PXI Multi-Banked Multiplexer 40-657A
ISSUE 1.0 FEB 2019
• High Density 2 Amp Multiplexer
• 8-Banks of 8-Chan, 4-Banks of 16, 2-Banks of 32 &
Single 64-Chan Multiplexer
• 1-Pole Switching
• 2A Current Rating With 90W/500VA Max Power
• Hot Switch to 110VDC/250VAC
• Cold Switch to 400VDC/250VAC
• VISA, IVI & Kernel Drivers Supplied for Windows
• Supported by PXI or LXI Chassis
• 3 Year Warranty
The 40-657A is a high density power multiplexer modules available
in a choice of congurations with up to 8 separate multiplexers
with 1-pole switching. They are suitable for switching signals to
110VDC/250VAC at 2 Amps, 90W.
40-657A Multi-Banked Multiplexer Range:
8-Bank, 8-Channel, 1-pole
4-Bank, 16-Channel, 1-pole
2-Bank, 32-Channel, 1-pole
1-Bank, 64-Channel, 1-pole
Larger multiplexers may be constructed by daisy chaining the
common signals from multiple modules. For example 7 modules
with 64-channels will form a 448-channel multiplexer.
The 40-657A can be operated as a conventional multiplexer
with break-before-make action when a new channel is selected.
Alternatively, product variants can be supplied that allow multiple
channels to be simultaneously selected.
The 40-657A channel selection congurations have been revised
from the 40-657. The 40-657A modules default to single channel
selection with multiple channel selection variants dened by use of
a sufx.
We can construct custom cable assemblies for all of our PXI
modules, please contact sales ofce for further assistance.
8-Bank, 8-Channel Multiplexer (40-657A-001-8/8/1)
Com
1
4
5
8
2
3
6
7
BANK 1
Com
1
4
5
8
2
3
6
7
BANK 2
Com
1
4
5
8
2
3
6
7
BANK 3
Com
1
4
5
8
2
3
6
7
BANK 4
Com
1
4
5
8
2
3
6
7
BANK 5
Com
1
4
5
8
2
3
6
7
BANK 6
Com
1
4
5
8
2
3
6
7
BANK 7
Com
1
4
5
8
2
3
6
7
BANK 8

2A Multi-Banked MUX – 40-657A
pickeringtest.com
Overview
4-Bank, 16-Channel Multiplexer (40-657A-001-4/16/1)
Com
1
4
5
16
2
3
6
7
BANK 1
8
9
10
11
12
13
14
15
Com
1
4
5
16
2
3
6
7
BANK 2
8
9
10
11
12
13
14
15
Com
1
4
5
16
2
3
6
7
BANK 3
8
9
10
11
12
13
14
15
Com
1
4
5
16
2
3
6
7
BANK 4
8
9
10
11
12
13
14
15
Com
1
4
5
32
2
3
6
7
BANK 1
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Com
1
4
5
32
2
3
6
7
BANK 2
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Com
1
4
5
64
2
3
6
7
BANK 1
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
2-Bank, 32-Channel Multiplexer (40-657A-001-2/32/1)
1-Bank, 64-Channel Multiplexer
(40-657A-001-1/64/1)

