User manual
User manual for the hardware and
software of FL MGUARD security
appliances
UM EN FL MGUARD2

2013-07-17
PHOENIX CONTACT 8334_en_02
User manual for the hardware and software of FL MGUARD security ap-
pliances
UM EN FL MGUARD2
02
—
Designation Revision Order No.
FL MGUARD RS2000 TX/TX VPN 2700642
FL MGUARD RS4000 TX/TX 2700634
FL MGUARD RS4000 TX/TX VPN 2200515
FL MGUARD SMART2 2700640
FL MGUARD SMART2 VPN 2700639
FL MGUARD PCI4000 2701274
FL MGUARD PCI4000 VPN 2701275
FL MGUARD DELTA TX/TX 2700967
User manual
Designation:
Revision:
Order No.:
This user manual is valid for:

PHOENIX CONTACT
Please observe the following notes
User group of this manual
The use of products described in this manual is oriented exclusively to qualified application
programmers and software engineers, who are familiar with the safety concepts of automa-
tion technology and applicable standards.
Explanation of symbols used and signal words
How to contact us
Internet Up-to-date information on Phoenix Contact products and our Terms and Conditions can be
found on the Internet at:
www.phoenixcontact.com
Make sure you always use the latest documentation. 
It can be downloaded at:
www.phoenixcontact.net/catalog
Subsidiaries If there are any problems that cannot be solved using the documentation, please contact
your Phoenix Contact subsidiary.
Subsidiary contact information is available at www.phoenixcontact.com.
Published by PHOENIX CONTACT GmbH & Co. KG
Flachsmarktstraße 8
32825 Blomberg
GERMANY
Should you have any suggestions or recommendations for improvement of the contents and
layout of our manuals, please send your comments to:
[e-mail]
This is the safety alert symbol. It is used to alert you to potential personal injury
hazards. Obey all safety measures that follow this symbol to avoid possible in-
jury or death.
There are three different categories of personal injury that are indicated with a
signal word.
DANGER This indicates a hazardous situation which, if not avoided, will re-
sult in death or serious injury.
WARNING This indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION This indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
This symbol together with the signal word NOTE and the accompanying text
alert the reader to a situation which may cause damage or malfunction to the
device, hardware/software, or surrounding property.
This symbol and the accompanying text provide the reader with additional in-
formation or refer to detailed sources of information.

Please observe the following notes
PHOENIX CONTACT
General terms and conditions of use for technical documentation
Phoenix Contact reserves the right to alter, correct, and/or improve the technical documen-
tation and the products described in the technical documentation at its own discretion and
without giving prior notice, insofar as this is reasonable for the user. The same applies to any
technical changes that serve the purpose of technical progress.
The receipt of technical documentation (in particular user documentation) does not consti-
tute any further duty on the part of Phoenix Contact to furnish information on modifications
to products and/or technical documentation. You are responsible to verify the suitability and
intended use of the products in your specific application, in particular with regard to observ-
ing the applicable standards and regulations. All information made available in the technical
data is supplied without any accompanying guarantee, whether expressly mentioned, im-
plied or tacitly assumed.
In general, the provisions of the current standard Terms and Conditions of Phoenix Contact
apply exclusively, in particular as concerns any warranty liability.
This manual, including all illustrations contained herein, is copyright protected. Any
changes to the contents or the publication of extracts of this document is prohibited.
Phoenix Contact reserves the right to register its own intellectual property rights for the
product identifications of Phoenix Contact products that are used here. Registration of such
intellectual property rights by third parties is prohibited.
Other product identifications may be afforded legal protection, even where they may not be
indicated as such.

