PHOENIX DIGITAL OCM-DPR-1 User manual

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
ROCKWELLALLEN-BRADLEY
DATAHIGHWAY PLUS and REMOTE I/O
COMMUNICATION MODULES
INSTALLATION
and
USERS MANUAL
PHOENIX DIGITALCORPORATION
7650 E. EVANS RD. BLDG.A, SCOTTSDALE,AZ 85260
Phone: [phone]
Fax: [phone]
E-Mail: [email protected]
Internet: www.phoenixdigitalcorp.com
0414-1400 REV A

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
PHOENIX DIGITALCORPORATION
ROCKWELLALLEN-BRADLEY
DATAHIGHWAY PLUS and REMOTE I/O
OPTICAL COMMUNICATION MODULES
Users Manual
Document # 0414-1400 REVA

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
ROCKWELLALLEN-BRADLEY
DATA HIGHWAY PLUS and REMOTE I/O
OPTICAL COMMUNICATION MODULES USERS MANUAL
TABLE OFCONTENTS
CHAPTER 1 DESCRIPTIONAND SPECIFICATION PAGE #
1.1 INTRODUCTION............................................................................................ 1-1
1.2 PRODUCT DESCRIPTION.............................................................................. 1-3
1.2.1 FAULT TOLERANT, SELF HEALING COMMUNICATION............................ 1-3
1.2.2 FAULT PREDICTIVE COMMUNICATION...................................................... 1-7
1.2.3 WAVELENGTH SELECTION.......................................................................... 1-7
1.3 PRODUCT SPECIFICATIONS......................................................................... 1-8
1.3.1 DEVICE INTERFACE SPECIFICATIONS....................................................... 1-8
1.3.2 OPTICALNETWORK INTERFACE SPECIFICATIONS.................................. 1-15
1.3.3 INTERACTIVE DIAGNOSTICS...................................................................... 1-18
1.3.4 POWER SUPPLYAND GROUNDING SPECIFICATIONS.............................. 1-37
1.3.5 MECHANICALAND ENVIRONMENTALSPECIFICATIONS....................... 1-42
CHAPTER 2 CONFIGURATIONAND INSTALLATION INSTRUCTIONS
2.1 UNPACKING INSTRUCTIONS....................................................................... 2-1
2.2 INSPECTION PROCEDURE............................................................................ 2-1
2.3 INSTALLATION MOUNTING PROCEDURE.................................................. 2-1
2.4 DIAGNOSTIC STATUS INDICATOR DEFINITION.........................................2-2
2.5 INITIAL SIGNAL SET POTENTIOMETERS.................................................... 2-4
2.6 DIAGNOSTIC STATUS I/O DEFINITION....................................................... 2-4
2.7 CONFIGURATION INSTRUCTIONS......................................................... 2-5
APPENDIX A: LIST OF FIGURES IN MANUAL............................................. A-1
APPENDIX B: LIST OF TABLES IN MANUAL............................................... B-1

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
1-1
CHAPTER 1
DESCRIPTIONAND SPECIFICATION
1.1 INTRODUCTION
Phoenix Digital’s family of RockwellAllen-Bradley Data Highway Plus and Remote I/O
(DH+/RIO) fiber optic modules provide the most advanced, comprehensive, state-of-the-art
fiber optic communication capabilities on the market today. Phoenix Digital’s DH+/RIO fiber
optic modules are available as standalone, panelmount modules with integral 120/220 VAC, 24
VDC, or 125 VDC power supplies (Optical Communication Modules... OCMs), 1771 plug-in
modules (Optical Communication Modules... OCMs), 1746 plug-in modules (Optical Link Cou-
plers... OLCs), and 1756 plug-in modules (Optical ControlLogix Modules... OCXs). These
fiber optic modules translate hardwire networks into an optical network medium, transparent to
the communication protocol and configurable for distribution by the user in ring, bus, star, tree,
or point-to-point network installations. Fiber optic network options include features not found
in even the most expensive communication network installations; on-line diagnostic monitoring
with high speed self healing communication recovery around points of failure (Fault Tolerant),
in-line signal strength monitoring with annunciation of impending communication failures (Fault
Predictive), interactive diagnostics to locate fault and impending fault conditions (accessible by
the user program), and wavelength selection for matching fiber media characteristics. Phoenix
Digital makes all of this possible through application of its patented self healing communication
switch and advanced optical measurement technologies.
The following table provides correspondence between Phoenix Digital fiber optic module Model
Numbers and RockwellAllen-Bradley network compatibility. The user should check the Model
Number label located on the side of the fiber optic module cover to verify network interface
compatibility.

