Phoenix Baby The GoTo GT111003 User manual

Read all instructions BEFORE assembly and USE of product.
KEEP INSTRUCTIONS FOR FUTURE USE.
MODEL # GT111003
PRN: PNX [15.06.04]AIM-GT111003-
A
FOLDING INFANT CAR SEAT STATION FOR HOME AND AWAY
Remove product from the box and remove all packaging materials.
Caution: make sure to throwaway all packaging materials.
Make sure to inspect every part to make sure there are no broken or missing
parts. If so, do not use and contact us!

Customer Care:
www.phoenix-baby.com 2
WARNING: Please follow all of these instructions to ensure the
safety of your child. Keep these instructions for future reference.
WARNING: Adult assembly required.
WARNING: Failure to follow these instructions could result in
serious injury or death. Avoid serious injury from falling or sliding
out, always use the safety harness and insure that the children
are properly positioned according to these instructions.
WARNING: Never leave children unattended.
WARNING: Care must be taken when folding and unfolding the
GoTo to prevent finger entrapment.
WARNING: Prevent serious injury or death from falls or sliding.
Always use seat belt. Secure your child at all times with the
restraint.
WARNING: This product is designed to be used by a child up to
3 years of age. Maximum weight 40 pounds (18kg).
!Caution: Be certain the GoTo is completely opened and locked
in place before allowing a child near the product.
!Never use near steps or uneven surfaces.
!Never allow your GoTo to be used as a toy.
!Check your GoTo for loose screws, worn parts, torn materials or
stitching on a regular basis. Replace or repair parts as needed.
!Discontinue use should it malfunction or become damaged.
Please contact our customer care department to arrange for
repair or obtain replacement parts if needed.
!If you experience any difficulty with the use of our product or
have a question regarding these instructions, please contact
our customer care department at 800-704-9058.
!To clean use only mild household soap or detergent and warm
water on a sponge or clean cloth.
WARNING

HARDWARE
3
A Padded Bar (x2)
B Cross Bar (x4)
D Feet (x4)
C Lower (x4) E Bolt (x8)
F Top Side (x2)
Sliding Lever
Padded Bar
Adjuster
Bottom
B-1 (x1)
B (x3)
D-L D-R
Hook

STEP 1A
ASSEMBLY INSTRUCTIONS
For ease of assembly your GoTo has been
partially assembled.
If any of the parts come apart when you
unpack the product from the box. Please
turn to page .11
F
D
C
STEP 1B
STEP 1C
F
D
C
Grab the foot of the GoTo and rotate
outward until it locks-as shown. Make sure
fingers are not close to joint. Repeat with
the 3 other legs.
Warning : Avoid FINGER ENTRAPMENT : Use care when folding and unfolding the GoTo.
F
D
C
1
4

2
3
ASSEMBLY INSTRUCTIONS
5
E
When attaching the crossbars, one of the bars
has 2 holes, make sure to place that bar thru 1 of
the feet part B-1 in .
Bolt bars in using the bolt part (E).
step 4
B-1
D-R
B
E
C
F
C

4
5
ASSEMBLY INSTRUCTIONS
6
C
C F
B B B-1
Label
Line up the sleeve in the fabric and slide across the tubes. Make sure the cut out area in
the fabric lines up with B-1 so that the vibrator can be attached.
D-L D-R
B
B-1

6
7
ASSEMBLY INSTRUCTIONS
7
F
CC
E
Hook
Attached second side to unit using bolts (E).
B
E
B
B-1
Label
D-L
D-R
E
B
Make sure to tighten all bolts (E).

B-1 E
Label
D-R
D-L
8
ASSEMBLY INSTRUCTIONS
F
F
1. Make sure the 4 adjusters are pointing up. If you need to adjust them, push in the
adjuster button and rotate til pointing up.
2. Make sure all adjusters line up, you may need to slide them as shown to line up.
Push in slider level to move.
9
8
Label
Slider Level

C
D
C
C
F
F
B
B
10
ASSEMBLY INSTRUCTIONS
Attach the 4 elastis loops on the fabric basket to the 4 hooks on the lower legs.
9
Label
Label
D-L
D-R

A
C
C
A
C
C
11
ASSEMBLY INSTRUCTIONS
Push padded Bar (A) down until it locks in the down position.
Pull up to make sure part (A) is loked down.
Repeat on other slide with part (A)
Label
Label
10

ASSEMBLY INSTRUCTIONS
1
2
Slide feet part (D) onto lower leg (C)
and insert bolt (E) thru feet part (D)
Note: there are right and left sides to the feet
Make sure you match the part to the photo.
Repeat on all 4 feet.
Make sure all 4 feet are flush to the floor-as shown.
D-L D-R
Hook
F
C
Slide together part (F) and Part (C) as shown.
Insert bolt (E) thru hole. See step 2A and 2B in next page.
Make sure hook is facing in and
the adjuster button is facing out.
Hook
E
C
E
11
If a part has separated when they were unpacked. Please follow this steps. Then go to back page.

ASSEMBLY INSTRUCTIONS
2A
3A
12
F
C
F
CC
E
E
Hook
D-L
D-R

3
1
13
A
F
A
F
2
A
F
ASSEMBLY INSTRUCTIONS

TO FOLD
1
2
14
Pull down on the lower bar (B)until the 2 legs separate from part (F). Continue to fold legs
until they are underneath – as shown, repeat on other side.

3
4
15
Push in Adjuster button and rotate padded bar dow–as shown
TO FOLD
Warning: AVOID FINGER ENTRAPMENT: Use care when folding and unfolding.
Make sure no children are near.

MADE IN CHINA
PRODUCT PACKAGING INFORMATION
501 S 9th street,
Reading, PA 19602 USA
www.phoenix-baby.com
Model #:
Color:
Date:
Shipment Ref. #:
BackFront
IMPORTANT: Please fill in your contact info on the bottom part of the card,
separate from top card and mail to us. Note, postage is prepaid if mailed in the
United States. Keep the top portion for your records. This information is important
to us should we need to contact you regarding the safety of this product.
www.phoenix-baby.com
www.phoenix-baby.com
Phoenix Baby, LLC.
c/o RBO, LLC.
PO BOX 91058
ALLENTOWN PA 18109-9917
Manufacturer's Contact Information/Coordonnées du fabricant
Phoenix Baby, LLC. (c/o RBO, LLC.)
501 S 9TH Street, Reading, PA 19602 USA
Customer Care: 1-800-704-9058
E-Mail: [e-mail]
www.phoenix-baby.com
Product Model/Modèle de produit#:
Shipment Ref./Réf. d'Expédition#:
Manufacture Date/date de fabrication:
KEEP THIS TOP PART FOR YOUR RECORDS.
FILL OUT AND RETURN BOTTOM PART.
GARDER CETTE PARTIE SUPÉRIEURE POUR VOS DOSSIERS.
REMPLIR ET RENVOYER PARTIE INFÉRIEURE.
Name/nom
Mailing Address/Mailing Address
City/ville Zip Code/Code postalState/état
Telephone Number/numéro de téléphone
E-mail Address/Adresse E-mail
Product Model #:
Shipment Ref./Réf. d'Expédition#:
Manufacture Date/date de fabrication:
/Modèle de produit
PRODUCT REGISTRATION
GT111003
16
