Congratulations on your purchase and welcome to Philips! To fully benet
from the support that Philips offers, register your product at www.philips.
com/welcome.

1 Cover
2 Cover release tab
3 Motor protection lter
4 Dustbag holder
5 Dustbag
6 Hose connection opening
7 Dustbag-full indicator
8 Top handle
9 Suction power selection wheel
10 On/off button
11 Cord rewind button
12 Ergonomic ComfortControl handgrip
13 Tube release button
14 Accessory holder release levers
15 Accessory holder
16 Hose
17 Flexible hose connection
18 Hard-oor nozzle
19 Combination nozzle
20 Parking/storage ridge
21 Rocker switch for carpet/hard oor settings
22 Small nozzle
23 Brush attachment
24 Crevice tool
25 Telescopic tube
26 Filter grille
27 Washable HEPA 12 lter
28 Parking slot
29 Mains cord with plug
30 Handgrip
31 Swivel wheel
32 Storage slot
33 Type plate
34 Rear wheels

Read this user manual carefully before you use the appliance and save it for
future reference.

- Never suck up water or any other liquid. Never suck up ammable
substances and do not suck up ashes until they are cold.

- Check if the voltage indicated on the appliance corresponds to the
local mains voltage before you connect the appliance.


- Do not use the appliance if the plug, the mains cord or the appliance
itself is damaged.
- If the mains cord is damaged, you must have it replaced by Philips, a
service centre authorised by Philips or similarly qualied persons in
order to avoid a hazard.
- This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety.
- Children should be supervised to ensure that they do not play with the
appliance.
- Do not point the hose, the tube or any other accessory at the eyes
or ears nor put it in your mouth when it is connected to the vacuum
cleaner and the vacuum cleaner is switched on.

- When you use the vacuum cleaner to vacuum ashes, ne sand, lime,
cement dust and similar substances, the pores of the dustbag become
clogged. As a result, the dustbag-full indicator will indicate that the
dustbag is full. Replace the dustbag, even if it is not full yet (see chapter
‘Replacing the dustbag’).
- Never use the appliance without the motor protection lter. This could
damage the motor and shorten the life of the appliance.
- Only use Philips s-bag ® synthetic dustbags.
- Noise level: Lc = 80 dB [A]

This Philips appliance complies with all standards regarding electromagnetic
elds (EMF). If handled properly and according to the instructions in this
user manual, the appliance is safe to use based on scientic evidence
available today.

1 Take the appliance and its accessories out of the box.
2 Remove any sticker, protective foil or plastic from the appliance.



- The unique ComfortControl handgrip is ergonomically designed to
give you sufcient comfort during vacuum cleaning.
 7

- To gain optimal benet from this handgrip, it is important that you do
not position your second hand on the tube. When you do so, you twist
and bend your back, which could result in back problems.

1 To connect the hose, push it rmly into the appliance (‘click’). Make
sure the recess in the hose connection opening ts exactly on the
projection on the housing of the appliance.
2 To disconnect the hose, press the buttons (1) and pull the hose out
of the appliance (2).

1 Attach the tube to the ComfortControl handgrip (‘click’).
8

2 To disconnect the tube from the ComfortControl handgrip, hold the
handgrip with one hand. With the other hand, press the tube release
button (1) on the telescopic tube and pull the tube off the handgrip
(2).
Note: This vacuum cleaner has been tted with holes at the end of the bend.
These holes may prevent objects from getting stuck or damaged when you use
your vacuum cleaner without the tube or accessories supplied.
3 Adjust the length of the telescopic tube in such a way that the
exible hose connection is at hip level.
4 Hold the tube at an angle of 45° to the oor.

1 To connect one of the nozzles to the tube, press the spring-loaded
lock button on the tube and insert the tube into the nozzle. Fit the
spring-loaded lock button into the opening in the nozzle (‘click’).
2 To disconnect the nozzle from the tube, press the spring-loaded lock
button on the tube and pull the tube out of the nozzle.