2A Multi-Banked MUX – 40-657A
pickeringtest.com
Specifications
Switching Specification
Contact Type: Gold clad silver alloy
Cold Switching Capacity
Maximum Current:
Maximum Voltage:
2A
400VDC/250VAC*
Hot Switching Capacity
Maximum Current:
Maximum Voltage:
Maximum Power: †
Minimum Switching Capacity:
2A
110VDC/250VAC*
90W/500VA
10mA, 5VDC
Initial On Path Resistance:
Off Path Resistance:
Thermal Offset:
<250mΩ
>109Ω
<20µV
Bandwidth: >20MHz
Operate Time: 21ms typical,
10.5ms for multichannel mode
Expected Life
Mechanical Life:
At Max. Switch Capacity:
>2x107operations
>1x105operations
* For full voltage rating, signal sources to be switched must be fully
isolated from mains supply and safety earth.
† For variation of maximum hot switching capacity of voltage with
current refer to plot.
Power Requirements
+3.3V +5V +12V -12V
0 1.7A†(typ 400mA) 0 0
† with all 64 relays operated
Operating/Storage Conditions
Operating Conditions
Operating Temperature:
Humidity:
Altitude:
0°C to +55°C
Up to 90% non-condensing
5000m
Storage and Transport Conditions
Storage Temperature:
Humidity:
Altitude:
-20°C to +75°C
Up to 90% non-condensing
15000m
PXI & CompactPCI Compliance
The module is compliant with the PXI Specication 2.2. Local Bus,
Trigger Bus and Star Trigger are not implemented.
Uses a 33MHz 32-bit backplane interface.
Safety & CE Compliance
All modules are fully CE compliant and meet applicable EU
directives: Low-voltage safety EN61010-1:2010, EMC Immunity
EN61326-1:2013, Emissions EN55011:2009+A1:2010.
Mechanical Characteristics
Single slot 3U PXI (CompactPCI card).
3D models for all versions in a variety of popular le formats are
available on request.
Connectors
PXI bus via 32-bit P1/J1 backplane connector.
Signals via front panel 78-pin male D-type connector, for pin outs
please refer to the operating manual.
Relay Type
The 40-657A modules are tted with electro-mechanical power
relays, gold clad silver alloy. A spare relay is built onto the circuit
board to allow easy maintenance with minimum downtime.
40-657A Current/Operating Life Plot
40-657A Current/Voltage Plot
AC Resisve
DC Resisve
125VAC Resisve
30VDC Resisve
250VAC Resisve

2A Multi-Banked MUX – 40-657A
pickeringtest.com
Ordering Information
Support Products
Spare Relay Kits
Kits of replacement relays are available for the majority of
Pickering’s PXI switching products, simplifying servicing and
reducing down-time.
Product Relay Kit
40-657A-001 91-100-020 (Relay Kit 20)
For further assistance, please contact your local Pickering sales
ofce.
Mating Connectors & Cabling
For connection accessories for the 40-657A modules please
refer to the 90-006D 78-pin D-type Connector Accessories data
sheet where a complete list and documentation can be found for
accessories, or refer to the Connection Solutions catalog.
Product Order Codes - Multiplexer
Channel
Selection Model Variant Order Code
Single
Single
Single
Single
8-Bank 8-Channel 1-Pole
4-Bank 16-Channel 1-Pole
2-Bank 32-Channel 1-Pole
1-Bank 64-Channel 1-Pole
40-657A-001-8/8/1
40-657A-001-4/16/1
40-657A-001-2/32/1
40-657A-001-1/64/1
Note: The above modules are available in multiple channel
selection mode by adding the “-M” sufx to the part number.
For example, the 8-bank, 8-channel 1-pole MUX with multiple
channel capability would be: 40-657A-001-8/8/1-M
Product Customization
Pickering PXI modules are designed and manufactured on our own
exible manufacturing lines, giving complete product control and
enabling simple customization to meet very specic requirements.
Customization can include:
• Alternative relay types
• Mixture of relay types
• Alternative number of relays
• Different performance specications
All customized products are given a unique part number, fully
documented and may be ordered at any time in the future. Please
contact your local sales ofce to discuss.

