Phonic SMARTMAN 300A User manual

User's Manual
Manual de Usuario
SMARTMAN 300A
SMARTMAN 700A
SMARTMAN 300A

ENGLISH........................................I
ESPAÑOL.......................................II
APPENDIX...........................................III
V1.0 10/29/2015
SMARTMAN 300A
SMARTMAN 700A
English Español
ALL-IN-ONE INTELLIGENT AUDIO SYSTEMS
SISTEMAS INTELIGENTES DE AUDIO TODO-EN-UNO

INTRODUCTION.................................................................1
FEATURES..............................................................................1
SYSTEM OVERVIEW.............................................................2
SETTING.................................................................3
SPECIFICATIONS................................................................4
APPENDIX
DIMENSIONS......................................................................1
CONTENTS
USER'S MANUAL
Phonic preserves the right to improve or alter any information within this
document without prior notice.
English

1. Read these instructions before operating this
apparatus.
2. Keep these instructions for future reference.
3. Heed all warnings to ensure safe operation.
4. Follow all instructions provided in this document.
5. Do not use this apparatus near water or in locations
where condensation may occur.
6. Clean only with dry cloth. Do not use aerosol or liquid
cleaners. Unplug this apparatus before cleaning.
7. Do not block any of the ventilation openings. Install
in accordance with the manufacturer
’ s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If
the provided plug does not into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plug, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories by the
manufacturer.
12. Use only with a cart, stand, tripod, bracket, or
table by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus
combination to avoid injury from tip-
over.
13. Unplug this apparatus during lighting
storms or when unused for long
periods of time.
14. Refer all servicing to service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED PERSONNEL
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated
“ dangerous voltage ” within the
product
’
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is in-
tended to alert the user to the presence of important operat-
ing and maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING: To reduce the risk of or electric shock, do
not expose this apparatus to rain or moisture.
CAUTION: Use of controls or adjustments or performance
of procedures other than those may result in
hazardous radiation exposure.
The apparatus shall not be exposed to dripping or splashingand that no objects with liquids, such as vases,
shall be placed on the apparatus. The MAINS plug is used as thedisconnect device,the disconnect device shall
remain readily operable.
Warning: the user shall not place this apparatus in the area during theoperation so that the mains switch
can be easily accessible.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
English

1SMARTMAN 300A / SMARTMAN 700A
English
INTRODUCTION
Congratulations on your purchase of Phonic Smartman
active expansion speaker. Smartman active expansion
speaker uses Class D to provide sufcient power for
a wide range of venues, large and small. Its stylish
polymer enclosure also improves acoustical accuracy
by minimizing distortion and diffraction. Finally, reliability
and durability was the paramount factor throughout the
Smartman’s development.
Smartman active expansion speaker is designed
uniquely to work with Smartman Integrated Audio
System. By chaining together, Smartman can offer innite
expandability for your live PA systems.
The Woofers and Tweeters Engineered Right Unlike many
other speaker manufactures that use pre-assembled
OEM woofers and tweeters, all components of Smartman
are designed from scratch, in-house, by Phonic.
Everything, from the cone pulp formula and the curvature
of the tweeter’s titanium membrane to the characteristic
of the magnetic eld, is uniquely Phonic, uniquely
Smartman.
Smartman’s state-of-the-art woofer has a distinctly
high BL force factor and a long-throw extension which
produce marvelously deep and dened bass traditionally
unattainable in small enclosures. The compression
tweeter and conical horn complete the Smartman’s vivid,
transparent sound signature.
FEATURES
4Remarkable sound, remarkable power, and remarkable
style in a lightweight, durable enclosure
4High-powered Class D technology adapted
4Innite expansion when work with Smartman Integrated
Audio System
435mm pole mount for extended audience reach
4Impact resistant polymer enclosure with internal
bracings
4Tour grade steel grille (1.2 mm)
1. Read these instructions before operating this
apparatus.
2. Keep these instructions for future reference.
3. Heed all warnings to ensure safe operation.
4. Follow all instructions provided in this document.
5. Do not use this apparatus near water or in locations
where condensation may occur.
6. Clean only with dry cloth. Do not use aerosol or liquid
cleaners. Unplug this apparatus before cleaning.
7. Do not block any of the ventilation openings. Install
in accordance with the manufacturer
’ s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If
the provided plug does not into your outlet, consult
an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plug, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories by the
manufacturer.
12. Use only with a cart, stand, tripod, bracket, or
table by the manufacturer, or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus
combination to avoid injury from tip-
over.
13. Unplug this apparatus during lighting
storms or when unused for long
periods of time.
14. Refer all servicing to service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED PERSONNEL
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated
“ dangerous voltage ” within the
product
’
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is in-
tended to alert the user to the presence of important operat-
ing and maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING: To reduce the risk of or electric shock, do
not expose this apparatus to rain or moisture.
CAUTION: Use of controls or adjustments or performance
of procedures other than those may result in
hazardous radiation exposure.
The apparatus shall not be exposed to dripping or splashingand that no objects with liquids, such as vases,
shall be placed on the apparatus. The MAINS plug is used as thedisconnect device,the disconnect device shall
remain readily operable.
Warning: the user shall not place this apparatus in the area during theoperation so that the mains switch
can be easily accessible.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

