2BIP-100 Manual
Content
Descriptions for safety and warnings 3
I. About the Product 4
Features of the terminal 4
How to install the product 5
Checking components 6
Names and descriptions of each part 7
Front part of the product and stylus pen image
Rear part of the product
Basic specifications 10
Telecommunication specifications 11
II. Learning basic installation methods 12
Connecting each line 12
Turning on/off the power 13
Using the stylus pen 13
Inserting roll paper 14
Inserting USIM card/MSAM card 15
Reading a smart card 16
Reading a magnetic card 16
III. Appendix 17
Q & A 17
Customer care center 17
Indicated authentication details 18
BIP-100 Manual-��(1016).indd 2 2008-10-16 ¿ÀÈÄ 4:53:06

3
BIP-100
1
Basic cautions
•If the terminal or the adapter gets wet, DO NOT put it into a microwave oven to
dry/heat the device. (If it gets wet, the label on the product is discolored and, in this
case, we will not offer guarantee for the product.)
•Use a specified pure product for adapter. DO NOT use the adapter for other uses than
our terminal use. (Otherwise, the adapter may be exploded or the lifespan of the
adapter may be shortened.)
•Insert and fix the adapter firmly. If the product shows abnormalities including smoke,
bad smell or noise, turn the power off as soon as possible and pull the plug out of the
outlet. In addition, in case of thunder/lightning, separate the adapter out of the outlet.
※This terminal is composed of precise electric and electronic parts.
※The descriptions given below aim at helping you use the product safely and
appropriately to prevent accidents and/or dangerous situations from occurring,
and so, we hope you will follow them in any case.
※This terminal is certified as suitable for standards to protect human bodies against
electromagnetic waves. For users’ health and safety, we advise you to use genuine
products provided by our headquarters. Otherwise, we are not liable for your safety.
•Please read electromagnetic wave-related information on the product. This product
sends/receives high frequency energy (RF energy) while it is turned on. Ministry of
Information and Communication made laws safety standards for the energy affecting
human bodies and this product complies with the standard. (If you do not use pure
products, we do not guarantee users’ safety against electromagnetic wave.)
•DO NOT put credit cards, bankbooks, passenger tickets and other objects using
magnetism near the terminal. If not, magnetism of the terminal may do harm to data
on the objects.
•Data may be damaged due to users’ negligence or repairing of the product. In either
case, the manufacturer is not liable for the data loss. Given this, please record/save
important data separately.
•In case of malfunctions, DO NOT reproduce, disassemble or repair the product as you
like; contact our customer care center.
•DO NOT dye/paint the terminal; it may cause marred appearance or screen or
malfunctions of the product.
•Install the product on a shady and flat site; the product may be exploded in case it is
being exposed to direct sun rays for a long time.
•If the product is used in high-temperature/high-humidity environments for a long time,
it may cause product errors.
•If you use awls, nails, ball-point pens or other sharp objects instead of the stylus pen, it
will hurt the LCD screen.
•This wireless device may cause propagation interference, and so, it cannot be involved
with life-saving services.
2
Cautions for telephone use and product cautions
3
Others
Descriptions for safety and warnings
BIP-100 Manual-��(1016).indd 3 2008-10-16 ¿ÀÈÄ 4:53:06

4BIP-100 Manual
•The terminal enables you to make settlement with all and every card including IC card.
•With enriched 260 thousand colors, bigger-sized 3.5-inch screen and support of
touch-sensitive screen function, the terminal enables you to enjoy various functions
including settlement programs.
•With powerful printing supportive of up to 90mm/sec printing speed, faster than other
products, the product enables you to reduce printing time.
•In support of Windows CE, the product can be equipped with software programs
appropriate for corporate environments.
•Through voice services, you can safely check how a settlement is going on.
•As the product can support a variety of wired/wireless functions including WLAN,
Ethernet, PSTN, GSM and CDMA, you can make settlement in a fast and consecutive
way.
•As the product can be equipped with an internal battery, it can be used in case of
power blackout, stoppage or other emergencies.
•With easy-to-use methods, any one unfamiliar with the product can easily install and
use the product.
•With wide scalability, the product can work together with various peripherals.
I. About the Product
1Features of the terminal
BIP-100 Manual-��(1016).indd 4 2008-10-16 ¿ÀÈÄ 4:53:06