Table of contents
8334_en_02 PHOENIX CONTACT 5
Table of contents
1 Introduction ................................................................................................................................9
1.1 Device versions ................................................................................................... 11
2 Operating elements and LEDs .................................................................................................13
2.1 FL MGUARD RS2000/4000 ................................................................................ 13
2.2 FL MGUARD SMART2........................................................................................ 14
2.3 FL MGUARD PCI4000......................................................................................... 15
2.4 FL MGUARD DELTA TX/TX................................................................................ 16
3 Startup .....................................................................................................................................17
3.1 Safety notes ........................................................................................................ 17
3.2 Checking the scope of supply.............................................................................. 19
3.3 Installing the FL MGUARD RS4000/RS2000....................................................... 20
3.3.1 Assembly/removal ............................................................................... 20
3.3.2 Connecting to the network ................................................................... 20
3.3.3 Service contacts ................................................................................ 21
3.3.4 Connecting the supply voltage ............................................................. 23
3.4 Connecting the FL MGUARD SMART2............................................................... 24
3.5 Installing the FL MGUARD PCI4000 ................................................................... 25
3.5.1 Installing the hardware ......................................................................... 25
3.5.2 Power-over-PCI mode ......................................................................... 26
3.6 Connecting the FL MGUARD DELTA TX/TX ....................................................... 28
3.6.1 Connecting to the network ................................................................... 28
3.6.2 Connecting the supply voltage ............................................................. 28
4 Preparing the configuration ......................................................................................................29
4.1 Connection requirements .................................................................................... 29
4.2 Local configuration on startup (EIS).....................................................................30
4.2.1 Configuring the FL MGUARD on startup with stealth mode by default . 31
4.2.2 Configuring the FL MGUARD on startup with router mode by default .. 36
4.2.3 Configuring the FL MGUARD PCI4000 on startup ............................... 37
4.2.4 Configuring the FL MGUARD PCI4000 on startup ............................... 41
4.3 Establishing a local configuration connection ...................................................... 43
4.4 Remote configuration .......................................................................................... 45
5 Configuration ...........................................................................................................................47
5.1 Operation............................................................................................................. 47
5.2 Management menu ............................................................................................. 50
5.2.1 Management >> System Settings ........................................................ 50

FL MGUARD2
6PHOENIX CONTACT 8334_en_02
5.2.2 Management >> Web Settings ............................................................ 68
5.2.3 Management >> Licensing ................................................................... 79
5.2.4 Management >> Update ...................................................................... 82
5.2.5 Management >> Configuration Profiles ................................................ 85
5.2.6 Management >> SNMP ....................................................................... 89
5.2.7 Management >> Central Management .............................................. 100
5.2.8 Management >> Restart .................................................................... 104
5.3 Network menu ................................................................................................... 104
5.3.1 Network >> Interfaces ........................................................................ 104
5.3.2 Network >> NAT ................................................................................ 142
5.3.3 Network >> DNS ................................................................................ 147
5.3.4 Network >> DHCP ............................................................................. 151
5.3.5 Network >> Proxy Settings ................................................................. 155
5.4 Authentication menu.......................................................................................... 156
5.4.1 Authentication >> Administrative Users ............................................. 156
5.4.2 Authentication >> Firewall Users ....................................................... 159
5.4.3 Authentication >> RADIUS Servers ................................................... 161
5.4.4 Authentication >> Certificates ............................................................ 163
5.5 Network Security menu ..................................................................................... 179
5.5.1 Network Security >> Packet Filter ...................................................... 179
5.5.2 Network Security >> DoS Protection .................................................. 194
5.5.3 Network Security >> User Firewall ..................................................... 196
5.6 CIFS Integrity Monitoring menu ....................................................................... 199
5.6.1 CIFS Integrity Monitoring >> Importable Shares ................................ 200
5.6.2 CIFS Integrity Monitoring >> CIFS Integrity Checking ........................ 201
5.6.3 CIFS Integrity Monitoring >> CIFS Integrity Status ............................. 207
5.6.4 CIFS Integrity Monitoring >> CIFS AV Scan Connector ..................... 210
5.7 IPsec VPN menu ............................................................................................... 214
5.7.1 IPsec VPN >> Global ......................................................................... 214
5.7.2 IPsec VPN >> Connections ................................................................ 222
5.7.3 IPsec VPN >> L2TP over IPsec ......................................................... 251
5.7.4 IPsec VPN >> IPsec Status ................................................................ 252
5.8 SEC-Stick menu ................................................................................................ 253
5.8.1 Global ................................................................................................ 253
5.8.2 Connections ....................................................................................... 256
5.9 QoS menu ......................................................................................................... 258
5.9.1 Ingress Filters .................................................................................... 258
5.9.2 Egress Queues .................................................................................. 261
5.9.3 Egress Queues (VPN) ........................................................................ 263
5.9.4 Egress Rules ...................................................................................... 266
5.10 Redundancy ...................................................................................................... 270
5.10.1 Redundancy >> Firewall Redundancy ............................................... 270
5.10.2 Redundancy >> FW Redundancy Status ........................................... 280
5.10.3 Ring/Network Coupling ...................................................................... 285