2 SMARTMAN 300A / SMARTMAN 700A
English
SYSTEM OVERVIEW
Smartman 300A and 700A share the same connection interface and controls.
LEVEL Knob
Adjust the input level.
PEAK Indicator
This indicator lights when the input signal hits the peak.
Combo Input Connector
This connector accepts both XLR and ¼” phone jack connectors for either balanced or unbalanced
connectors.
LINK OUT
This output XLR connector send out the signal received from input jack and is for chaining another
speaker.
POWER ON Indicator
This indicator lights when the power switch is in the position of “I”.
Power Switch
This switch will turn the Smartman speaker on and off.
AC Power Connector
Connect the included AC power cable to this connector and into a suitable power source allowing
the unit to be powered. This connector also contains the Smartman’s fuse. If the fuse blows, please
replace it with an identical fuse.

3SMARTMAN 300A / SMARTMAN 700A
English
SETUP EXAMPLE
The Smartman series allows for innite expansion of your setup through our active expansion speakers.
Speakers can easily be chained through each unit’s link outputs using balanced cables up to 20 meters long.
Each Smartman is congured to allow this expansion to as many speakers as you need.
Small Venue (Not Exceeding 30M)
Mono System
Larger Venue (Exceeding 30M)
Stereo System
Smartman 303A Smartman 300A
Distance
10M
Additional Speakers Monitoring
PA
Smar
tman 703A
Smartman 700D Smartman 700A
Smartman 700A
Smartman 700A
L
Distance
15M
Distance 30M
Distance
15M
Shorter than
15M
Shorter than
15M
+44.5ms+44.5ms
+44.5ms
Delay Offset
+89ms
Delay Offset
+44.5ms
Smartman 700D Smartman 700A
15M15M
R
Smartman 700A
Distance
15M
Smartman 700A
15M
+44.5ms
+44.5ms
Smar
tman 700D
Distance
15M
Smar
tman 700D
15M
Delay Offset ms
044.589133.5222.5

4 SMARTMAN 300A / SMARTMAN 700A
English
SMARTMAN 300A SMARTMAN 700A
Amplifier Technology Class D Class D (Low Frequency)
Class AB (High Frequency)
Power Output 240 Watt Peak
120 Watt Continuous
1400 Watt Peak
700 Watt Continuous
Woofer 8" 12"
Tweeter 1" 1¾"
Frequency Response 50 Hz to 18 kHz 48 Hz to 20 kHz
Inputs Combo (XLR/¼") Combo (XLR/¼")
Output XLR XLR
Signal Processors N/A N/A
Body Material Polymer Polymer
Handle Top 3 PU Handles
Dimensions (HxWxD) 418 x 292 x 252 mm
(16.5'' x 11.5'' x 9.9'')
635 x 375 x 372.5 mm
(25” x 14.8” x 14.7”)
Net Weight 9.5 kg (21 lbs) 19 kg (41.9 lbs)
SPECIFICATIONS