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
OCM MODEL # NETWORK COMPATIBILITY
OCM-DPR-(1)-(2)-(3)-(4)-(5)-(6)-(7) DH+/RIO Communications (1771 Plug-In and
Standalone, Panelmount modules)
OLC-DPR-(1)-(3)-(4)-(6)-(7) DH+/RIO Communications (1746 Plug-In modules)
OCX-DPR-(1)-(3)-(4)-(6)-(7) DH+/RIO Communications (1756 Plug-In modules)
(1) “85” = 850 nanometer wavelength selection
“13” = 1300 nanometer wavelength selection
“15” = 1550 nanometer wavelength selection
(2) “P” = Standalone, Panelmount Enclosure
blank = 1771, 1746, or 1756 Plug-In Module
(3) “D” = Interactive Diagnostics
blank = No Diagnostics
(4) “ST” = ST Fiber Optic Connector Style
“SMA” = SMA Fiber Optic Connector Style (Available with
850nm Wavelength only.)
(5) “24V” = 24 VDC Operation
“ACV” = 120/220 VAC, 50/60 Hz Operation
“125V” = 125 VDC Operation
(6) “SM” = Singlemode Fiber Compatibility (Available with 1300nm
or 1550 nm Wavelengths, and ST connector options only.)
blank = Multimode Fiber Compatibility
(7) “EXT” = Extended Capacity Feature (24+ fiber optic modules on a
single bus or ring network configuration.)
blank = No Extended Capacity Feature (Maximum of 12 fiber optic
modules on a single bus or ring network configuration.)
PRODUCT MODEL NUMBER DEFINITION
TABLE 1
1-2

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
1-3
A summary of selected fiber optic features is given below:
o Supports a Wide Range of Communication Distances: Beyond 6 miles/10 kilometers
between nodes using Multimode fiber, and beyond 16 miles/25 kilometers using
Singlemode fiber.
o FaultTolerant Communication:Provides On-lineDiagnosticMonitoring andHigh
Speed,SelfHealing Communication Recovery.
o FaultPredictiveCommunication: ProvidesIn-lineOptical Signal StrengthMonitoring and
Annunciationof ImpendingCommunication Failures.
o Interactive Diagnostics (User Program Accessible): Locates Fault and Impending Fault
Conditions Throughout the Network.
o Selectable Wavelengths: 850 nanometer, 1300 nanometer (multimode and singlemode), and
1550 nanometer (multimode and singlemode).
o Extended capacity option: Supports over 24 fiber optic modules on a Single Multidrop
bus or ring network
o Easy to see, visual indication of Communication Diagnostic Status.
1.2 PRODUCT DESCRIPTION
1.2.1 FAULTTOLERANT, SELFHEALINGCOMMUNICATION
PhoenixDigital’s FaultTolerant, Self-HealingCommunicationtechnology providesdiagnostic moni-
toring of the communication signal waveforms at each node on the network, and ultra-high speed
detection,isolation,and correctionofpoints ofcommunication failure anywhereon the networkgrid.
Phoenix Digital’s fiber optic modules will self heal around communication failures in ring, bus, star,
tree, or point-to-point network configurations. Figure 1 illustrates Examples of Typical Fiber Optic
Module Network Configurations.

