below) will detect whether or not cable input
is present.
If, however, you want to set the TUNER MODExs to
CABLE or ANTENNA, press the CURSOR UP or CUR-
SOR DOWN button until either CABLE or ANTENNA is
highlighted.
7Press the STATUS/EXIT button to clear the menu from
the screen.
TUNER MODE
When CABLE is selected, channels 1–125 are available.
When ANTENNA is selected, channels 2–69 are available.
HELPFUL HINT
Your TV can automatically set itself for local area (or cable TV) channels. This makes it easy for you to select only the TV
stations in your area by pressing the CHANNEL (+) or (–) button.
1Press the MENU button on the remote control to show
the onscreen menu.
2Press the CURSOR DOWN button repeatedly until
INSTALL is highlighted.
3Press the CURSOR RIGHT button to shift the menu to
the left. LANGUAGE will be highlighted.
4Press the CURSOR DOWN button repeatedly until the
AUTO PROGRAM control is highlighted.
5Press the CURSOR RIGHT button to start the Auto
Program scanning of channels.
6Press the STATUS/EXIT button to clear the menu from
the screen.
AUTO PROGRAM
3
SOUND
FEATURES
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
ENGLISH
FRANCAIS
ESPANOL
˜
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
INSTALL ENGLISH
FRANCAIS
ESPANOL
˜
䡲3
4
6
1
2
5
䡲
SOUND
FEATURES
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
INSTALL
INSTALL
SEARCH
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
CABLE
PLEASE WAIT
CHANNEL 12
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
ENGLISH
FRANCAIS
ESPANOL
˜
1
2
4
3
5
6
After you’ve run Auto Program, check out the results. Press the
CHANNEL (+) or (–) button and see which channels you can
select.
Remember, an antenna or cable TV signal must first be connect-
ed to your TV (see instructions for making connections on page
1 of this guide).
HELPFUL HINT
Remember, the LANGUAGE control makes only the TV’s
onscreen MENU items appear in English, Spanish, or French
text. It does not change the other onscreen text features, such as
Closed Captioning (CC), with TV shows.
HELPFUL HINT

HOW TO USE THE INSTALL ATION FEATURES
C
HANNEL EDIT makes it easy for you to add or delete channels
from the list of channels stored in the TV’s memory.
1Press the MENU button on the remote control to show the
onscreen menu.
2Press the CURSOR DOWN button repeatedly until
INSTALL is highlighted.
3Press the CURSOR RIGHT button to shift the menu to the
left. LANGUAGE will be highlighted.
4Press the CURSOR DOWN button repeatedly until the
CHANNEL EDIT control is highlighted.
5Press the CURSOR RIGHT button to access the CHAN-
NEL EDIT menu.
6Press the CURSOR UP or CURSOR DOWN button to
scroll through the list of available channels. Or press the num-
ber buttons on your remote control to select a specific channel
(for example, press 0and then 2to select channel 2).
7With the channel you want to edit selected, press the CUR-
SOR RIGHT button to mark the channel as SKIPPED. The
channel you’ve marked SKIPPED will not appear when you
are changing from channel to channel while watching TV.
NOTE: When you want to add a channel that has been marked
SKIPPED, press the CURSOR UP or CURSOR DOWN button
to highlight the channel; then press the CURSOR RIGHT button
to remove the word SKIPPED.
CHANNEL EDIT
T
he channel NAME feature allows you to list the “call” letters of
your favorite stations beside their channel numbers when they
appear on the screen. The TV has in memory a list of the 50 most
popular channel names (for example, ABC, NBC, FOX, etc.). You
also can enter a custom name (up to five characters).
1Press the MENU button on the remote control to show the
onscreen menu.
2Press the CURSOR DOWN button repeatedly until
INSTALL in highlighted.
3Press the CURSOR RIGHT button to shift the menu to the
left. LANGUAGE will be highlighted.
4Press the CURSOR DOWN button repeatedly until the
NAME control is highlighted.
5Press the CURSOR RIGHT button to highlight the NAME
options area.
