Phoenix International VL2-350-SC-SSD Manual

VL2-350-SC-SSD
MASS STORAGE SUBSYSTEM
Technical Information
Copyright ©Phoenix International 2005. All Rights Reserved
812 W. Southern Avenue, Orange, CA 92865

PREFACE
A number of conventions are used throughout this manual in order to provide clarity and
descriptive accuracy. These include:
1. The use of an 'H' (character) suffix to a number indicates that the number reference is
in hexadecimal notation.
2. The use of a '-' (minus) postfix to a signal name indicates that the signal is either true
when the signal is at a logic 0 level or that the signal initiates actions on a high-to-low
signal transition.
DISCLAIMER
The information contained within this document has been carefully checked and is believed to
be entirely reliable and consistent with the product that it describes. However, no
responsibility is assumed for inaccuracies. Nor does Phoenix International assume any
liability arising out of the application or use of any product or circuit described herein. Phoenix
International reserves the right to make changes to any product and product documentation in
an effort to improve performance, reliability or design. Furthermore, the information contained
herein is of a proprietary nature and is not to be reproduced without prior written consent of
Phoenix International.
TRADEMARKS
IBM, PC/XT, PC/AT, EGA, CGA, and VGA are registered trademarks of International Business
Machines Corporation. MS-DOS is a registered trademark of Microsoft Corporation.
REV 1.0
DATE 4-07

Table of Contents
Chapter 1 Manual Organization and Introduction 1-1
Scope 1-3
Manual Organization 1-3
VL2-350-SC-SSDIntroduction 1-3
Chapter 2 Features and Specifications 2-1
Scope 2-3
Features 2-3
SCSI Interface Description 2-3
VL2-350-SC-SSD Specification 2-4
Chapter 3 Configuration, Installation, and Operation 3-1
Scope 3-3
Drive Hardware Configuration 3-3
Hard Drive Hardware Configuration 3-3
Considerations for Installation 3-3
VMEbus Slot Requirements 3-3
VMEbus Backplane Requirements 3-3
Power Supply Requirements 3-3
Termination ` 3-3
Terminator Power Configuration 3-4
Installing the VL2-350-SC-SSD3-4
Drive Software Configuration 3-4
Hard Drive Software Configuration 3-4
Operation 3-4
Chapter 4 Solid State Disk Drive Detail 4-1
Scope 4-3
Introduction 4-3
Key Features 4-3
Physical Configuration 4-3
Drive Performance 4-3
Read/Write Performance 4-3
Power Requirements 4-4
Physical Characteristics 4-4
Environmental Characteristics 4-4
Reliability 4-4
Shock and Vibration 4-4
Functional Description 4-4
Error Correction 4-4
Power Connectors 4-4
SCSI Interface Connector 4-4

Chapter 5 Product Support, Service and Warranty 5-1
Scope 5-3
Warranty Statement 5-3
If You Have a Problem 5-3
Product Repairs 5-3
Obtaining an RMA 5-3
Shipping the Product 5-3
Providing a Product Defect Report 5-4
Warranty Repairs 5-4
Non-warranty Repairs 5-4
Product Updates 5-4
Tables
Table 2-2 Ultra 320 SCSI Pin Definition 2-3
Table 2-3 P2 Pin Definition 2-5
Figures
Figure 1-1 VL2-350-SC-SSD Front Panel 1-4

Chapter 1
Manual Organization
and Introduction

This page intentionally left blank.

Scope
This chapter describes the organization of this manual and gives an overview of the VL2-350-SC-SSD.
Manual Organization
This manual is organized as follows:
Chapter 1 MANUAL ORGANIZATION AND INTRODUCTION
Contains an overview of the manual organization and provides a brief product description.
Chapter 2 FEATURES AND SPECIFICATIONS
Describes the product features, compatibility, and electrical specifications.
Chapter 3 CONFIGURATION, INSTALLATION AND OPERATION
Provides information on how to configure and install the VL2-350-SC-SSD .
Chapter 4 SCSI DISK DRIVE DETAILS
Contains specific details about the disk drive used on the VL2-350-SC-SSD .
Chapter 5 PRODUCT SUPPORT, SERVICE AND WARRANTY
Describes what to do if you have trouble and how we will support you.
VL2-350-SC-SSD Introduction
The VL2-350-SC-SSD has been designed to provide a complete disk drive subsystem which is mechanically compatible
with the VMEbus. It has been designed specifically to interface with VMEbus processors with an embedded Ultra 320
SCSI Host Adapter. Together with the processor, a complete system can be installed in only three standard VMEbus sys-
tem slots. The VL2-350-SC-SSD provides one or two disk drives within the same module making it very convenient
to have fixed data storage. The drives used on board the VL2-350-SC-SSD were chosen for their compatibility, rugged-
ness and reliability. The Ultra 320 SCSI bus can be connected to the module via the front panel 68 pin Wide SCSI con-
nector or via the P2 connector.
Manual Organization and Introduction 1-3

HD
S
C
S
I
2
1 3
0 4
7 6
6
UNIT 0
ID
HD
2
1 3
0 4
7 6
6
UNIT 1
ID
ID Switch and Disk Drive Activity
indicator for Second disk drive
Figure 1-1: VL2-350-SC-SSD Front Panel
VL2-350-SC-SSD User's Manual1-4

Chapter 2
Features and
Specifications

This page intentionally left blank.