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
(1) OPTICALCOMMUNICATION MODULE (3)OPTICAL LINKCOUPLER
MODEL # OCM-DPR-85-P-D-ST-ACV MODEL # OLC-DPR-85-D-ST
(2) OPTICALCOMMUNICATION MODULE (4) OPTICAL ControlLogix MODULE
MODEL # OCM-DPR-85-D-ST MODEL # OCX-DPR-85-D-ST
CHA
CH A
CH B
CH B
txtx
txtx
rx
rx
rx
OCM (1) OCM (2) ASB
PLC
DUPLEXFIBERCABLES
REDUNDANTFIBER CHANNELS
FAULTTOLERANT, REMOTE I/O POINT-TO-POINT NETWORK CONFIGURATION
WORKSTATION
PLC PLC PLC PLC
OCM (1) OLC (3) OCX (4) OCM (1)
CH A CH B
tx tx
tx tx tx tx
rx
rxrx
rx rx
FAULT TOLERANTDATA HIGHWAYPLUS RING NETWORK CONFIGURATION
RIOTWINAXCOPPER WIRE
DH+TWINAX
COPPERWIRE
FIGURE 1
EXAMPLES OF TYPICAL FIBER OPTIC DH+ and RIO NETWORK CONFIGURATIONS
rx
rx
1-4
tx tx
rx
rx

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
1-5
The ultra-high speed, self healing communication technology on each fiber optic module will auto-
matically redirect network traffic around points of failure (wrapback communication). In a failed
condition the fiber optic communication network will self heal around a fault by redirecting data
communications around the point of failure. This is accomplished by wrapping back network com-
munications at the communication nodes on either side of the point of failure, through the use of a
high-speed, combinational wrapback communication switch (hardware pass-thru, non-software in-
teractive) built into the front-end optical interface of each Phoenix Digital fiber optic module.
Figure2 illustratesatypical fiberoptic DH+fault tolerantring networkconfiguration. Inthis configu-
ration, the fiber optic modules must be connected ChATransmit to ChAReceive, ChATransmit to
ChAReceive, etc., around the ring (counter-clockwise in Figure 2); and Ch B Transmit to Ch B
Receive, Ch BTransmit to Ch B Receive, etc., around the ring (clockwise in Figure 2). Diagnostic
monitoringcircuitry ateach modulewillcontinuously monitorthe integrityof thecommunication car-
riers present at the receive data inputs of each communication channel. This high speed combina-
tionaldiagnosticmonitoring circuitry willmonitor and detectcommunication failures incarrier sym-
metry, jitter, amplitude, and babble. In the event a fault condition is diagnosed on the network
(Figure 2: Node 2/Channel B receiver and Node 3/ChannelAreceiver) the fiber modules detecting
the failure (Nodes 2 and 3) will immediately redirect communication around the point of failure, the
opposite way around the ring. Essentially, the network dynamically reconfigures to form a new
communication path from Node 2 to Node 3, away from the point of failure (the long way around the
network),thus insuringcommunication networkcontinuity andfault isolaton. Inaddition toproviding
networkfault tolerance, PhoenixDigital’sfiberoptic modulesenable maintenancepersonnel tolocate
faultconditions(remote statusmonitoring), add/delete nodes,and splice/terminate/replace mediaon-
line,without disruptingnetwork communications.
Communication continuity will be unconditionally maintained by the fiber optic modules in the
event of either node or media failure. When the source of the network failure is corrected, the
fiber optic modules will automatically restore the communication network to its original traffic pat-
terns.