5
BIP-100
Install the terminal as described below:
1For easy use, put the terminal on a flat and safe
place to avoid drop and shock.
2Connect the AC adapter with the power port
seen at the rear part of the terminal.
3When you use phone line and Ethernet, connect
the phone cable with the Line port.
4Open the printer cover at the front of the
terminal and insert roll paper.
(For details, see page 14.)
5Turn on the power switch at the left of the
terminal and set communication before use.
2How to install the product
BIP-100 Manual-��(1016).indd 5 2008-10-16 ¿ÀÈÄ 4:53:06

6BIP-100 Manual
3Checking components
I. About the Product
Before use the product, please check if all of the components are provided.
Main body of BIP-100 Stylus pen Roll paper User’s manual
Telephone cable USB cable USB host cable
Serial converter cable Key protection pad BIP-110
※Depending on buyers’ requests, the components may vary.
※For products available for telephone communication, a telephone line cable is
provided.
※Images of the components may be different from actual components.
※To buy supplementary or optional products, please contact our customer care center.
Options (Not provided with the product)
LCD protection film Power cable AC adapter
BIP-100 Manual-��(1016).indd 6 2008-10-16 ¿ÀÈÄ 4:53:07

7
BIP-100
1Printer Prints usage details of a credit card on roll paper when the credit
card is used and the use is approved.
2Speaker Notifies progress of the operation of the product.
3Power switch Turns on/off the product.
4LED for charging
display
Shows battery status of the product. (The LED for charging display
shows charging status only in products with a battery.)
5LED for communication
display Shows connection status for communication of the product.
6Touch screen Enables you to select a menu using a stylus pen.
7Numeric/character
buttons Enables you to enter numbers or characters.
8Smart Card reader Reads the smart card of a debit/credit card.
9Magnetic card reader Reads the magnetic card from the top to the bottom.
0Printer open/close
button Use this button to open/close the printer cover.
!Exit/edit/enter button Enables you to exit, edit or enter current operation.
@Function buttons Sets product functions.
#Stylus pen Enables you to select a menu from the LCD touch-sensitive screen.
Front part of the product and stylus pen image
※Depending on buyers’ requests, the key pad part may vary.
1
2
3
4
5
7
8
9
0
!
@
6
#
4Names and descriptions of each part
BIP-100 Manual-��(1016).indd 7 2008-10-16 ¿ÀÈÄ 4:53:07

8BIP-100 Manual
Classification Status
LED 1 LED 2
Charging status display Communication display
Green/Orange Blue
Charging status
Being in charge Orange light is lit. -
Fully charged Green light is lit. -
Wireless
telecommunication
CDMA
In calling status - Blue light is lit.
Call available area - Blue light blinks slowly.
Call connection
error occurs. - -
GSM
In calling status - Blue light is lit.
Call available area - Blue light blinks slowly.
Call connection
error occurs. - Blue light blinks fast.
< LED Indications >
I. About the Product
BIP-100 Manual-��(1016).indd 8 2008-10-16 ¿ÀÈÄ 4:53:07

9
BIP-100
1Power Enables you to connect the AC adapter.
2Line (option) Works for PSTN and enables the terminal to be connected with the
outlet for telephone use.
3Phone (option) Enables the terminal to be connected with the phone.
4PS-232 I/II Enables connection with such peripherals as RFID, Barcode Scanner and
dongle (BIP-110).
5USB-C Works as client to send data for PC, POS and others.
6USB-H Works as host to receive data for memory stick, sign pad and others.
7Ethernet (option) Enables connection through IT network (LAN).
8Cover Slot cover for USIM Card and SAM Card.
9Fixing screw Fixes the cover to open/close status.
Rear part of the product
※option : Depending on buyers’ requests, the components may vary.
< Connection specifications for PS-232 >
No.1(Left) 2 3 4 5 6
SERIAL-1
TURE-232 GND GND RXD TXD (From bip-100) 5V/500mA 9V/300mA
SERIAL-2
TURE-232 GND GND RXD TXD (From bip-100) 5V/500mA 9V/300mA
1
2
3
4
5
6
7
8
9
BIP-100 Manual-��(1016).indd 9 2008-10-16 ¿ÀÈÄ 4:53:07