6Press the CURSOR RIGHT button again; then press the
CURSOR UP or CURSOR DOWN button to scroll through
a list of options for the first character (A through Z, 0 through
9). Press the CURSOR RIGHT button and repeat for the
second, third, fourth, and fifth characters
7After you have selected a name for the channel, press the
MENU button to save the name in the TV’s memory.
8Press the STATUS/EXIT button to clear the menu from the
screen.
NAME
A
utoChronTM can automatically set the TV’s onscreen clock.
Because the time is received from a broadcast signal, you must
be sure that a cable TV or antenna signal is present before you
attempt to use the AutoChronTM feature.
1Press the MENU button on the remote to show the
onscreen menu.
2Press the CURSOR DOWN button repeatedly until
INSTALL is highlighted.
3Press the CURSOR RIGHT button to shift the menu to the
left. LANGUAGE will be highlighted.
4Press the CURSOR DOWN button until the AutoChron
control is highlighted.
5Press the CURSOR RIGHT button to start the
AutoChron™ feature. Then just follow the onscreen instruc-
tions to set the clock.
6Press the CURSOR RIGHT button to select AUTO.
Within a few seconds, a menu for choosing your time zone
will appear.
7Press the CURSOR UP or CURSOR DOWN button to
highlight your correct time zone.
8With your correct time zone highlighted, press the CUR-
SOR RIGHT button. Within a few seconds, you will be
given the option to choose whether you want to select
Daylight Savings Time.
9Press the CURSOR UP or CURSOR DOWN button to
navigate through the YES and NO selection list; then with
the item you want to select highlighted, press the CUR-
SOR RIGHT button. Follow the onscreen instructions
(shown below) to set the AutoChron™ time either automati-
cally or manually.
AUTOCHRON™
4
䡲
SOUND
FEATURES
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
INSTALL
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
66 SKIPPED
67 SKIPPED
68 SKIPPED
69 SKIPPED
AV1
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
1
2
4
6
3
5
7
6
ENGLISH
FRANCAIS
ESPANOL
˜
66 SKIPPED
67 SKIPPED
68 SKIPPED
69 SKIPPED
AV1
䡲
INSTALL INSTALL
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
W-
SOUND
FEATURES
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
INSTALL ENGLISH
FRANCAIS
ESPANOL
˜
1
7
2
4
6
3
5
6
8
6
WX- WXY- WXYZ- WXYZ3
SOUND
FEATURES
INSTALL
BRIGHTNESS
COLOR
SHARPNESS
TINT
SOUND
FEATURES
INSTALL
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
LANGUAGE
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
INSTALL
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
INSTALL TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
INSTALL
SET TIME
AUTO
MANUAL
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
INSTALL
TIME ZONE?
CENTRAL
MOUNTAIN
PACIFIC
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
INSTALL
DAYLIGHT
SAVING TIME?
YES
NO
ENGLISH
FRANCAIS
ESPANOL
˜
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
INSTALL
SEARCH FOR
TIME . . .
(Please wait)
12 PBS
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
INSTALL
SEARCH FOR
TIME . . .
Time Found
END: PRESS STATUS
12 PBS
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
INSTALL
SEARCH FOR
TIME . . .
Time Found
11:00 AM
SET TIME
AUTO
MANUAL
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
INSTALL
SET TIME
AUTO
MANUAL
The channels available for you to edit are the ones that the AUTO
PROGRAM feature found through a search of your TV antenna
or cable TV signals. Channels not found during the search are
marked SKIPPED.
HELPFUL HINT
The five characters that the channel NAME feature allows you
to input can be letters, a dash character, or the numbers 0
through 9.
HELPFUL HINT
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
INSTALL
SET TIME
AUTO
MANUAL
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
INSTALL
ENTER TIME
1_:__ AM
TUNER MODE
AUTO PROGRAM
CHANNEL EDIT
AutoChron
NAME
INSTALL
ENTER TIME
11:30 AM
Setting the
AutoChron Feature
Automatically:
Setting the
AutoChron Feature
Manually:
Note: When turned ON, the AutoChron™ feature can affect the start up of your television. When the power
button is press and the AutoChron™ feature is set to the AUTO position, the TV will scan the channels for a
PBS channel to set the clock automatically. It may take SEVERAL seconds before the TV powers itself ON.