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
OCM DATA HIGHWAY PLUS NETWORK ILLUSTRATING
SELF HEALING COMMUNICATION WRAPBACK
FIGURE 2
B
CH B Tx Rx Tx Rx Tx Rx Tx Rx CH B
CHANNELA
CHANNELB
CH A Rx Tx Rx Tx Rx Tx Rx Tx
NETWORKEXPANDABLE
TO AMAXIMUM OF 24
FIBEROPTICMODULES
WITH“-EXT” FEATURE
CH A
COMMUNICATION
FAILURE
OPERATOR
INTERFACE PLC 5/40(4)
PLC 5/40
SLC 5/04(5)
(1) OCM = Optical Communication Module
Model # OCM-DPR-85-P-D-ST-ACV
(1771 Plug-In or Standalone, Panelmount)
(2) OLC = Optical Link Coupler
Model # OLC-DPR-85-D-ST (1746 Plug-In)
(3) OCX = Optical ControlLogix Module
Model # OCX-DPR-85-D-ST (1756 Plug-In)
(4) PLC 5/40 = PLC 5/40 with DH+ Interface
(5) SLC 5/04 = SLC Processor with DH+ Interface
(6) Logix L555x w/ 1756-DHRIO = ControlLogix
Processor with DH+ Comm Module
DH+ TWINAX
HARDWIREMEDIA
A
A
B
WRAPBACKFIBERS
CHANNELB
CHANNELA
1-6
OCM(1) OCM OLC(2) OCX(3)
NODE 1 NODE 2 NODE 3 NODE N
LogixL555xw/
1756-DHRIO(6)

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
1-7
1.2.2 FAULT PREDICTIVE COMMUNICATION (850 nm and 1300 nm
MULTIMODE ONLY)
Phoenix Digital’s Fault Predictive CommunicationTechnology provides diagnostic monitoring and
detectionof impendingcommunication failuresresultingfrom gradualdegradation ofthe communica-
tionlink itself. Phoenix Digital’sfiber opticmodules monitor impendingfault conditionsby continu-
ously measuring the actual in-line signal strength (optical power) of the data comunications at each
receive input on the module. The fiber modules continuously compare these actual in-line measure-
ments to preset optical power reference thresholds, which are normalized to power levels where
valid network communications will still be assured, but impending communication failures can be
accurately predicted. If the actual in-line data communication signal strength degrades below these
power thresholds (resulting from one or more sources of link degradation) the fiber modules will
automaticallydetect andannunciate theimpending failureconditionsviavisualindicators onthe front
of the module. Phoenix Digital’s fiber optic modules also provide User ProgramAccessible, Inter-
activeDiagnostics(1771, 1746,and 1756 Plug-InFiber Modules) andHardwired Diagnostic Ouputs
(Standalone, Panelmount Fiber Modules) for remote monitoring, detecting, and locating of impend-
ing fault conditions (remote status monitoring). In addition, the fiber optic modules provide a linear
DC voltage representation (analog) of the actual in-line signal strength (normalized for a 0 to +3.5
VDCrange)for moreprecisemonitoring ofcommunicationlink status(on-lineoptical powermeter-
ing). Thus,communication linkstatus iscontinuouslymonitoredandimpending failureconditions are
annunciatedby the fibermodules beforethecommunication failureactually occurs,enablingmainte-
nance personnel to perform Predictive Maintenance on the fiber optic communication network at-
large. (The Impending Fault Monitoring feature is available only on 850 nm or 1300 nm
multimode fiber optic modules with the “-D” Diagnostic Option.)
1.2.3 WAVELENGTH SELECTION
Phoenix Digital’s fiber optic modules provide five options for wavelength selection. The
economical 850 nanometer multimode wavelength may be selected for data communication
networks with less than 12,000 feet (3,650 meters) between communication nodes. The higher
performance 1300 and 1550 nanometer multimode wavelengths may be selected for longer
distance applications, extending communication distances between nodes to over 6 miles (10
kilometers). For maximum distance, the ultra-high performance 1300 and 1550 nanometer
singlemode wavelengths may be selected, extending communication distances to over 16 miles
(25 kilometers) between communication nodes!

