Pilot Communications PBAT-61 User manual

PBAT-61 Cell Sensor
Installation & Operation Manual
V1.0
PILOT (HENGQIN) CO., LTD.
珠海横琴派诺技术有限公司

Danger and warning!
This device can be installed only by professionals.
The manufacturer shall not be held responsible for any accident caused by the
failure to comply with the instructions in this manual.
Risks of electric shocks, burning, or explosion
This device can be installed and maintained only by qualified people.
Before operating the device, isolate the voltage input and power supply and
short-circuit the secondary windings of all current transformers.
Use appropriate voltage tester to make sure the voltage has been cut-off.
Put all mechanical parts, doors, or covers in their original positions before
energizing the device.
Always supply the device with the correct working voltage during its operation.
Failure to take these preventive measures could cause damage to equipment or
injuries to people.

Contents
Chapter 1 Product Overview.................................................................................................... 1
Chapter 2 Installation and Wiring............................................................................................ 2
2.1 Environment.................................................................................................................. 2
2.2 Order Information......................................................................................................... 5
2.3 Power Supply ............................................................................................................... 7
2.4 Wiring............................................................................................................................. 7
Chapter 3 Measuring Parameters........................................................................................... 8
3.1 Voltage........................................................................................................................... 8
3.2 Internal resistance....................................................................................................... 8
3.2 Negative pole temperature........................................................................................ 8
Chapter 4 Accessibility Features............................................................................................. 9
4.1 Communication............................................................................................................ 9
4.2 Dormancy...................................................................................................................... 9
Chapter 5 Indicate Light Description...................................................................................... 9
Chapter 6 Maintenance and Trouble shooting...................................................................10
Chapter 7 Technical Specifications.......................................................................................11

1
Chapter 1 Product Overview
PBAT61 battery cell sensor is specially designed as highly integrated smart
sensor module for VRLA batteries, can quickly and accurately measure the
VRLA’s voltage, resistance and negative pole temperature. Cell sensors use
specified isolated communication bus, and multiple sensors can be very easily
cascaded to realize the real-time monitoring of the entire strings of batteries.
The cell sensor can fulfill following functions:
Measurement of real-time voltage
Measurement of Internal resistance on line
Measurement of negative pole temperature
Sleep mode to achieve ultra-low standby power consumption
Built-in anti-reverse in put circuit aims to protect the sensor and
battery away from damage even if the power supply is connected
conversely.
Built-in fuse with high reliability and safety
Communication interface’s isolation voltage is AC 3750V
Wiring easily with distributed installation
One PBAT-Gate can support up to 240 cell sensors by cascade
Passive balancing function, the balancing current up to 200mA

2
Chapter 2 Installation and Wiring
2.1 Environment
2.1.1 Environmental requirements
◇Standard operating temperature：0℃～+45℃
◇Operating temperature limit：-10℃~ +55℃
◇Storage temperature：-40℃～+70℃
◇Working humidity：5% ～95%RH，Non-condensing
2.1.2 Installation and Dimensions
（1）Dimensions Unit：mm
（2）Structure and Terminals Unit：mm

3
Note: wire length 30cm
2.1.3 The main terminal definitions
NO
Symbol
Definition
1
V- Bat
Negative power supply, connected directly with the
battery negative pole.
2
V- Sensea
Measuring input of the voltage, connected directly with
the battery negative pole. It contacts with V-Bat.
3
PTC
Temperature sensor input
4
PTC
Temperature sensor input
5
V+ Sensea
Measuring input of the voltage, connected directly with
the battery positive pole. It contacts with V+ Bat.

4
6
V+ Bat
Positive power supply, connected directly with the
battery positive pole.
7
COM1b
DL-BUS communication，RJ11 interface
8
COM2b
DL-BUS communication，RJ11 interface
Note:
a. The cell sensor uses four-line method to measure the internal
resistance of VRLA.‘V+ Sense’ and ‘V- Sense’ need to be connected
directly with the battery pole. In order to obtain proper measurement
accuracy described in this document, the users should use the
standard factory wire especially for measurement.
b. COM1 connect to the previous node, COM2 connect to the next
node.

5
2.2 Order Information
Model：PBAT61
PBAT61-02
For 2V battery
Real-time cell voltage
measurement
Internal resistance
measurement on line
Negative pole temperature
measurement
DL-BUS Communication
PBAT61-12
For 12V battery
Real-time cell voltage
measurement
Internal resistance
measurement on line
Negative pole temperature
measurement
DL-BUS Communication
PBAT61-02-B
For 2V battery
Real-time cell voltage
measurement
Internal resistance
measurement on line
Negative pole temperature
measurement
DL-BUS Communication
Balancing function

6
PBAT61-02-B
For 12V battery
Real-time cell voltage
measurement
Internal resistance
measurement on line
Negative pole temperature
measurement
DL-BUS Communication
Balancing function

7
2.3 Power Supply
PBAT61-2 is supplied by the battery with the range from DC 1.6~2.6V,
Power loss when working is less than＜200mW, and power loss when
dormancy is less than＜12mW.
PBAT61-12 is supplied by the battery with the range from DC 7.5~15.6V ,
Power loss when working is less than＜125mW, and power loss when
dormancy is less than＜10mW.
2.4 Wiring
PBAT61 could be pasted on the battery surface, and connected with the
battery poles by the standard 6pin cable securely, and cascaded with another
sensor through RJ11.
