1. INTRODUCTION
YEAR2000 COMPLIANCE
This Intel chipset mainboard is Hardware Year2000 Compliance and supports the latest Pentium
III Processor. It achieves the highest performance which based on the advanced Pentium II
Microprocessor and featuring PCI ocal Bus and Accelerated Graphics Port feature. This
mainboard offers a high degree of flexibility in configuration and is fully IBM PC/AT
compatible.
1.1 KEY FEATURES
This manual applies to different models of Intel chipset mainboard. Please refer to appropriate
section and mainboard layout according to the model no.
Model No. T -BX31 T -ZX31 T -BX21 T -ZX21
Chipset i440BX i440ZX i440BX i440ZX
Socket Slot 1
Front-Side Bus 66 / 100 MHz
Processor INTE Pentium III 450 MHz or above Processor (Please download the updated
BIOS from our website)
INTE Pentium II 233 – 450 MHz Processor
INTE Celeron / Celeron A 266 MHz or above Processor
CPU Speed Jumperless setting
oltage Regulator Built in switching voltage regulator to support 1.5V to 3.5V
Cache Built in evel 2 cache: 512KB (PII and PIII), 128KB (Celeron A)
SDRAM Support 66MHz and 100MHz (PC100) SDRAM module. Also SPD or Non SPD.
Each DIMM slot supports up to 256 MB.
168 pin DIMM
Slot
3 2 3 2
Max. System
Memory
768 MB 512 MB 768 MB 512 MB
Expansion Slots 1 x AGP 1.0 slot (1X/2X mode)
4 x PCI slots
3 x ISA slots
1 x AGP 1.0 slot (1X/2X mode)
3 x PCI slots
2 x ISA slots
On-borad I/O 2 x Ultra DMA/33 Bus Master IDE Ports (support up to 4 IDE devices and PIO
Mode 3 & 4, DMA 2 & Ultra DMA 33)
Support HD greater than 8.4GB
1 x Floppy port (up to 2.88 MB floppy)
1 x Serial ports (16550 Fast UART)
1 x Parallet port (ECP/EPP)
2 x USB ports
1 x PS/2 mouse port
1 x Infra-red port
System BIOS Award 1M or 2M Flash BIOS
Support ACPI, DMI, PnP, Green, Wake on Modem (external) features
Wake on LAN Yes -- --
Power Connector ATX ATX and AT
Sound on Board -- -- Crystal Sound (4235)
1

INTEL PII
User’s Guide
Form Factor ATX Baby AT
Model No. T -IBX3-13 T -IZX3-13 T -IBX2-13 T -IZX2-13
Chipset i440BX i440ZX I440BX i440ZX
Socket Socket 370
Front-Side Bus 66 / 100 MHz
Processor INTE Socket 370 Celeron A 300 MHz or abover Processor
CPU Speed Jumperless setting
oltage Regulator Built in switching voltage regulator to support 1.5V to 3.5V
Cache Built in evel 2 cache: 128 KB
SDRAM Support 66MHz and 100MHz (PC100) SDRAM module. Also SPD or Non SPD.
Each DIMM slot supports up to 256 MB.
168 pin DIMM
Slot
3 2 3 2
Max. System
Memory
768 MB 512 MB 768 MB 512 MB
Expansion Slots 1 x AGP 1.0 slot (1X/2X mode)
4 x PCI slots
3 x ISA slots
1 x AGP 1.0 slot (1X/2X mode)
3 x PCI slots
2 x ISA slots
On-borad I/O 2 x Ultra DMA/33 Bus Master IDE Ports (support up to 4 IDE devices and PIO
Mode 3 & 4, DMA 2 & Ultra DMA 33)
Support HD greater than 8.4GB
1 x Floppy port (up to 2.88 MB floppy)
1 x Serial ports (16550 Fast UART)
1 x Parallet port (ECP/EPP)
2 x USB ports
1 x PS/2 mouse port
1 x Infra-red port
System BIOS Award 1M or 2M Flash BIOS
Support ACPI, DMI, PnP, Green, Wake on Modem (external) features
Wake on LAN Yes -- --
Power Connector ATX ATX and AT
Sound on Board -- -- Crystal Sound (4235)
Form Factor ATX Baby AT
Crystal (4235) Sound on Board
-Compatible with Sound Blaster, Sound Blaster Pro and Windows Sound System
-Advanced MPC3-compliant input and output mixer
-Enhanced stereo full duplex operation
-Dual Type-F DMA support
-Integrated CrystalClear 3D stereo enhancement
-Industry leading Delta-sigma data converters (90 dB DAC)
-Internal default PnP resources
-CS9236 wavetable interface
-CS4610 audio accelerator interface
2