The combination nozzle can be used on either carpets or hard oors.
1 To clean hard oors, push the rocker switch on top of the nozzle
with your foot.
,The brush strip for cleaning hard oors comes out of the nozzle
housing.
45°
 9

2 To clean carpets, push the rocker switch again.
,The brush strip disappears into the nozzle housing.

- The hard-oor nozzle is designed for gentle cleaning of hard oors.

1 To connect crevice tool (1) or small nozzle (2) to the tube, press the
spring-loaded lock button on the tube and insert the tube into the
crevice tool or small nozzle. Fit the spring-loaded lock button into
the opening in the crevice tool or small nozzle (‘click’).
Note: You can also attach the crevice tool and the small nozzle directly to the
ComfortControl handgrip.
2 To disconnect the crevice tool or small nozzle, press the spring-
loaded lock button on the tube and pull crevice tool or small nozzle
off the tube or ComfortControl handgrip.

1 To assemble the brush attachment, slide it onto the bottom of the
small nozzle (‘click’).
2 To disassemble the brush attachment, slide it off the bottom of the
small nozzle.
10


When you are not using the small nozzle and the crevice tool, you can
store them in the accessory holder.
1 Slide the small nozzle and the crevice tool into the accessory holder.
2 Slide the accessory holder with accessories onto the handgrip
(‘click’).
3 To detach the accessory holder, squeeze the release levers
together (1) and slide the accessory holder off the handgrip (2).

1 Pull the mains cord out of the appliance and put the mains plug in
the wall socket.
2 Press the on/off button on top of the appliance to switch on the
appliance.
Tip: To avoid bending your back, press the on/off button with your foot.
3 If you want to park the tube for a moment during vacuum cleaning,
insert the ridge on the nozzle into the parking slot.
4 To ensure stable parking of the telescopic tube, adjust the tube to
the shortest length.
5 To switch off the appliance, press the on/off button on top of the
appliance.
 11


1 During vacuum cleaning, you can adjust the suction power with the
selection wheel on top of the appliance.
- Use maximum suction (+) power to vacuum very dirty carpets and
hard oors.
- Use minimum suction power (-) to vacuum curtains, tablecloths etc.

1 Switch off the appliance and remove the mains plug from the wall
socket.
2 Press the cord rewind button to rewind the mains cord.
3 Put the appliance in upright position. To attach the nozzle to the
appliance, insert the ridge on the nozzle into the storage slot.
4 To ensure stable storage of the telescopic tube, adjust the tube to
the shortest length.

Always unplug the appliance before you replace the dustbag.

- Replace the dustbag as soon as the dustbag-full indicator has changed
colour permanently, i.e. even when the nozzle is not placed on the
oor.
12

1 Pull the cover upwards to open it.
2 Lift the dustbag holder out of the appliance.
Make sure you hold the dustbag upright when you lift it out of the
appliance.
3 Pull at the cardboard tag to remove the full dustbag from the holder .
,When you do this, the dustbag is sealed automatically.
4 Slide the cardboard front of the new dustbag into the two grooves of
the dustbag holder as far as possible.
5 Put the dustbag holder back into the vacuum cleaner.
Note: If no dustbag has been inserted, you cannot close the cover.
6 Push the cover downwards to close it (‘click’).

Always unplug the appliance before you clean or replace the lters.
 13


Clean the permanent motor protection lter every time you replace the
dustbag.
1 Remove the dustbag holder with the dustbag.
2 Press down the tab at the top of the motor protection lter holder
to release it.
3 Pull the top of the motor protection lter holder towards you (1)
and lift the lter holder out of the dustbag compartment (2).
4 Shake the lter over a dustbin to clean it.
5 Put the clean lter back into the lter holder.
6 Fit the two lugs of the lter holder behind the ridge at the bottom
to ensure that it ts properly at the top (1). Then press the lter
holder home (‘click’) (2).
7 Place the dustbag holder with the dustbag back into the appliance
and close the cover.