10 BIP-100 Manual
Classification Specifications
CPU ARM920T Core, 200MHz Max, Clock Rate
OS Windows CE 5.0
Memory • RAM : 64MB
• ROM : 64MB
Display 3.5”TFT LCD, 240 × 320 Pixel
Communication
• GSM / GPRS: 900 / 1800MHz, 850 / 1900MHz or
CDMA2000 1X
• WLAN (Option) : IEEE 802.11b/g, Ethernet (Option),
PSTN (Option) : 56,000bps
Interface Serial × 2, USB Host × 1, Client × 1
SAM Slot × 3, SIM Slot × 1
CONTACT SMART CARD
READER ISO7816, EMV2000 Level 1, 2 certified
MAGNETIC STRIPE
READER ISO7810, Track 1/2/3, JIS Option
Printer 2” Thermal Printer, 50Pie
Input Keypad: 10 Numeric Buttons, 12Function Buttons,
1Power Switch, Touch screen
LED • Power Charger (left) : 1EA
• Communication (right) : 1EA
AUDIO Speaker (Mono)
POWER External Power Adapter, 9V 3A 1380mAH Battery (Optional)
OPERATING
TEMPERATURE -20℃~ 55℃
HUMIDITY 93% non-considering
DIMENSION (W × H × D) 131mm × 62.2mm × 250.7mm
5Basic specifications
I. About the Product
BIP-100 Manual-��(1016).indd 10 2008-10-16 ¿ÀÈÄ 4:53:07

11
BIP-100
Classification Specifications
CDMA
•Used frequency : Tx 824.64~848.37; Rx 869.64~893.37MHz
•Power for antenna : 280mW (+20% ~ -50%)
•Modulation method : G7W
GSM
•Dual Band (850/1900MHz) / (900/1800MHz)
- GSM 850 (Tx : 824.20 ~ 848.80MHz, Rx : 869.20 ~ 893.80)
DCS 1900 (Tx : 1850.20 ~ 1909.80MHz, Rx : 1930.20 ~ 1989.80MHz)
- DCS 900 (Tx : 880.20 ~ 914.80MHz, Rx : 925.20 ~ 959.80MHz)
PCS 1800 (Tx : 1720.20 ~ 1784.80MHz, Rx : 1805.20 ~ 1879.80MHz)
•GPRS Multislot Class 12, Class B
•Tx output (Max) – GSM850 / GSM900 ( 2W )
- DCS / PCS ( 1W )
•Modulation method: 0.3GMSK
WLAN
•Used frequency : 2,412MHz ~ 2,472MHz
•Number of channels : 13
•Power for antenna : 25mW or less
•Modulation method : G1D, D2D
6Telecommunication specifications
BIP-100 Manual-��(1016).indd 11 2008-10-16 ¿ÀÈÄ 4:53:07

12 BIP-100 Manual
When you use the communication port for the terminal and the telephone
(Phone port), either of the terminal and the telephone is not available if the
terminal or the telephone is used.
In addition, if you pick up the phone or press a number while the terminal is
used, data error may occur on the terminal.
Connect each line in the right position as seen in the following figures; otherwise, the
product may be damaged.
Connect through IT network (LAN) (Option).
Connect through memory stick and sign pad.
Connect through PC and POS.
Connect through RFID, Barcode Scanner and
dongle (BIP-110).
Connect through a telephone cable (Option).
Connect through an outlet for telephone (Option).
Connect through the AC adapter.
II. Learning basic installation methods
1Connecting each line
BIP-100 Manual-��(1016).indd 12 2008-10-16 ¿ÀÈÄ 4:53:08

13
BIP-100
Press the power button seen at the left of the product to turn on/off the power.
In initial booting, it takes around 45~50 seconds for program setting.
Power button
The stylus pen is an input device to let you select, execute or move an object from the LCD
screen in touch-sensitive method.
If you use ball-point pens, pins, awls or other sharp tools instead of a dedicated
stylus pen, it may hurt the LCD screen.
•Press the stylus pen (Tab)
Enables you to touch an icon from the screen with the stylus pen one time to
select or execute an item.
•Drag the stylus pen (Drag)
Enables you to select multiple items at one time; this function lets you select
characters or images.
•Press and hold the stylus pen (Tap and hold)
Enables you to look at functions for a corresponding item; when you press
the screen with the stylus pen, related pop-up menu appears.
2Turning on/off the power
3Using the stylus pen
BIP-100 Manual-��(1016).indd 13 2008-10-16 ¿ÀÈÄ 4:53:08