INTEL PII
User’s Guide
Yamaha 128 oice SoftSynth Software
The Yamaha Software Synthesizer S-YXG50 makes it possible for computers with MMX
technology to playback MIDI data with higher sound quality than ever. Even to CD quality level
without using hardware. As it also supports DirectSound as well, you can also enjoy the sound
effects from the latest DirectSound multimedia games.
Yamaha XG Studio Mixer
This versatile playback software allows you to play MIDI files in tandem with animation, video
and still images to create a wonderful multimedia effect. In addition, it allows you to change all
aspects of the MIDI files from its tempo, volume, source, special effects, voice and individual
instruments; so that you are in complete control of the sound effects.
1.2 CHECKLIST
Mainboard x 1
User’s Guide x 1
CD Driver x 1
FDD & HDD Cable Pack (Sound connector card & ATX form card for Baby AT mainboard
only)
1.3 STATIC ELECTRICITY PRECAUTIONS
Static electricity can easily damage your mainboard. Following procedures can help you to
protect your mainboard from electrostatic discharge :
- Keep the mainboard and other system components in their anti-static packaging until you are
ready to install them.
- Ground yourself before removing any system component from its protective anti-static
packaging. A grounded surface within easy reach is the expansion slot covers at the rear of the
system case or any other unpainted portion of the system chassis.
- Frequently ground yourself to discharge any static electric charge that may build up in your
body while working on installation and/or configuration.
- Handle the mainboard by its edges or by the mounting bracket to avoid touching its
components.
3

INTEL PII
User’s Guide
2. HARDWARE CONFIGURATION
Before you install the mainboard into the system chassis, you may find it convenient to
first configure the mainboard’s hardware. This chapter describes how to set jumpers and
install memory modules, and where to attach components.
**You can find the Model No. label on the mainboard.**
2.1 MAINBOARD LAYOUT
Model No: T -BX31
USB 0 /1
C O M1 C O M2
LPT1
Inte l PCIset
RTC
1
Speaker
1
PWR+
KEY OCK
P1
J23
P6
RESET Power Button
P2
HD- ED
P5
JP11
“Normal”
DIMM0
DIMM1
J26 ATX POWER CONNECTOR
A G P S L O T
SLO T 1
LO WER:
PS2
KEYBO ARD
UPPER:
PS2 MO USE
J7
J8
IDE1
IDE2
1
1
Floppy J1
1
P9
BIOS J25
1
1 2
J27
J21
P4
+
1
P11
DIMM2
AT On board Connector Description
PS/2 Mouse USB Port 1 Printer Port
4

INTEL PII
User’s Guide
PS/2 Keyboard USB Port 2 Serial Port 1 / 2
5

INTEL PII
User’s Guide
Model No: T -ZX31
USB 0/1
C O M1 C O M2
LPT1
Inte l PC Iset
RTC
1
Speaker
1
PWR+
KEY OCK
P1
J23
P6
RESET Power Button
P2
HD- ED
P5
JP11
“Normal”
DIMM0
DIMM1
J26 ATX POWER CONNECTOR
A G P S L O T
SLO T 1
LO WER:
PS2
KEYBO ARD
UPPER:
PS2 MO USE
J7
J8
IDE1
IDE2
1
1
Floppy J1
1
P9
BIOS J 25
1
1 2
J27
J21
P4
+
1
P11
6

INTEL PII
User’s Guide
Model No.: T -BX21
Inte l PC Ise t
RTC
1
Speaker
1
P1
J23
P6
P2
HD- ED
P5 JP11
“Normal”
AGP SLOT
SLOT 1
1
BIOS
J25
1
2 1
J27
P4
+
J32
J31
IDE1IDE2
1 1
J30
Jp13
Floppy
1
AT -From card
J28
P11
+ +
7

INTEL PII
User’s Guide
Model No.: T -ZX21
Inte l PC Ise t
RTC
1
Speaker
1
P1
J23
P6
P2
HD- ED
P5 JP11
“Normal”
AGP SLOT
SLOT 1
1
BIOS
J25
1
2 1
J27
P4
+
J32
J31
IDE1IDE2
1 1
J30
Jp13
Floppy
1
AT -From card
J28
P11
+ +
8