5SMARTMAN 300A / SMARTMAN 700A
English
SERVICE AND REPAIR
For replacement parts, service and repairs please contact the Phonic distributor in your
country. Phonic does not release service manuals to consumers, and advice users to not
attempt any self repairs, as doing so voids all warranties. You can locate a dealer near you at
http://www.phonic.com/where/.
WARRANTY INFORMATION
Phonic stands behind every product we make with a no-hassles warranty. Warranty coverage
may be extended, depending on your region. Phonic Corporation warrants this product for a
minimum of one year from the original date of purchase against defects in material and
workmanship under use as instructed by the user’s manual. Phonic, at its option, shall repair
or replace the defective unit covered by this warranty. Please retain the dated sales receipt as
evidence of the date of purchase. You will need it for any warranty service. No returns or repairs
will be accepted without a proper RMA number (return merchandise authorization). In order to
keep this warranty in effect, the product must have been handled and used as prescribed in the
instructions accompanying this warranty. Any tampering of the product or attempts of self repair
voids all warranty. This warranty does not cover any damage due to accident, misuse, abuse,
or negligence. This warranty is valid only if the product was purchased new from an authorized
Phonic dealer/distributor. For complete warranty policy information, please visit
http://www.phonic.com/warranty/.
CUSTOMER SERVICE AND TECHNICAL SUPPORT
We encourage you to visit our online help at http://www.phonic.com/support/. There you can find
answers to frequently asked questions, tech tips, driver downloads, returns instruction and other
helpful information. We make every effort to answer your questions within one business day.
FCC Caution: To assure continued compliance, any changes or modifications not expressly
approved by the party responsible for compliance could void the user's authority to operate this
equipment. (Example - use only shielded interface cables when connecting to computer or
peripheral devices).
THIS DEVICE COMPLIES WITH PART 74 OF THE FCC RULES. This equipment complies with
FCC RF radiation exposure limits set forth for an uncontrolled environment.
[email protected]
http://www.phonic.com

Español
6 SMARTMAN 300A / SMARTMAN 700A
INTRODUCCIÓN........................................................................................1
CARACTERÍSTICAS...................................................................................1
RESUMEN DEL SISTEMA......................................................3
EJEMPLO CONFIGURACIÓN......................................................4
ESPECIFICACIONES...............................................................................16
APÉNDICE
DIMENSIONES.................................................................................1
CONTENIDO
MANUAL DEL USUARIO
Phonic se reserva el derecho de mejorar o alterar cualquier información
dentro de este documento, sin previo aviso.

Español
1SMARTMAN 300A / SMARTMAN 700A

Español
2 SMARTMAN 300A / SMARTMAN 700A
INTRODUCCIÓN
Le damos la enhorabuena por la compra de su Smartman
de Phonic, “el altavoz de expansión activo”. El Smartman
utiliza la tecnología de clase D, que proporcionar energía
suciente para toda clase de lugares; grandes y pequeños.
Su elegante envase de polímero, también mejora la
precisión acústica, reduciendo al mínimo la distorsión y
la difracción. Por último, la abilidad y la durabilidad del
Smartman fue uno de los factores principales en todo el
desarrollo.
El altavoz de expansión activo Smartman, está
especialmente diseñado para operar con su propio
sistema de audio integrado Smartman. Encadenando los
altavoces Smartman podrá obtener una capacidad de
expansión de audio innito; para sus sistemas de Audio
(PA).
Los woofers y tweeters han sido exclusivamente
diseñados para el Smartman; Al contrario de muchos
otros fabricantes de altavoces que usan woofers y
tweeters de OEM pre-fabricados, todos los componentes
de Smartman están diseñados exclusivamente por
Phonic.
Todo, desde la pulpa de cono, a la curvatura de la
membrana de titanio del tweeter, a las características
del campo magnético, todo es de Phonic y solo para el
Smartman.
El Woofer del Smartman representa una verdadera punta
de la tecnología; tiene una fuerza BL, y una extensión
de audio que producen graves increíbles, mientras
mantiene una denición de audio casi perfecta, lo cual
ha tradicionalmente sido inalcanzable por los altavoces
con pequeños envases. El tweeter de compresión y la
bocina cónica son las que permiten el sonido cristalino
del Smartman.
CARACTERÍSTICAS
4Sonido remarcable, sorprendente potencia, y el estilo
elegante con envase ligero y duradero
4Tecnología de clase D de alta potencia
4Expansión innita cuando se utiliza el Sistema de
Audio Integrado Smartman
4Montaje en rack de 35mm para mayor alcance de
audiencia
4Envase de polímero resistente con refuerzos internos
4Rejilla de acero de 1,2 mm