Table of contents
8334_en_02 PHOENIX CONTACT 7
5.11 Logging menu.................................................................................................... 286
5.11.1 Logging >> Settings ........................................................................... 286
5.11.2 Logging >> Browse local logs ............................................................ 287
5.12 Support menu.................................................................................................... 291
5.12.1 Support >> Tools ............................................................................... 291
5.12.2 Support >> Advanced ........................................................................ 293
5.13 CIDR (Classless Inter-Domain Routing) ............................................................ 294
5.14 Network example diagram................................................................................. 295
6 Redundancy ..........................................................................................................................297
6.1 Firewall redundancy .......................................................................................... 297
6.1.1 Components in firewall redundancy ................................................... 298
6.1.2 Interaction of the firewall redundancy components ............................ 300
6.1.3 Firewall redundancy settings from previous versions ......................... 300
6.1.4 Requirements for firewall redundancy ................................................ 300
6.1.5 Fail-over switching time ..................................................................... 301
6.1.6 Error compensation through firewall redundancy ............................... 303
6.1.7 Handling firewall redundancy in extreme situations ........................... 304
6.1.8 Interaction with other devices ............................................................. 306
6.1.9 Transmission capacity with firewall redundancy ................................ 309
6.1.10 Limits of firewall redundancy .............................................................. 310
6.2 VPN redundancy ............................................................................................... 311
6.2.1 Components in VPN redundancy ....................................................... 311
6.2.2 Interaction of the VPN redundancy components ................................ 312
6.2.3 Error compensation through VPN redundancy ................................... 312
6.2.4 Setting the variables for VPN redundancy .......................................... 313
6.2.5 Requirements for VPN redundancy ................................................... 314
6.2.6 Handling VPN redundancy in extreme situations ............................... 314
6.2.7 Interaction with other devices ............................................................. 316
6.2.8 Transmission capacity with VPN redundancy .................................... 318
6.2.9 Limits of VPN redundancy .................................................................. 319
7 NOTE: Restart, recovery procedure, and flashing the firmware .............................................323
7.1 Performing a restart........................................................................................... 323
7.2 Performing a recovery procedure ...................................................................... 324
7.3 Flashing the firmware/rescue procedure ........................................................... 325
7.3.1 Requirements for flashing .................................................................. 325
7.3.2 Flashing procedure for FL MGUARD RS4000/RS2000, FL MGUARD
SMART2, FL MGUARD DELTA TX/TX .............................................. 326
7.3.3 Flashing procedure for the FL MGUARD PCI4000 ............................. 328
7.3.4 Installing the DHCP and TFTP server ................................................ 329

FL MGUARD2
8PHOENIX CONTACT 8334_en_02
8 Technical data .......................................................................................................................331
8.1 FL MGUARD RS4000/RS2000 ......................................................................... 331
8.2 FL MGUARD PCI4000....................................................................................... 332
8.3 FL MGUARD DELTA TX/TX.............................................................................. 334
8.4 FL MGUARD SMART2 ...........................................................................................................335
8.5 Ordering data .................................................................................................... 336
8.5.1 Products ............................................................................................ 336
8.5.2 Accessories ....................................................................................... 336

Introduction
8334_en_02 PHOENIX CONTACT 9
1Introduction
The FL MGUARD protects IP data connections by combining the following functions:
– Network card (FL MGUARD PCI4000)
– VPN router (VPN - Virtual Private Network) for secure data transmission via public
networks (hardware-based DES, 3DES, and AES encryption, IPsec protocol).
– Configurable firewall for protection against unauthorized access. The dynamic packet
filter inspects data packets using the source and destination address and blocks
undesired data traffic.
The device can be configured easily using a web browser.
Network features – Stealth (auto, static, multi), router (static, DHCP client), PPPoE (for DSL), PPTP (for
DSL), and modem
–VLAN
– DHCP server/relay on the internal and external network interfaces
– DNS cache on the internal network interface
– Administration via HTTPS and SSH
– Optional conversion of DSCP/TOS values (Quality of Service)
– Quality of Service (QoS)
–LLDP
– MAU management
–SNMP
Firewall features – Stateful packet inspection
–Anti-spoofing
– IP filter
– L2 filter (only in stealth mode)
– NAT with FTP, IRC, and PPTP support (only in router modes)
–1:1NAT(onlyinrouter network mode)
– Port forwarding (not in stealth network mode)
– Individual firewall rules for different users (user firewall)
– Individual rule sets as action (target) of firewall rules (apart from user firewall or VPN
firewall)
Anti-virus features – CIFS integrity check of network drives for changes to specific file types (e.g.,
executable files)
– Anti-virus scan connector which supports central monitoring of network drives with
virus scanners
Further information can be found on the Phoenix Contact website at:
phoenixcontact.net/products

