Pico Macom PFR-2 User manual

1
6260 Sequence Drive San Diego, CA 92121
Ph: 858-546-5050 Toll Free: 800-421-6511 Fax: [phone]
www.picomacom.com
Fiber Optic Series PICO MACOM
Rev. 9/07
The Pico Macom models PFR-2 and PFR-4 professional series fiber optic receivers take an optical source from a forward trans-
mitter in the frequency range of 54~860MHz and convert to RF signals. The PFR series has one optical input and is available
in two and four-output versions. Employing state-of-the-art GaAs amplifier design, the PFR-2 and PFR-4 operate at a low
optical window with improved composite distortion performance. These optical receivers utilize a new low noise, impedance
matched, high efficiency 1310/1550nm broadband photodiode and advanced RF amplification circuitry to facilitate carriage of
critical upstream video, data, telephony and Internet traffic in an HFC broadband environment.
PFRSeries Optical Forward Receivers
•Available in 2 and 4 RF output configurations.
•Optical power monitoring.
•54~860MHz bandwidth allows operation for current and
future CATV broadband services.
•Operates at a high 45dBmV RF output at an optical
wavelength of 1310/1550nm, providing excellent C/N ratio.
•-20dB RF test point for convenient RF system monitoring.
•Low power consumption.
•Wide optical window -3dBm to 3dBm for improved system
performance.
•Adjustable equalization.
Features

PICO MACOM Fiber Optic Series
6260 Sequence Drive San Diego, CA 92121
Ph: 858-546-5050 Toll Free: 800-421-6511 Fax: [phone]
Rev. 9/07 www.picomacom.com
2
Optical Wavelength: 1290nm/1600nm
Optical Input Range: -3dBm to 3dBm
Optical Connector Type: SC/APC
(FC/APC Optional)
RF Frequency Range: 50~860MHz
RF Output Level: 45 dBmV
RF Output Impedance: 75Ω
RF Flatness: ±1dB
Output Return Loss: ≥15dB
Carrier-to-Noise Ratio (CNR)*: ≥50dB
Composite Second Order (CSO): ≥60dB
Composite Triple Beat (CTB)*: ≤65dB
Power Consumption (typical): 30 watts
Operating Temperature: 0~50°C
Storage Temperature: -20~+65°C
Relative Humidity: <10%
Dimensions: 19˝W x 13˝D x 1RU
Weight: 7.50 lbs PFR-2
8.15 lbs PFR-4
90-264 VAC
47-63
RF OUT 2
LOC IN
RF OUT 1
FUSE
FUSE
FUSE
ON/OFF
FUSE
POWER -5dBm -3dBm -2dBm -1dBm 0dBm 2dBm
OPTICAL POWER DISPLAY
VAR EQL VAR ATT
CATV ROOM OPTICAL RECEIVER
Specifications
PFR-2 Single Optical Input Dual RF Output Forward Receiver
PFR-4 Single Optical Input Quad RF Output Forward Receiver
90-264 VAC
47-63
RF OUT 2
LOC IN
RF OUT 1
FUSE
FUSE
FUSE
ON/OFF
FUSE
POWER -5dBm -3dBm -2dBm -1dBm 0dBm 2dBm
OPTICAL POWER DISPLAY
VAR EQL VAR ATT
CATV ROOM OPTICAL RECEIVER
Rear View of PFR-2
Front View
Ordering Information
* Test results are typical and were performed at our San Diego test center