Español
3SMARTMAN 300A / SMARTMAN 700A
RESUMEN DEL SISTEMA
Smartman 300A y 700A comparten la misma interfaz y los mismos controles de conexión.
Perillas de Ajuste de Nivel
Ajustan el nivel de entrada.
Indicador de Máximo/pico.
Este indicador se ilumina cuando la señal de entrada alcanza el máximo nivel.
Conector de entrada Combo
Este puerto acepta conectores XLR y Jack de 6.35mm, para las conexiones equilibradas y no
equilibradas.
Salida de Enlace (LINK OUT)
Este conector de salida XLR transmite la señal recibida a otro altavoz. Esta toma sirve para enlazar
otros altavoces.
Indicador de Encendido (POWER ON)
Este indicador se activa, cuando el interruptor de encendido está en la posición “I”.
Interruptor de alimentación
Este interruptor enciende y apaga el altavoz Smartman.
Conector de Alimentación de CA
Conecte el cable de alimentación de CA incluido en este puerto; conecte la otra parte del cable a una
fuente de alimentación adecuada; para que la unidad pueda ser alimentada. Este conector también
contiene un fusible seguridad. Si el fusible se funde, por favor sustituirlo por un fusible idéntico.

Español
4 SMARTMAN 300A / SMARTMAN 700A
EJEMPLO CONFIGURACIÓN
Los altavoces de la serie Smartman, permiten una configuración con posibilidades de expansión infinita; gracias a sus
sistemas de audio de expansión activa. Los altavoces pueden ser fácilmente enlazados con los conectores de salida de
cada unidad, utilizando cables balanceados de hasta 20 metros de largo. Cada Smartman está configurado para permitir
este tipo de expansión.
Ejemplo viable para lugares con pequeños espacios (30 Metros máximo)
Sistema mono
Ejemplo viable para lugares de grandes espacios (30 Metros Mínimo)
Sistema Estéreo
Smartman 303A Smartman 300A
Distancias
10M
Altavozes Adicionales Supervisión
PA
Smar
tman 703A
Smartman 700D Smartman 700A
Smartman 700A
Smartman 700A
L
Distancia
15M
Distancia 30M
Distancia
15M
Mas corto que
15M
Mas corto que
15M
+44.5ms+44.5ms
+44.5ms
Retraso
Compensado
+89ms
Retraso Compensado
+44.5ms
Smartman 700D Smartman 700A
15M15M
R
Smartman 700A
Distancia
15M
Smartman 700A
15M
+44.5ms
+44.5ms
Smartman 700D
Distancia
15M
Smartman 700D
15M
Retraso
Compensado ms
044.589133.5222.5
Smartman 303A Smartman 300A
Distancias
10M
Altavozes Adicionales Supervisión
PA