FL MGUARD
10 PHOENIX CONTACT 8334_en_02
VPN features – Protocol: IPsec (tunnel and transport mode)
– IPsec encryption in hardware with DES (56 bits), 3DES (168 bits), and AES (128, 192,
256 bits)
– Packet authentication: MD5, SHA-1
– Internet Key Exchange (IKE) with main and quick mode
– Authentication via:
– Pre-shared key (PSK)
– X.509v3 certificates with public key infrastructure (PKI) with certification authority
(CA), optional certificate revocation list (CRL), and the option of filtering by subject
or
– Partner certificate, e.g., self-signed certificates
– Detection of changing partner IP addresses via DynDNS
– NAT traversal (NAT-T)
– Dead Peer Detection (DPD): detection of IPsec connection aborts
– IPsec/L2TP server: connection of IPsec/L2TP clients
– IPsec firewall and 1:1 NAT
– Default route over VPN
– Data forwarding between VPNs (hub and spoke)
– Depending on the license: up to 250 VPN channels
– Hardware acceleration for encryption in the VPN
Additional features – Remote logging
– Router/firewall redundancy (can be installed later for each license, not for firmware
version 7.0))
– Administration using SNMP v1-v3 and FL MGUARD device manager (FL MGUARD
DM)
– PKI support for HTTPS/SSH remote access
– Can act as an NTP and DNS server via the LAN interface
Support
Additional information on the device as well as on release NOTE: notes and software up-
dates can be found on the Internet at: phoenixcontact.net/products.

Introduction
8334_en_02 PHOENIX CONTACT 11
1.1 Device versions
The FL MGUARD is available in the following device versions, which largely have identical
functions. All devices can be used regardless of the processor technology and operating
system used by the connected computers.
FL MGUARD RS4000/ 
FL MGUARD RS2000
The FL MGUARD RS4000 is a security router with intelligent firewall and optional IPsec
VPN (10 to 250 tunnels). It has been designed for use in industry to accommodate strict
distributed security and high availability requirements.
The FL MGUARD RS2000 is a version with basic firewall and integrated IPsec VPN
(maximum of two tunnels). Its scope of functions is reduced to the essentials. It is suitable
for secure remote maintenance applications in industry and enables the quick startup of
robust field devices for industrial use, thereby facilitating error-free, independent operation.
Both versions support a replaceable configuration memory in the form of an SD card. (The
SD cards are not supplied as standard.) The fanless metal housing is mounted on a DIN rail.
The following connectivity options are available
Figure 1-1 FL MGUARD RS4000/FL MGUARD RS2000
FL MGUARD RS4000: (LAN/WAN) FL MGUARD RS2000: (LAN/WAN)
TX/TX Ethernet/Ethernet TX/TX VPN Ethernet/Ethernet + VPN
TX/TX VPN Ethernet/Ethernet + VPN

FL MGUARD
12 PHOENIX CONTACT 8334_en_02
FL MGUARD SMART2 The FL MGUARD SMART2 is the smallest device version. For example, it can be easily
inserted between the computer or local network (at the LAN port of the FL MGUARD) and
an available router (at the WAN port of the FL MGUARD), without having to make
configuration changes or perform driver installations on the existing system. It is designed
for instant use in the office or when traveling.
The FL MGUARD SMART2 is a further development of the FL MGUARD SMART.
Figure 1-2 FL MGUARD SMART2
FL MGUARD PCI4000 The FL MGUARD PCI4000 has the design of a PCI-compatible plug-in board.
The FL MGUARD PCI4000 is suitable for distributed protection of industrial and panel PCs,
individual machines, or industrial robots. It has a configuration memory in the form of a
replaceable SD card, which can be easily accessed on the front.
Figure 1-3 FL MGUARD PCI4000
FL MGUARD DELTA TX/TX The FL MGUARD DELTA TX/TX is ideal for use in desktop applications, in distribution
compartments, and other environments close to production process with low requirements
for industrial hardening.
Individual devices or network segments can be safely networked and comprehensively
protected. The FL MGUARD DELTA TX/TX can be used as a firewall between office and
production networks as well as a security router for small and medium-sized workgroups.
Figure 1-4 FL MGUARD DELTA TX/TX