INTEL PII
User’s Guide
Model No.: T -IBX3-13
USB 0/1
C O M1 C O M 2
LPT1
Intel PC Iset
RTC
1
Speaker
1
PWR+
KEY OCK
P1
J23
P6
RESET Power Button
P2
HD- ED
P5
JP11
“Normal”
DIMM0
DIMM1
J26 ATX POWER CONNECTOR
AG P SLO T
LOWER:
PS2
KEYBO ARD
UPPER:
PS2 M O USE
J7
J8
IDE1
IDE2
1
1
Floppy J1
1
P9
BIOS J25
1
1 2
J27
J21
P4
+
1
SLO T 1
1
DIMM2
P11
9

INTEL PII
User’s Guide
Model No.: T -IZX3-13
USB 0/1
C O M1 C O M2
LPT1
Inte l PC Iset
RTC
1
Speaker
1
PWR+
KEY OCK
P1
J23
P6
RESET Power Button
P2
HD- ED
P5
JP11
“Normal”
DIMM0
DIMM1
J26 ATX POWER CONNECTOR
AG P SLO T
LO WER:
PS2
KEYBO ARD
UPPER:
PS2 MO USE
J7
J8
IDE1
IDE2
1
1
Floppy J1
1
P9
BIOS J25
1
1 2
J27
J21
P4
+
1
SLO T 1
1
P11
10

INTEL PII
User’s Guide
Model No.: T -IBX2-13
Inte l PC Ise t
RTC
1
Speaker
1
P1
J23
P6
P2
HD- ED
P5 JP11
“Normal”
AGP SLOT
1
BIOS
J25
1
2 1
J27
P4
+
J32
J31
IDE1IDE2
1 1
J30
Jp13
Floppy
1
AT -From card
J28
P11
+ +
P12
SLO T 1
1
11

INTEL PII
User’s Guide
Model No.: T -IZX2-13
Inte l PC Ise t
RTC
1
Speaker
1
P1
J23
P6
P2
HD- ED
P5 JP11
“Normal”
AGP SLOT
1
BIOS
J25
1
2 1
J27
P4
+
J32
J31
IDE1IDE2
1 1
J30
Jp13
Floppy
1
AT -From card
J28
P11
+ +
P12
SLO T 1
1
12

INTEL PII
User’s Guide
2.2 INSTALLING CPU
This mainboard supports the Pentium II CPU using Single Edge Contact (SEC) slot and Socket 370.
Slot 1
To install the CPU, flatten the two latches on the side of the CPU, insert the CPU into the
retention clip. ock the two latches to secure the CPU. Insert the clip portion of the CPU
supporter so that the heat sink can sit on top of the whole CPU supporter.
Socket 370
Match pin 1 of the CPU with pin 1 of the CPU socket. The pin 1 corner of the CPU socket is
designated by a small triangle printed on the motherboard. Carefully insert the CPU into the
CPU socket and move the metal arm downward to replace it in its original position.
13

INTEL PII
User’s Guide
2.3 HOW TO SET JUMPER
Jumper switch is used to select between various operating modes. A jumper switch consists of
two or three gold pins, which stretches out from the system board. By using the cap to cover two
pins is to short those pins. If the cap is not placed on any pins at all, it indicates to leave the pins
open.
To set a jumper switch, please refer to below :
¨to close a jumper, insert the plastic jumper cap over two pins of a jumper
¨to open a jumper, remove the jumper cap
The following conventions are used to represent the proper jumper settings :
OPEN
3 1 3 1
C OSED (2-3 position)
3 1 3 1
NOTE : When you open a jumper, attach the plastic jumper cap to one of the pins so you
won’t lose it.
2.4JUMPERS & CONNECTORS
Setting the CPU Voltage
This mainboard supports Pentium II VID function, the CPU core voltage is automatically
detected, the range is from 1.3V to 3.5V.
Pentium II VID signal provides CPU voltage auto-detection, therefore, no worries on
wrong CPU voltage select.
14