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
1.3 PRODUCT SPECIFICATIONS
Fiber Optic Module Mounting Dimensions and Connector Designations are provided in Figures
3 thru 6.
1.3.1 DEVICE INTERFACE SPECIFICATIONS
The standalone, panelmount OCM and 1771 plug-in OCM Device Interface Port Connections are
provided on the front of the OCM module (designated as J1 - see Figures 3 and 4).
The 1746 plug-in OLC and 1756 plug-in OCX Device Interface Port Connections are provided on
the bottom of the fiber modules (designated as J2 - see Figures 5 and 6).
The user must follow all RockwellAllen-Bradley Installation, Wiring Guidelines, and Termination
Proceduresforinterconnect wiringof DH+ andRIO devicesandPhoenix Digitalfiber optic modules.
1-8

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
ROCKWELLALLEN-BRADLEY DH+/RIO
STANDALONE, PANELMOUNT OCM MOUNTING
DIMENSIONS AND CONNECTOR DESIGNATIONS
1.50 (1)
(38.1) 2.50
(63.5)
10.38
(263.7)
7.50
(190.5)
5.38
(136.7)
.38 (9.7)
1.38
(35.1)
1.76
(44.7)
.50 (12.7)
1.00
(25.4) 1.76 (44.7)
6.14
(156.0)
.093 (2.40)
1
2
3
4
5
6
7
8
Tx
Rx
ACT
ISD
IFD
ERR
ACT
ISD
IFD
ERR
TX
RX
TX
RX
ISS
ISS
TM
J1
CH B
CH A
(1) ALL DIMENSIONS SHOWN IN INCHES (MILLIMETERS) +/- 2 %
(2) POWER SUPPLY ATTACHED TO SIDE COVER FOR 120/220 VAC
(“-ACV”) AND 125 VDC (“-125V”) OPERATION ONLY. POWER
SUPPLY INTEGRAL TO MAIN CHASSIS FOR 24 VDC OPERATION (“-24V”).
1-9
LOCAL
1 2 3 4 5 6 7 8 1 2 3 4 5
1 2 3 4 5 6
P1
P2
L1 L2 J4
J5
1 2 3 4 5 6 7 8 1 2 3 4 5
1 2 3 4 5 6
P1
P2
+125V -125V C-GND J4
J5
1 2 3 4 5 6 7 8
J4
FIGURE 3
(2)
24 VDC
125 VDC
120/220 VAC
1 2 3 4 5
+24V -24V
C-GND NC NC
J5

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
ROCKWELLALLEN-BRADLEYDH+/RIO
1771 PLUG-IN OCM CONNECTOR DESIGNATIONS
FIGURE 4
1
2
3
4
5
6
7
8
Tx
Rx
ACT
ISD
IFD
ERR
TX
RX
TX
RX
ISS
ISS
TM
J1
CH B
CH A
ACT
ISD
IFD
ERR
1-10
LOC

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
1-11
ROCKWLLALLEN-BRADLEYDH+/RIO
1746 PLUG-IN OLC CONNECTOR DESIGNATIONS
FIGURE 5
A
B
AC/ER AC/ER
Ch A Ch B
ID/IF ID/IF
Tx/Rx OK
ChA Tx
ChA Rx
ChB Tx
ChB Rx
ISS
ISS
TM
FIBEROPTICS
RSS
(AnalogOutputs)
DH+/RIO TWINAX
HARDWIRE CONNECTION
ON BOTTOM OF MODULE
J1 CONNECTOR (UNUSED)
1
2
3
J2 CONNECTOR

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
1-12
A
B
Ch A Ch B
ACT/ERR ACT/ERR
Ch A Ch B
ISD/IFD ISD/IFD
LOCAL OK
Tx/Rx
ROCKWELLALLEN-BRADLEYDH+/RIO
1756 PLUG-IN OCX CONNECTOR DESIGNATIONS
FIGURE 6
ChA Tx
ChA Rx
ChB Tx
ChB Rx
ISS
ISS
TM
FIBEROPTICS
RSS
(AnalogOutputs)
DH+/RIO TWINAX
HARDWIRE CONNECTION
ON BOTTOM OF MODULE
J1 CONNECTOR (UNUSED)
J2 CONNECTOR 1
2
3