Operating elements and LEDs
8334_en_02 PHOENIX CONTACT 13
2 Operating elements and LEDs
2.1 FL MGUARD RS2000/4000
Figure 2-1 Operating elements and LEDs on the FL MGUARD RS2000/4000
LEDs, see Table 2-1
COMBICON plug-in connector, for
assignment see Page 21
Configuration
(SD card)
Connections at bottom: 
9-pos. serial interface
(console)
Table 2-1 LEDs on the FL MGUARD RS2000/4000
LED State Meaning
P1 Green ON Power supply 1 is active
P2 Green ON Power supply 2 is active (FL MGUARD RS2000: not used)
STAT Green Flashing Heartbeat. The device is correctly connected and operating.
ERR Red Flashing System error. Restart the device.
– Press the Rescue button (for 1.5 seconds).
– Alternatively, briefly disconnect the device power supply and then connect it
again.
If the error is still present, start the recovery procedure (see Page 324) or contact your
dealer.
STAT+ ERR Flashing
alternately: green
and red
Boot process. When the device has just been connected to the power supply. After
a few seconds, this LED changes to the heartbeat state.
SIG –(Notused)
FAULT Red ON The alarm output is open due to an error (see “Installing the FL
MGUARD RS4000/RS2000” on page 20).
(The alarm output is interrupted during a restart.)
MOD Green ON Connection via modem established
INFO Green ON The configured VPN connection has been established.
Flashing The configured VPN connection is being established or aborted.
LAN Green ON The LAN/WAN LEDs are located in the LAN/WAN sockets (10/100 and duplex LED)
Ethernet status. Indicates the status of the LAN or WAN port. As soon as the device
is connected to the relevant network, a continuous light indicates that there is a
connection to the network partner in the LAN or WAN. When data packets are
transmitted, the LED goes out briefly.
WAN Green ON

Product designation
14 PHOENIX CONTACT 8334_en_02
2.2 FL MGUARD SMART2
Figure 2-2 Operating elements and LEDs on the FL MGUARD SMART2
LED 2
Rescue button
(Located in the opening.
Can be pressed with a
straightened paper clip,
for example.) LED 1 LED 3
Table 2-2 LEDs on the FL MGUARD SMART2
LED State Meaning
1Green ON LAN: connection to the network partner is present
Flashing LAN: data transmission is active
2Red/gr
een
Flashing Boot process. When the device has just been connected to the power supply. After a
few seconds, this LED changes to the heartbeat state.
Green Flashing Heartbeat. The device is correctly connected and operating.
Red Flashing System error. Restart the device.
•Press the Rescue button (for 1.5 seconds).
•Alternatively, briefly disconnect the device power supply and then connect it again.
If the error is still present, start the recovery procedure (see “Performing a recovery pro-
cedure” on page 324) or contact your dealer.
3Green ON WAN: connection to the network partner is present
Flashing WAN: data transmission is active
1, 2, 3 Various LED light
codes
Recovery mode. After pressing the Rescue button.
See “NOTE: Restart, recovery procedure, and flashing the firmware” on page 323

Operating elements and LEDs
8334_en_02 PHOENIX CONTACT 15
2.3 FL MGUARD PCI4000
Figure 2-3 Operating elements and LEDs on the FL MGUARD PCI4000
WAN 1 LED
SD card slot (configuration
memory)
Reset button
RJ45 socket (LAN 1) for
connecting the internal
network
RJ45 socket (WAN 1) for
connecting the external
network/Internet
LAN 1 LED
Battery (can be replaced)
STAT LED
LAN 2 LED
WAN 1 LED
Table 2-3 LEDs on the FL MGUARD PCI4000 SD
LEDs State Meaning
WAN 1
LAN 1
Green ON Full duplex
OFF Half duplex
WAN 2
LAN 2
Yellow ON 10 Mbps
Flashing 10 Mbps, data transmission active
Green ON 100 Mbps
Flashing 100 Mbps, data transmission active
LAN 1
LAN 2
WAN 1
Various LED light
codes
Recovery procedure/flashing
See “NOTE: Restart, recovery procedure, and flashing the firmware” on page 323
STAT Red/
green
Flashing Boot process. When the device has just been connected to the power supply. After a few
seconds, this LED changes to the heartbeat state.
Green Flashing Heartbeat. The FL MGUARD is connected correctly and ready to operate.
Red Flashing System error. Restart the device.
•Press the Reset button (for 1.5 seconds).
•Alternatively, briefly disconnect the device power supply and then connect it again.
If the error is still present, start the recovery procedure (see “Performing a recovery
procedure” on page 324) or contact your dealer.