The washable HEPA 12 lter is able to remove 99.5% of all particles down
to 0.0003mm in size from the outlet air. This not only includes normal
house dust, but also harmful microscopic vermin such as dust mites and
their excrements, which are well-known causes of respiratory allergies.
Note: To guarantee optimal dust retention and performance of the vacuum
cleaner, always replace the HEPA lter with an original Philips lter of the
correct type (see chapter ‘Ordering accessories’).
Clean the washable HEPA 12 lter every 6 months. You can clean the
washable HEPA 12 lter max. 4 times. Replace the lter after it has been
cleaned 4 times.
14

1 To remove the HEPA lter grille, grab the tabs and pull the lter
grille upwards.
2 Take the HEPA 12 lter out of the appliance.
3 Rinse the pleated side of the HEPA 12 lter under a hot slow-
running tap.
- Hold the lter in such a way that the pleated side points upwards and
the water ows parallel to the pleats. Hold the lter at an angle so that
the water washes away the dirt inside the pleats.
- Turn the lter 180° and let the water ow along the pleats in opposite
direction.
- Continue this process until the lter is clean.
Never clean the washable lter with a brush.
Note: Cleaning does not restore the original colour of the lter, but does restore
its ltration power.
4 Carefully shake the water from the surface of the lter. Let the lter
dry at least 2 hours before you put it back into the vacuum cleaner.
Note: Make sure that the lter is completely dry before you put it back into
the appliance.
 15

5 Put the lter back into the appliance.
Note: Make sure that the two lugs of the HEPA lter point downwards.
6 To reattach the HEPA lter grille, rst align the top of the grille with
the appliance (1). Then press the tabs downwards until the grille
locks into place (2) (‘click’).

To purchase dustbags, lters or other accessories for this appliance, please
visit www.philips.com, consult the worldwide guarantee leaet or contact
the Philips Consumer Care Centre in your country.

- Philips Classic s-bag ® synthetic dustbags are available under type
number FC8021.
- Philips Clinic s-bag ® high ltration synthetic dustbags are available
under type number FC8022.
- Philips Anti-odour s-bag ® synthetic dustbags are available under type
number FC8023.
Note: Please visit www.s-bag.com for more information about the s-bag.

- Washable HEPA 12 lters are available under type number FC8044.

- Do not throw away the appliance with the normal household waste
at the end of its life, but hand it in at an ofcial collection point for
recycling. By doing this, you help to preserve the environment.
16


If you need service or information or if you have a problem, please visit
the Philips website at www.philips.com or contact the Philips Consumer
Care Centre in your country (you nd its phone number in the worldwide
guarantee leaet). If there is no Consumer Care Centre in your country, go
to your local Philips dealer.

This chapter summarises the most common problems you could
encounter with the appliance. If you are unable to solve the problem with
the information below, contact the Consumer Care Centre in your country.
1 The suction power is insufcient.
A Check if the dustbag is full.
If necessary, replace the dustbag.
B Check if the lters need to be cleaned or replaced.
If necessary, clean or replace the lters.
C Check if the suction power selection wheel is in maximum position.
D Check if the nozzle, tube or hose is blocked up.
- To remove the obstruction, disconnect the blocked-up item and
connect it (as far as possible) the other way around. Switch on the
vacuum cleaner to force the air through the blocked-up item in
opposite direction.
 17

18

Blahopřejeme vám k nákupu a vítáme vás ve společnosti Philips. Abyste
mohli plně využít podpory, kterou Philips poskytuje, zaregistrujte svůj
výrobek na adrese www.philips.com/welcome.

