Qlightec SHD User manual

SHD / SHD2
Thank you for purchasing Q.Light product.
Please read this manual carefully before installing this system
for safe and long use of the product.
▪ Aluminum housing product with high durability.
▪ Signal sound built-in product of self-standing type with warning
light and phone integrated. This structure can transmit both
visual signal and auditory signal at same time.
▪ Material : Lens-PC, Body-DIECAST AL,
Horn Housing-SUS316L, Reflector-Heat Resisting ABS,
Protection Cage(Option)-SUS316L
▪ RPM : 120-140/Min.(Controllable) ▪ Protection Class : IP56
▪ Volume : SHD 113-118dB(1m), SHD2 113-118dB x 2(1m)
1) SHD
▪ Product Specification
Model Rated
Voltage Current Bulb Weight Color
DC12V 2.240A 12V15W G23 15S 17
DC24V 1.440A 24V15W G23 15S 18 3.18Kg
AC110V 0.321A 12V15W G23 15S 17
SHD
AC220V 0.156A 12V15W G23 15S 17 3.89Kg
Red-R
Amber-A
Green-G
Blue-B
▪ External View Drawing
2) SHD2
▪ Product Specification
Model Rated
Voltage Current Bulb Weight Color
DC12V 3.270A 12V15W G23 15S 17
DC24V 2.130A 24V15W G23 15S 18
4.23Kg
AC110V 0.514A 12V15W G23 15S 17
SHD2
AC220V 0.273A 12V15W G23 15S 17
4.95Kg
Red-R
Amber-A
Green-G
Blue-B
▪ External View Drawing
Type Main Built-in
Sound CH Sound Tone Volume
WS 5 Warning
Sounds
ch1
ch2
ch3
ch4
ch5
Fire A-ANG(Wail)
Emergency WA-U(Yelp)
Ambulance PI-PO(High-Low)
Machinery Fault( PI-PI-PI-)
Foam Release Alarm
(PI~Continuous)
118dB
(SHD)
118dB x 2
(SHD2)
WP
5 Special
Warning
Sounds
ch1
ch2
ch3
ch4
ch5
Fire A-ANG(Wail)
Abandon Alarm
Machinery Fault(PI-PI-PI-)
Foam Release Alarm
(PI~Continuous)
General Alarm
(Long PI~+ 7 Short PI.)
118dB
(SHD)
118dB x 2
(SHD2)
WM 5 Melodies
ch1
ch2
ch3
ch4
ch5
Sweet Home
For Elise
Cuckoo’s Waltz
Piano Sonata
Turkish March
118dB
(SHD)
118dB x 2
(SHD2)
WA 5 Alarms
ch1
ch2
ch3
ch4
ch5
Beep(Intermittent)
Door Chime
Phone Ring
Machinery Fault(PI PI PI PI.)
Tripping Bead Sound
116dB
(SHD)
116dB x 2
(SHD2)
WV 3 Voice
Signals
ch1
ch2
ch3
Reproduction of Voice Recording
3 Channels
113dB(SHD)
113dB x 2
(SHD2)
OPERATING MANUAL
Heavy Duty Bulb Revolving
Light with Phone
ООО “РусАвтоматизация” 454010 Челябинск, Гагарина 5,
русавтоматизация.рф
Россия, тел. [phone],
тел./факс [phone]
(звонок бесплатный)
,[email protected], www.rusautomation.ru,

