DEMO MANUAL DC1198B-A
Description
LTM4605
20V, 5A High Efficiency
Buck-Boost µModule Regulator
Demonstration circuit DC1198B-A features the
LT M
®
4605EV, the high efficiency, high density switch
modebuck-boostµModule
®
regulator. The LTM4605EV can
regulate its output voltage from an input voltage above,
below, or equal to the output. The input voltage range
of DC1198B-A is from 4.5V to 20V with a preset output
voltage of 12V. The rated load current is 5A, although
derating is necessary for certain VIN, VOUT, and thermal
conditions. The switching frequency may be synchronized
to an external clock from 200kHz to 400kHz. This PLL
L, LT, LTC, LTM, µModule, Linear Technology and the Linear logo are registered trademarks of
Linear Technology Corporation. All other trademarks are the property of their respective owners.
perForMAnce sUMMArY
BoArD photo
can be used not only to reduce undesirable frequency
harmonics but also to parallel LTM4605 to provide high
output current. The LTM4605 data sheet must be read in
conjunction with this demo manual prior to working on
or modifying DC1198B-A.
Design files for this circuit board are available at
http://www.linear.com/demo
(TA= 25°C)
PARAMETER CONDITIONS VALUE
Input Voltage Range VIN 4.5V to 20V
Output Voltage VOUT VIN = 12V, IOUT = 5A. 12V ± 2%
Maximum Continuous Output Current Derating Is Necessary for Certain VIN, VOUT, and
Thermal Conditions
5ADC at 5VIN
12ADC at VIN > VOUT
Default Operating Frequency 300kHz
Efficiency VIN = 12V, VOUT = 12V, IOUT = 5A 97.6%, See Figure 3 for More Information
Load Transient VIN = 5V, VOUT = 12V See Figure 4 for Details
Downloaded from Arrow.com.

2
dc1198bafa
DEMO MANUAL DC1198B-A
qUick stArt proceDUre
Figure 1. Test Setup of DC1198B-A
Demonstration circuit DC1198B-A isaneasywayto evaluate
the performance of the LTM4605EV. Please refer to Figure
1 for proper measurement equipment set-up and follow
the procedure below:
1. Place jumpers in the following positions for a typical
12VOUT application:
RUN CLOCK MODE START
ON PROG CCM SSO
2. With power off, connect the input power supply, load
and meters as shown in Figure 1. Preset the load to 0A
and VIN supply to be less than 20V.
3. Turn on the power at the input. The output voltage
should be 12V ± 2%.
4. Once the proper output voltage is established, adjust
the load within the operating range and observe the
output voltage regulation, ripple voltage, efficiency and
other parameters. Cooling fan andlower current sensing
resistor are necessary for VIN < 5V and IOUT = 5A.
5. To measure input and output ripple, please refer to
Figure 2 for proper setup.
6. The voltage of pin PLLFLTR determines the switching
frequency. Modify R6 and R7 to adjust the switching
frequency. Turn off the power supply before attempting
to remove and replace R6 and R7. Do not allow voltage
at pin PLLFLTR exceed 2.4V.
7. The Inductor, RS1 and RS2 should be modified to ac-
commodate certain input and output condition. Please
refer to the LTM4605 data sheet for recommended
component values.
DC1198B F01
Downloaded from Arrow.com.Downloaded from Arrow.com.

3
dc1198bafa
DEMO MANUAL DC1198B-A
qUick stArt proceDUre
Figure 2. Proper Scope Probe Placement for Measuring Input or Output Ripple
Figure 3. Measured Supply Efficiency with Different VIN. (VOUT = 12V)
Figure 4. Measured Load Transient Response (2.5A Step, 25% to 75%)
LOAD CURRENT (A)
0
EFFICIENCY (%)
80
90
100
6 8 10
DC1198B F03
70
60 2 4 12
VIN = 5V
VIN = 12V
VIN = 20V
DC1198B F02
INPUT OR OUTPUT CAPACITOR
VIN = 5V, VOUT = 12V
CONTINUOUS CURRENT MODE (CCM)
1.25A TO 3.75A LOAD STEP
COUT = 2x22µF CERAMIC (1812, X7R), 2x180µF OSCON (16V)
PEAK-TO-PEAK OUTPUT VOLTAGE DEVIATION = 413mV
200µs/DIV
VOUT
AC-COUPLED
100mV/DIV
ISTEP
2A/DIV
DC1198B F04
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