1 Kryt
2 Otvírací kroužek krytu
3 Ochranný ltr motoru
4 Držák prachového sáčku
5 Prachový sáček
6 Otvor pro připojení hadice
7 Indikátor naplnění prachového sáčku
8 Horní rukojeť
9 Kolečko pro výběr sacího výkonu
10 Vypínač
11 Tlačítko navíjení kabelu
12 Ergonomické držadlo ComfortControl
13 Tlačítko uvolnění trubice
14 Uvolňovací páčky držáku příslušenství
15 Držák příslušenství
16 Hadice
17 Přípojka ohebné hadice
18 Hubice na tvrdé podlahy
19 Kombinovaná hubice
20 Parkovací/skladovací výčnělek
21 Překlápěcí přepínač pro nastavení čištění koberců/tvrdých podlah
22 Malá hubice
23 Kartáčový nástavec
24 Nástavec pro štěrbiny
25 Teleskopická trubice
26 Mřížka ltru
27 Omyvatelný ltr HEPA 12
28 Parkovací drážka
29 Síťový kabel se zástrčkou
30 Držadlo
31 Otočné kolečko
32 Skladovací otvor
33 Štítek s označením typu
34 Zadní kolečka

Před použitím přístroje si důkladně přečtěte tuto uživatelskou příručku a
uschovejte ji pro budoucí použití.

- Nikdy nevysávejte vodu nebo jinou tekutinu. Také nikdy nevysávejte
hořlavé látky nebo popel, pokud není zcela vychladlý.

- Dříve než přístroj připojíte do sítě, zkontrolujte, zda napětí uvedené na
přístroji souhlasí s napětím v místní elektrické síti.


- Pokud byste zjistili závadu na zástrčce, na síťové šňůře nebo na přístroji,
dále jej nepoužívejte.
- Pokud by byla poškozena síťová šňůra, musí její výměnu provést
společnost Philips, autorizovaný servis společnosti Philips nebo
obdobně kvalikovaní pracovníci, aby se předešlo možnému nebezpečí.
- Osoby (včetně dětí) s omezenými fyzickými, smyslovými nebo
duševními schopnostmi nebo nedostatkem zkušeností a znalostí by
neměly s přístrojem manipulovat, pokud nebyly o používání přístroje
předem poučeny nebo nejsou pod dohledem osoby zodpovědné za
jejich bezpečnost.
- Dohlédněte na to, aby si s přístrojem nehrály děti.
- Nesměřujte hadicí, trubkou ani jiným příslušenstvím na oči nebo uši,
ani do úst, pokud jsou tyto součásti připojeny k vysavači a vysavač je
zapnutý.

- Pokud budete používat přístroj k vysávání popelu, jemného písku, vápna,
cementového prachu nebo podobných látek, póry v prachovém sáčku
se zanesou. Tím pádem bude indikátor naplnění prachového sáčku
ukazovat, že je sáček plný, i když tomu tak nebude (viz kapitola ‚Výměna
prachových sáčků‘).
- Nikdy nepoužívejte vysavač bez vloženého ochranného ltru motoru.
To by mohlo mít za následek poškození motoru a tím zkrácení
životnosti přístroje.
- Používejte výhradně syntetické prachové sáčky Philips s-bag ®.
- Hladina hluku: Lc = 80 dB [A]

Tento přístroj společnosti Philips odpovídá všem normám týkajícím se
elektromagnetických polí (EMP). Pokud je správně používán v souladu
s pokyny uvedenými v této uživatelské příručce, je jeho použití podle dosud
dostupných vědeckých poznatků bezpečné.

1 Vyjměte přístroj a jeho příslušenství z krabice.
2 Sejměte všechny případné nálepky, ochranné fólie a igelity z přístroje.



- Jedinečné držadlo ComfortControl je ergonomicky navrženo tak, aby
vám při vysávání poskytovalo přiměřený komfort.
 19

- Pro dosažení optimálních výhod tohoto držadla je důležité, abyste
druhou ruku nepokládali na trubici. Pokud tak učiníte, dojde k ohýbání a
zkroucení páteře, které může vést k potížím se zády.

1 Chcete-li připojit hadici, pevně ji do přístroje zasuňte (ozve se
„klapnutí“). Zkontrolujte, zda otvor v připojení hadice přesně padne
na výstupek krytu přístroje.
2 Hadici odpojíte tak, že stisknete tlačítka (1) a hadici vysunete (2).

1 Připojte trubici k držadlu ComfortControl (ozve se „klapnutí“).
20