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
1-13
1.3.1.1 STANDALONE, PANELMOUNT OCMAND 1771 PLUG-IN OCM
J1 CONNECTOR PIN DESIGNATIONS
OCM J1 Connector Pin Numbers (1) DH+/RIO Signal Name
1(2) Ch A Receive Signal Strength (RSS)
2 RSS Signal Ground
3(2) Ch B Receive Signal Strength
4 Shield In
5 Shield Out
6(3, 4) Serial 2/Blue(DH+), Serial 1/Blue (RIO)
7(3, 4) Serial 1/Clear (DH+), Serial 2/Clear (RIO)
8(3) Termination
(1) J1 Connector Orientation on the front of the OCM module is top to bottom, Pin #s 1 thru 8 respectively.
(All unused J1 connector screw terminals should be fully seated.) See Figures 3 and 4 for J1 Connector
Designations.
(2) ChannelAand Channel B RSS provide DC voltage outputs proportional to the optical receive signal strength
of fiber optic channelsAand B respectively. (Available only on fiber optic modules operating on the 850nm
or 1300 nm multimode wavelengths. See Interactive Diagnostics in Section 1.3.3 for detailed information.)
(3) Each end of each hardwired DH+ or RIO network stub (wire connection made to the OCM J1 connector)
must be terminated with either an 82 ohm, 5%, 1/4 watt resistor (230 K baud and Remote I/O “Extended
Node” networks), or a 150 ohm, 5%, 1/4 watt resistor (57.6 K baud and 115.2 K baud networks, excluding
“Extended Node” RIO networks).
A150 ohm, 5%, 1/4 watt termination resistor is internally provided in every OCM module. This resistor is
connected across Serial 1 and Serial 2 by jumpering together pin #s 7 and 8 on the OCM J1 connector
(Factory Default). If the OCM is located on either end of the hardwired network stub (connected to the
OCM J1 connector), and a 150 ohm termination resistor is required, then a termination jumper must be
provided on the OCM J1 connector between pin #s 7 and 8. If a 150 ohm termination resistor is not required
at the OCM location then the jumper should not be installed. If an 82 ohm resistor is required at the OCM
location then this resistor must be installed externally, on the OCM J1 connector, across J1 connector
pin #s 6 and 7. In this case, J1 connector pin #s 7 and 8 should NOT be jumpered together. (An external 82
ohm resistor is provided with every OCM-DPR.)
If the OCM is used as a fiber optic repeater and is not connected to any Rockwell devices, then it should
have the J1 Connector Local Interface disabled. See Interactive Diagnostics in Section 1.3.3 for more
information.
(4) All of the DH+ and RIO devices on each hardwired nework stub must be interconnected Serial 1 to Serial 1
and Serial 2 to Serial 2. Cross-connecting Serial 1 to Serial 2 will cause communication failures. Consult
Rockwell DH+ and RIO Network Installation Guidelines for more information on correct network
installation and wiring procedures.
OCM DH+/RIO DEVICE INTERFACE CONNECTOR PIN DEFINITIONS
TABLE 2

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
1-14
1.3.1.2 1746 PLUG-IN OLCAND 1756 PLUG-IN OCX J2 CONNECTOR
PIN DESIGNATIONS (CONNECTOR ON BOTTOM OF MODULE)
OLC/OCX J2 Connector Pin Numbers (1) DH+/RIO Signal Name
1(2, 3) Serial 1/Clear (DH+), Serial 2/Clear (RIO)
2 Shield
3(2, 3) Serial 2/Blue (DH+), Serial 1/Blue (RIO)
(1) J2 Connector Orientation on the bottom of OLC and OCX modules is front to back, Pin #s 1 thru 3
respectively. See Figures 5 and 6 for J2 Connector Designations.
(2) Each end of each hardwired DH+ or RIO network stub (wire connection made to the OLC/OCX J2
connector) must be terminated with either an 82 ohm, 5%, 1/4 watt resistor (230 K baud and Remote I/O
“Extended Node” networks), or a 150 ohm, 5%, 1/4 watt resistor (57.6 K baud and 115.2 K baud networks,
excluding “Extended Node” RIO networks). (External 82 ohm and 150 ohm termination resistors are
provided with every OLC and OCX module.)
If the OLC or OCX is used as a fiber optic repeater and is not connected to any Rockwell devices, then it
should have the J2 Connector Local Interface disabled. See Interactive Diagnostics in Section 1.3.3 for
more information.
(4) All of the DH+ and RIO devices on each hardwired nework stub must be interconnected Serial 1 to Serial 1
and Serial 2 to Serial 2. Cross-connecting Serial 1 to Serial 2 will cause communication failures. Consult
Rockwell DH+ and RIO Network Installation Guidelines for more information on correct network
installation and wiring procedures.
OLC and OCX DH+/RIO DEVICE INTERFACE CONNECTOR PIN DEFINITIONS
TABLE 3