INTEL PII
User’s Guide
Selecting the CPU Frequency
The possible settings of current CPU available on the market are listed below, and pls
verify the BIOS – “CPU SPEED SETTING” to set the correct CPU Clock+Ratio.
Pentium II / Celeron A CLock Ratio
233MHz 66MHz 3.5
266MHz 66MHz 4
300Mhz 66MHz 4.5
333MHz 66MHz 5
366MHz 66MHz 5.5
400MHz 66MHz 6
433MHz 66MHZ 6.5
466MHz 66MHZ 7
Pentium II / III CLock Ratio
350MHz 100MHz 3.5
400MHz 100MHz 4
450MHz 100MHZ 4.5
500MHz 100MHZ 5
FOR INTERNAL TEST ONLY
F.S.B 66 / 100 MHz Selector (Pin 11)
Pin 11 Description
Open 100 Mhz
Close 66 / 100 Mhz
Note: The mainboard chipset supports maximum 100 Mhz frequency, the over 100
Mhz settings are for internal test only, which may cause serious system damage
15

INTEL PII
User’s Guide
2.4.1 ATX Main oard
CPU FAN connector (P4)
Plug in the fan cable to the 3-pin fan connector onboard. The fan connector is marked CPU
FAN and FAN on the system board.
Pin1 Sense
Pin2 +12V
Pin3 GND
Flash ROM Voltage Selector (J25)
Pin Description
1-2
2-3
12v (default)
5v
Note : The factory default is 1-2, it is not recommended to change the factory default setting.
AT Soft-Power Switch Connector (P2)
The ATX soft-power switch connector is a 2 pin header on the system board. ocate the
power switch cable from your ATX housing. Plug this connector to the soft-power switch
connector marked P2 PWRBT.
P2 PWERBT function
Post ON Instant ON/OFF
Post OFF Delay 4 second
16

INTEL PII
User’s Guide
AT power connector pinout
The ATX power supply provides a single 20-pin connector.
Pin Description Pin Description
1
2
3
4
5
6
7
8
9
10
3.3V
3.3V
Ground
+5V
Ground
+5V
Ground
Power OK
5VSB
+12V
11
12
13
14
15
16
17
18
19
20
3.3V
-12V
Ground
PS-ON
Ground
Ground
Ground
-5V
+5V
+5V
Note: Some ATX-Power does not have –5V voltage output, it will effect some functional of
ADD-ON card device.
Software Power-Off
Following the steps below to use the “Software Power-Off control” function in windows
95 with ATX power supply.
1.Click the START button on the Windows 95 task bar.
2.Select Shut Down The computer to turn off the system. It is now safe to turn off your
computer.” will not be shown when using this function.
Power Led and Keylock Connector (J23)
Keylock connector enables and disables the keyboard key-in function on the case.
Pin Description
1
2
3
4
5
ED Output
N.C
Ground
Keylock
Ground
17

INTEL PII
User’s Guide
Infra Red Connector (J21)
Pin Description
1
2
3
4
VCC
IRRX
Ground
IRTX
SB-Link (J27)
SB- ink is a connector used especially with a Creative PCI sound card. The SB-link guides
signals from the ISA bus to the PCI sound card through a cable which comes with the PCI
sound card. This is necessary because some DOS based games address the ISA bus directly.
Speaker Connector (P1)
Pin Description
1
2
3
4
Data Out
N.C
Ground
+5V
Hard-Disk Active LED (P5)
Pin Description
1
2
3
4
Active signal
Ground
Ground
Active signal
Reset Switch Connector (P6)
Attach the Reset push cable to this connector
Setting Description
Open
Close
Normal Mode
Reset System
18

INTEL PII
User’s Guide
CMOS state (JP11)
JP11 CMOS Setting
1-2 Normal operation
2-3 Clear CMOS
Wake-on-LAN Connector (P9)
The Wake-on- AN connector powers up the system when a wakeup packet or signal is received from
the network tthrough the INTE 101 AN card:
INPORTANT: This feature requires that the Wake-on- AN Power up control BIOS is set to Enabled
and that your system has an ATX power supply with +5V standby power.
WAKE-LAN(P9)
Pin Description
1 +5V Standby
2 GND
3 NC
What is Wake-on-LAN?
The Wake-on- AN feature provides the capability to remotely power on systems supporting
Wake-on- AN by simply sending a wake-up frame. With this feature, remotely
uploading/downloading data to/from systems during off-peak hours will be feasible.
Wake-on- AN is a remote management tool with advantages that can reduce system
management workload, provide flexibility to the system administrator’s job, and then of course
save your time-consuming efforts and costs.
To enable Wake—on- AN function, your system requires Ethernet AN adapter card that can activate
Wake-on— AN function, a client with Wake-on- AN capability, and software such as DCM rev3.10 or
up that can trigger wake-up frame.
19