This product has a volume(1) for controlling revolving speed and
voltage selection switch(2) on assembling board. Refer to above
structure drawing together with below drawing and explanation for
right operating.
1) Lens(Protection Cage) Removal
Remove Protection Cage② and Lens③ from the product by
loosening bolt(M4-4EA)① and make sure assembling board④.
2) Revolving Speed Control
▪ The volume(1) for revolving speed control is built-in this
product. Turn it closckwise for increasing revolving speed and
turn it counterclockwise for decreasing revolving speed.
▪ If give excess power to the volume, it can be broken.
Be careful !
3) Bulb Change
※ Warning ! ! Turn off Power
Must turn off power supply and change the bulb after at least
1 minute.
▪ Make sure the rated voltage and wattage of new bulb. If the
voltage of new bulb is higher than that of original bulb, the
self-life of product can be reduced and can cause damage on
lens and reflector. Therefore, please use same bulb as original
one which has same rated voltage and wattage or lower one.
▪ Bulb Removal : Press slightly the bulb downward and turn it
counterclockwise for removing.
▪ Bulb Fitting : Fit new bulb into the socket by pressing it
clockwise.
Bulb Removing Bulb Fitting
4) Lens(Protection Cage) Assembling
Assemble the lens(or Lens and Protection Cage) in reverse order
of separating.
Refer to structure drawing together with below drawing and
explanation for right operating.
1) Body Cover Removal
▪ Remove body cover⑥ by loosening body cover bolt(M5 4EA)⑤
and make sure related parts on phone control board.
2) Sound Tone Selection
▪ 5 Warning sound tones are built-in this product. In case of
standard product, select preferable sound tone by using internal
sound tone selection switch(S1).
▪ In case of LC Type(Custom-Made) product,refer to below
explanation and drawing.
3) Volume(dB) Control
▪ Volume controller(S2) is built-in this product. Turn it clockwise
for increasing volume or turn it counterclockwise for decreasing
volume
4) Wiring Power Line
▪ Make sure terminal plate⑦ inside the body of the product.
▪ Treat the end of power cable by using “O” or “U” type terminal
for safe wiring.
▪ Connect power cable to terminal plate.
▪ In case of product using AC voltage, connect the line without
polarity(wire color).
▪ In case of product using DC voltage, black line is negative(-).
ООО “РусАвтоматизация” 454010 Челябинск, Гагарина 5,
русавтоматизация.рф
Россия, тел. [phone],
тел./факс [phone]
(звонок бесплатный)
,[email protected], www.rusautomation.ru,

5) Treating Power Entry
▪ Keep the tightness of power entry⑧ by using water-proof
connector(flexible connector #16 is supplied as a standard
specification) or cable grand.
▪ Product can be damaged by water or dust if the cable entry is
exposed outdoor without airtightening.
6) Body Cover Assembling
Assemble the body cover in reverse order of separating.
■ Wiring for LC(External Contact) Type – Custome Made
▪ In case of LC type which selets sound tone by external
contact, power line and signal line come out. Connect each
line as below.
▪ Power Line : UL1015-NO.16(1.25sq) x 2C 400mm
▪ Signal Line : UL1007-NO.22(0.3sq) 400mm
▪ In case of product using AC voltage, do not allow power
supply either to common line or to signal line..
▪ This product is water-proof and anti-corrosion type for
outdoor use. But, install with vertical direction at a place or
machine where exists no big vibration and no strong impact as
long as possible.
▪ Refer to below information and drill necessary mounting holes on
profitable part of the product.
(Make sure PCD from external view drawing.)
▪ Fix the product by using mounting bolt(M8-4EA).
▪ This product is explosion-proof, water-proof and anti-corrosion
type. When separate and assemble the product for wiring, repair
or check, keep the airtightnees of the product by tightening each
bolt and nut.
▪ If using voltage is seriously higher or lower than rated voltage, it
can reduce the self-life of the product or can cause a problem
on product operating. Make sure the using voltage does not
exceed +/- 5% of the rated voltage.
▪ If lens or body of the product is contaminated by chemicals such
as thinner, benzene, the product can be damaged, discolored
or deformed. Please be careful.
▪ Keep airtightness of cable entry by using water-proof cable
grand or water-proof connector. Product can be damaged by
water or dust if the cable entry is exposed outdoor without
airtightening
▪ Do not give strong impact to the product. It can be a reason of
part(s) damage or short circuit.
▪ Do not strongly pull the wire out from the product. It can cause a
disorder.
Situation Main Cause Solution
Non Lighting Wire Disconnection
with Bulb
Wire Re-connection or
Bulb Change
Supplying Voltage Lower
Than Rated Voltage
Making Sure Using
Voltage
Wrong Selecting Voltage
Selection Switch to 220V
(In Case of AC Type)
Selecting Voltage
Selection Switch to
110V
Feeble Lighting
Low Revolving Speed
Sound Tone Deter orat on
Wrong Operating Revolving
Speed Control Volume
Turn the Volume
Clockwise
Short Self-Life of Bulb Supplying Voltage Higher
than Rated Voltage
Making Sure Using
Voltage
Lens Deformation Caused
by Bulb Overheating
Damage on Transformer
(AC Type)
The Voltage of Bulb
is Higher than Rated
Voltage
Changing Bulb with
Rated Voltage
Non Revolving Problem with Motor Contact Q.Light or
Their Agent
Higher dB than Standard Supplying Voltage Higher
than Rated Voltage
Making Sure Using
Voltage
Short Circuit of Sound Tone
Signal Line Making Sure Wiring
Double Sound Tone Problem with Sound Tone
Selection Switch
Contact Q.Light or
Their Agent
Wrong Wiring Making Sure Wiring
No Power Supply Making Sure Wiring
No Sound
Problem with Horn Contact Q.Light or
Their Agent