Product designation
16 PHOENIX CONTACT 8334_en_02
2.4 FL MGUARD DELTA TX/TX
Figure 2-4 Operating elements and LEDs on the
SD card slot (configuration
memory)
RJ45 socket (LAN 1)
for connecting the
internal network
RJ45 socket (WAN 1)
for connecting the
external network
Reset button
LEDs
LAN 2/WAN 2
LEDs
LAN 1/WAN 1
LEDs
Table 2-4 LEDs on the FL MGUARD DELTA TX/TX
LEDs State Meaning
WAN 1
LAN 1
Green ON Full duplex
OFF Half duplex
WAN 2
LAN 2
Yellow ON 10 Mbps
Flashing 10 Mbps, data transmission active
Green ON 100 Mbps
Flashing 100 Mbps, data transmission active
PWR Green ON Supply voltage OK
STAT Green Flashing The FL MGUARD is ready to operate.
ERR Red ON System error
FAULT Red ON FL MGUARD in the booting or flashing state
INFO Not used

Startup
8334_en_02 PHOENIX CONTACT 17
3Startup
3.1 Safety notes
To ensure correct operation and the safety of the environment and of personnel, the FL
MGUARD must be installed, operated, and maintained correctly.
Please also note the additional safety notes for the device in the following sections.
General notes regarding usage
WARNING: Intended use
Only use the FL MGUARD in an appropriate way and for its intended purpose.
WARNING: Only connect LAN installations to RJ45 sockets
Only connect the FL MGUARD network ports to LAN installations. Some telecommunica-
tions connections also use RJ45 sockets; these must not be connected to the RJ45 sock-
ets of the FL MGUARD.
NOTE: Connection notes
– A free PCI slot (3.3 V or 5 V) must be available on your PC when using the
FL MGUARD PCI4000.
– Do not bend the connecting cable. Only use the network connector for connection to
a network.
NOTE: Select suitable ambient conditions
– Ambient temperature:
0°C ... +40°C (FL MGUARD SMART2, FL MGUARD DELTA TX/TX)
0°C ... +60°C (FL MGUARD PCI4000 with battery)
0°C ... +70°C (FL MGUARD PCI4000 without battery)
-20°C ... +60°C (FL MGUARD RS4000/FL MGUARD RS2000)
– Maximum humidity, non-condensing
20% ... 90%(FL MGUARD SMART2)
5% ... 95%, (FL MGUARD RS4000/FL MGUARD RS2000, FL MGUARD PCI4000,
FL MGUARD DELTA TX/TX)
To avoid overheating, do not expose to direct sunlight or other heat sources.
NOTE: Cleaning
Clean the device housing with a soft cloth. Do not use abrasive solvents.

Product designation
18 PHOENIX CONTACT 8334_en_02
Steps for startup
To start up the device, carry out the following steps in the specified order:
Step Aim Page
1 Check the scope of supply
Read the release notes
Page 19
2Connect the device
FL MGUARD RS4000/FL MGUARD RS2000 Page 20
FL MGUARD PCI4000 Page 25
FL MGUARD DELTA TX/TX Page 28
3Configure the device, if required.
Work through the individual menu options offered by the 
FL MGUARD configuration interface.
Read the explanations in this user manual in order to determine
which settings are necessary or desirable for your operating
environment
Page 30

Startup
8334_en_02 PHOENIX CONTACT 19
3.2 Checking the scope of supply
Before startup, check the scope of supply to ensure nothing is missing.
The scope of supply includes:
– The FL MGUARD RS4000, FL MGUARD RS2000, FL MGUARD SMART2,
FL MGUARD PCI4000, FL MGUARD DELTA TX/TX device
– Packing slip
The FL MGUARD RS4000 and FL MGUARD RS2000 also include:
– COMBICON plug-in connector for the power supply connection and inputs/outputs (in-
serted)
The FL MGUARD DELTA TX/TX also includes:
– 12 V DC power supply including different country adapters