4
dc1198bafa
DEMO MANUAL DC1198B-A
pArts list
ITEM QTY REFERENCE PART DESCRIPTION MANUFACTURER/PART NUMBER
Required Circuit Components
1 1 CIN1 CAP, ALUM, 150µF, 20%, 35V SANYO, 35ME150WXV+TS (NOW SUNCON 35ME150WXV)
2 2 CIN2, CIN3 CAP, X7R, 10µF, 20%, 35V, 1206 TAIYO YUDEN, GMK316BJ106ML-T
3 1 CSS CAP, X7R, 0.01µF, 25V, 10%, 0603 AVX 06033C103KAT4A
4 2 CO3, CO4 CAP, X7R, 22µF, 16V, 20%, 1812 TDK C4532X7R1C226M
5 2 CO5, CO6 CAP, OS-CON, 180µF, 16V SANYO 16SVP180MX
6 1 L1 IND IRON POWER SMT FIXED, 3.3µH TOKO FD1254-3R3M=P3
7 1 R5 RES, CHIP, 7.15k, 1/16W, 1%, 0603 VISHAY CRCW06037K15FKEA
8 1 R6 RES, CHIP, 4.64k, 1/16W, 1%, 0603 VISHAY CRCW06034K64FKEA
9 1 R7 RES, CHIP, 1.21k, 1/16W, 1%, 0603 VISHAY CRCW06031K21FKEA
10 2 RS1, RS2 RES, CHIP, 0.015 1/2W, 1%, 1206 VISHAY WSL1206R0150FEA
11 1U1 I.C., LTM4605EV#PBF LINEAR TECHNOLOGY CORPORATION LTM4605EV#PBF
Additional Demo Board Circuit Components
1 0 CIN4, CIN5 (OPT) CAP, 1206
2 0 C2, C4, C5, CP, CFF
(OPT)
C A P, 0 6 0 3
3 0 CO1, CO2 (OPT) CAP, SVP, 100µF, D3L
4 0 CO7 (OPT) CAP, 1206, 16V
5 0 CO8 (OPT) POSCAP, D3L
6 2 D1, D2 ZENER DIODE, 4.7V CENTRAL SEMICONDUCTOR CMDZ5230B-7-F
7 1 R1 RES, CHIP, 100k, 1/16W, 5%, 0603 VISHAY CRCW0603100KJNEA
8 1 R2 RES, CHIP, 51k, 1/16W, 5%, 0603 VISHAY CRCW060351K0JNEA
9 1 R8 RES, CHIP, 20k, 1/16W, 1%, 0603 VISHAY CRCW060320K0FKEA
10 1RS3 (OPT) RES,1206
11 1 R9, RUVLO (OPT) RES, 0603
Hardware/Components (For Demo Board Only)
1 2 JP1, JP2 2mm SINGLE ROW HEADER, 3 PIN SAMTEC TMM-103-02-L-S
2 2 JP3, JP4 2mm SINGLE ROW HEADER, 4 PIN SAMTEC TMM-104-02-L-S
3 4 JP1, JP2, JP3, JP4 SHUNT SAMTEC 2SN-BK-G
410 TP1, TP4, TP5, TP7,
TP9, TP11 TO TP15
TESTPOINT, TURRET, 0.095” MILL-MAX 2501-2-00-80-00-00-07-0
5 4 TP2, TP3, TP8, TP10 BANANA JACK KEYSTONE 575-4
6 4 STAND OFF STAND OFF, NYLON 0.50” TALL KEYSTONE 8833 (SNAP ON)
Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.Downloaded from Arrow.com.

5
dc1198bafa
DEMO MANUAL DC1198B-A
Information furnished by Linear Technology Corporation is believed to be accurate and reliable.
However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa-
tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.
scheMAtic DiAgrAM
A
A
B
B
A A
BB
5A MAX
RUN
ON OFF
DCM
CCM
BS (BURST/SKIP_CYCLE) OFF
SSO (SOFT START ON) LO (LDO ON)
EXT
PROG
CLOCK
12V
MODE
*