14 BIP-100 Manual
1Press the Printer open/close button to hold up
and open the printer cover.
2Insert roll paper into the groove.
(If you completely push the cover backward,
the roll paper may be caught. Given this,
insert the paper with the cover softly pulled
forward.)
3Softly pull out the starting point of the roll
paper from the terminal.
4Press and close the printer cover.
As seen in the figures below, replace roll paper of the terminal appropriately.
•To prevent damage, you need to use dedicated roll paper
(57(Width)×50(Diameter)×12(Paper bobbin length)mm) complying with the
standard suitable for the printer.
•In replacing roll paper, you need to cut the power of the terminal.
4Inserting roll paper
II. Learning basic installation methods
BIP-100 Manual-��(1016).indd 14 2008-10-16 ¿ÀÈÄ 4:53:08

15
BIP-100
1With a coin, turn the two screws at each lower
part of the back of the terminal to open the
case.
2Put the cover upward and separate it from the
body.
3Insert USIM card/MSAM card.
(For a reference, USIM card is inserted into the
first position; MSAM card can be inserted into
one of the second ~ fourth position.)
4Close the cover to fix it to the groove and turn
the screws back to lock the cover.
As seen in the figures below, insert USIM card/MSAM card appropriately.
What is USIM card?
This card is a combination of SIM card with subscriber information and UICC
(Universal IC Card); with this card, users can put, into one card, various functions
of authentication, global roaming and e-trade.
What is MSAM card?
This card is a complementary application module inserted into a smart card;
inserted into a card reader, this card authenticates validity of cards and terminals,
makes encryption of communication data to prevent information from being
leaked and authenticates and verifies communication messages.
5Inserting USIM card/MSAM card
BIP-100 Manual-��(1016).indd 15 2008-10-16 ¿ÀÈÄ 4:53:09

16 BIP-100 Manual
Turn the front part of a debit/credit card to the left direction and insert the card into the
smart card reader to use it.
You can ask for settlement only with a debit/credit card with integrated circuits.
Turn the front part of a debit/credit card to the left direction to put the magnetic line
downward. Insert the card into the magnetic card reader and pull it slowly downward.
6Reading a smart card
7Reading a magnetic card
II. Learning basic installation methods
BIP-100 Manual-��(1016).indd 16 2008-10-16 ¿ÀÈÄ 4:53:09

17
BIP-100
Q. The terminal gets wet. What can I do?
A. If the terminal doesn’t work after it is dried for a certain time, its main board and other
parts should be replaced. In this case, contact the customer care center.
Q. The terminal fails to boot.
A. Check if all of the lines are appropriately connected. If the problem continues, it may
be caused from a damaged program. Then, contact the customer care center.
Q. How can I ask for after-sales service?
A. All you need to do is send the product to our customer care center (Headquarters)
through express courier service. The delivery service fee should be pre-paid. When the
product is repaired, it will be sent once the repairing fee is paid in the headquarters.
Q. Can I check if the terminal is sent accurately?
A.Our customer care center (Headquarters) lets you know the number of the transport
paper. Otherwise, you can ask related delivery company about it.
Before asking for after-sales service
Before requesting after-sales service, the user needs to back up data in the device in
person.
We do not back up data for any of products received to our customer care center.
Therefore, we are not liable for loss/deletion of data, in any case.
Customer care center of Bluebird Soft Inc.
•Fax : [phone]
•E-Mail : [email protected]
•Address : Customer care center, 2nd floor, room 558-8, Sinsa-dong, Gangnam-gu, Seoul
•Business Day
Monday though Friday 9 AM ~ 6 PM
We do not work on Sundays and holidays.
How to ask for after-sales service
•For after-sales service, please contact your local dealer or our customer care center.
•Do not remove the label of the product on purpose.
•Make sure to deliver the product in a safe way. Bluebird Soft is not liable for device loss
during delivery.
III. Appendix
1
Q & A
2Customer care center
BIP-100 Manual-��(1016).indd 17 2008-10-16 ¿ÀÈÄ 4:53:09

18 BIP-100 Manual
•Authenticator’s name : Bluebird Soft Inc.
•Device name :
•Model name : BIP-100
•Manufacturing date :
•Manufacturer/country : Bluebird Soft Inc./Korea
•Authenticator’s identification No. : BBS
3Indicated authentication details
III. Appendix
BIP-100 Manual-��(1016).indd 18 2008-10-16 ¿ÀÈÄ 4:53:09