Español
5SMARTMAN 300A / SMARTMAN 700A
SMARTMAN 300A SMARTMAN 700A
Tecnología de Amplificación Clase D Clase D (Baja Frecuencia)
Clase AB (Alta Frecuencia)
Potencia de Salida 240 Vatios Máximo,
120 Vatios Continuos
1400 Vatios Máximo,
700 Vatios Continuos
Woofer 8 " 12 "
Tweeter 1 " 1¾ "
Respuesta de Frecuencias 50 Hz a 18 kHz 48 Hz a 18 kHz
Entradas Combo (XLR / ¼ ") Combo (XLR / ¼ ")
Salida XLR XLR
Procesadores de Señal N / A N / A
Material de Envase Polímero Polímero
Manejo Parte Superior 3 Asas PU
Dimensiones (HxWxD) 418 x 292 x 252 mm
(16,5 '' x 11,5 '' x 9.9 '')
635 x 375 x 372.5 mm
(25” x 14.8” x 14.7”)
Peso Neto 9.5 kg (21 libras) 19 kg (41.9 lbs)
ESPECIFICACIONES

Español
6 SMARTMAN 300A / SMARTMAN 700A
SERVICIO Y REPARACIÓN
Para refacciones de reemplazo y reparaciones, por favor póngase en contacto con nuestro
distribuidor de Phonic en su país. Phonic no distribuye manuales de servicio directamente a los
consumidores y, avisa a los usuarios que no intenten hacer cualquier reparación por si mismo,
haciendo ésto invalidará todas las garantías del equipo. Puede encontrar un distribuidor cerca
de usted en http://www.phonic.com/where/.
INFORMACIÓN DE LA GARANTIA
Phonic respalda cada producto que hacemos con una garantía sin enredo. La cobertura de
garantía podría ser ampliada dependiendo de su región. Phonic Corporation garantiza este
producto por un mínimo de un año desde la fecha original de su compra, contra defectos en
materiales y mano de obra bajo el uso que se instruya en el manual del usuario. Phonic, a su
propia opinión, reparará o cambiará la unidad defectuosa que se encuentra dentro de esta
garantía. Por favor, guarde los recibos de venta con la fecha de compra como evidencia de la
fecha de compra. Va a necesitar este comprobante para cualquier servicio de garantía. No se
aceptarán reparaciones o devoluciones sin un número RMA apropiado (return merchandise
autorization). En orden de tener esta garantía válida, el producto deberá de haber sido
manejado y utilizado como se describe en las instrucciones que acompañan esta garantía.
Cualquier atentado hacia el producto o cualquier intento de repararlo por usted mismo,
cancelará completamente esta garantía. Esta garantía no cubre daños ocasionados por
accidentes, mal uso, abuso o negligencia. Esta garantía es válida solamente si el producto fue
comprado nuevo de un representante/distribuidor autorizado de Phonic. Para la información
completa acerca de la política de garantía, por favor visite http://www.phonic.com/warranty/.
SERVICIO AL CLIENTE Y SOPORTE TÉCNICO
Le invitamos a que visite nuestro sistema de ayuda en línea en www.phonic.com/support/. Ahí
podrá encontrar respuestas a las preguntas más frecuentes, consejos técnicos, descarga de
drivers, instrucciones de devolución de equipos y más información de mucho interés. Nosotros
haremos todo el esfuerzo para contestar sus preguntas lo antes posible.
FCC Caution: To assure continued compliance, any changes or modifications not expressly
approved by the party responsible for compliance could void the user's authority to operate this
equipment. (Example - use only shielded interface cables when connecting to computer or
peripheral devices).
THIS DEVICE COMPLIES WITH PART 74 OF THE FCC RULES. This equipment complies with
FCC RF radiation exposure limits set forth for an uncontrolled environment.
[email protected]
http://www.phonic.com

Appendix Apéndice
1SMARTMAN 300A / SMARTMAN 700A
DIMENSIONS DIMENSIONES
Measurements are shown in mm/inches
Todas las medidas están mostradas en mm/pulgadas.
292 / 11.5 252 / 9.9
418 / 16.5
553 / 21.8
350 / 13.8 333 / 13.1
375 / 14.8”
372.5 / 14.7”
635 / 25”
292 / 11.5 252 / 9.9
418 / 16.5
553 / 21.8
350 / 13.8 333 / 13.1
375 / 14.8”
372.5 / 14.7”
635 / 25”
SMARTMAN 300A
SMARTMAN 700A