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
1.3.2 OPTICAL NETWORK INTERFACE SPECIFICATIONS
The Optical Network Interface is designated as ChA Tx, Ch A Rx, Ch B Tx, and ChB Rx on the
fiber optic module faceplate (see Figures 3, 4, 5, and 6). Phoenix Digital fiber optic modules are
compatible with either ST or SMA 905/906 style fiber optic connectors... as an ordering option
(matingconnectorwhich isterminated to thefiber media). (Alignmentsleevesshould beprovided on
all SMA Style 906 connectors for optical alignment.) Detailed specifications describing optical net-
worktransmitand receive capabilitiesat the 850nmmultimode, 1300nm multimode,1550nm multi-
mode, 1300nm singlemode, and 1550 nm singlemode wavelengths are provided below:
1-15
OPTICALTRANSMITTER (850nm MULTIMODE)
Electro-Optical Characteristics
TABLE 4
Parameter TestCondition SYM. MIN. TYP. MAX. UNITS
Fiber 50/125micron, Poc 10/-20.0 20/-17.0 microwatts/dBm
Coupled Graded, 0.20NA
Power 62.5/125micron, 21.9/-16.6 45/-13.5 microwatts/dBm
Graded, 0.28NA
100/140micron, 58.0/-12.4 115/-9.4 microwatts/dBm
Graded, 0.29NA
200/230 micron, 320/-4.9 microwatts/dBm
Graded, 0.37NA
Peak λ P850 nm
Wavelength
Spectral λ W50 nm
Width

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
OPTICALTRANSMITTER (1300nm MULTIMODE)
Electro-Optical Characteristics
Parameter Test Condition SYM. MIN. TYP. MAX. UNITS
Fiber 50/125micron Poc 25/-16.0 microwatts/dBm
Coupled Graded, 0.20NA
Power 62.5/125micron 50/-13.0 microwatts/dBm
Graded, 0.28NA
Wavelength λ P1290 1350 nm
Spectral λW 160 nm
Width
OPTICALTRANSMITTER (1550nm MULTIMODE)
Electro-Optical Characteristics
Parameter TestCondition SYM. MIN. TYP. MAX. UNITS
Fiber 50/125 micron Poc 50/-13.0 microwatts/dBm
Coupled Graded, 0.20NA
Power
Wavelength λP 1510 1580 nm
Spectral λW 45 100 nm
Width
TABLE 6
TABLE 5
1-16

DH+/RIO OPTICALCOMMUNICATION MODULES USERS MANUAL
Copyright © 2003 by Phoenix Digital Corporation,All Rights Reserved.
OPTICAL TRANSMITTER (1300nm SINGLEMODE)
Electro-Optical Characteristics
Parameter TestCondition SYM. MIN. TYP. MAX. UNITS
Fiber 9/125 micron Poc 16/-18.0 microwatts/dBm
Coupled
Power
Wavelength λP 1270 1340 nm
FWHM λW 70 90 nm
TABLE 7
OPTICAL TRANSMITTER (1550nm SINGLEMODE)
Electro-OpticalCharacteristics
Parameter TestCondition SYM. MIN. TYP. MAX. UNITS
Fiber 9/125 micron Poc 30/-15.0 microwatts/dBm
Coupled
Power
Wavelength λP 1510 1580 nm
FWHM λW 45 100 nm
TABLE 8
1-17