2A Multi-Banked MUX – 40-657A
pickeringtest.com
Supporting Products & Software
We also offer customized cabling and have a free online Cable Design Tool that can
be used to create custom cable solutions for many applications.
Visit: pickeringtest.com/cdt to start your design.
Mass Interconnect
We recommend the use of a mass interconnect solution when an Interchangeable
Test Adapter (ITA) is required for a PXI or LXI based test system. Our modules are
fully supported by both Virginia Panel and MacPanel.
Pickering Reed Relays
We are the only switch provider with in-house reed relay manufacturing capability
via our sister company, Pickering Electronics. These instrument grade reed relays
feature SoftCenter® technology, ensuring long service life and repeatable contact
performance
To learn more, please go to: pickeringrelay.com
Chassis Compatibility
This PXI module must be used in a suitable chassis. It is compatible with the following chassis types:
• All chassis conforming to the 3U PXI and 3U Compact PCI (cPCI) specication
• Legacy and Hybrid Peripheral slots in a 3U PXI Express (PXIe) chassis
• Pickering Interfaces LXI or LXI/USB Modular Chassis
Chassis Selection Guide
Standard PXI or hybrid PXIe Chassis from any Vendor:
• Mix our 1000+ PXI switching & simulation modules with any
vendor’s PXI instrumentation
• Embedded or remote Windows PC control
• Real-time Operating System Support
• High data bandwidths, especially with PXI Express
• Integrated module timing and synchronization
Pickering LXI or LXI/USB Modular Chassis—only accept
our 1000+ PXI Switching & Simulation Modules:
• Ethernet or USB control enables remote operation
• Low-cost control from practically any controller
• LXI provides manual control via Web browsers
• Driverless software support
• Power sequencing immunity
• Ethernet provides chassis/controller voltage isolation
• Independence from Windows operating system
Connectivity Solutions
We provide a full range of supporting cable and connector solutions for all our switching products—20 connector families with 1200+
products. We offer everything from simple mating connectors to complex cables assemblies and terminal blocks. All assemblies are
manufactured by Pickering and are guaranteed to mechanically and electrically mate to our modules.
Connectors & Backshells Multiway Cable Assemblies RF Cable Assemblies Connector Blocks

2A Multi-Banked MUX – 40-657A
pickeringtest.com
Supporting Products & Software
© Copyright (2019) Pickering Interfaces. All Rights Reserved Pickering Interfaces maintains a commitment to continuous product development, consequently we reserve the right to vary from the description given in this data sheet.
Programming
Pickering provide kernel, IVI and VISA (NI & Keysight) drivers which are compatible with all Microsoft supported versions of Windows and
popular older versions. For a list of all supporting operating systems, please see: pickeringtest.com/os
The VISA driver is also compatible with Real-Time Operating Systems such as LabVIEW RT. For other RTOS support contact Pickering.
These drivers may be used with a variety of programming environments and applications including:
• Pickering Interfaces Switch Path Manager
• National Instruments products (LabVIEW, LabWindows/CVI, Switch Executive, MAX, TestStand, VeriStand, etc.)
• Microsoft Visual Studio products (Visual Basic, Visual C+)
• Keysight VEE
• Mathworks Matlab
• Marvin ATEasy
• MTQ Testsolutions Tecap Test & Measurement Suite
Drivers for popular Linux distributions are available, other environments are also supported, please contact Pickering with specic enquiries.
We provide Soft Front Panels (SFPs) for our products for familiarity and manual control, as well as comprehensive documentation and
example programs to help you develop test routines with ease.
To learn more about software drivers and development environments, please go to: pickeringtest.com/software
Signal Routing Software
Our signal routing software, Switch Path Manager, automatically selects and energizes switch
paths through Pickering switching systems. Signal routing is performed by simply dening
test system endpoints to be connected together, greatly accelerating Test System software
development.
To learn more, please go to: pickeringtest.com/spm
Diagnostic Relay Test Tools
eBIRST Switching System Test Tools are designed specically for our PXI, PCI or LXI
products, these tools simplify switching system fault-nding by quickly testing the system
and graphically identifying the faulty relay.
To learn more, please go to: pickeringtest.com/ebirst
Three Year Warranty & Guaranteed Long-Term Support
All standard products manufactured by Pickering Interfaces are warranted against
defective materials and workmanship for a period of three years from the date of delivery
to the original purchaser. Extended warranty and service agreements are available for all our modules and systems with various levels to
suit your requirements. Although we offer a 3-year warranty as standard, we also include guaranteed long-term support—with a history of
supporting our products for typically 15-20 years. To learn more, please go to: pickeringtest.com/support
Available Product Resources
We have a large library of product resources including success stories, product and support videos, articles, as well as complete product
catalogs and product reference maps to assist when looking for the switching, simulation and cable and connector solutions you need.
We have also published handy reference books for the PXI and LXI standards.
To view, download or request any of our product resources, please visit: pickeringtest.com/resources
